Ecotec Amalfi Quick start guide

Amal Wood Pellet Burning Heater
Owner’s & Installation Manual
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET BURNING ROOM
HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR EVEN DEATH.
Contact your local building or re ofcial about restrictions and installation inspection requirements in your area.
economicaluser
friendly
leading
design
healthy
home
visible
ame
clean air
approved

2
Owner’s Section
Table of Contents
1. Introduction ..................................................................................... 4
1.1 Specications.................................................................................................... 4
1.1.1 Rating label Location .................................................................................... 4
1.1.2 Specications ............................................................................................... 4
1.1.3 Floor Protection ............................................................................................ 4
1.2 Measurements................................................................................................... 5
2. Safety Warnings & Recommendations ......................................... 6
2.1 Deciding where to locate your wood pellet burning heater.......................... 6
2.2 Ash ..................................................................................................................... 6
2.3 Clinkering........................................................................................................... 6
2.4 Filling Fuel Hopper............................................................................................ 6
2.5 Flammable Liquids............................................................................................ 7
2.6 Installation ......................................................................................................... 7
2.7 Operating Instructions...................................................................................... 7
2.8 Safety Devices................................................................................................... 8
2.9 Responsibility.................................................................................................... 8
2.10 Spare Parts ........................................................................................................ 8
3. Operating your Pellet Fire.............................................................. 9
3.1 Description of the Controls.............................................................................. 9
3.2 Switching on the Stove..................................................................................... 9
3.3 Operating Precautions...................................................................................... 9
3.4 Priming of the Screw (Auger)......................................................................... 10
3.5 Description of Menus...................................................................................... 10
3.6 Setting the Clock (Clock Set Menu)............................................................... 11
3.7 Chronothermostat Setting Menu ................................................................... 11
3.7.1 Description Of The Strings ......................................................................... 12
3.8 Setting the Language (Language Menu)....................................................... 14
3.9 Settings Menu.................................................................................................. 14
3.10 Description of Functions................................................................................ 14
3.10.1 Change of Operating Power ....................................................................... 14
3.11 Modications of the room temperature setting............................................ 14
3.11.1 Room temperature functioning procedure .................................................. 14

3
3.12 Modication of the boiler water temperature setting .................................. 15
3.13 Stove Status Menu.......................................................................................... 15
3.14 Working Hours Menu...................................................................................... 15
3.15 Description of Screen Displays & Symbols.................................................. 15
3.15.1 Screen Displays ......................................................................................... 15
3.15.2 Symbols ...................................................................................................... 16
3.16 Description of Alarms..................................................................................... 16
3.17 Amal Electrical Circuit Diagram .................................................................. 17
4. Maintenance and Cleaning........................................................... 18
4.1 Cleaning the surfaces..................................................................................... 18
4.2 Cleaning the re pot before and after each lighting.................................... 18
4.3 Description of Inner parts of the Ecoteck Amal......................................... 19
4.4 Routine Cleaning (every two - three days) ................................................... 19
4.5 Cleaning the glass .......................................................................................... 21
4.6 Cleaning the Flue ........................................................................................... 21
4.7 Access to the inspection hatches for cleaning the smoke ........................ 21
4.8 Frequency of Component Cleaning .............................................................. 21
5. Guarantee ...................................................................................... 22
5.1 Certicate of Guarantee ................................................................................. 22
5.2 Conditions of Guarantee ................................................................................ 22
6. What are Wood Pellets? ............................................................... 23
7. The Components of the Stove ..................................................... 23

4
1. Introduction
This manual is designed for both the technician and the home owner.
Please read this entire manual before installing or operating your Ecoteck Amal Freestanding Wood
Pellet Burning Heater. Failure to follow these instructions may result in property damage, bodily
injury or even death. Any unauthorized modication of the appliance or use of replacement parts not
recommended by the manufacturer is prohibited. All national and local regulations shall be complied
with when installing this appliance. Your local Nature’s Flame dealer will be happy to assist you in
obtaining information with regards to your local building codes and installation restrictions.
1.1 Specications
1.1.1 Rating label Location
Ecoteck Amal Freestanding: The rating label is located on the back of unit.
1.1.2 Specications
*Note: Consumption will vary with the type of fuel used.
IMPORTANT: The above values were found during testing and may vary with the fuel type, climate and
installation style.
1.1.3 Floor Protection
This pellet heater requires oor protection which must be non-combustible, extending beneath the
stove the full width and depth of the unit including (150mm) in front for ember protection.
AS/NZS2918 states that a 300mm forward projecting and 200mm side projecting oor protector must
be used from any door opening extremity as an absolute minimum. Due to the operating nature of
the Amal pellet heater where opening the door causes a loss of vacuum and the re will shut down
completely, meaning the likelihood of any hot embers or burning fuel escaping from the combustion
chamber is extremely minimal, a 150mm forward projecting oor protector will be sufcient.
Classication Testing Standard Description
Class I IP-20 Efciency: AS/NZS 4012:1999
Appliance: AS/NZS 4013:1999
Residential Wood Pellet Heater
Voltage 220- 240 Volt Current: 2.92 – 3.18 Amps Frequency: 50Hz
Max Power Requirement
550 watts
Unit with full hopper: 185kg Hopper Capacity: 25kg
Mean Flue Gas Temp –
High: 181.5 degrees
Mean Flue Gas Temp-
Medium: 153 degrees
Mean Flue Gas Temp-
Low: 112 degrees
Fuel Consumption –
High: 2 kg per hour
Fuel Consumption –
Medium: 1.4kg per hour
Fuel Consumption –
Low: 0.8kg per hour
Heat/Power Output –
High: 8.4kw
Heat/Power Output –
Medium: 5.9kw
Heat/Power Output –
Low: 3.4kw
Average Particular Emissions (dry weight)
0.5gms per kg
Average Emissions Rate
29.9mg/MJ
Average Efciency
79.8%
Gross Caloric Value of pellets (dry weight)
20.1MJ/kg
Fuel Type:
Wood pellets – 6mm dia, - complying
with draft standard AS/NZS 4014.6
2008

5
1.2 Measurements
590
34
575
1079 1046
34 554 16
Figure 1.

6
2. Safety Warnings & Recommendations
Pellet quality is important, please read the following:
Your pellet heater has been designed to burn ¼” (6mm) diameter wood pellets, manufactured to the
AS/NZS 4014.6 only.
DO NOT use this appliance as an incinerator.
DO NOT use unsuitable and non recommended fuels, including liquid fuels as this will void any
warranties stated in the manual.
The performance of your pellet heater is greatly affected by the type and quality of wood pellets being
burned. As the heat output of various quality wood pellets differs, so will the performance and heat
output of the pellet stove.
Caution: It is important to select and use only pellets that are dry and free of dirt or any impurities such
as high salt content. Wood pellets manufactured to the AS/NZS 4014.6 standard are recommended.
Dirty fuel will adversely affect the operation and performance of the unit and will void the warranty. The
Pellet Fuel Industries (PFI) has established standards for wood pellet manufacturers. We recommend
the use of pellets that meet or exceed these standards. Ask your dealer for a recommended pellet type.
2.1 Deciding where to locate your wood pellet burning heater
1. Do not install the pellet heater in a bedroom or room where people sleep.
2. Locate the pellet heater in a large and open room that is centrally located in the house.
This will optimize heat circulation.
3. Check clearances to combustibles (refer page 30).
2.2 Ash
The ash content of the fuel and operation of your stove will directly determine the frequency of cleaning.
The use of high ash fuels may result in the stove needing to be cleaned daily. A low ash fuel may allow
longer intervals between cleaning.
2.3 Clinkering
Clinkers are silica (sand) or other impurities in the fuel that will form a hard mass during the burning
process. This hard mass will block the air ow through the Burn Pot Liner and affect the performance
of the stove. Any fuel, even approved types, may clinker. Check the Burn Pot Liner daily to ensure
that the holes are not blocked with clinkers. If they become blocked, remove the liner (when the unit is
cold) and clean/scrape clinkers out. Clean the holes with a small pointed object if required. Refer to
the section Routine Cleaning and Maintenance.
2.4 Filling Fuel Hopper
Check hopper for foreign objects, then empty the bag of pellets into the hopper (see “Figure 18.” on
page 23). DO NOT OVER FILL as miscellaneous pellets could smoke if left to rest on an operating heater.
Store pellets at least one metre (1m) away from the pellet stove.
Warning: parts of the appliance, especially the external surfaces, will be hot to touch when in operation
so use due care.

7
2.5 Flammable Liquids
Never use gasoline, gasoline – type lantern fuel, kerosene, charcoal lighter uid or similar liquids to
start or “freshen up” a re in the heater. Keep all such liquids well away from the heater while it is in use.
2.6 Installation
The stove must be installed and tested by specialised personnel approved by Nature’s Flame. Please
read this manual before installing or operating the stove. If you require further information, please
contact your Nature’s Flame dealer. Installation must be performed by authorized personnel, who must
give the purchaser a declaration of conformity of the appliance, and who will assume all responsibility for
the nal installation and consequent correct functioning of the product installed. It is also necessary to
take into consideration all the laws and national, regional, provincial and local regulations present in the
country in which the appliance has been installed. In the event of failure to respect these precautions,
Nature’s Flame declines all responsibility.
IMPORTANT:
• The place of installation of the heater must comply with local & national regulations. The
stove must be fuelled only with quality pellets manufactured to standard AS/NZS4014.6.
The stove cannot operate with traditional wood.
• The heater must not be used as an incinerator.
• Before connecting the heater electrically, the connection of the exhaust spigot must be
completed (specically for pellet stoves, not made from aluminum) with the ue. (All ue
joins must be sealed with maniseal exhaust cement).
• The protection grill inside the pellet tank must never be removed.
• There must be sufcient circulation of air in the room where the stove is installed. Never
open the door of the stove whilst it is functioning.
• When the heater is operating, the surfaces, the glass, the handle and the pipes become
overheated: during functioning, these parts must only be touched with the adequate
protection.
• Do not light the heater without having rst performed the daily inspection as described in
the MAINTENANCE & CLEANING chapter of this manual (see page 18).
• Scrupulously follow the maintenance program.
• Do not turn the heater off by disconnecting the electricity mains supply (use the control
panel or remote control).
• Do not clean the heater until the structure and the ashes have cooled down completely.
Carry out all operations in maximum safety.
Amal requires a power source to function. This is standard mains feed 240v plug - if this is unavailable
in close proximity a grounded extension lead may be used.
Amal is to be installed on a non-combustible surface which must have a forward projection of a
minimum of 150mm from the glass door.
Please check all clearances to combustibles as listed on page 30 of this Owner’s/Technical manual.
In accordance with the requirements of AS/NZS 2918:2001 Amal must be secured by seismic restraint.
2.7 Operating Instructions
The heater is completely automated and will self-regulate the ignition phase, ve levels of power and

8
the switching off phase, guaranteeing safe functioning. The burn pot used for combustion allows most
of the ashes produced by the combustion of the pellets to fall into the collection drawer. However,
it is recommended that you check the burn pot every day, as not all pellets have high standards of
quality and could leave residue that is difcult to remove. The glass has special air circulation for self-
cleaning, however, a slight greyish lm cannot be avoided after a few hours of functioning. Pellets with
a diameter of 6mm, manufactured to the AS/NZ4014.6 or higher must be used with the stove.
2.8 Safety Devices
The heater is tted with sophisticated safety systems so that, in the case of breakage of one of the
individual parts or defects in the ue, no damage will be caused to the stove and the room in which it
is installed. In any case, when a problem arises, the pellets stop falling immediately and the switch off
phase is activated. The corresponding alarm will be shown on the display. The details can be seen in
the chapter on the alarms (page 16).
2.9 Responsibility
Nature’s Flame declines all responsibility, both civil and criminal, with the delivery of this manual, for
any accidents deriving from partial or total failure to observe the instructions it contains.
Nature’s Flame declines all responsibility deriving from the improper use of the stove, from its incorrect
use by the user, by unauthorised modications and/or repairs or from the use of spare parts which are
not original. The manufacturer declines all direct civil or criminal responsibility due to:
• Poor maintenance.
• Failure to observe the instructions in the manual.
• Use not compliant with the safety instructions.
• Installation that is not compliant with the regulations in force in the country.
• Installation by personnel who are not qualied or authorized.
• Modications and repairs that are not authorized by the manufacturer.
• Use of spare parts that are not original.
• Exceptional events.
2.10 Spare Parts
Use original spare parts only. Do not wait for the components to be worn before replacing them.
Replace a worn component before it is completely broken to prevent any accidents caused by the
sudden breakage of components. Perform the periodic maintenance checks as described in the
dedicated chapter on “Maintenance and Cleaning” on page 18

9
3. Operating your Pellet Fire
3.1 Description of the Controls
3.2 Switching on the Stove
1. Before switching the stove on, proceed as follows:
2. Plug in the power lead.
3. Put the switch at the back of the stove in position 1.
4. Check that the plant is connected to the ue.
5. Make sure that the hydraulic plant has been installed correctly by a technician and that
the boiler has been lled with water and bled correctly as described in chapter 2.9.3 of the
Installation Section at the back of this manual.
6. Fill the tank with 6-mm pellets as described in “Figure 18.” on page 23.
7. Load the screw as described in chapter “3.4 Priming of the Screw (Auger)” on page 10.
8. Press key P3 for 3 seconds.
At this point the thermostove will carry out the ignition phase. The following messages will appear on
the screen:
• ON
• LOAD PELLET
• WAIT FOR FLAME
• FLAME PRESENT
• WORK
During the working phase, you must check the following settings:
• POWER SETTING as described in chapter 3.10.1 on page 14.
• ROOM TEMPERATURE SETTING as described in chapter 3.11.1 on page 14.
• BOILER WATER TEMPERATURE SETTING as described in chapter 3.12 on page 15.
3.3 Operating Precautions
• In case of faulty operation turn the stove off pressing button no. 3.
• Do not manually load the re pot with pellets.
• Any build up of unburned pellets inside the re pot after repeatedly trying to light the
stove, must be removed before further attempts.
• Do not use any fuels other than wood pellets.
• Should the ignition system be faulty, do not attempt to light the stove using ammable
materials.
20°C
10:00 20°C
OFF
P1 : Turns heat level down
P2 : Turns heat level up
P3 : Turns ire on-off
P4 : Turns thermostat down
P5 : Turns thermostat up
P6 : Decrease water temperature
P7 : Increase water temperature
Figure 2.

10
3.4 Priming of the Screw (Auger)
To prime the screw/auger (when the stove is new or has been completely run out of fuel, the loading
screw/auger is empty), proceed as follows:
1. Turn the stove off completely, using the general switch on the back
2. The display will show FINAL CLEANING and then OFF.
3. Turn the the power back on, using the general switch on the back.
4. Keep button P4 pressed for 2 seconds. CLOCK SETTING MENU will appear.
5. Press button P4 until the display shows STOVE STATUS MENU
3.5 Description of Menus
The stove has various functions, available in its individual programming menus. Some of these menus
are accessible by the user, others are protected by a password and accessible only by a Service
Technician.
The menus are as follows:
• CLOCK SET Menu
• TIME SET Menu
• LANGUAGE Menu
• STOVE STATUS Menu
• WORKING HOURS Menu
• SEE CALIBRATIONS Menu
• DATABASE Menu (protected by password)
• TIME CANCELLATION Menu (protected by password)
• FACTORY CALIBRATIONS (protected by password)
IMPORTANT AFTER LOADING THE SCREW/AUGER, EMPTY THE FIRE POT INTO THE
HOPPER BEFORE SWITCHING ON.
2000
150°
SCREW 0
STATE
THE SCREW IS IDLE
PRESS BUTTON P5 TO ACTIVATE THE SCREW
(AUGER)
Figure 3.
2000
150°
SCREW 1
STATE
SCREW ACTIVATED
Repeat the operation several times until you can see
the pellets fall into the re pot.
This operation is possible only if the stove is in nal
cleaning or shut down
Figure 4.

11
3.6 Setting the Clock (Clock Set Menu)
Proceed as follows to set the current time:
1. Switch the power supply to the thermostove on and off using the main switch at the back
of the stove.
2. The display will display FINAL CLEANING and then OFF.
3. Keep key P4 pressed for 2 seconds. The message CLOCK SET MENU will appear.
Conrm with key P6 to gain access.
4. The message UT01 CLOCK DAY will appear on the screen and a day of the week ( from
DAY1 to DAY7 ): using keys P4 and P5 set the current day and press key P6 to conrm.
If OFF is set, the chronothermostat will be disconnected.
5. The message UT02 CLOCK TIME will appear on the screen together with the current time:
using keys P4 and P5 adjust the time and conrm with key P6
6. The message UT03 CLOCK MINUTES will appear on the screen: using keys P4 and P5
adjust the minutes and conrm with key P6.
7. To return to the initial menu press key P3.
3.7 Chronothermostat Setting Menu
With the chronothermostat function, switching on and off the stove for each day of the week can be
programmed in two independent time intervals (PROGRAMME 1 and PROGRAMME 2). To enter this
menu, proceed as follows:
1. Keep button P4 pressed for 2 seconds, CLOCK SETTING MENU will appear,
2. Press button P4 once; the display will show CHRONOTHERMOSTAT SETTING MENU
3. Access with button P6: the display will show the screen desired.
Display Meaning
Day 1 Monday
Day 2 Tuesday
Day 3 Wednesday
Day 4 Thursday
Day 5 Friday
Day 6 Saturday
Day 7 Sunday
UT05
10:00
PROGRAM 1
START
If this black segment is not lit on the
display corresponding with the clock
symbol, no programming will be
possible.
To activate it refer to the chapter
dedicated to setting the current day,
since the value must not be OFF. Figure 5.

12
The strings that appear on the display go from UT05 to PR40. A setting from a program corresponds
to each string.
3.7.1 Description Of The Strings
UT05: This parameter shows the switch ON time of Programme 1.
UT06: This parameter shows the switch OFF time of Programme 1 (this must be at least 60 minutes
after UT05)
UT07: With this parameter we set which day you want Program 1 and 2 to be active.To set this
parameter, proceed as follows: set with button P5 the days desired (Monday is 1, Tuesday is
2, etc) and with button P4 select ON or OFF; if you select OFF the programming set will not
be activated on the days desired; if you select ON the programming will be valid. At the and
of this setting, press P6 to go to next programme.
PR36 Parameter shows the operting power when PROGRAM 1 is being executed
UT09 This parameter shows the time PROGRAM 2 comes on.
UT10 This parameter shows the time PROGRAM 2 goes off (it must be at least 60 minutes after
UT05)
UT011 This parameter we decide on which days we want PROGRAM 2 to be on.
PR40 This parameter shows the operating power when PROGRAM 2 is being executed.
Strings Description Values that can be set
UT05 START PROGRAM 1 From 00:00 to 23:50 at steps of 10’
UT06 STOP PROGRAM 1 From 00:00 to 23.50 at steps of 10’
UT07 DAYS ON 1 Between on/off for days 1 to 7
PR36 POWER PROGRAM 1 From 1 to 5
UT09 START PROGRAM 2 From 00:00 to 23:50 at steps of 10’
UT10 STOP PROGRAM 2 From 00:00 to 23:50 at steps of 10’
UT11 DAYS ON 2 Between on/off for days 1 to 7
PR40 POWER PROGRAM 2 From 1 to 5
UT07
ON 1
IGNITED 1
DAYS
ON - OFF YADDERIUQER
INDICATION
Figure 6.

13
Example
Let us suppose we want to turn the stove on at 06:00 and switch it off at 08:30 ( PROGRAM 1 ) and
that we want to switch it on again at 16:00 and switch it off at 22:00 (PROGRAM 2). Programming will
be as follows:
At this point you must decide on which days you want the programming carried out above to be active.
Let us pretend that PROGRAM 1 is active on Mondays and Wednesdays, while it is off on all the other
days. Programming will be as follows:
At this point we select the power of PROGRAM 1.
Carry out the same operations, changing the times and days the stove is on for PROGRAM 2 also.
Day 1
Monday
Day 2
Tuesday
Day 3
Wednesday
Day 4
Thursday
Day 5
Friday
Day 6
Saturday
Day 7
Sunday
PROGRAM 1 UT07 ON1 OFF2 ON3 OFF4 OFF5 OFF6 OFF7
UT05
06:00
PROGRAM 1
START
Display this screen as described in chapter 3.7.
Set the time you want PROGRAM 1 to come on
with keys P4 and P5. Press key P6 to conrm
and go on to string UT07. ( if you make a mistake,
press key P7 to go back one step)
Figure 7.
UT06
08:30
PROGRAM 1
STOP
Set the time you want the PROGRAM 1 to go off
with keys P4 and P5. Press key P6 to conrm
and go on to string UT07.
Figure 8.
UT07
ON - 1
IGNITED 1
GIORNI
Set the days you want PROGRAM 1 to be on or
off using key P5. At this point set the on/off value
that switches PROGRAM 1 on or off using key P4.
Repeat this operation for every day of the week.
Figure 9.
PR36
P - 3
PROGRAM 1
POWER
Set the required power for PROGRAM 1 using
keys P4 and P5.
Figure 10.

14
3.8 Setting the Language (Language Menu)
To set the language, proceed as follows:
4. Remove and reset the electricity supply of the stove using the general switch on the back.
5. The display will show FINAL CLEANING and then OFF.
6. Keep button P4 pressed for 2 seconds, CLOCK SETTING MENU will appear.
7. Press button P4 twice; the display will show LANGUAGE MENU.
8. Access with button P6: the display will show the language selected.
9. With buttons P4 and P5, select the language desired.
10. Conrm with button P6 to return automatically to MENU’ 03 SELECT LANGUAGE MENU.
3.9 Settings Menu
In this menu you can check the values of the parameters set in the control unit. This menu is used when
a Service Technician has to understand the parameters set in the machine, to nd any modications to
improve the functioning of the stove.
To enter this menu, proceed as follows:
1. Keep button P4 pressed for 2 seconds: CLOCK SETTING MENU will appear.
2. Press button P4 3 times; the display will show SEE SETTINGS MENU.
3. Access with button P6: the display will show the screen desired.
4. Scroll using the button P6 to display the parameters set.
5. Scroll till last parameter to return automatically to MENU’ 04 SEE SETTINGS MENU’.
3.10 Description of Functions
3.10.1 Change of Operating Power
To change the operating power, press key P1 to enter the appropriate menu and with keys P1 and P2
adjust the required power from 1 to 5. Ecoteck recommends that you leave the stove power at power 5
so that the boiler water temperature setting is reached as soon as possible; in this way the thermostove
may operate in modulation, decreasing pellet consumption. The power setting cannot be changed
during the MODULATE WORK phase.
3.11 Modications of the room temperature setting
3.11.1 Room temperature functioning procedure
The stove functioning procedures when the room thermostat is on can be divided into 3 types:
• using the supplied room sensor
• with external thermostat
PROCEDURE WITH SUPPLIED ROOM SENSOR
If the room sensor supplied is used, the room temperature will be shown on
the display.
To set the desired temperature (modication of the room temperature setting),
press button P4 to enter the appropriate menu and with buttons P4 and
P5 adjust the desired value. When temperature is reached on the display,
MODULATION WORK will appear on the screen and the stove will reduce the
consumption of pellets to a minimum, reducing heating power.
External Thermostat
Figure 11.

15
EXTERNAL THERMOSTAT PROCEDURE
If an external thermostat is used, correctly connected to the mother board as shown in the electrical
circuit diagram, the message T ON will be shown on the display instead of room temperature. Room
temperature will be adjusted directly by the thermostat mounted on the wall. When the temperature
shown on the display is reached, the message WORK MODULATION will appear on the screen. In this
case the thermostove will stop sending hot water to our plant.
3.12 Modication of the boiler water temperature setting
To change the boiler water temperature setting, press key P6 to enter the appropriate menu and with
keys P6 and P7 adjust the required value.
3.13 Stove Status Menu
In this menu, you can check the correct functioning of the most important components of the pellet
stove.
To enter this menu, proceed as follows:
1. Keep button P4 pressed for 2 seconds, CLOCK SETTING MENU will appear.
2. Press button P4 4 times: the display will show STOVE STATUS MENU.
3. Access using button P6: the display will show the desired screen.
4. Conrm with button P6 to return automatically to MENU’ 05 STOVE STATUS. This menu
is for use by a service technician to diagnose performance issues and for the customer
when loading pellets into the pellet hopper when the stove has been completely run out
of fuel.
3.14 Working Hours Menu
The WORKING HOURS Menu shows the total hours of work done by the stove. In some cases, the
working hours may not be zeroed. i.e. numbers similar to 5000/15000/25000 may be shown. The
technician will zero set these numbers when lighting the stove for the rst time. A non-zero number
does not mean that the stove has worked for all those hours. It is only a setting given by the programme
during rst inspection at Ecoteck, before the stoves are packaged and sent.
To enter this menu, proceed as follows:
1. Keep button P4 pressed for 2 seconds: CLOCK SETTING MENU will appear.
2. Press button P4 5 times: the display will show WORKING HOURS MENU.
3. Access with button P6: the display will show the screen desired.
4. Conrm with button P6 to return automatically to MENU’ 06 WORKING HOURS MENU’.
3.15 Description of Screen Displays & Symbols
3.15.1 Screen Displays
68°C
10:35 20°C
WORK
FLOW STAT ON FIRE POT CLEANING ON
BOILER WATER
TEMPERATURE ROOM TEMPERATURE
STOVE STATUS
Figure 12.

16
3.15.2 Symbols
3.16 Description of Alarms
WARNING REASON SOLUTION
SMOKE PROBE ALARM
• Fault in the sensor recording ue
temperature
• CONTACT YOUR LOCAL SERVICE TECHNICIAN.
• Sensor is faulty or disconnected
HOT SMOKE ALARM • Smoke sensor detects a
temperature over 280ºC
• Press the off button and repeat switching on the stove.
• IF THE PROBLEM CONTINUES, CONTACT YOUR LOCAL
SERVICE TECHNICIAN.
NO IGNITION ALARM
• The pellet hopper is empty
• Check whether there are pellets in the hopper and rell if
necessary. IF THE PROBLEM CONTINUES, CONTACT
YOUR LOCAL SERVICE TECHNICIAN.
• Firebox is dirty
• Switch re off, empty rebox and try to light it again. IF
THE PROBLEM CONTINUES, CONTACT YOUR LOCAL
SERVICE TECHNICIAN.
PELLETS HAVE RUN OUT
ALARM • The pellet hopper is empty • Fill the tank with pellets and carry out the automatic auger loading procedure.
RESET THERMAL ALARM
• Thermostat sensor records
a temperature above the trip
threshold.
• Reset the thermostat and switch the re back on. IF
THE PROBLEM CONTINUES, CONTACT YOUR LOCAL
SERVICE TECHNICIAN.
DEPRESSION ALARM
• The combustion chamber is dirty • Follow the cleaning operations of the stove as per the
instructions manual
• The ue is blocked • Check that the ue is clear and clean
• The vacuum switch is
malfunctioning • Contact local Service Technician
THERMAL ALARM WITH
RESET
• The thermostat with manual reset
has intervened
• Reset the thermostat pressing the button on the back of the
stove (see Figure below this table)
• The centrifugal fan is defective • Contact local Service Technician
• Combustion in the re pot is not
optimal
• Switch off the stove, clean the re pot and regulate
combustion with the setting of the pellets
WATER PRESSURE
ALARM
• Water pressure is too high or too
low.
• Rell the water or bleed it to return the pressure to normal
values. IF THE PROBLEM CONTINUES, CONTACT YOUR
LOCAL SERVICE TECHNICIAN.
BLACK OUT ALARM
• There is a power black out while
the re is being used. When the
power comes back on the display
will indicate “BLACK OUT”.
• The smoke fan will automatically switch to maximum speed
and the auger will switch off. When the ue temperature
goes below the ignition threshold, the re will start the
ignition process.
VENTILATION • The re is in cooling phase. • Wait until ue temperature goes below the minimum
operating threshold before attempting to re-ignite.
EVERY ALARM CONDITION CAUSES THE FIRE TO SWITCH ITSELF OFF IMMEDIATELY
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
Chronothermostat On Winter Setting On (Always)
Resistance On Three-Way Valve Positioned
On Radiators
CWater Temperature Lower Than
Set Temperature PWater Pressure Anomaly
PPump On

17
3.17 Amal Electrical Circuit Diagram
F NFUMI
SCAMB.
COC.ACC.AL2AL1N
-TC1+TERM.N.AMB.N.H2O
N.PEL.
ENC +5V GND BLU
Red
Blue
Azzurro
Blu/Nero
Yellow / Green
Blue
Encoder
Red
Black
White
Brown
Flat cable
Red
Trasducer
water circulator
Cod. 55130
Cod. 38000-51-001
Room probe
Water Probe
Smoke Probe
Brown
Azzurro
White
condenser
MICROCHIP
Ratio-motor load pellet 3RPM
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black Black
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue Blue
Blue
Blue
Brown
Brown
Brown
Brown
Brown
Brown
Brown
Yellow / Green
Yellow / Green
Yellow / Green
Brown
Yellow / Green
Brown
Smoke engine
Electric filter
Figure 13.

18
4. Maintenance and Cleaning
Before carrying out any maintenance take the following precautions:
• Make sure that the re has been turned off, and that the general power supply has been disconnected
(Ensure that the plug is disconnected from the socket, thus avoiding accidental electric shocks).
• Make sure that all parts of the pellet heater are cold.
• Make sure that the ashes have cooled completely.
• Make sure that the general switch is in the zero position (off).
• Always use appropriate tools for maintenance.
• When you have nished re-install all safety guards before using the pellet heater again.
The pellet heater requires little maintenance if quality wood pellets are used which is why we recommend
pellet fuel that is manufactured to the AS/NZS4014.6.
4.1 Cleaning the surfaces
To clean the surfaces on the painted metal parts, use a damp cloth.
Important: the use of aggressive detergents or abrasive cleaners can damage the surfaces of the stove.
4.2 Cleaning the re pot before and after each lighting
You must check that the re pot, where the combustion takes place, is clean and that no waste or
residue blocks the holes, in order to always guarantee excellent combustion of the stove. This will help
avoid possible overheating, which could causes changes in the colour of the paint, as well as failure to
light the stove.
Only a clean re pot can guarantee that the pellet stove will function without problems. During functioning,
deposits may be formed, which have to be immediately eliminated. It is easy to see when the re pot
has to be cleaned! It only needs a glimpse, each day, before switching on. For minor cleaning, it can be
left in the stove, but if the residue is difcult to remove, it has to be extracted from its housing and the
waste scraped out.
The residue of ash depends on the quality of pellets used.
Important: even with a new batch of pellets, although using the same brand, there may be differences
during combustion and therefore they may burn more or less cleanly.
Correct daily cleaning will allow the pellet heater to burn properly with high performance avoiding
problems in the long term which could require the intervention of a technician to repair the pellet heater.
Clean basket with all the
holes clearly visible
Basket needing cleaning with
the holes blocked by ashes
Figure 14.

19
4.3 Description of Inner parts of the Ecoteck Amal
4.4 Routine Cleaning (every two - three days)
Fire pot cover grill
Fire pot
Drawer cover guard
Fire pot holder
Ash drawer Ash drawer compartment
Remove the re pot cover grill so that the
drum is clearly visible
Remove the re pot to check how clean it is
and to be able to reach the re pot holder.
Press the drawer cover guard down to reach
the ash draw. Pull the lever up to remove the
drawer.
Vacuum the ash deposited in the drawer
with a vacuum cleaner.
Figure 15. Figure 16.
1 2
34

20
Vacuum the ash deposited in the compartment
under the drawer with a vacuum cleaner.
Unscrew the side ceramic brick to reach the
smoke duct cleaning plates. Unscrew and
vacuum the deposited ash.
Before carrying out the operation described above, clean the tube bundle with the cleaning rods, as
shown in the following gure. Carry out this movement 3-4 times until the rods run without friction.
Lower the cleaning rodsLift up the cleaning rods
The thermostove is a solid fuel heat generator and as such must be checked by a qualied technician
at least once a year at the beginning of the season. The purpose of this maintenance is to make sure
that all the components are in good working order. You are advised to agree an annual contract for the
product with your installer/dealer.
Figure 17.
56
