Zonotip(+)
Service Manual & Repair Guide
This document is part of the ASPO Service & Repair set and describes the procedure how to
isolate defects, disassemble the instruments, exchange parts, assemble and test the Zonotip
and Zonotip+
Key Words: Zonotip, Zonotip+, Ultrasonic, Thickness gauge, Transducer, Single Crystal,
Double Cristal, Step Block, Repair, Service, Calibration, Manual, ASPO
Document Number : 820 79 004E
Document Revision: 1.1
Revision Date: 11-May-2011
Document State: Released
Author: Andreas Klinter [email protected]
Company: Proceq SA
Ringstrasse 2
CH-8603 Schwerzenbach
Switzerland
Classification: for internal use only
Revision requests: to request revision or permission to work in deviation from this guide, please
contact the author(s) or the responsible product manager

Zonotip Service Manual & Repair Guide
Doc: 820 79 004E Rev: 1.0 Page 2/12
© Copyright 2012, Proceq SA, CH-8603 Schwerzenbach Working copy if printed
Revision History
Rev Date Author, Comments
_ 09. Dec 2011 Andreas Klinter
1.1 14.Sept 2012 Andreas Klinter - addition of Calibration sample set to
ASPO kit, adaptation of calibration procedure
Table of Contents
1. ASPO Set for Zonotip(+) ........................................................................................................ 3
2. Spare Part Kits........................................................................................................................ 3
3. Preparation.............................................................................................................................. 5
4. Troubleshooting ..................................................................................................................... 5
5. Disassembly............................................................................................................................ 5
5.1 Housing ...........................................................................................................................................5
5.2 PCB.................................................................................................................................................6
5.3 Display.............................................................................................................................................8
6. Assembly & Replacement...................................................................................................... 9
6.1 Display, PCB, and Housing Cover ..................................................................................................9
6.2 Battery Pack and Housing Base ...................................................................................................10
6.3 Closing the Instrument ..................................................................................................................11
7. Calibration Certificate .......................................................................................................... 11
