Ecosoft ROBUST 1000 User guide

СИСТЕМ ОБРАТНОГО ОСМОСА
ECOSOFT ROBUST 1000, ROBUST 3000
FOR REVERSE OSMOSIS SYSTEMS
ECOSOFT ROBUST 1000, ROBUST 3000

INSTALLER AND USER GUIDE

28 29
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
28
CONTENTS
1Application 30
2Specifications and components 33
2.1 Technical specifications 33
2.2 Feed water requirements 34
2.3 System components 34
3Installation diagrams 36
3.1 ECOSOFT RObust base model 36
3.2 ECOSOFT RObust with pressure tank 37
3.3 ECOSOFT RObust with pressure tank and ultraviolet lamp 37
4Installation steps 38
4.1 Installation conditions and package completeness check 38
4.2 Installation 38
5Post-installation 42
6Operation 42
6.1 Description and average lifespan of system components 43
6.2 Filter replacement 44
6.3 Membrane replacement 44
7Sanitization 45
8Troubleshooting 45
9Maintenance record 48
10 Health and environment safety information 50
11 Purchasing 50
12 Transportation and storage 50
13 Warranty 50
14 Authorized services in your area 51

30
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
1. APPLICATION
Reverse osmosis process is one of the most advanced technologies of water puricaon. Reverse
osmosis lter uses a special semipermeable membrane similar in its structure and properes to the
membrane of a living cell. It can be conceived of as having ny pores that are 200 mes smaller
than viruses and 4000 mes smaller than most bacteria. The principle of reverse osmosis water pu-
ricaon is modelled aer living cell’s natural water cycle. It allows purifying drinking water from all
harmful impuries, including nitrates and viruses (see Figure 1 below). Only molecules of a certain
size can penetrate through cellular membrane.
Ecoso RObust is a high recovery direct ow operaon capable reverse osmosis system. The system
can be equipped with a pressure tank for increasing puried water ow rate, and its mulstage
design allows obtaining a high recovery up to 50%.
The system is tapped in water mains using feed adapter and feed valve. Tube is run from feed valve
to the inlet port in system’s port rack (labeled). The port rack also includes connecon ports for the
drain, pressure tank 6 (if used), and puried water faucet 1 or puried water pipe. Feed water rst
undergoes pre-ltraon in the sediment and carbon pre-lters where it is stripped of suspended
parcles (rust, sand, hemp strands etc.), organic color and chlorine compounds. Pressure gauge no.
1 on front panel displays water pressure aer the pre-lter.
Figure 1. Reverse osmosis process illustraon
Tap water under
pressure
Concentrate
for disposal
Membrane
Water
molecules
Molecules of smaller
size, pure water
Larger molecules

30 31
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
ROBUST 1000
Technological scheme of RObust 1000 is shown in Figure 2. Aer the pre-lters, the pressure
booster pump feeds the water to the reverse osmosis membrane array with two membrane
modules. Permeate from both modules goes to the permeate collector, and concentrate from the
1st and 2nd modules goes to the 3rd one. Second stage permeate goes to the permeate collector, and
the concentrate is discarded to drain via concentrate ow restrictor and drain port in port rack.
Pressure gauge no. 2 shows pressure between the 2nd and 3rd membranes. Permeate goes to the
puried water line or pressure tank (if installed), passing through the carbon post-lter. Puried
water line may go to puried water faucet or be connected with some other consumer appliance.
High-pressure switch installed before the post-lter reads pressure in permeate line and starts the
reverse osmosis system when it drops (due to taking of some water from the pressure tank or
opening puried water faucet). When the system switches on, entry solenoid valve is opened and
booster pump is powered up, which allows to feed water into the system. When puried water
stops being drawn from the system, pressure starts to build up and closes high-pressure switch
switching o the system.
Figure 2
Water inlet
connection
Sediment
pre-filter
Carbon
pre-filter
Low-pressure
switch
Inlet
pressure
gauge
Inlet
solenoid
valve
Booster
pump
Membrane
module
Operating
pressure
gauge
High-pressure
switch
Carbon
post-filter
Drain
outlet
Tank
connection
Permeate
outlet
Flow
restrictor

32
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
ROBUST 3000
Water inlet
connection
Sediment
pre-filter
Inlet solenoid valve
Inlet pressure
gauge
Low-pressure
switch
Booster
pump
Membrane
module
Operating
pressure
gauge
Flow restrictor
Drain outlet
High-pressure
switch
Carbon
post-filter
Tank
connection
Permeate outlet
Figure 3
Technological scheme of RObust 3000 is shown in Figure 2. Aer the pre-lters, the pressure
booster pump feeds the water to the reverse osmosis membrane array. Permeate from both
modules goes to the permeate collector, and the concentrate from the 1st module goes to the 2nd
one. Second stage permeate goes to the permeate collector, and concentrate is discarded to drain
via concentrate ow restrictor and drain port in port rack. Pressure gauge no. 2 shows pressure
between two membranes. Permeate goes to the puried water line or pressure tank (if installed),
passing through the carbon post-lter. Puried water line may go to the puried water faucet (not
included) or be connected with some other consumer appliance. High-pressure switch installed
before the post-lter reads pressure in permeate line and starts the reverse osmosis system when it
drops (due to taking of some water from the pressure tank or opening puried water faucet). When
the system switches on, entry solenoid valve is opened and booster pump is powered up, which
allows to feed water into the system. When puried water stops being drawn from the system,
pressure starts to build up and closes high-pressure switch switching o the system.
RObust 3000 system has low feed water pressure protecon implemented with a low-pressure
switch, which prevents the pump and solenoid from operang if feed pressure is less than
0.4 bar (5.8 psi). Two pressure gauges on the front panel show operang pressure in the system,
which allows diagnosing potenal and occurring problems.

32 33
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
1At feed water TDS of 1000 mg/L (ppm) and temperature of feed water of 25 °С (77 °F), ±10%.
2If the pressure of water in your system does not meet the requirement, install a pressure booster pump to raise
it. If water pressure exceeds the upper limit, install a pressure regulator before the RObust .
3Using the RObust with feed water temperature between 20 °С (68 °F) and 30 °С (86 °F) produces a lower rejec-
on rate and higher ow rate, which yields higher TDS of puried water. Using the system with feed water above
30 °С (86 °F) is advised against.
2. SPECIFICATIONS AND COMPONENTS
2.1 TECHNICAL SPECIFICATIONS
Parameter Value
RObust 1000 RObust 3000
Puried water ow rate1, L/h
gpm
55–60
0.24–0.26
145–150
0.64–0.66
Feed water ow rate, L/h
gpm
110–130
0.48–0.57
290–310
1.28–1.37
Concentrate ow rate, L/h
gpm
55–65
0.24–0.26
145–150
0.64–0.66
Inlet water pressure, bar (psi) 2.0–5.02 (29–72.5)
Operang pressure, bar (psi) 5.0–7.0 (72.5–101.5)
Feed water temperature, °С (°F) 4…303 (39…86)
Ambient air temperature, °С (°F) 5…403 (41…104)
Connecon to water mains JG ¼ JG ⅜
Overall dimensions, H × W × D, mm
inсh
420 x 220 x 425
16.5 x 8.7 x 16.7
445 x 480 x 380
17.5 x 18.9 x 15.0
Weight, kg (lb), max. 6 (13) 25 (55)
Electrical rang 230 V, 50 Hz
110 V, 60 Hz (USA)
Power consumpon, W (hp), max. 80 (0.11) 250 (0.34)
Ingress protecon rang IP 54

34
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
1) Filter rack with booster
pump
2) Pre-lters and post-lter 3) Reverse osmosis
membranes
2.3 SYSTEM COMPONENTS
2.2 FEED WATER REQUIREMENTS
Parameter Value1
pH 6.5…8.5
TDS, mg/L (ppm) <1500
Total hardness, °dH
ppm CaCO3
<30
<500
Active chlorine, mg/L (ppm) <0.5
Total iron, mg/L (ppm) <0.3
Total manganese, mg/L (ppm) <0.1
COD, mg O2/L (ppm O2)<5
Total microbial count (TMC), CFU per 1 mL <100
E. coli, CFU per 100 mL None
1If feed water quality does not meet specied requirements, membrane and lter service life may decrease. If
aiming to purify raw water (well water/ground water etc.), it is recommended to carry out detailed water anal-
ysis. If any constuents exceed the above limitaons, it is advisable to install a special lter upstream of your
reverse osmosis system. Consult professional water treatment specialist for proper selecon of an appropriate
lter for your water.
ROBUST 1000

34 35
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
4) Feed adapter 6) Puried water faucet
7) Feed valve
1) Filter rack with booster
pump
5) Drain saddle
8) Colored tubing
2) Pre-lter and post-lter
9) Service wrenches
ROBUST 3000

36
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
Run blue tube from puried water port to puried water faucet.
Drain. Run black tube from drain port to drain saddle installed on drain pipe.
Pressure tank. No connecon.
Inlet. Run red tube from feed water outlet to the inlet port in port rack.
CAUTION! The addional accessories should be used for the installaon of RObust 3000 reverse
osmosis system. These accessories are not included in the system components.
4) Service wrenches
3) Reverse osmosis
membranes
The manufacturer reserves the right to amend design or components of the product if such amend-
ment does not result in deterioraon of its quality and performance.
3. INSTALLATION DIAGRAMS
3.1. ECOSOFT ROBUST BASE MODEL
Puried
water Drain Tank Inlet

36 37
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
Run blue tube from puried water port to puried water faucet.
Drain. Run black tube from drain port to drain saddle installed on drain pipe.
Pressure tank. Run white tube from pressure tank port to the pressure tank.
Inlet. Run red tube from feed water outlet to the inlet port in port rack.
CAUTION! The addional accessories should be used for the installaon of RObust 3000 reverse
osmosis system. These accessories are not included in the system components.
Run blue tube from puried water port to puried water faucet.
Drain. Run black tube from drain port to drain saddle installed on drain pipe.
Pressure tank. Run white tube from pressure tank port to the pressure tank.
Inlet. Run red tube from feed water outlet to the inlet port in port rack.
Ultraviolet lamp. Run blue tube from puried water port to inlet of the ultraviolet lamp, run the
outlet of the ultraviolet lamp to puried water faucet.
CAUTION! The addional accessories should be used for the installaon of RObust 3000 reverse
osmosis system. These accessories are not included in the system components.
3.2. ECOSOFT ROBUST WITH PRESSURE TANK
3.3.ECOSOFT ROBUST WITH PRESSURE TANK AND ULTRAVIOLET LAMP
Puried
water Drain Tank Inlet
Puried
water Drain Tank Inlet

38
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
4. INSTALLATION STEPS
4.1. INSTALLATION CONDITIONS AND PACKAGE COMPLETENESS CHECK
4.2. INSTALLATION
Carefully read this manual before installing the reverse osmosis system.
CAUTION!
This product has been factory tested for leaks, and may contain residual moisture.
Before installaon of tubing, lters, and membranes, wash your hands with anbacterial soap.
Ensure that the installaon place is shielded from the direct sunlight and removed from heang
appliances.
— check other parameters of the technical specicaon (secon 2.1);
— check that feed water meets requirements shown in secon 2.2.
If the water quality does not meet requirements, refer to a water treatment specialist company

3) Before proceeding with the installaon, ensure there is enough space for the assembled system.
If using pressure tank, provide room for it as well. In case of shortage of space, pressure tank can
be removed to the distance of connecng tube length.
4) Install the reverse osmosis system in accordance with below procedure.
*If any of the parameters does not meet the requirement, consult secon 2.1 for possible correcve
acon.
1) Check that all components of the reverse osmosis system (see secon 2.3) are inside the package.
Do not open the plasc bag before you make sure it contains all parts. Missing part claims will not
be accepted if the package is broken.
2) Ensure that your ulies meet this product’s requirements:
 
Test water pressure at the tapping point. It must
comply with the specicaon in secon 2.1.
Test water temperature and verify
compliance with specicaon in secon 2.1.

38 39
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
1Remove the reverse osmosis system from the box and check that all parts are inside the
bag. Do not open the bag before verifying. You will not be able to claim missing parts if the
bag is opened.
2Shut o the water supply in place of installaon and open a water tap for 1 minute to re-
lieve pressure in the system. Then close the tap.
3Tap feed adapter 4 into the cold water plumbing. In-
stall feed valve into the feed adapter. To avoid leaks
use PTFE seal tape.
The adapter size ts the most common ½″ pipe. If
your pipe has another size, install an appropriate
ng piece.
4Unscrew compression nut from the feed valve
tube connecon. Slip red tube through the nut and
connect it to the feed valve tube connecon, then
screw compression nut back on ll snug. Connect
the other end of the red tube to the inlet port of
the RO system’s port rack. Push tube all the way to
the tube stop when making push-t connecons.
5Drain saddle 5 ts most standard drain pipe. Install
the drain saddle on drain pipe as follows. Bore 5 mm
(0.2″) hole in the drain pipe, apply rubber gasket
with scky base (included in the package). Install
drain saddle on top of the gasket so that push-t t-
ng in the saddle is located precisely above the hole
in the drain pipe. Tighten nuts on drain saddle fas-
teners with a wrench. Insert black tube in the push-
t ng in drain saddle. Connect the other end of
the black tube with drain port of the RO system’s
push-t port rack.
A
A
feed water adapter
red tube
feed valve
compression nut
feed water adapter
feed water adapter
PTFE tape
PTFE tape
feed valve
Fig. А1 Fig. А2 Fig. А3

40
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
6Put a few turns of PTFE tape on tank nipple thread.
Screw tank valve on the tank nipple. Turn the valve
fully o.
NOTE! Test air pressure in the empty tank bladder
(remove the cap on the lateral boom to access
valve stem). Reading should be 0.6–1.0 bar (8.7–
14.5 psi). If necessary, use the air pump to inate the
bladder. If pressure is too high already, push on the
valve stem’s core to relieve it.
7Install the faucet.
7.1 To install puried water faucet 8 bore a hole with di-
ameter of 12.5 mm (0.49″) in the desired locaon on
sink or coun tertop.
CAUTION! Metal shavings can damage your sink, re-
move them carefully once you have nished drilling.
If the mounng surface is stone or ceramic, use a
carbide drill bit.
7.2 Mount the faucet over the hole on top of small rub-
ber washer, chrome plated base, and large rubber
washer. Fix the faucet rmly with plasc washer, lock
washer, and nut put on the faucet shank underneath
sink surface.
7.3 Put compression nut on the free end of the blue
tube, then put on the ferrule and the insert inside
the tube.
7.4 Push the end of the blue tube inside the shank
boom a few cenmeter deeper, seat the ferrule
against shank boom and the screw compression
nut snugly on shank thread. The faucet should now
be rmly xed on the top of sink, and the blue tube
ghtly seated in compression ng at the boom of
the faucet shank.
8Remove 1st and 2nd pre-lter housings (le to right), put the polypropylene lter in the rst
bowl, carbon lter in the second.
9Install the housings back on the system frame. Hand ghten only.
10 Prepare a suitable water container. Remove feed water tubes from the two rst stage mem-
brane housings and place the free ends in the prepared container. Open main shuto valve
and the system feed valve to start rinsing pre-lters. Collect running water in the container
and discard when full. Repeat unl there are no carbon nes in the rinse water. Install the
free tube ends back in push-t ngs in membrane housings and lock with locking clips.
PTFE tape
PTFE tape
tank valve
small rubber gasket
chrome-plated cover
blue tube
large rubber gasket
large plasc gasket
lock washer
nut
counter
1/4 ferrule
1/4 compression nut
plasc insert

40 41
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
11 Install carbon post-lter.
12 Install all membranes in membrane housings.
CAUTION! When installing reverse osmosis mem-
brane, do not take it out of the bag. Cut the bag at
the opposite end to membrane’s brine seal, push the
membrane inside membrane housing. Do not touch
membrane surface at any me.
13 Open feed valve and puried water faucet for 30 minutes to rinse membranes and other
parts of the system. Do not open tank valve at this me. Close the puried water faucet and
check all connecons for leaks.
CAUTION!

main valve to remove water supply to the system.
14 Open tank valve and let the system ll it. The system will switch o when the tank is full.
Open puried water faucet and discard the rst tankful of puried water. When the tank is
drained empty, close the puried water faucet and let the system rell the tank. The water
can be used now.
* Skip steps 6 and 14 if installing a tankless system.
A
A (1 : 1)
A
A (1 : 1)

42
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
Figure 4. Operang parameters of the system.
* Skip if using a tankless system.

6. OPERATION
1. Use calibrated TDS meter to test total dissolved solids in tap and puried water.
Write down the readings in the maintenance log.
2. Verify proper funconing of feed water solenoid. The system must switch o and stop
discharging concentrate when pressure tank is full* and puried water faucet is closed.
3. Inspect the system carefully for leaks.
4. Advise the system’s owner how to operate and maintain the system, refer to this manual.
5. Make a record of system installaon in the maintenance log.
6*. When using a pressure tank, note that the tank is full when high-pressure switch is
acvated, pump switches o and concentrate stops running to drain. The me to ll the tank
depends on water pressure at the tapping point.
RObust should be used for puricaon of cold water only. If puried water ow rate has decreased
or tank is taking longer than normal to ll, the likelihood is that pre-lter is clogged and need to be
replaced as soon as possible.
Delayed replacement of pre-lters can result in damage or failure of the membranes. In order to
avoid this, it is recommended to replace pre-lters at least once in three months of connuous use.
If puried water ow rate drops signicantly and is not caused by pre-lter wear or abnormal op-
erang condions, the array of membranes has to be replaced. For best puried water quality,
replace membranes at least once a year.
If the system is to be out of operaon for two weeks or longer, sanize the system as described in
secon 7. When disconnuing use of the system, it is recommended to shut o the water supply.
   st   If pressure aer pre-lters is less than 1 bar
(14.5 psi), this may indicate low mains pressure or clogged pre-lters. Test pressure at the feed
adapter site. If it exceeds reading on the pressure gauge signicantly, replace pre-lters. Otherwise,
low feed water pressure is at fault and has to be sorted out. If the 1st pressure gauge displays over 5 bar
(72.5 psi) aer the system switches on, power down the system immediately, disconnect water sup-
ply, and install a pressure regulator upstream of the system. Then, connue seng up the system.
Maximum recommended feed water pressure is 3.5 bar (51 psi).
14.5 psi 58 psi
72.5 psi 101.5 psi

42 43
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
nd. If operang pressure in the membrane array
is lower than 4 bar (58 psi) or amounts to feed water pressure, this can be caused by any of the
following:
• motor power supply fault (possibly due to broken/torn pump motor cord);
• air trapped inside pump’s chamber;
• jamming of the pump with solids such as carbon nes (if carbon lter was not properly washed
before use).
Generally, if the value of operang pressure on the 2nd pressure gauge falls below its normal range,
contact your dealer’s service. If pressure on the 2nd pressure gauge is over 7 bar (101.5 psi), this
could be due to pressure regulator failure or the RO system’s high-pressure switch fault. Contact
your dealer’s service for help.


stage Filter type
Service life
RObust 1000 RObust 3000
1st Pre-lters 8 000 L (2100 gal)* but
not less than once in
3 months. Service life
depends on feed water
quality and intensity of
usage
15 000 L (4000 gal)* but
not less than once in
3 months. Service life
depends on feed water
quality and intensity of
usage
2nd Reverse osmosis mem-
branes
24 000 L (6300 gal)* but
not less than once a year
40 000 L (10500 gal)*
but not less than once
a year
3rd Acvated carbon post-
lter
8 000 L (2100 gal)* but
not less than once in 3
months
15 000 L (4000 gal)* but
not less than once in 3
months
*Service life depends on the quality of feed water.

44
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000

6.2. FILTER REPLACEMENT
6.3. MEMBRANE REPLACEMENT
1Open puried water faucet while the system is plugged in, close feed water valve, close
pressure tank valve (if installed).
2Wash your hands with anbacterial soap thoroughly.
3Aer water has stopped running from puried water faucet, unplug the RO system from
the mains and screw o three lter housings. Take care as the bowls will be full of water.
4Remove spent lters.
5Wash the bowls thoroughly with non-aromac soap, and then rinse with water.
6Install new lters in bowls.
7Unplug feed water tubes from the two rst-stage membrane housings and put them in a
container for collecng rinse water. Plug the cord in mains and openfeed water valve 5.
Let enough water through the lters to ush out the carbon nes and dust. When run-
ning water becomes free of carbon parcles, close feed water valve. Plug the tubes back
in the inlets in membrane housings. Secure connecons with locking clips.
8Open feed valve and plug the system in the mains. Let the RO system run for some me
with open puried water faucet to wash o carbon nes from carbon post-lter. Close
puried water faucet when water appears clear and free of parculate impuries.
1Shut o feed water valve, close pressure tank valve (if used).
2Open puried water faucet to relieve pressure in the system. Remove power from the
system.
3Unplug tube from each membrane housing cap. Screw o the housing caps. Extract
used membranes from membrane housings and take note of their orientaon inside the
housings.
4Take new membranes and grease their brine seals and membrane housing cap O-ring-
seals.
CAUTION! Only use food grade glycerol or cered RO membrane compable lubricant
for greasing the seals to avoid damage.
5Install new RO membranes in housings observing proper orientaon of each.
CAUTION! Do not remove plasc bag when installing membrane. Make a cut in the
head end of the bag and push the membrane out of the bag into the housing. Do not
touch membrane surface with your hands.

44 45
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
7. SANITIZATION
8. TROUBLESHOOTING
Sanizaon of the reverse osmosis system is recommended aer it has been in operaon for an
extended period (over 6 months) or when the system is to be shut down for 3 weeks or longer. It is
also advisable to sanize the system when replacing lters.

6Screw on membrane housing caps.
7Plug tubes back in the housings.
8Open feed valve 5. Restore power supply to the system.
9Let the system run for 30 minutes to ush out membrane preservave. Then, close
puried water faucet and open pressure tank valve (if used).
Problem Possible cause Method of handling
Fing leak Tube is not connected ghtly Remove and reinstall the tube
properly.
Filter housing leak O-ring seal is missing or mis-
aligned
Check that the O-ring seal is
correctly seated in circular
groove inside bowl.
Filter bowl is not ghtened Hand ghten the housing ll
snug.
Puried water ow rate is
lower than normal
Low feed water pressure If feed water operang pres-
sure is lower than 2 bar
(29 psi), eliminate any
upstream pressure drop and
consider installing pressure
booster pump.
Clogged pre-lter Replace pre-lter.
Clogged membranes Replace membranes.
Bent exible tube Inspect the tubing and
straighten if necessary.
Puried water runs normally
for a few seconds, then slows
down to a trickle (in a pressure
tank equipped system)
Deated pressure tank bladder Pressure tank must drain
empty when puried water
tap is open and the RO system
is unplugged. If the pressure
in the bladder of empty tank
is less than 0.4 bar (5.8 psi),
inate to required pressure.

46
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
The system keeps switching
on and o and does not stop
Surges in feed water pres-
sure just above low pressure
switch seng
Eliminate pressure surges.
Check supply water piping for
clogs and other obstrucons
and eliminate if present.
The system does not switch
on
Feed valve or main shut o
valve is closed
Open all valves on supply
water pipes. Check for clogs/
obstrucon.
Low pressure switch failure Replace low pressure switch.
Verify proper electrical
contact.
The system does not switch
o (although puried water
faucet is closed, pressure tank
is full or not used)
High pressure switch failure Replace high pressure switch.
Verify proper electrical
contact.
Clogged membranes Replace membranes.
The system has switched o
but connues to send water
to drain
Solenoid valve failure Replace the solenoid valve.
Protect the system from de-
bris and parculates if present
in feed water.
Clogged membranes Replace membranes.
Recovery has decreased
signicantly
Clogged pre-lter Replace pre-lter.
Clogged membranes Replace membranes.
Water is not discharged to
drain when the system is on
Clogged ow restrictor Clean ow restrictor or
replace if necessary.
Puried water is hazy or
cloudy but becomes clear
aer a few minutes
Air bubbles trapped in the
system
Some air may remain in the
system for a few days aer
installaon and will go away
on its own.
Air bubbles may appear in
water if there is a large dier-
ence between feed water and
ambient temperature.
Puried water has a taste or
odor
Expired post-lter Replace post-lter.
Membrane preservave was
not completely ushed aer
the installaon
Flush the RO system and
discard all rinse water.
Contaminaon of the system Sanize the system according
to instrucons in secon 7.

46 47
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2016
INSTALLER AND USER GUIDE FOR REVERSE OSMOSIS SYSTEM ECOSOFT ROBUST 1000, ROBUST 3000
Contaminaon of pressure
tank
Sanize pressure tank.
Pressure tank may become
contaminated if lters or
membranes are used beyond
their service life.
Pressure tank is not full when
the system switches o
Tank bladder is over inated Pressure in empty tank
bladder must be 0.6–1.0 bar
(8.7–14.5 psi). Release some
pressure if necessary.
Tank valve is closed Check tank valve posion.
