Operating Instructions
Magnet-Ex 12

11
Table of Contents
1. Application 12
2. Safety information 12
3. Errors and impermissible loading 12
4. Safety regulations 12
5. Ex-Data 13
6. Technical specifications 13
7. Functional description / operating instructions 14
7.1 General 14
7.2 Application 14
7.3 Battery replacement 15
8. Repair 16
9. Disposal 16
10 Cleaning, maintenance and storage 16
11 Warranty and liability 17
12 EC Declaration of Conformity 18
13 EC type approval test certificate 19
Note:
The current operating manual, the EC Declaration of Con-
formity and the Ex-certificate can be downloaded from the
relevant product page at www.ecom-ex.com, or alternatively
they can be requested directly from the manufacturer.
BAL_Magnet_Ex_12_2010.indd 11 30.11.10 15:20

12
1. Application
The Magnet-Ex 12 is a device for the detection and testing
of magnetic fields for industrial application in areas with an
increased risk of explosion in zones 2 and 1, in accordance
with directive 1999/92/EC (ATEX 137).
2. Safety information
These operating instructions contain information and safety
regulations which are to be observed without fail for safe
operation in the described conditions. Non-observance of
this information and these instructions can have serious
consequences or it may violate regulations.
Please read these operating instructions carefully before
starting to use the unit!
In case of any doubt (in the form of translation or printing
errors) the German language operating instructions shall
apply.
3. Errors and impermissible loading
If there is any reason to suspect that the safety of the unit
has been impaired, it must be withdrawn from use and
removed immediately from the Ex-area.
Measures must be taken to prevent it from being restarted
accidentally.
We recommend that the unit is returned to the manufacturer
for inspection.
The safety of the unit may be compromised, if, for example:
- there is visible damage to the housing.
- the unit has been subjected to excessive loads.
- the unit has been improperly stored.
- the unit has been damaged in transit.
- unit markings or inscriptions are illegible.
- malfunctions occur.
- permitted limit values have been exceeded.
4. Safety regulations
Use of this unit assumes that the operator observes the
conventional safety regulations and has read the certificate
in order to eliminate faulty operation of the unit.
The following safety regulations must also be complied with:
- The device may not be opened inside the Ex-area.
- The batteries may only be exchanged outside the Ex-area.
- Additional batteries must not be carried in the Ex-area.
BAL_Magnet_Ex_12_2010.indd 12 30.11.10 15:20

13
- Only type-tested batteries may be used.
- Avoid use in aggressive acids or bases.
- It must be ensured that the unit is not taken into zone 0.
5. Ex-Data
EC type approval test certificate no.: PTB 01 ATEX 2018
Ex-designation: II 2 G Ex ia IIC T4
Approved for zone 1, device group II, explosion group IIC
(explosive gases, vapours or mist), temperature class T4.
6. Technical specifications
Detection: no contact with test object required
Detectable
magnetic: alternating, direct and permanent fields
Indicator: optical, via built-in LED
Ambient
temperature Ta: -20 °C ... + 50 °C
Storage
temperature: -40 °C ... + 60 °C (without batteries)
Batteries /
power supply: 2 x LR03 according to IEC, AAA
(Table with type-tested batteries)
Manufacturer: Type:
1 Varta LR03 High Energy No.4903
2 Varta LR03 Industrial Alkaline No. 4003
3 Eveready Energizer No. E92
4 Duracell Plus MN2400 LR03
5 Duracell Procell MN2400 LR03
6 Varta LR03 Maxi Tech No.4703
7 Energizer Ucar Gold LR03
8 Varta No.8003 Electric Power LR03
9 Ampercell Super Plus Alkaline
10 Rayovac Maximum Plus
Dimensions: 150 x Ø 18mm
Weight: approx. 60g (with battery)
IP protection: IP 54
CE-designation: 0 0102
BAL_Magnet_Ex_12_2010.indd 13 30.11.10 15:20

14
7. Functional description / operating instructions
Please read these operating instructions carefully so that
you are familiar with, and are able to use, all features of the
Magnet-Ex 12. For your own safety and information please
read the instructions on the following pages carefully!
7.1 General
The Magnet-Ex 12 can be used to detect quickly and
precisely magnetic fields on solenoid valves, spools, trans-
formers, relays and flowmeters. The LED of the Magnet-Ex
12 responds to all types of magnetic fields, no matter if the
magnetic fields are alternating, direct and permanent fields.
The LED responds even if the probe is not in direct contact
with a solenoid valve, for example. The built-in test magnet,
which is located in the cap of the housing, allows you to run
a self-test and to check the battery simultaneously.
7.2 Application
Before each use, it is recommended to run a functional test.
This can be done by using the test magnet and placing it
close to the probe. The LED of the probe should light up.
The probe of the Magnet-Ex 12 can then be placed near to
a suspected magnetic field of, for example, a solenoid valve.
If there is a sufficiently active magnetic field, the probe lights
up. The Magnet-Ex 12 detects via the magnetic field if a
solenoid valve is working properly. An intrinsically safe mul-
timeter can only measure the current or voltage of a valve,
but the Magnet-Ex 12 will indicate as to whether or not there
is a sufficiently active magnetic field. This way the operator
can detect a fault of the valve spool. If the valve does not
work properly although the probe has detected a magnetic
field, the valve is probably jammed.
BAL_Magnet_Ex_12_2010.indd 14 30.11.10 15:20

15
Using the test magnet,
a self-test is performed.
If the probe is placed near
a magnetic field, for example
of a solenoid valve, the LED
indicator of the probe will light up.
7.3 Battery replacement
When the power of the batteries is becoming exhausted,
the LED becomes perceptibly darker while the sensor unit
still works faultlessly. Use the test magnet, which is located
in the cap of the housing of the Magnet-Ex 12, to check
the brightness and the proper functioning of the LED. If the
LED is becoming darker or does not light up at all, you
have to replace the batteries (always outside the Ex-area).
Only type-tested batteries are to be used (refer to the
table with type-tested batteries under section 6, „Technical
specifications“). The use of any other type of batteries is
strictly forbidden.
In order to replace the batteries, first remove the cap of the
housing by unscrewing in an anti-clockwise direction.
Replace the batteries. Close the cap of the housing by firmly
screwing it in a clockwise direction.
- Always replace all batteries simultaneously.
- Pay attention to the correct polarity.
- Please ensure that all used batteries are properly
disposed of in an environmentally friendly manner.
- Make sure that the cap of the housing has been screwed
firmly.
Probe
LED indicator
Clip
Removable
cap with
test magnet
BAL_Magnet_Ex_12_2010.indd 15 30.11.10 15:20

16
8. Repair
Repairs are to be conducted by ecom instruments GmbH
or by personnel or service centres authorised by ecom
instruments GmbH, because the safety of the unit needs to
be tested after repairs are implemented.
9. Disposal
Old electrical devices as well as „historical“ old electrical
devices from ecom instruments GmbH are supplied for
disposal at our expense and disposed of free of charge in
accordance with European Directive 2002/96/EC and the
German electrical law of 16/03/2005. The costs associated
with returning devices to ecom instruments GmbH are to be
borne by the sender.
In accordance with “Directive 2006/66/EC on batteries
and accumulators and waste batteries” we are obligated to
provide you with the following information:
Your device contains an alkaline battery.
Depleted batteries should never be disposed of along with
normal or household waste. Old batteries can contain harm-
ful substances that are hazardous to health and damaging
to the environment. Please return the batteries. Return is
free of charge and required by law. Please only dispose of
discharged batteries in the designated containers.
Note: The battery used in this unit poses a fire hazard and
can cause chemical injuries if it is used improperly. Neither
the battery nor the battery cells should be opened or
disassembled and they should not be burned or exposed to
temperatures exceeding 100°C.
If the battery needs to be disposed of, it can be removed
as described under point (7.3). The disposal regulations
specified above are also applicable for old devices.
All batteries can be recycled. Precious raw materials such
as iron, zinc and nickel can therefore be reused.
The symbol
has the following meaning: Batteries and
rechargeable batteries should not be disposed of along with
normal or household waste.
10. Cleaning, maintenance and storage
- Only use a suitable cloth or sponge to clean the unit. Do
not use any solvents or abrasive cleaning agents when
cleaning.
BAL_Magnet_Ex_12_2010.indd 16 30.11.10 15:20

17
- It is recommended that you have the functionality and
accuracy of the unit inspected by the manufacturer every
two years.
- The batteries should be removed from the unit during
prolonged periods of storage.
- Do not allow storage temperatures to exceed or fall below
the permitted range of - 40 °C to ... 60 °C.
11. Warranty and liability
In accordance with our general terms and conditions ecom
instruments GmbH provides a warranty for this product for
a period of two years regarding its function and material un-
der the specified and permitted operating and maintenance
conditions. This excludes all parts that are subject to wear
and tear (e.g. batteries, probes, calibrations, LEDs, etc).
This warranty does not extend to products that are used
improperly, have been modified, neglected, damaged in
accidents or exposed to abnormal operating conditions and
inappropriate handling.
Any claims under the warranty can be invoked by returning
the defective equipment to the manufacturer. We reserve the
right to repair, adjust or exchange the device.
The aforementioned guarantee conditions are the sole and
only right of the purchaser to compensation, are exclusively
valid and replace all other contract or legal warranty
obligations. ecom instruments GmbH assumes no liability
for special, direct, indirect, accompanying or consequen-
tial damage as well as losses including the loss of data,
independent of whether it was caused by violation of the
warranty obligation, lawful or unlawful action, action in good
faith or any other action.
If the limitation of a legal warranty as well as the exclusion
or limitation of accompanying or consequential damage
is not permissible in certain countries, it may be that the
aforementioned limitations and exclusions are not valid for
every purchaser. Should any such clause of these warranty
conditions be declared ineffective or unenforceable by a
competent court, then the effectiveness or enforceability
of any of the other conditions of these warranty conditions
shall remain unaffected by such a judgement.
BAL_Magnet_Ex_12_2010.indd 17 30.11.10 15:20

18
12. EC Declaration of Conformity
Further details regarding the Declaration of Conformity can be
found at: www.ecom-ex.com in the product download area.
mobile experts
ecom instruments GmbH · Industriestraße 2 · 97959 Assamstadt · Germany
Tel.: [phone] / 42 24-0 · Fax: [phone] · E-Mail: [email protected] · www.ecom-ex.com
Communication
Portable Lighting
Mobile Computing
Measuring & Calibration
WEEE-Reg.-Nr.: DE 934 99306
2200ME01A01
Declaration of EC-Conformity
according to directive 94/9/EC (ATEX)
We ecom instruments GmbH, declare under our sole responsibility, that the product to which this declaration relates, is in
accordance with the provision of the following standards, directives and norms:
name & adress of manufacturer in the EC ecom instruments GmbH
Industriestraße 2
97959 Assamstadt
Germany
description of device explosion protected magnet testing pen
type: Magnet-Ex 12
Ex-designation
II 2 G Ex ia IIC T4
EC-type examination certificate PTB 01 ATEX 2018
Certification body Physikalisch-Technische Bundesanstalt
Bundesallee 100
38116 Braunschweig, Germany
identification number: 0102
name & address of auditing body
a) Quality Management System according
to ISO 9001
TÜV Süd Management Service GmbH
Ridlerstraße 65
80339 München, Germany
name & address of auditing body
b) Quality Management System of production
according to directive 94/9/EC (ATEX)
Physikalisch-Technische Bundesanstalt
Bundesallee 100
38116 Braunschweig, Germany
identification number: 0102
applied harmonized standards EN 60079-0:2006
EN 60079-11:2007
applied European directives
and recommendations
94/9/EC
ecom instruments GmbH
Assamstadt 23.11.2010
Rolf Nied
Managing Director
BAL_Magnet_Ex_12_2010.indd 18 30.11.10 15:20

19
13. EC type approval test certificate
BAL_Magnet_Ex_12_2010.indd 19 30.11.10 15:20

20
Physikalisch-Techn ische Bundesanstalt • Bundesa llee 100 • 38116 Braunschweig • GERMANY
Physikalisch-Technische Bundesanstalt
Brunswick and Berlin
1st addendum to EC type approval test certif icate PTB 01 ATEX 2018
Varta LR03 Maxi Tech No. 4703
Energizer Ucar Gold LR03
Varta No. 8003 Electric Power LR03
Ampercell Super Plus Alkaline
Rayovac Maximum P lus
Applied standards
EN 60079-0:2006, EN 60079-11:2007
Evaluation and test report: PTB Ex 09-28295
Certification supervisor
By order of
Dr.-Ing. U. Johanns meyer
Director and Professor
Brunswick, 24 March 2009
EC type approval test certificate s without a signature and seal are not valid. This EC type approval test
certificate may only be circulated without alteration. Extra cts or alterations are subject to approval by the
Physikalisch-Technisc hen Bundesanstalt.
Page 2/2
Physikalisch-Technische Bu ndesanstalt • Bundesallee 100 • 38116 Braunschweig • GERMA NY
Physikalisch-Technische Bundesanstalt
Brunswick and Be rlin
1st A D D E N D U M
in accordance w ith directive 94/9/ EC, appendix III number 6
to EC type approval test certificate
PTB 01 ATEX 2018
Translation
Device: Magnet - Ex 12 pr obe
Designation: II 2 G EEx ia IIC T4
Manufacturer: ECOM Rolf Nied GmbH
Address: Industriestraße 2, 9795 9 Assamstadt, Germany
Description of the amendments and alterations
The Magnet-Ex 12 probe may also be manufactured and operated in accordance with the test documen ts specified in sec tion 3.
The changes relate to the company name, electrical data, designation an d use of the abo ve-mentioned test sp ecification.
The company nam e has changed to ecom instruments G mbH.
The designation has changed to
II 2 G Ex ia HC T4
All other data rem ains unchanged. Electrical
data
Supply from 2 x AAA batteries, LR03/R03, Umax  3.3 V
Permitted battery types:
Company Type
Varta LR03 High En ergy No. 4903
Varta LR03 Industria l Alkaline No. 400 3
Eveready Energizer No . E92
Duracell Procell MN240 0 LR03
Duracell Plus MN2400 LR03
Page 1/2
EC type approval test certificates with out a signature and seal are not valid. This EC type ap proval test
certificate may only be circ ulated without alteration. Extracts or alterations are subje ct to approval by the
Physikalisch-Technischen Bundesanstalt.
BAL_Magnet_Ex_12_2010.indd 20 30.11.10 15:20

PA000003 / 1000 / 11 / 10
WEEE-Reg.-Nr. DE 934 99306
2200AL01A04 11/10
Änderungen vorbehalten! Subject to change without notice!
ecom instruments GmbH
Industriestraße 2 • 97959 Assamstadt • Germany • Tel.: [phone] / 42 24-0
Fax: [phone] • E-Mail: [email protected] • www.ecom-ex.com
Copyright© 2010 ecom instruments GmbH.
Der Inhalt dieses Dokuments darf ohne vorherige schriftliche Genehmi-
gung durch die ecom instruments GmbH in keiner Form, weder ganz
noch teilweise vervielfältigt, weitergegeben, verbreitet oder gespeichert
werden.
Der Inhalt dieses Dokuments wird so präsentiert, wie er aktuell vor-
liegt. Die ecom instruments GmbH übernimmt weder ausdrücklich
noch stillschweigend irgendeine Gewährleistung für die Richtigkeit oder
Vollständigkeit des Inhalts dieses
Dokuments, einschließlich, aber nicht
beschränkt auf die stillschweigende
Garantie der Markttauglichkeit
und der Eignung für einen bestimmten Zweck, es sei denn, anwendbare
Gesetze oder Rechtsprechungen schreiben zwingend eine Haftung vor.
Die ecom instruments GmbH behält sich das Recht vor, jederzeit ohne
vorhergie Ankündigung Änderungen an diesem Dokument vorzuneh-
men oder das Dokument zurückzuziehen.
Copyright© 2010 ecom instruments GmbH.
The contents of this document, either in part or in their entirety, may
not be reproduced, forwarded, distributed or saved in any way without
ecom instruments GmbH prior written consent.
The contents of this document are presented as they currently exist.
ecom instruments GmbH does not provide any express or tacit gu-
arantee for the correctness or completeness of the contents of this
document, including, but not restricted to, the tacit guarantee of market
suitability or tness for a specic purpose unless applicable laws or court
decisions make liability mandatory. ecom instruments GmbH reserves
the right to make changes to this document or to withdraw it any time
without prior notice.
