Ecom X.COM 200 -EX Installation instructions

x.com 200 -Ex
Safety instructions

15
Table of Contents
1. Application 16
2. Safety precautions 16
3. Faults and damage 16
4. Safety regulations 17
5. Ex-Data 18
6. Specifications 18
7. Button functions 19
8. Rechargeable battery and commissioning 20
8.1 Changing the battery 20
8.2 Commissioning 20
8.3 Safety precautions 22
9. Repair 23
10. Cleaning, maintenance and storage 23
11. Disposal 24
12. Warranty and liability 25
13. EC Declaration of Conformity 26
14. Certificate of Conformity 27
Note:
The current safety precautions, operating instructions, EC
Declaration of Conformity and the Certificate of Conformity
can be downloaded from the relevant product page at www.
ecom-ex.com, or alternatively they can be requested directly
from the manufacturer.

16
1. Application
The x.com 200 –Ex is an explosion-shielded, water-, dust-
and impact-resistant mobile phone for industrial application
in areas with an increased risk of explosion in zone 2 in
accordance with directive 1999/92/EC (ATEX 137) and 94/9/
EC (ATEX 95).
2. Safety precautions
These operating instructions contain information and safety
regulations which are to be observed without fail for safe
operation in the described conditions. Non-observance of this
information and these instructions can have serious conse-
quences or it may violate regulations.
Please read these operating instructions carefully before
starting to use the unit! In the event of conflicting information
the details specified in the safety precautions shall apply.
In case of any doubt (in the form of translation or printing
errors) the German version shall apply.
3. Faults and damage
If there is any reason to suspect that the safety of the unit has
been impaired, it must be withdrawn from use and removed
immediately from the Ex-area. Measures must be taken to
prevent it from being restarted accidentally.
The safety of the unit may be compromised, if, for example:
- there is visible damage to the housing.
- the unit has been subjected to excessive loads.
- the unit has been improperly stored.
- the unit has been damaged in transit.
- unit markings or inscriptions are illegible.
- malfunctions occur.
- permitted limit values have been exceeded.

17
4. Safety regulations
Use of the x.com 200 –Ex explosion-shielded mobile phone
assumes that the operator observes the conventional safety
regulations and has read the certificate of conformity in order
to eliminate faulty operation of the unit.
The following points are to be observed:
- The device has to be protected against strong impact.
- The unit should not be opened inside the Ex-area.
- The battery module may not be changed inside the Ex-area!
- The battery module may only be charged outside the Ex-
area and only then using the following appropriate chargers:
battery charger DSA-0051-05C, USB data cable PCX 20 or
car charger ALX 20
- The battery module may only be charged in a temperature
range of 0 °C - 45 °C.
- Only accessories approved by ecom instruments GmbH
may be used.
- Observe the corresponding laws that are in force in the re-
spective country regarding the use of mobile phones while
operating a vehicle!
- Use of the mobile phone in an airplane is not permitted!
- Switch off the mobile phone when in close proximity to
medical instruments and if you are requested to do so by
corresponding regulations!
- Manufacturers of cardiac pacemakers recommend a
minimum distance of 15.3 cm (6“) is maintained between a
mobile phone and a pacemaker.
- Do not switch on the mobile phone when the use of such
devices is prohibited, as it may cause interference or result
in danger.
- Only the original battery module AM X20 (Li-Polymer 3.7V)
should be used!
-
The charging socket cover must be firmly engaged in the unit.
- When changing the battery the unit and the battery terminals
are to be checked for cleanliness and cleaned, if necessary.
- It must be ensured that the unit is not taken into zones 0 or 1!

18
5. Ex-Data
Certificate of Conformity no.: PTB 09 ATEX 2042 X
Ex-designation: II 3G Ex nA nL IIC T4
x.com 200 –Ex
Approved for zone 2, device group II, explosion group IIC
(explosive gases, vapours or mist), temperature class T4.
6. Specifications
Networks:
GSM: 900 MHz
1800 MHz
1900 MHz
Power supply: Battery module AM X20
Dimensions: 119 x 57 x 25 mm
Weight: approx. 160 g
CE-designation: 0 0102
Ambient temperature: -20 °C ... +50 °C
Protection rating: IP 57

19
7. Button functions
Volume control
Phonebook/
PTT-function
Left
selection
button
Accept/Make-
call button
Press and hold
to access
the mailbox
For entering a ‚+‘ for
international numbers
Charging socket cover
Press and hold
to activate/
deactivate
the silent mode.
To activate/deactivate
the loud-
speaker during a call.
To display the ring
type menu
in the standby mode.
On/Off/Call
end button
Flashlight
Menu button
Navigation buttons
(up/down/left/right)
Press and hold
to lock/unlock
the keypad.
Right selection
button

20
8. Rechargeable battery and commissioning
8.1 Changing the battery
The AM X20 battery module for the x.com 200 –Ex unit may
only be changed outside the Ex-area. Only those battery
modules which are approved by the manufacturer for your
device type may be used (see Safety regulations under point
4). Other battery modules may not be taken into the Ex-area.
8.2 Commissioning
1) Unscrewing the cover:
Switch off the phone. To
open the battery compart-
ment cover turn the screws
in the cover anti-clockwise.
2) Lifting the cover:
Remove the cover for the
battery compartment.
3) Inserting the SIM:
Remove the battery. Slide the
silver card holder to the right
and carefully lift the SIM card
holder. Insert the SIM card
into the designated holder in
the lower part of the phone.

21
4) Securing the SIM:
Lower the SIM card holder.
Slide the card holder gently to
the left over the SIM card.
5) Inserting the battery:
Insert the battery. Close
the cover for the battery
compartment. Turn the screws
of the battery compartment
clockwise.
6) Charging the phone:
The battery supplied with the
phone is not fully charged. It
is recommended to charge
the phone for three hours be-
fore using it for the first time.
The full capacity of the battery
is reached after 4-6 complete
charge/discharge cycles.
IMPORTANT: To ensure water tightness the screws should
only be tightened by hand!

22
NOTE - There is a risk of explosion if the battery is not ex-
changed properly or if it is exposed to a flame.
Do not short-circuit the battery.
The battery does not contain any parts that can be ex-
changed. The casing of the battery should not be opened
under any circumstances.
Only use ecom charging accessories (see point 4).
The use of other chargers or batteries is not permitted. If such
items are used, your Ex-protection will expire.
Used batteries are to be disposed of properly.
If you do not intend using the phone for a prolonged period,
you should remove the battery.
We strongly advise against connecting your phone to the
charger if the battery is not inserted.
If the battery is completely discharged, the phone will not
switch on and the display will not show a charging process.
Connect the phone to the charger. After charging for a few
minutes the display will appear again and you can then
switch on the phone.
8.3 Safety precautions
Damaged batteries and chargers should be removed from
use and sent to ecom instruments GmbH for inspection.
Note:
Extreme temperatures can have an adverse effect on char-
ging the battery module AM X20.
Do not dispose of the battery module in a fire!
Do not short-circuit the battery module!
Dispose of the battery module in accordance with local
regulations. Do not dispose of the battery module with normal
household waste.
High quality lithium-ion batteries are used in your x.com 200
–Ex. These batteries have numerous advantages in everyday
use, such as a low weight and high capacity in a nevertheless
compact construction. In addition these batteries also exhibit
practically no memory effect.

23
However, these batteries are susceptible to a natural ageing
process which impairs their functionality. Modern batteries
today have a lifespan of around 500 charge cycles, which,
when used daily, corresponds to a service life of approxi-
mately 2 years. The ageing process increases rapidly after
this period, which means that the batteries are deemed
technically defective after 500 charge cycles. Moreover, the
batteries could blow up and cause irreparable damage to
your device in a worst case scenario.
For this reason rechargeable batteries with lithium cells
should be replaced after 2 years at the latest or after reaching
a battery capacity that is 50% of its initial value.
Note: The battery used in this unit poses a fire hazard and
can cause chemical injuries if it is used improperly. Neit-
her the battery nor the battery cells should be opened or
disassembled and they should not be burned or exposed to
temperatures exceeding 100 °C.
9. Repair
Repairs are to be conducted by ecom instruments GmbH
or by personnel or service centres authorised by ecom
instruments GmbH, because the safety of the unit needs to be
tested after repairs are implemented.
10. Cleaning, maintenance and storage
- Only use a suitable cloth or sponge to clean the phone.
Do not use any solvents or abrasive cleaning agents when
cleaning.
- It is recommended that you have the functionality and
accuracy of the phone inspected by the manufacturer every
two years.
- The battery should be removed from the phone during
prolonged periods of storage.
- Do not exceed the permissible storage temperature range of
-20 °C ... +50 °C!

24
11. Disposal
Old electrical devices as well as „historical“ old electrical
devices from ecom instruments GmbH are supplied for
disposal at our expense and disposed of free of charge in
accordance with European Directive 2002/96/EC and the
German electrical law of 16/03/2005. The costs associated
with returning devices to ecom instruments GmbH are to be
borne by the sender.
In accordance with Article 1, Section 18 and Article 2 of the
Act revising the law of Waste-Related Product Responsibility
for Batteries and Accumulators (Gesetz zur Neuregelung der
abfallrechtlichen Produktverantwortung für Batterien und
Akkumulatoren) dated 25 June 2009, we are obligated to
provide the following information.
Your device contains a rechargeable lithium battery.
Depleted batteries or rechargeable batteries that can no
longer be recharged should never be disposed of along with
normal or household waste. Old batteries can contain harmful
substances that are hazardous to health and damaging to the
environment. Please return the batteries/rechargeable batte-
ries. Return is free of charge and required by law. Please only
dispose of discharged batteries in the designated containers
and tape the terminals of lithium batteries.
Note: The battery used in this unit poses a fire hazard and
can cause chemical injuries if it is used improperly. Neit-
her the battery nor the battery cells should be opened or
disassembled and they should not be burned or exposed to
temperatures exceeding 100°C. If the battery needs to be dis-
posed of, it can be removed as described under point (8.1).
The disposal regulations specified above are also applicable
for old devices. All batteries and rechargeable batteries can
be recycled. Precious raw materials such as iron, zinc and
nickel can therefore be reused.
The symbol has the following meaning: Batteries and
rechargeable batteries should not be disposed of along with
normal or household waste.

25
12. Warranty and liability
In accordance with our general terms and conditions ecom
instruments GmbH provides a warranty for this product for a
period of two years regarding its function and material under
the specified and permitted operating and maintenance con-
ditions. This excludes all parts that are subject to wear and
tear (e.g. batteries). We provide a 6-month manufacturer‘s
warranty especially for the supplied Ex-battery.
This warranty does not extend to products that are used
improperly, have been modified, neglected, damaged in
accidents or exposed to abnormal operating conditions and
inappropriate handling.
Any claims under the warranty can be invoked by returning
the defective equipment to the manufacturer. We reserve the
right to repair, adjust or exchange the device.
The aforementioned warranty conditions are the sole and only
right of the purchaser to compensation, are exclusively valid
and replace all other contract or legal warranty obligations.
ecom instruments GmbH assumes no liability for special, di-
rect, indirect, accompanying or consequential damage as well
as losses including the loss of data, independent of whether
it was caused by violation of the warranty obligation, lawful or
unlawful action, action in good faith or any other action.
If the limitation of a legal warranty as well as the exclusion
or limitation of accompanying or consequential damage
is not permissible in certain countries, it may be that the
aforementioned limitations and exclusions are not valid for
every purchaser. Should any such clause of these warranty
conditions be declared ineffective or unenforceable by a
competent court, then the effectiveness or enforceability of
any of the other conditions of these warranty conditions shall
remain unaffected by such a judgment.

26
13. EC Declaration of Conformity
mobile experts
ecom instruments GmbH · Industriestraße 2 · 97959 Assamstadt · Germany
Tel.: [phone] / 42 24-0 · Fax: [phone] · E-Mail: [email protected] · www.ecom-ex.com
Communication
Torches/Flashlights
Mobile Computing
Measuring & Calibration
WEEE-Reg.-Nr.: DE 934 99306
500012 ME 02 A00
Declaration of EC-Conformity
according to directive 94/9/EC (ATEX)
We ecom instruments GmbH, declare under our sole responsibility, that the product to which this declaration relates, is in accor-
dance with the provision of the following standards, directives and norms:
name & adress of manufacturer in the EC ecom instruments GmbH
Industriestraße 2
97959 Assamstadt
Germany
description of device explosion protected mobile phone
type: X.com 200 -Ex
Ex-designation
II 3 G Ex nA nL IIC T4
Conformity statement PTB 09 ATEX 2042 X
Certification body Physikalisch-Technische Bundesanstalt
Bundesallee 100
38116 Braunschweig, Germany
identification number: 0102
name & address of auditing body
a) Quality Management System according to ISO 9001: 2000
TÜV Süd Management Service GmbH
Ridlerstraße 65
80339 München, Germany
name & address of auditing body
b) Quality Management System of production according to
directive 94/9/EC (ATEX)
Physikalisch-Technische Bundesanstalt
Bundesallee 100
38116 Braunschweig, Germany
identification number: 0102
applied harmonized standards EN 60079-0: 2006
EN 60079-15: 2005
EN 300 328: 2006
EN 60950-1: 2006
EN 301 511: 2003
EN 301 489-1: 2005
EN 301 489-7: 2005
EN 301 489-17: 2002
EN 50360: 2001
EN 50361: 2001
applied European directives 94/9/EC
99/5/EC
ecom instruments GmbH
Assamstadt 24. 11. 2009
Rolf Nied
Managing Director

27
14. Certificate of Conformity
Physikalisch-Technische Bundesanstalt
Braunschweig und Berlin
Translation
(1) Declaration of conformity
(2) Equipment and protective systems intended for use in potentially explosive atmospheres -
Directive 94/9/EC
(3) Test certificate number
PTB 09 ATEX 2042 X
(4) Device: Intrinsically safe mobile phone X.com 200-Ex
(5) Manufacturer: ecom instruments GmbH
(6) Address: Industriestrasse 2,97959 Assamstadt, Germany
(7) The design of this device and its various approved embodiments are defined in the appendix to this
type approval test certificate and the documents specified therein.
(8) On the basis of the Council Directive of the European Communities dated 23 March 1994
(94/9/EC), the Physikalisch-Technische Bundesanstalt certifies the fulfilment of the fundamental
health and safety requirements for the conception and construction of devices and protective
systems for intended use within explosive areas in accordance with appendix II of the directive.
The results of the examination are specified in the confidential evaluation and test report
PTB Ex 09-29105.
(9) The basic health and safety requirements are met by virtue of conformance with
EN 60079-0:2006, EN 60079-15:2005
(10) If the certification number is followed by an "X", then this indic ates that special conditions exist for
the safe operation of the device. These special conditions are contained in the attachment to this
certific ate.
(11) This declaration of conformity only relates to the design and structure of the specified device in
accordance with Directive 94/9/EC. Further requirements contained in this directive apply to the
production and marketing of this device.
(12) The device must be labelled with the following information:
II 3 G Ex nA nL IIC T4
Certification sector for explosion protection, Braunschweig, 6. Januar 2010
By order of
L.S.
Dr.-Ing. U. Johannsmeyer
Director and professor
Page 1/1
Declarations of conformity without a signature and seal are not valid. This declaration of conformity may only be circulated without alteration. Extracts
or alterations are subject to approval by the Physikalisch-Technischen Bundesanstalt.
Physikalisch-Technische Bundesanstalt· Bundesallee 100·38116 Braunschweig· GERMANY
Translation

28
Physikalisch-Technische Bundesanstalt
Braunschweig und Berlin
(13) Appendix
(14) Declaration of conformity PTB 09 ATEX 2042 X
(15) Description of the device
The X.com 200-Ex intrinsically safe mobile phone is intended for GSM communication in
explosive Zone 2 areas.
Maximum permissible ambient temperature range: -20°C to +50°C
Electrical data
Power supply Battery, type AM X20
3.7 V, 1180 mAh
Transmitting power 2W
(16) Evaluation and test report PTB Ex 09-29105
(17) Special conditions
1. The X.com 200-Ex intrinsically safe mobile phones are to be operated in the explosive area
in such a way that they are protected against excessive impact.
2. Charging or exchanging the battery is only permitted outside the explosive area. The safety
precautions are to be observed when doing this.
3. The c harging socket cover must be firmly engaged on the unit.
(18) The basic health and safety requirements are met by virtue of conformance with the
aforementioned standards.
Certification sector for explosion protection, Braunschweig, 6. Januar 2010
By order of
L.S.
Dr.-Ing. U. Johannsmeyer
Director and professor
Page 2/2
Declarations of conformity without a signature and seal are not valid. This declaration of conformity may only be circulated without alteration. Extracts
or alterations are subject to approval by the Physikalisch-Technischen Bundesanstalt.
Physikalisch-Technische Bundesanstalt· Bundesallee 100·38116 Braunschweig· GERMANY
Translation

PA000361 / 4000 / 02 / 2010
WEEE-Reg.-Nr. DE 934 99306
500012AL03A01 02/10 Änderungen vorbehalten! Subject to change without notice!
Copyright© 2010 ecom instruments GmbH.
Der Inhalt dieses Dokuments darf ohne vorherige schriftliche Genehmigung durch die
ecom instruments GmbH in keiner Form, weder ganz noch teilweise vervielfältigt, weiter-
gegeben, verbreitet oder gespeichert werden.
Der Inhalt dieses Dokuments wird so präsentiert, wie er aktuell vorliegt. Die ecom
instruments GmbH übernimmt weder ausdrücklich noch stillschweigend irgendeine
Gewährleistung für die Richtigkeit oder Vollständigkeit des Inhalts dieses
Dokuments,
einschließlich, aber nicht beschränkt auf die stillschweigende
Garantie der Markt-
tauglichkeit und der Eignung für einen bestimmten Zweck, es sei denn, anwendbare
Gesetze oder Rechtsprechungen schreiben zwingend eine Haftung vor. Die ecom
instruments GmbH behält sich das Recht vor, jederzeit ohne vorherige Ankündigung
Änderungen an diesem Dokument vorzunehmen oder das Dokument zurückzuziehen.
Copyright© 2010 ecom instruments GmbH.
The contents of this document, either in part or in their entirety, may not be reproduced,
forwarded, distributed or saved in any way without ecom instruments GmbH prior written
consent.
The contents of this document are presented as they currently exist. ecom instruments
GmbH does not provide any express or tacit guarantee for the correctness or complete-
ness of the contents of this document, including, but not restricted to, the tacit guarantee of
market suitability or fitness for a specific purpose unless applicable laws or court decisions
make liability mandatory. ecom instruments GmbH reserves the right to make changes to
this document or to withdraw it any time without prior notice.
Kommunikation
Mobile Computing
Portable Handlampen
Mess- & Kalibriertechnik
Communication
Portable Lighting
Mobile Computing
Measuring & Calibration
ecom instruments GmbH ·Industriestr. 2 · 97959 Assamstadt · Germany
Tel.: + 49 (0) 62 94 / 42 24 0 · Fax: + 49 (0) 62 94 / 42 24 100
E-Mail: [email protected] · www.ecom-ex.com
