ECOTEST STORA-TU RKS-01 User manual

RKS-01 “STORA-TU”
GAMMA, BETA RADIOMETER-DOSIMETER
Operating manual

1
CONTENTS
1 DESCRIPTION AND OPERATION..............................................................4
1.1 PURPOSE OF USE.......................................................................................4
1.2 TECHNICAL SPECIFICATIONS ....................................................................5
1.3 DELIVERY KIT .......................................................................................15
1.4 DESIGN AND PRINCIPLE OF OPERATION..................................................17
1.5 LABELING AND SEALING ........................................................................22
1.6 PACKING ................................................................................................23
2 PROPER USE................................................................................................23
2.1 OPERATING LIMITATIONS.......................................................................23
2.2 PREPARATION OF THE RADIOMETER FOR OPERATION .............................24
2.3 USE OF THE RADIOMETER......................................................................28
3 TECHNICAL MAINTЕNANCE ..................................................................97
3.1 TECHNICAL MAINTENANCE OF THE RADIOMETER...................................97
3.2 VERIFICATION OF THE RADIOMETER.....................................................100

2
4 CERTIFICATE OF ACCEPTANCE .......................................................... 111
5 PACKING CERTIFICATE ........................................................................ 112
6 WARRANTY ............................................................................................. 113
7 REPAIR ...................................................................................................... 114
8 STORAGE.................................................................................................. 116
9 SHIPPING .................................................................................................. 117
10 DISPOSAL ............................................................................................... 118
APPENDIX А................................................................................................ 119
APPENDIX B................................................................................................ 121
APPENDIX C................................................................................................ 122
APPENDIX D................................................................................................ 123
APPENDIX E ................................................................................................ 124
APPENDIX F ................................................................................................ 128
APPENDIX G................................................................................................ 130

3
This operating manual (hereinafter referred to as the OM) is intended to
inform the user about the principles of operation and rules of application of the
RKS 01 “STORA-TU” gamma, beta radiometer-dosimeter. The manual contains all
information necessary for proper use of the radiometer and full realization of its
technical possibilities
The manual contains the following abbreviations and symbols:
DER - ambient dose equivalent rate.

4
1 DESCRIPTION AND OPERATION
1.1 Purpose of use
The RKS-01 “STORA-TU” gamma, beta radiometer-dosimeter (hereinafter
referred to as the radiometer) is designed to measure ambient dose equivalent rate
(DER) of gamma and X-ray radiation (hereinafter called photon-ionizing radiation),
and surface beta-particles flux density.
The radiometer is used in ecology research; as visual aids for educational
establishments, for dosimetry and radiometry control at industrial enterprises;
apartment, building, and construction control, ground surface of infields and vehicles
control, personal radiation safety.

5
1.2 Technical specifications
1.2.1 Key specifications are presented in Table 1.1.
Table 1.1 –Key specifications
Name
Unit of
measurement
Standardized values
according to technical
specifications
1 Measurement range of photon-ionizing
radiation DER
μSv/h
0.1 –999.9
2 Main relative permissible error limit of
photon-ionizing radiation DER
measurement with confidence probability
of 0.95
%
)10(H 2
15  
,
where
)(H 10


is a
numeric value of the
measured DER in
μSv/h

6
Table 1.1 (continued)
Name
Unit of
measurement
Standardized
values
according to
technical
specifications
3 Energy range of registered photon-ionizing
radiation
MeV
0.05 –3.00
4 Energy dependence of the radiometer readings
at photon-ionizing radiation DER measurement in
the energy range of 0.05 to 3.00 MeV
%
from - 25
to +40
5 Anisotropy of the radiometer at gamma
quantum incidence at solid angle of 30oto 150o
relative to the main axis of the detector and from
the side of the main measurement direction for:
- 137Cs and 60Co isotopes;
- 241Am isotopes
%
25
60

7
Table 1.1 (continued)
Name
Unit of
measurement
Standardized values
according to technical
specifications
6 Measurement range of surface
beta-particles flux density
part./(cm2 min)
5 - 105
7 Main relative permissible error
limit of beta-particles flux density
measurement with confidence
probability of 0.95
%


200 20
,
where
β
φ
is a numeric
value of the measured
surface beta-particles
flux density in
part./(cm2·min)

8
Table 1.1 (continued)
Name
Unit of
measure-
ment
Standardized
values according
to technical
specifications
8 Energy range of registered beta-particles
MeV
0.5 –3.0
9 Time of the radiometer operating mode setting,
not more than
s
10
10 Battery life (two AAA batteries of 1200 mA·h
capacity) under + 20 оС temperature, natural
background radiation and switched off audio
signaling of registered gamma quanta and no
display backlight, not more than
h
1500
11 Unstable readings of the radiometer for 6 hours
of continuous operation, not more than
%
5

9
Table 1.1 (continued)
Name
Unit of
measureme
nt
Standardized
values according to
technical
specifications
12 Operating supply voltage of the radiometer
from two AAA batteries
V
3.0
13 Additional permissible error limit at
measurement of photon-ionizing radiation DER
and surface beta-particles flux density in the
supply voltage range of 3.2 to 2.4 V
%
±5
14 Additional permissible error limit at
measurement of photon-ionizing radiation DER
and surface beta-particles flux density in the
ambient air temperature range of –20 to + 50оС
%,
per each
1 оС
deviation
from
20 оС
±0.5

10
Table 1.1 (continued)
Name
Unit of
measure
ment
Standardized
values according to
technical
specifications
15 Average operating life of the radiometer till the
first major repair, not less than
h
10000
16 Average service life of the radiometer, not less than
year
6
17 Mean time to failure, not less than
h
6000
18 Dimensions, not more than
mm
1607536
19 Weight of the radiometer, not more than
kg
0.5
20 Weight in package, not more than
kg
0.8
(with tube –1.1)
1.2.2 The radiometer displays the statistical error value of measurement result
of photon-ionizing radiation DER and surface beta-particles flux density.

11
1.2.3 The radiometer measures photon-ionizing radiation DER and surface
beta-particles flux density until the specified statistical error is gained.
1.2.3.1 The specified statistical error can be programmed by the user or
automatically determined by the radiometer depending on the radiation intensity.
1.2.4 For fast of photon-ionizing radiation DER and surface beta-particles flux
density the radiometer provides a twelve-segment indicator of instantaneous value.
The information is updated on the indicator of instantaneous value each 500 ms.
1.2.5 Threshold alarm system with two independent threshold levels is realized
in the radiometer:
- photon-ionizing radiation DER;
- surface beta-particles flux density.
1.2.5.1 Threshold level values of photon-ionizing radiation DER are
programmed in the range of 0 to 999,9 µSv/h with discreteness of 0.01 µSv/h.
1.2.5.2 Threshold level values of surface beta-particles flux density are
programmed in the range of 0 to 9999·103part./(cm2·min) with discreteness of
0.01103part./(cm2·min).

12
1.2.5.3 The programmed values of the threshold levels are saved in the
nonvolatile memory of the radiometer, and are not changed when the radiometer is
turned on/off or the batteries are replaced.
1.2.6 The radiometer provides light and audio alarm about the programmed
threshold levels exceeding: a two-tone audio signal and a blinking red LED
“ALARM”.
1.2.6.1 The radiometer also provides visual alarm of the exceeded threshold
levels in the form of a measurement result that blinks on the LCD, and periodic and
gradual highlighting (from left to right) of the sound symbol segments (4) according
to Figure 3.
1.2.7 The radiometer sends a short one-tone audio signal if gamma quantum or
beta-particle gets to the detector.
1.2.8 The radiometer stores up to 1200 measurement results of photon-ionizing
radiation DER or surface beta-particles flux density in its nonvolatile memory. For
more convenient identification every measurement result is stored along with a
three-digit number of measurement object, as well as with time and date of
measurement. Time and date of measurement is received from the radiometer’s
clock, while the object number is entered by the user during saving.

13
1.2.9 The radiometer sends the measurement results, which have been saved in the
nonvolatile memory, to the personal computer (hereinafter called the PC) through
Bluetooth radio channel. There is also a possibility to view this information on the liquid
crystal display of the radiometer (hereinafter called the LCD).
1.2.10 The radiometer has the mode of clock when the current time in hours
and minutes, as well as the current date, month and year are displayed on the LCD.
1.2.11 The radiometer has the mode of alarm clock.
1.2.12 The radiometer provides the possibility to work in the mode of
intelligent detecting unit (hereinafter called the IDU). In this mode the radiometer
sends to the PC via the Bluetooth radio channel:
- current measurement results of photon-ionizing radiation DER or surface beta-
particles flux density;
- current value of supply voltage,
and receives from the PC the commands to change the measurement modes and to
synchronize the time based on the PC clock.
1.2.13 The radiometer provides indication of low battery status.

14
1.2.14 The radiometer performs measurements under the following conditions:
- temperature from –20 to + 50 oC;
- relative humidity up to (95±3) % at + 35 oC temperature;
- atmospheric pressure from 84 to 106.7 kPa.
1.2.15 The radiometer is resistant to the following external factors:
- high frequency sinusoidal vibrations (with crossover frequency from 57 to 62 Hz)
in the range of 10 to 55 Hz, 0.15 mm bias for frequency lower than the crossover
frequency;
- shocks with a shock pulse duration of 5 ms, a total number of shocks 1000±10
and maximum acceleration of 100 m/s2;
- shocks in shipping container with an acceleration of 98 m/s2, with a shock
pulse duration of 16 ms (number of shocks - 1000±10 in each direction), or
equivalent shake tests;
- exposure in shipping container to ambient air temperature from - 25 to
+ 55 oC and relative humidity up to (95±3) % at + 35 oC;
- photon-ionizing radiation with exposure dose rate that corresponds to ambient
DER up to 0.1 Sv/h during 5 minutes.

15
1.3 Delivery kit
1.3.1 The delivery kit of the radiometer consists of the items and the
maintenance documentation presented in Table 1.2.
Table 1.2 - Delivery kit of the radiometer
Type
Item
Quantity
Note
ВІСТ.412129.015-02.02
RKS-01 “STORA-TU”
gamma, beta radiometer-
dosimeter
Bluetooth
radio
channel
included
ВІСТ.412129.015-02.02 НЕ
Operating manual
1 copy
ВІСТ.412915.002-02
Package
1 pc.
ENERGIZER
Battery of ААА
1,5 V type
2 pcs.
Analogs
permitted

16
Table 1.2 (continued)
Type
Item
Quantity
Note
ВІСТ.323382.002-
02
Packing bag
1 pc.
ВІСТ.304592.004
Telescopic tube
1 pc.
Supplied in a
separate order
ВІСТ.301524.005
Holder
1 pc.
ВІСТ.758156.004
Screw
2 pcs.
Custom-made software
“Computer-aided
programming and operation
logging of the dosimeter ”
(“Cadmium-
ECOMONITOR”)
1
Supplied with the
devices equipped
with Bluetooth
channel

17
1.4 Design and principle of operation
1.4.1 Design of the radiometer
The radiometer (according to Figure 1) is designed as a rectangular
parallelepiped rounded on each side. The plastic damp and dustproof body of the
radiometer (ingress protection rating IP54) consists of two parts –upper (1) and
lower (2) covers. The LCD (3), “ALARM” light-emitting diode (4) and two key of
control MODE (5) and THRESHOLD (6) are located on the panel of the upper cover.
The printed-circuit board with the electric circuit of the device is screwed with four
screws to the upper cover of the radiometer. All inscriptions of the upper cover are
serigraphy applied.

18
Figure 1 - External view of the radiometer (top view)
