ECOTEST STORA-ABG RKS-01 User manual

RKS-01 “STORA-ABG”
RADIOMETER-DOSIMETER
Operating Manual

1
ЗМІСТ
1 DESCRIPTION AND OPERATION..................................................................................4
1.1 PURPOSE OF USE OF THE RADIOMETER ..........................................................................4
1.2 TECHNICAL SPECIFICATIONS.........................................................................................5
1.3 DELIVERY KIT............................................................................................................19
1.4 DESIGN AND PRINCIPLE OF OPERATION .......................................................................24
1.5 LABELING AND SEALING.............................................................................................31
1.6 PACKING....................................................................................................................32
2 PROPER USE ...................................................................................................................33
2.1 OPERATING LIMITATIONS ...........................................................................................33
2.2 PREPARATION OF THE RADIOMETER FOR OPERATION...................................................33
2.3 USE OF THE RADIOMETER ...........................................................................................40
3 TECHNICAL MAINTЕNANCE ....................................................................................109
3.1 TECHNICAL MAINTENANCE OF THE RADIOMETER ......................................................109
3.2 VERIFICATION OF THE RADIOMETER .........................................................................113

2
4 CERTIFICATE OF ACCEPTANCE .................................................................................... 123
5 PACKING CERTIFICATE................................................................................................... 124
6 WARRANTY........................................................................................................................ 125
7 REPAIR ................................................................................................................................ 126
8 STORAGE............................................................................................................................ 128
9 SHIPPING............................................................................................................................. 129
10 DISPOSAL.......................................................................................................................... 130
ДОДАТОК А .......................................................................................................................... 131
APPENDIX B.......................................................................................................................... 133
APPENDIX C.......................................................................................................................... 134
APPENDIX D.......................................................................................................................... 135
APPENDIX E .......................................................................................................................... 136
APPENDIX F........................................................................................................................... 142
APPENDIX G.......................................................................................................................... 144

3
This operating manual (OM) is intended to inform the user about the
principle of operation of RKS-01 “STORA-ABG”radiometer-dosimeter, the
procedure for working with it and contains all the data necessary for full application
of its technical capabilities and its proper use.
The OM includes the following abbreviations and symbols:
DER - ambient dose equivalent rate.

4
1 DESCRIPTION AND OPERATION
1.1 Purpose of use of the radiometer
RKS-01 “STORA-ABG”radiometer-dosimeter (hereinafter –the radiometer) is
intended for:
- measurement of ambient DER of gamma and X-ray radiation (hereinafter –
photon-ionizing radiation)
- measurement of surface beta-particles flux density
- measurement of surface activity of beta-emitting radionuclides
- measurement of surface alpha-particles flux density
- measurement of surface activity of alpha-emitting radionuclides
- display of pulse count rate from alpha, beta, gamma detector.
The radiometer is used for environmental research; as visual aids for educational
establishements; for radiometric and dosimetric control at industrial enterprises; to
monitor radiation purity of residential premises, buildings and structures, territories
adjacent to them, vehicles, household items, clothes, surface of soil on garden plots.

5
1.2 Technical specifications
1.2.1 Key specifications and data are presented in Table 1.1.
Table 1.1 –Key specifications and data
Name
Unit of
measurement
Standardized values
according to specifications
1
2
3
Measurement range of photon-ionizing radiation
DER
μSv/h
0,1 –100 000
Display range of photon-ionizing radiation DER
μSv/h
0,01 –100 000
Main relative permissible error limit when
measuring photon-ionizing radiation DER at
137Cs calibration with a confidence probability of
0.95
%
15+2/М,
where M is a
dimensionless value that
is numerically equal to
the DER value measured
in μSv/h

6
Table 1.1 (continued)
1
2
3
Energy range of photon-ionizing radiation being registered
МеV
0,012 –3,00
Energy dependence of radiometer readings when measuring
photon-ionizing radiation DER relativeto 0.662 MeV (137Cs):
- in the energy range from0.012 to 0.040 MeV, not more:
-- in the energy range from 0.040 to 1.25 MeV,not more:
%
35
25
Anisotropy of the radiometer at gamma quantum incidence
at solid angle of ±60 relative to the main (perpendicular to
the back cover of the device marked with a "+" symbol)
direction of measurement, must be:
- for 137Cs and 60Co isotopes;
- for 241Am isotopes
Note. Anisotropy diagrams are given in Appendix A.
%
25
60

7
Table 1.1 (continued)
1
2
3
Measurementrange of surfacebeta-particles flux
density
part./(cm2 min)
5 –999 999
Display range of surface beta-particles flux
density
part./(cm2 min)
1 - 999 999
Measurement range of surface activity of beta-
emitting radionuclides
Bq/cm2
0,22 –9999
for
С0 1) source type
(90Sr/90Y)
Display range of surface activity of beta-
emitting radionuclides
Bq/cm2
0,01 - 9999

8
Table 1.1 (continued)
1
2
3
Main relative permissible error limit when
measuring surface beta-particles flux density in the
range from 5 part./(cm2 min) to
999 999 part./(cm2 min) at 90Sr/90Y calibration with
a confidence probability of 0.95
%
20+150/F,
where F is a dimensionless
value that is numerically
equal to the value of
surface beta-particles flux
density measured in
part./(cm2 min)
Main relative permissible error limit when
measuring surface activity of beta-emitting
radionuclides in the range from 0.22 Bq/cm2to
9999 Bq/cm2at 90Sr/90Y calibration with a
confidence probability of 0.95 from С0 source
type
%
20+10/А,
where А is a dimensionless
value that is numerically
equal to the value of
surface activity of beta-
emitting radionuclides
measured in Bq/cm2

9
Table 1.1 (continued)
1
2
3
Energy range of beta-particles being
registered
MeV
0,15 - 3,00
Measurement range of surface alpha-
particles flux density
part./(cm2 min)
5 –999 999
Display range of surface alpha-particles
flux density
part./(cm2 min)
1 –999 999
Measurement range of surface activity of
alpha-emitting radionuclides
Bq/cm2
0,2 –9999
for П9 2) source type (239Pu)
Display range of surface activity of
alpha-emitting radionuclides
Bq/cm2
0,01 - 9999
Display range of pulse count rate
from alpha, beta, gamma radiation
counter
cps
0,001 –9999

10
Table 1.1 (continued)
1
2
3
Main relative permissible error limit when
measuring surface alpha-particles flux
density in the range from 5 part./(cm2 min) to
999 999 part./(cm2min) at 239Pu calibration
with a confidence probability of 0.95
%
20+150/F,
where F is a dimensionless value that
is numerically equal to the value of
surface alpha-particles flux density
measured in part./(cm2 min)
Main relative permissible error limit when
measuring surface activity of alpha-emitting
radionuclides in the range from 0.2 Bq/cm2
to 9999 Bq/cm2at 239Pu calibration with a
confidence probability of 0.95 from a
standard П9 source type
%
20+10/А,
where A is a dimensionless value that
is numerically equal to the value of
surface activity of alpha-emitting
radionuclides measured in Bq/cm2
Detector type
-
Alpha-, beta-, gamma-sensitive
Geiger-Muller counter with a mica
window

11
Table 1.1 (continued)
1
2
3
Window area
см2
13,8
Typical sensitivity to photon-ionizing radiation with an energy of
0.662 MeV (137Cs)
4,5
Time of operating mode setting of the radiometer, not more
min
1
Time of continuous operation of the radiometer when powered
from a new battery of two 1200 mAh galvanic cells under normal
conditions and given gamma background not more than 0.5 μSv/h,
disabled sounding of registered gamma quanta and disabled
backlight of the scale, no less
hour
2000

12
Table 1.1 (continued)
1
2
3
Unstable readings of the radiometer for 6 hours of
continuous operation, not more than
%
5
Operating supply voltage of the radiometer power supply
from two AAA galvanic cells
V
3,0
Additional relative permissible error limit when measuring
photon-ionizing radiation DER, surface beta-particles flux
density and surface alpha-particles flux density in the range
of supply voltage from 2.4 V to 3.2 V
%
±5
Additional relative permissible error limit when measuring
photon-ionizing radiation DER, surface beta-particles flux
density and surface alpha-particles flux density caused by
changes in the environmental temperature from -20 оСto
+50 оС
%
±0,5
per each 1 оС of
deviation from
20 оС

13
Table 1.1 (end)
1
2
3
Average life of the radiometer till the first major
repair, no less
hour
10000
Average service life of the radiometer, no less
year
6
Mean time to failure, no less
hour
6000
Overall dimensions of the radiometer, no less
mm
1607537
Weight of the radiometer, not more
kg
0,4
Weight of the radiometer in package, not more
kg
4.2 (case –3.2)
1) –efficiency of С0 type sources is 0.377
2) –efficiency of П9 type sources is 0.490
1.2.2 The radiometer provides for automatic subtraction of gamma-component
of radiation when measuring beta radiation parameters.

14
1.2.3 The radiometer provides for automatic subtraction of gamma- and beta-
components of radiation while measuring alpha radiation parameters.
1.2.4 The radiometer provides for analogue indicator of instantaneous radiation
intensity being measured. Time of information update is 500 ms.
1.2.5 The radiometer allows programming the values of alarm threshold levels
for each radiation parameter being measured.
1.2.5.1 The values of threshold levels of photon-ionizing radiation DER are
programmed in the range from 0 mSv/h to 99.9 mSv/h with a resolution of
0.01 μSv/h.
1.2.5.2 The values of threshold levels of surface beta-particles flux density are
programmed in the range from 0 part./(cm2·min) to 999.9·103part./(cm2·min) with
a resolution of 0.01·103part./(cm2·min).
1.2.5.3 The values of threshold levels of surface activity of beta-emitting
radionuclides are programmed in the range from 0 Bq/cm2to 9999.99 Bq/cm2with
a resolution of 0.01 Bq/cm2.

15
1.2.5.4 The values of threshold levels of surface alpha-particles flux density are
programmed in the range from 0 part./(cm2·min) to 999.9·103part./(cm2·min) with
a resolution of 0.01·103part./(cm2·min).
1.2.5.5 The values of threshold levels of surface activity of alpha-emitting
radionuclides are programmed in the range from 0 Bq/cm2to 9999.99 Bq/cm2with
a resolution of 0.01 Bq/cm2.
1.2.5.6 The values of threshold levels of pulse count rate from alpha, beta,
gamma counter are programmed in the range from 0 cps to 9999 cps with a
resolution of 0.01 cps.
1.2.5.7 The programmed values of threshold values are stored in the non-
volatile memory of the radiometer and remain unchanged when the radiometer is
turned on/off and its batteries are replaced.
1.2.6 The radiometer alarms about exceeding of the programmed threshold
levels with a two-tone sound signal and a red flashing ALARM LED. In this case,
the measurement result blinks on the liquid crystal display (hereinafter referred to
as LCD).

16
1.2.7 The radiometer generates a short one-tone sound signal if gamma
quantum, alpha- or beta-particle gets to the detector.
1.2.8 The radiometer stores up to 1000 measurement results in its nonvolatile
memory. For ease of identification, information about the date and time of
measurement and a conditional three-digit number of the object of measurement,
which is entered during recording, is added to each record.
1.2.9 The radiometer allows viewing measurement results that were previously
recorded in the nonvolatile memory on its own LCD, as well as communicating this
information to a personal computer via Bluetooth.
1.2.10 The radiometer has a clock mode where the current time in hours and
minutes, as well as the current date, month, and year are displayed on the
radiometer’s LCD.
1.2.11 There is the alarm clock mode in the radiometer.

17
1.2.12 The radiometer provides for an option to work in the mode of intelligent
detecting unit (hereinafter referred to as the IDU). In this mode, the radiometer
sends the following to the PC via Bluetooth:
- current measurement results;
- current value of supply voltage,
and receives the commands from the PC to change measurement modes and
synchronize time relative to the PC clock.
1.2.13. The radiometer provides indication of low battery status.
1.2.14 The radiometer performs measurements under the following conditions:
- temperature from - 20 to +50оС;
- relative humidity up to (95±3)% at +35 оС temperature;
- atmospheric pressure from 84 to 106.7 kPa.

18
1.2.15 The radiometer remains operational after the impact of the following
external factors:
- high frequency sinusoidal vibrations (with a crossover frequency from 57 to
62 Hz) in the range of 10 to 55 Hz, 0.15 mm bias for frequency lower than the
crossover frequency;
- shocks with a shock pulse duration of 5 ms, total number of shocks (1000±10)
and maximum shock acceleration of 100 m/s2;
- shocks in shipping container with an acceleration of 98 m/s2, a shock pulse
duration of 16 ms (number of shocks - (1000±10) in each direction) or equivalent
shake tests;
- exposure in shipping container to ambient air temperature from - 25 to + 55 оС
and relative humidity up to (95±3) % at + 35 оС temperature;
- photon-ionizing radiation with exposure dose rate that corresponds to ambient
dose equivalent rate up to 10 Sv/h during 5 minutes.
