EcoFlow PowerOcean DC Fit User manual

EcoFlow PowerOcean DC Fit
USER MANUAL
V1.0
English

CONTENTS
1About This Manual
1Disclaimer
1Intended Use
1Intended User
1Safety Instructions
1Symbol Conventions
1General Safety
1Environment Requirements
1Personnel Requirements
1Electrical Safety
2Disposal
2Storage
2Residual Current Device (RCD) Selection
2Product Nameplate
2Symbols on Enclosure or Nameplate
3System Introduction
3Module
3Dimension
3Appearance
4LED explanation
5System Installation
5Overview
5Procedure
5System Operation
5System Power On
5System Power Off
5System Modes
6PV-Storage System Co-working Tips
6System Management
6For End User
6For Installer
7System Maintenance
7Routine Maintenance
7Troubleshooting
7System Decommissioning
7Removal
7Disposal
8Technical Parameters
8EcoFlow PowerOcean PV Storage Converter
9EcoFlow PowerOcean LFP Battery Pack
10 EU Declaration of Conformity

1
About This Manual
DISCLAIMER
Please read the product documents and ensure that you understand it fully
before using the product. After reading this document, keep it for future
reference. Improper use of this product may cause serious injury to yourself
or others, or cause product damage and property loss. Once you use this
product, it is deemed that you understand, approve and accept all the terms
and content in this document. EcoFlow is not liable for any loss caused by the
user's failure to use the product in compliance with the product document.
In compliance with laws and regulations, EcoFlow reserves the right to the
final interpretation of this document and all documents related to the product.
This document is subject to changes (updates, revisions, or termination)
without prior notice. Please visit EcoFlow's official website to obtain the latest
product information: https://www.ecoflow.com/.
INTENDED USE
This User Manual complements the product's Installation Guide. While the
Installation Guide offers instructions for the installation and initial setup of the
product, this manual provides a general understanding of product functions
and features.
Please note that all illustrations in this manual are for demonstration only and
may vary from the actual product due to regions and firmware versions.
INTENDED USER
This manual is intended for qualified persons and end users. Please note
that only qualified persons are allowed to perform professional or skilled
work on the equipment, such as installation, maintenance, or other electrical
operations.
Safety Instructions
SYMBOL CONVENTIONS
Symbol Description
Indicates a hazard with a high level of risk
which, if not avoided, will result in death or
serious injury.
Indicates a hazard with a medium level of risk
which, if not avoided, could result in death or
serious injury.
Indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate
injury.
Indicates a potentially hazardous situation
that, if not avoided, could result in equipment
damage, data loss, performance deterioration, or
unanticipated results.
NOTICE is used to address practices not related
to personal injury.
Indicates additional information that promotes
understanding of the product or a topic.
GENERAL SAFETY
1. Do not work with power on during installation or maintenance.
2. Do not touch the energized equipment, as the enclosure is hot.
3. Do not touch the exposed electrical cable or parts with bare hands.
4. When the photovoltaic (PV) array is exposed to light, it supplies direct current
voltage to the power conversion equipment (PCE).
5. Do not use the equipment as backup power for important devices, such as
data centers, elevators, and life-sustaining medical devices.
6. The PV modules connected to this equipment must meet application class A
(safety class II )of IEC 61730-1 and must be compatible with this equipment.
7. Do not ground the PV array positive/negative hole.
8. Do not touch enclosure of the equipment during operation.
9. Do not operate outdoor equipment and cables in harsh weather conditions
such as lightning, thunder, and hurricanes.
10. Do not disassemble or modify the equipment hardware without permission
from the manufacturer.
11. Do not reverse engineer, decompile, disassemble, adapt, add code to the
equipment software, or alter the equipment software in any other way. Avoid
any operation that violates the original design specifications of the product
hardware and software.
12. Do not scrawl, damage, or block any warning labels on the equipment.
13. Do not clean the equipment with flammable or toxic solvents. Wipe it with a
dry soft cloth.
ENVIRONMENT REQUIREMENTS
• Operating Temperature: –20°C (–4°F) to 50°C (122°F), derating at
temperature > 40°C.
• Operating Humidity: 4% RH to 100% RH (Condensing).
• Storage Temperature: –20°C ( –4°F) to 50°C (122°F).
14. Install the equipment in a tidy, dry, and well-ventilated environment.
15. Do not expose the equipment to direct sunlight, rain, and snow.
16. Do not install or operate the equipment near any sources of heat, fire, or water.
17. Do not place the equipment on a tilted or uneven ground.
18. Do not block or restrict the heat dissipation system of the equipment.
19. Keep the equipment away from solvents, explosive material, flammable
material, and infrared radiation.
20. Keep the equipment away from children and from areas where people live or
work.
21. Keep the equipment at least 500 m away from the sea to prevent salt
corrosion.
22. Do not leave leftover items in installation area like cardboard boxes, foam,
plastic, and wires.
PERSONNEL REQUIREMENTS
23. Only qualified professionals are allowed to install or maintain the equipment.
24. Wear suitable personal protective equipment (PPE) for all professional or
skilled work on the equipment.
25. Personnel who plan to install, maintain, or perform electrical operations
on the equipment must receive thorough training, and be familiar with all
necessary safety precautions and instructions.
26. Personnel who plan to perform special operations should have the necessary
local or national qualifications for tasks such as high-voltage operations,
working at heights, and so on.
Professionals: personnel who are trained or experienced in equipment
operations and are clear of the sources and degree of various potential hazards
in equipment installation, operation, and maintenance.
27. When moving heavy equipment, assign enough personnel to prevent
personal injury and equipment damage.
28. When installing, strictly prevent screws, nuts and spacers from falling inside
the equipment or the gap between the equipment and wall.
29. When drilling screw holes, avoid drilling into water pipes and electrical wires.
ELECTRICAL SAFETY
Grounding
30. When installing the equipment, connect the protective earthing cable first.
When dismantling it, remove protective earthing cable last.
31. All grounding terminals should be fully connected.
32. Do not operate the equipment in the absence of a properly installed ground
conductor.
33. Do not damage the ground conductor.
34. Ensure that the equipment is connected permanently to the protective
ground.
35. Before operating the equipment, check the electrical connection to ensure
that the equipment is securely grounded.
Electrical connection
36. Before connecting any electrical cables, ensure that all equipment, components,
cables, and terminals are in good condition to prevent electric shocks or fires.
37. Ensure that all electrical connections comply with local electrical standards.

2
38. Use dedicated insulated tools when performing high-voltage operations.
39. Before servicing, disconnect all power to the equipment and wait for the
corresponding delayed discharge time to ensure that the equipment is
completely de-energized.
Cabling
40. Ensure that the cable used in connections meet local regulations and the
manufacturer' s recommended specifications.
41. The cabling path must avoid the equipment heat dissipation system and
parts.
42. The distance from cables to heat-generating components or areas must be
at least 30 mm.
43. The distance from cables to each other must be at least 30 mm when routing
different types of cables. Mutual entanglement or cross-deployment is not
allowed.
44. Only bind cables of the same type together. Electrical connection
DISPOSAL
For information on the disposal of electrical and electronic equipment, please
visit the following website: https://eu.ecoflow.com/pages/electronic-devices-
disposal.
STORAGE
The following requirements should be met if the equipment is not put into use
directly:
1. Storage Temperature: -20°C (-4°F) to 50°C (122°F).
2. Store the equipment in the original packaging.
3. Store the equipment in a clean and dry place and be protected from dust and
water vapor corrosion.
4. Do not place the equipment near water, fire or other heat sources (heaters,
direct sunlight, gas ovens, and so on).
5. During the storage period, check the equipment condition periodically.
6. If the equipment has been stored for a long time (more than 6 months), it
must be checked and tested by professionals before being put into use.
For details about battery maintenance, see EcoFlow PowerOcean LFP
Battery User Manual at https://enterprise.ecoow.com/documentation.
RESIDUAL CURRENT DEVICE (RCD) SELECTION
EcoFlow recommends using an RCD with a rated residual operating current of
100mA to avoid electrical shock and nuisance tripping. However, if there are
specific local regulations regarding RCD, please ensure to adhere to those.
PRODUCT NAMEPLATE
①
③
⑤
④
②
⑥⑦
① Trademark
② Product name
③ Key technical specications
④ Manufacturer information
⑤ Compliance symbols
⑥ Product support hotline
⑦ Serial Number
The nameplate gure is for reference only.
SYMBOLS ON ENCLOSURE OR NAMEPLATE
Symbol Meaning
Caution! Risk of Electric Shock
1.Do not remove the cover (or back). No user-
serviceable parts inside. Refer servicing to
qualied service personnel.
2.High voltage exists after the equipment is
powered on. Only qualied and trained electrical
technicians are allowed to perform operations
on the equipment. Ground the equipment before
powering it on.
Caution! Risk of Danger
1.Disconnect the equipment from all voltage
sources before servicing.
2.Do not disconnect under load.
Warning: Risk of Fire
The equipment contains high energy during
operation. Do not use it in any habitable space
or area.
5 mins
Caution! Risk of Electric Shock
Wait at least 5 minutes after all voltage sources are
disconnected before servicing.
Caution! Hot surface
Do not touch the enclosure of the equipment during
operation.
Refer to Documentation
Read all documentation supplied with the product.
Protective Earth (Ground)
Indicates the position for connecting the protective
earthing (PE) cable.
WEEE Directive
Do not dispose of the product together with
household waste but follow the local disposal
regulations for electronic waste.
CE Marking
The product complies with the essential
requirements of the relevant EU legislation.
Serial Number
Indicates the SN of the equipment.
The labels are for reference only.

3
APPEARANCE
- EcoFlow PowerOcean PV Storage Converter
⑧
①
②
③
④
⑤
⑥
⑦
⑨⑩
① Battery Button
② Battery Switch
③ PV Terminals
④ INV Terminals
⑤ Meter Port
⑥ WAN Port
⑦ Grounding Terminals
⑧ LED Indicator
⑨ Heat Sinks
⑩ Wi-Fi Antenna
Appearance Definition Description
①BATTERY BUTTON Long press to turn on or off the
EcoFlow PowerOcean DC Fit.
②BATTERY SWITCH
Flip the switch to change the
system mode.
ON: When switched to ON,
the system stores the excess
electricity generated by PV
strings, and then supplies it to the
home load when solar power is
insufcient.
OFF-BYPASS: When switched
to OFF-BYPASS, the system does
not function as a power storage
or backup unit. The electricity
produced by PV strings goes
to the PV inverter through the
converter.
System Introduction
MODULE
EcoFlow PowerOcean DC Fit is an easy and unique PV-coupled retrofit battery
storage solution. It enables direct connection of the battery to the solar system on
the PV side, eliminating the need for an additional storage inverter. This streamlined
installation process saves valuable time while maximizing the efficiency of the user’s
existing solar power system.
EcoFlow PowerOcean DC Fit (hereinafter referred to as the system or the storage
system) consists of three main modules:
①
②
③
1EcoFlow PowerOcean PV Storage Converter (EF PD-5-S1)
2EcoFlow PowerOcean LFP Battery Pack* (EF BD-5.1-S1)
3EcoFlow PowerOcean LFP Battery Base (EF BD-B-S1)
*The battery module is expandable to 3 batteries.
DIMENSION
680 mm
679 mm
1 074 mm
1 469 mm
201 mm

4
System Reminder
LED Status Description
The converter is energized by a
DC voltage source (PV or battery
pack), but the system is not
functioning or is not completely
powered-off.
• To turn on the system:
Press and hold the BATTERY ON/
OFF button for about 5 seconds.
Wait until the LEDs light up and
then ash twice.
• To power off the system:
Turn the BATTERY SWITCH to
OFF-BYPASS position.
OTA (Over-the-air) Reminder
LED Status Description
The over-the-air update is in
progress.
Discharge Status
LED Status Battery Level
<5%
5%-25%
25%-50%
50%-75%
75%-100%
Charge Status
LED Status Battery Level
0%-25%
25%-50%
50%-75%
75%-99%
100%
Faulty Status
LED Status Description
Abnormal System installation.
Check if all equipment is installed
correctly and securely.
Abnormal smart meter
communication.
Battery is faulty.
Converter is faulty.
Abnormal IoT communication.
Abnormal battery communication.
Abnormal converter communication.
If the LED displays a faulty status, visit the EcoFlow / EcoFlow Pro app to
retrieve the error code.
- EcoFlow PowerOcean LFP Battery Pack
① ②
②③ ④
① Lifting Handle
② Battery Docking Terminal
③ Pressure release valve
④ Heat Sinks
- EcoFlow PowerOcean LFP Battery Base
③
① ②
① Lifting Handle
② Gradienter
③ Adjustable feet mounting holes
LED EXPLANATION
On
Solid White
Solid Orange
Flashing White
Flashing Orange
Carousel white
Off /

5
System Installation
OVERVIEW
DC AC
EthernetRS485 Wi-Fi
App
Load
Internet
Web
Router
Solar Panels
Solar Inverter
EcoFlow PowerOcean DC FIT
Grid
Smart Meter
PROCEDURE
• Only professionals with appropriate qualifications can perform the following
activities.
Topic in Installation Guide Description
Preparing Tools and
Instruments
Get to know the tools or equipment that will
be used during the installation.
Package Inspection Get to know the delivery scope of product
packages.
Installation Environment
Get to know the environment and space
requirements for the installation.
Installation Space
System Installation
Instructions for hardware installation:
1. How to install a battery base;
2. How to install battery packs;
3. How to install the converter;
4. How to install protective earthing cables.
Electrical Connection
Instructions for electrical connection:
1.How to connect the system to an existing
PV system;
2.How to install the smart meter to the
system;
3.How to connect the system to the internet.
Installation Review Follow the checklist to review if everything is
well-prepared before powering the system.
System Power-On
Instructions for standard operation process
for System power on or off.
System Power-Off
LED Indicator Get to know the denition of the LED status.
System Commissioning Instructions for initial setup and device
binding.
For detailed installation instructions, please refer to the Installation Guide
delivered with the product, or download it at
https://enterprise.ecoow.com/documentation.
System Operation
SYSTEM POWER ON
1. Turn the BATTERY SWITCH on the converter to the ON position.
2. Press and hold the BATTERY ON/OFF button on the converter for about
5 seconds. Wait until the LEDs light up and then flash twice, indicating a
successful system power-on.
SYSTEM POWER OFF
1. Shut down the system via the EcoFlow app.
2. Turn the BATTERY SWITCH on the converter to the OFF-BYPASS position.
3. Press and hold the BATTERY ON/OFF button on the converter for about 10
seconds.
4. Wait until the LEDs are completely off, indicating a successful system power-
off.
SYSTEM MODES
Operating Mode
When the BATTERY SWITCH is set to ON, the system works in operating
mode.
In operating mode, the system stores the excess electricity generated by solar
panels, and then supplies it to the home load when solar power is insufficient.
PV power first supports local loads via a solar inverter, then charges the
storage system with excess solar energy.
The system discharges when PV power is low.

6
PV-STORAGE SYSTEM CO-WORKING TIPS
Work with Third-Party I-V Curve Scan
If your solar inverter supports an I-V curve scan or diagnosis feature, turn off
the storage system first to obtain accurate scanning reports of photovoltaic
details.
Turning off the storage system:
1. Shut down the EcoFlow PowerOcean DC Fit via the EcoFlow app.
2. Run the I-V curve scan via your inverter's management interface. Await for
the I-V curve scan report.
3. Start up the EcoFlow PowerOcean DC Fit via the EcoFlow app.
Keep the Solar Inverter On at Night
Some solar inverters may shut down at night to save energy. To ensure the
storage system continues to supply power to home appliances, keep the
inverter running at night.
System Management
EcoFlow provides thorough support for the system. Both the end user and
installer benefit from our comprehensive guides and resources.
FOR END USER
Effortlessly manage, monitor, and control your PowerOcean devices through
a sleek, user-friendly interface via app or web management. Access real-time
energy data, detailed power generation, storage and energy bills savings
anytime and anywhere. Professional technical support is also readily available
when needed.
• App Management
Scan the QR code or download at https://download.ecoflow.com/app
EcoFlow App
FOR INSTALLER
Streamline the commissioning process, monitor device status in real-time,
access detailed troubleshooting solutions for system faults and also offer
customer support from EcoFlow professional support team.
• App Management
Scan the QR code or download at
https: //download.ecoflow.com/ecoflowproapp
EcoFlow Pro
• For an inverter that supports multiple PV strings in one input, avoid
paralleling the system with a PV string to prevent potential damage to solar
panels.
PV1 PV2
PV1 PV2
Bypass Mode
When the BATTERY SWITCH is set to OFF-BYPASS, the system works in
bypass mode.
In bypass mode, the system does not function as a power storage or backup
unit. The electricity produced by solar panels goes to the PV inverter through
the converter.

7
System Maintenance
ROUTINE MAINTENANCE
Before routine maintenance, power off both the storage system and the PV
system. Also, ensure you are wearing insulating gloves for your safety.
Powering off the entire system:
1. Shut down the system via the EcoFlow app.
2. Turn the BATTERY SWITCH on the converter to the OFF-BYPASS position.
3. Press and hold the BATTERY ON/OFF button on the converter for about 10
seconds.
4. Shut off the PV inverter from both AC and DC voltage sources.
5. Turn off the DC breaker or isolator of the PV strings (if applicable).
6. Wait at least 5 minutes to ensure that the entire system is completely off.
• If you find any problem, contact the installer or EcoFlow technical support for
assistance. Do not disassemble or repair the device on your own, as it could
lead to personal injury or damage to the device.
Routine maintenance item
Check item Check Method Maintenance
Interval
Cleanliness Clean the equipment enclosure with a
dry, soft cloth.
Once every 6
months
Hardware status
• Check for any abnormal sounds during
the operation.
• Check the outer enclosure for any
physical damage.
• Check that the mounting piece and
screws are secured.
Electrical
connection
Check for any exposed electrical
conductors.
Grounding Check that the protective earthing
cables are connected and not damaged.
Sealing Check that unused terminals and ports
are protected by waterproof covers.
Heat dissipation Check for any obstacles blocking or
restricting the heat dissipation system.
TROUBLESHOOTING
• Only professionals with appropriate qualifications can perform the following
activities.
1. Visit and log in to the EcoFlow Pro app.
2. Retrieve the error code and in-app instructions.
3. Completely power off the entire system:
a. Ask the user to shut down the system via the EcoFlow app.
b. Turn the BATTERY SWITCH on the converter to the OFF-BYPASS position.
c. Press and hold the BATTERY ON/OFF button on the converter for about 10
seconds.
d. Shut off the PV inverter from both AC and DC voltage sources.
e. Turn off the DC breaker or isolator of the PV strings (if applicable).
f. Wait at least 5 minutes to ensure that the entire system is completely off.
4. Follow the in-app instructions to x the issue.
If the problem persists, contact the EcoFlow technical support team.
System Decommissioning
REMOVAL
• Only professionals with appropriate qualifications can perform the following
activities.
• Do not work with power on.
• Wear proper PPE (Personal protective equipment) before any operations.
• When moving heavy equipment, assign enough personnel to prevent
personal injury and equipment damage.
1. Completely power off the entire system:
a. Shut down the system via the EcoFlow app.
b. Turn the BATTERY SWITCH on the converter to the OFF-BYPASS position.
c. Press and hold the BATTERY ON/OFF button on the converter for about 10
seconds.
d. Shut off the PV inverter from both AC and DC voltage sources.
e. Turn off the DC breaker or isolator of the PV strings (if applicable).
f. Wait at least 5 minutes to ensure that the entire system is completely off.
2. Remove connections from the METER port and WAN port.
3. Remove connections from PV terminals and INV terminals.
4. Remove protective earthing cables.
5. Loosen the screws to remove the converter.
6. Loosen the screws to remove the battery pack.
7. Remove the battery base.
DISPOSAL
If the system can not work anymore, dispose of it in accordance with the local
disposal requirements for electrical equipment waste. The modules of the
system cannot be disposed of together with household waste.
Hereby, our battery module has met the regulations of BattG in Germany.

8
Protection
Direct Current Insulation Resistance
Testing Yes
PV Input Reverse Polarity Protection Yes
Direct Current Switch Yes
Overcurrent Protection Yes
Overvoltage/Undervoltage Protection Yes
Low/High Temperature Protection Yes
Compliance
Certificates CE, CB, TUV Mark, RoHS
Safety Standard IEC/EN62109-1
EMC
ETSI EN 300 328 V2.2.2
EN IEC 62311:2020
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4
EN IEC 61000-6-1
EN IEC 61000-6-3
Technical Parameters
ECOFLOW POWEROCEAN PV STORAGE CONVERTER
Model EF PD-5-S1
General
Bypass Power 15kW/15kW
Protective Class I
Overvoltage Category (OVC) II (PV)
Converter Dimension 680 mm*201 mm*230 mm (±1 mm)
Converter Weight 18.5 kg (±0.5 kg)
Installation Floor Stand
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Operating Relative Humidity 4%-100% (Condensing)
Operating Altitude ≤3000 m
IP Rating IP65
Noise Level ≤35 dB
Communication Method Ethernet, Wi-Fi, Bluetooth, RS485
Cooling Method Natural convection
Pollution Degree 2
Environmental Category Outdoor / Indoor
DC Input (PV)
Max. Input Voltage (Absolute
Maximum) 1000V
Operating Voltage Range 150V-800V
Max. Input Current 20A/20A
Isc PV (Absolute Maximum) 21A/21A
DC Output (Inverter side)
Supported Solar Inverter Type Single phase / Three phase
Max. Output Voltage 1000V
Operating Output Voltage Range 150V-800V
Max. Output Current 20A/20A
Battery Port
Battery Discharging Voltage Range 800V-900V
Max. Discharging Current 6.5A
Max. Discharging Power 5.2kW*
Battery Charging Voltage Range 800V-900V
Max. Charging Current 6A
Max. Charging Power 4.8kW*
* The value of maximum discharging power and maximum charging power are
measured with 3 battery packs installed.

9
ECOFLOW POWEROCEAN LFP BATTERY PACK
Number of battery packs EF BD-5.1-S1 x 1
EF BD-B-S1 x 1
EF BD-5.1-S1 x 2
EF BD-B-S1 x 1
EF BD-5.1-S1 x 3
EF BD-B-S1 x 1
Performance
Battery module capacity 5.1kWh 10.2kWh 15.3kWh
Max. output power 3.3kW 6.6kW 9.9kW
Max. input power 2.5kW 5kW 7.5kW
Nominal voltage 800V
Operating voltage range 720V-960V
Battery cell type LFP
Compliance
Certificates CE/CB/TUV Mark
Safety standard IEC/EN62619, IEC/EN62040-1, IEC/EN62477-1, ISO13849
Delivery standard UN38.3
EMC EN 61000-6-1, EN 61000-6-3
General
Dimension (without adjustable feet) 680*612*183 mm 680*1009*183 mm 680*1406*183 mm
Power module weight 65.6 kg 120.9 kg 176.2 kg
Installation Floor stand
Operating temperature -20°C to 50°C (-4°F to 122°F)
Max. Operating altitude 3000 m
Cooling method Natural convection
Noise level ≤35 dB
Relative humidity 0%~100% RH
Protection level IP65
Protective class I

10
10
EU Declaration of Conformity
We, EcoFlow Inc. declare under our sole responsibility that the products
PRODUCT:
EcoFlow PowerOcean PV Storage Converter
MODELS: EF PD-5-S1
to which this declaration relates, is in compliance with the follow documents:
Directives:
Product Safety and Performance Standard(s):
EMC Standards:
Radio Standards:
EU Representive:
EcoFlow Europe s.r.o
Signed for and on behalf o
f
：
EN 62109-1:2010
Health Standards:
EN IEC 62311:2020
EcoFlow Inc.
EU Declaration of Conformity
2014/53/EU (RED)
2011/65/EU(RoHS)
(EU)2015/863(RoHS)
Address: 1st Floor, Building 1, Plant E, Jiehe Industrial City, Shuitian Community, Bao'an District,Shenzhen City, Guangdong
Province, China
Tel: [phone]
ETSI EN 301489-1 V2.2.3
ETSI EN 301489-17 V3.2.4
EN IEC 61000-6-1
EN IEC 61000-6-3
EN55032:2015+A11:2020
EN55035:2017+A11:2020
ETSI EN 300 328 V2.2.2
RoHS Standards:
IEC 62321
EN IEC 63000
Doubravice 110, 533 53 Pardubice, Czech Republic
Compliance Engineer 2023-11-03
signature and seal position date of issue

10|11
© 2023 EcoFlow Inc. All rights reserved.
