ECOVACS Deebot D54 User manual

D54 User Guide
Robot Vacuum Cleaner

Thanks for purchasing
products Hope you can enjoy it
Thanks again for your choice!
patented
. !
Robot
Vacuum Cleaner

Enjo y S m a r t e r Life!
Content
1. Safety Instruction....
User Guide...... . . . ........ . . . ....... . . . . ..... 8. Cycle c .. .... . ..... . . . .
Power Supply for the Product.. . .. ....... . .
The Spectrum of Product Use.. . . ....... . . . Cancel Cycle Cleaning
Notes before Cleaning.......................
Child Safety. . . ....... . . . ...... ... . . . ....... . . .
10. Maintenance ...... . . . ....... . . . ........ .
Battery Replacement and Disposal
Resource Utilization
Dust Box Cleaning
When Product is in Failure. . ....... . . . ....
Sponge Filter and Dust Box Cleaing....
2. Content in the Original Package
and Technical Parameter. . . . .......
Main Brush Cleaning.......................
3. Name of Par ts
Side Brush Cleaning
Host .................................... . ...
4. Battery Charging. ....... . . . .. ...
Placement of Charging Block.. . . . . .......
11. Alar m function. . . . ... .... .. . . . .
Robot charging.... . . . ..... .
12. Common Failure.... . . . ....... . . . ......
5. Power On/Pause/Power Off. . . . . ..
Other Problems. ........ . . . ....... . . . ..
Get pawer supply and power On... . . . ..
Pause. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Off.....................................
Mode Selection....... . . . . ....... . . . ..
Auto Mode ..... . . ..
Mode. . . .. .. ..
................... 7 o Back ..... . . . . ........ . . .
313
.. 3 leaning .... . . . .... . 14
.3Set Cycle Cleaning..... . . . ........ . . . ....... 14
4..... . . . ........ . . . .. 14
5
9. Day-to-Day Storage . . . . ....... . . . ....... 14
.5
.15
....... 6
Host Cleaning................................. 15
......................... 6
..... . . . ........ . . . ....... 15
6
.16
Sponge Filter Replacement...............
.17
7
.17
..... . . . ........ . . . ....... . . . .
..... . . . ........ . . . ..... 18
.. . .. . 8
Replace Side Brush. . . . ........ . . . ....... . . . . 18
Control Panel...... . . . ........ . . . ........ . . . .... 9
Up-Ground Height Sensor Cleaning. . . . 18
..... . . . . 9Dust Sensor Cleaning........ . . . ....... . . . . 19
10
..... .. . 19
..... . . . ........ . . 10
20
. . 10
13. 21
.. 10
. . . 11
.11
6.. . 12
..... . ..... . . . ........ . . . . . . 12
Intensive cleaning ..... . . . . . 12
. G Charging
8
.
...

3
Do not open the equipment. The components inside the robot host are beyond repair by
user himself.
This product is only for domestic use, not suitable for industry or outdoor surroundings.
Note：
1.Safety Instruction
The User Guide
Please conform to the basic safety precautions as follows:
● Read the content in this user guide carefully and install the robot according to the detailed instructions.
● Safekeeping this guide. If you transfer this machine to another person, please make sure attach this booklet.
● Any inconsistent operation with this guide would probably cause serious damage to both human being and the
machine itself.
Power Supply for the Product
● The power supply is from a Ni-MH chargeable battery inside the host of the
robot and it is specially assigned with a charging block to do recyclable
charge.
● Please double check the marked supply voltage on the charging block and
make sure it is applied according to the instructions.
● Do not use the damaged power cord or plug, while contact our after-sales
service or find our authorized supplier to maintain.
● As the charging block is heavy, please never drag the block via pulling it’s
power cord.
● Remember never to twist and swing or screw the power cord excessively,
neither to block it when close the door.
We should not put heavy things on it as well.
● Do not let power cord touch hot or sharp surfaces.
● Do not draw out the plug by pulling the cord.
● Keep wet hands away from the plug or machine.
● Pull the plug out of socket when you no longer use the charging block for
some time.
● Use dry cloth to wipe the dust on the plug frequently.
Cloth
cleaning
Where there is a drop off in the cleaning area due to a step or stairs and they
are not carpeted, you should operate the unit to see that the unit can detect
the step without falling over the edge. It may become necessary to place a
physical barrier at the edge to keep the unit from falling over the drop but
make sure the physical barrier is high enough so that you or a family member
will not trip on the barrier and cause themselves injury.
War ning
Correct
Electricity
leakage
Draw out
the plug
NO
Guardrail
NO
Guardrail
Set up
Guardrail

The Spectr um of the Product Use
● This robot is applicable to domestic sweeping, including wooden floor,
rubber floor, ceramic tile, linoleum and medium or short-haired carpet
however, it is inapplicable to long-haired carpet.
● It can not be used for the floor as below:
-- -- Have water on the surface (including flammable liquids), such
as wet floor.
-- -- Inside toilet, shower room or other humid situation.
-- -- Staircase
-- -- The room with furnace or flame
● The following objects are definitely forbidden:
-- -- Not extinguished soot, burning cigarette butts or match, because
these objects would cause fire.
-- -- Sharp objects like glass debris, pin, paper clip,stones, gypsum,
and large piece of paper. These things may block the machine.
-- -- Water or other kind of liquid, especially detergent, kerosene,
petrol, paint, alcohol, perfume, as well as carpet or floor cleaning solution.
It would make the interior of the machine wet, so that may cause short-
circuit.
-- -- The toner of laser printer and copier which may bring fire and
explosion.
● Please keep the machine away from hot source such as oven and
fireplace, because the hot can distort the crust.
● Do not use the machine in the surroundings with any explosion risk.
For example, at gas station, oil depot, chemical plant and so on.
● Never use the machine outdoors. As rain or solid dust may get inside it and
cause damage.
● Do not repair or change any performance by yourself.
● Do not throw or bend the machine.
● Do not dampen it, or else the short-circuit would cause fire or electric
shock accident.
● Take care of routine maintenance and keep it in a clean place.
● Do not expose the machine in the extreme hot or cold surroundings. This
product is not allowed to long-time kept in the temperature below zero or
over thirty degree.
● Do not keep the machine in the liquid or expose it to high humidity.
● Do not place the machine close to burning cigarette or fire.
4
Enjo y S m a r t e r Life!

5
Notes before Cleaning
● Take extra care of the robot when the first it works. Please remove the
obstacles when it is beyond the robot. Try to avoid the situation that the
robot stops working.
● Make precautions to solve the problem which may make the cleaning in
trouble, such as:
Keep the easily knock over objects in a safe place.
-- -- Permian the edge of the carpet.
-- -- The hanging table cloth and curtain should not touch the ground.
-- -- The flammable object should be cut from the fire source.
-- -- Sort out the tangled power cord on the floor.
● Check whether the main brush is correctly fixed inside the robot before
cleaning.
● Examine if the dust box is empty and insure it is fixed before it works.
● See if up-ground height sensor and dust sensor are wiped clean.
If you only need to clean one room, please close the door.
-- --
-- -- Pick up the newspaper, book, magazine and large piece of paper
scattered on the floor.
●
● Child, physically or mentally disabled and inexperienced are not allowed
to use it, unless their safety supervisor is there to give instruction.
Child Safety

6
● Take good care of the product and keep it beyond child and people who can
not judge danger nearby. Extra attention should be paid when it stats
working.
● You should get the person inside the room know that the machine is
working, in order to avoid man-made damage like tripping.
● Do not take robot as toy. Carefully attention should be paid when child or pet
is around.
● The plastic package may bring danger of asphyxia and is supposed to
keep away from child.
● You need to contact our after-sales when you want to change the battery. It
will cause explosion if you use replacement battery of wrong model.
● There is potential danger if you use other producer's battery and
charging block. The damage cause hence is not within the warranty.
● Please dispose the spent battery properly, because there is hazardous
substance which may pollute the environment.
● Conform with local environmental legislation and dispose it at the recovery
site.
● Do not take the package material as domestic garbage and discard it
freely.
● Please deliver the package material to proper recovery site for recycle.
● Do not repair or disassemble the machine when there is damage of the
power cord or failure of the host.
● Contact our after-sales service or our designate maintenance organization
for professional repair.
Battery Replacement
and Disposal
Resource Utilization
When Product
is in Failure
Enjo y S m a r t e r Life!

D5 4 Us er G u id e
Ro bot Va c uu m C le a ner
Host Charging block
Roll brush clean-up
gadget
User guide
7
DC14.4V 220-240V~
DC17.5V
50Hz
30W
0.7A
30W
0.25meter/second
0.7L
≤62dB
About 4~5 hours
45 minutes
90-120 2 M
335×335×100mm
2.8Kg
The host The charging block
Working voltage In-put voltage
rated out-put voltage
rated frequency
rated power
rated out-put
currency
Rated power
Speed
Capacity of dust box
Noise
Charging duration
Duration upon full
battery 60 minutes
Max Coverage upon
full battery
Size
Net weight
technique parameter
2.Content

8
3.Name of parts
control button
wind gate
rotating side brush
up-ground height sensor
All-round
wheel
suspended
driving wheel
rubber scraper
on/off switch
dust sensor
dust sensor
dust box
dust box handle
ash exit
sponge filter
lock of dust box
charging and
alarm indicator
open button of upper cover
docking electrode
wind gate
power cord
power indicator
infrared transmitter
anti-skid band
main brush
welted
induction
infrared
receiver
buffer plate
bottom view of
robot
elevation of robot
charging block
dust box
host
charging dock
electrode
Enjo y S m a r t e r Life!

9
1.5m
0. 5m
0. 5m
1
23
45
678910
Control Panel
AUTO
Put the block at an even place and make the base perpendicular to the ground.
Meanwhile, take a look at the marked electricity voltage to make sure the
product is used under instruction.
Placement of charging block
4.Robot Charging
Tangle the power cord and do not scatter it besides the block in case that
robot would get impeded when it turns back.
There should not be any object at least 1.5 meter in front of the charging
block. Besides, anything with strong reflector is not supposed to stay ahead of
the infrared receiver. For example, ground glass, smooth ceramic vase and
so on. Otherwise, the machine shall not detect the charging block.
1. Power
2. AUTO mode button
3. intensive mode buttom
4. Cycle mode button
5. Back charging button
6. Battery level
7. Alarming indicator
8. Auto mode indicator
9. Cycle mode indicator
10. Intensive mode indicator
Please do not put the charging block to the staircase to avoid accidental
cases.
Tips:

To make sure the robot is working in saturation, we suggest you
to keep charging connected even though the charging indicator
lasts lighting. At the same time, the system would transfer to
weak current for supplementary charging.
According to actual ground situation, robot can keep working for
around minutes after being charged full.
The capacity of battery, which is not used for long time, will get
certain decrease, so the use time can be shorten accordingly.
45
Tips:
charging
status
charging
status
Indicator
flashing
Indicator
last
lighting
10
AU TO
Robot Charging
● You need to charge the robot the first time it works. Put away the full-
charged battery for use to ensure it's performance.
● Charging duration should be around 4-6 hours.
● Charging is only allowed under the temperature between 0 and 45 degree
and extreme hot or cold would extend charging duration or even
cause damage to the battery.
● Get power supply and press the button on host. There would be a
short music tip and at the same time the battery indicator lights.
5.Power On/Pause/Power
Get power supply and power on
● Turn on the power switch on the bottom firstly.
Enjo y S m a r t e r Life!

● Press button, power is off and robot stops running.
If you want the robot to stop running, you can press button
under pause status.
Put the robot back to the charging block after it stops working for fear
that others would be tripped.
Put the robot on the charging block and keep it charging after finishing
house cleaning.
Do not keep the robot on pause status for long time, because the full
20
.
charged battery could only last for around hours We suggest
.
you to turn it off when you do not want it to work
Tips:
Tips:
● Press any button except the power button, it can pause the operation of
robot and keep it stay where it is.
On the status of pause, you can reset the cleaning mode, then press
or button to restart the robot.
Aanother way to pause the robot is that you can press any button or lift
the robot.
Tips:
Pause
Power off
AU TO
11
AU TO
● Then choose the cleaning mode according to your needs. Press or
button, the robot starts to work.
AUTO

Under the Auto Mode, the AUTO indicator lights.
Route description: First the robot going straight ahead, it turns when it
meets obstacle. The robot will go back charging before run off the battery.
●
●
If take this mode, the cleaning coverage would reach maximum compared
by the same ground situation.
We recommend this mode when the ground is not too dirty and needs the
quick cleaning.
If robot detects that there is plenty of dust during the clean process. It
will take the fan-shaped or spiral route.
Under normal circumstance, it will take spiral route when it detects
plenty of large particles, and will take fan-shaped route when
few of small particles.
The clean can last 45 minutes under this mode, when it detects low
battery, the robot will go back charging automatically and the AUTO
indicator disappeared.
12
0. 5 m
6.Mode Selection
Auto Mode
Intensive Cleaning Mode
Route description:
automatic cleaning. It would search for charging block by itself before it
runs of battery.
under this mode, robot takes the same route as
Under the same ground circumstance, the cleaning effect is the
best.
If the ground is quite dirty, we recommend this mode.
Enjo y S m a r t e r Life!

7.Go Back Charging
13
?
?
？
●When robot detects the low battery, it will go back charging
automatically. Now, the battery indicator is yellow. You also can
press button to stop the working and go back charging, and
the color of the battery indicator will not change.
Route description: Robot will search for charging block automatically when it
detects low battery, after the charger connected successfully, the
indicator light flashing.
●To make it easy for robot to search for charging block, you need to put the
block back to the wall and make sure there is no obstacle within 1.5
meters ahead of the infrared receiver. Check carefully whether there
is strong reflector in front of the charger, such as ground glass,
smooth ceramic vase and so on.
●It takes time for robot to seek the charger. Robot can reserve enough
battery to go back the charging block.
●If put the robot in a strait room, please make sure that there is enough
space for robot to go back charging.
●Robot can return to the charger if the ground situation is not too
complicated. Under extreme circumstance, such as, huge house,
complex layout would bring difficulty for robot to seek for charger. So,
you should help to put the robot back to the charging block.
●Please take care of the first automatic charging, if you find the robot
keeps turning in the certain area after trying several times to seek
back, you can help to place it on the charging block and look
through the charging.
When the robot goes back charging, the main brush will stop working.
And robot shall stay at the charger when it finishes charging and it
transfer to small currency to charge until you start operating.
●
strait room
strait room

8.Cycle Cleaning8.Cycle Cleaning
14
AU T O
AU T O
AU T O
Set Cycle Cleaning
Cancel the Cycle Cleaning
If you need the robot to work in the fixed time every day, please set the
procedure as belowing instruction:
Turn on the power button, then press the button, robot will
work according to the AUTO mode till it show the low battery and go
back to charging.
● The time you press the button, then robot will start to work at that
time next.
●If you set the Cycle Cleaning, indicator will light on.
●After you set the cycle cleaning, please do not choose another mode,
and also not press button, otherwise, the cycle function will be
canceled. If want to pause the robot, press any button (except power
button). However, when you need to restart the robot, please still
press button. Press any button will cancel the cycle function.
●After set the cycle function, if you need the robot return to charging,
please pause it at first, and move it to the charging block manually. Do
not press the button, which will cancel the cycle function.
●If you turn off the robot, although you have set the Cycle Cleaning, the
robot will not work when the setting time coming.
●Please make sure the charging block have connected with the electrical
source, otherwise, robot will not work due to the run out of the
battery, even it is in the standby status.
If you need to cancel the cycle function:
Method One: Turn off the power and restart the robot the cycle function
will be canceled.
Method Two:During the working status, press any button except
power button) to pause the robot, and then press or or
button, the c ycle fu nction w ill b e c anceled.
;
(
AUTO
Enjo y S m a r t e r Life!

9.Day-to-day Storage
10.Maintenance
15
1
1
●
●
You should keep robot stay at charger even though it finishes charging,
because it will change to small currency to supplement charging.
Charge the robot until full battery and put it back to the package if
you do not need to use it for long time. Keep the package in dry
surroundings to avoid sunshine or humidity.
● Turn off the power before cleaning the host.
● Draw out the plug of charger before cleaning the block.
● Do not use petrol or oil-like to clean the surface, while you can use water
or neutral detergent to scrub. Make sure you use dry cloth to wipe,
because any water is not allowed to infiltrate into the machine.
Host Cleaning
Dust Box Cleaning
1. Turn off the power.
2. Press “open” button.
3. Take off the upper cover.
open button
of upper cover

16
Tips：
If the dust box is not placed back or not properly placed. The indicator lights.
1
3
1
41
5
1
6
1
2
1
7
Hold the handle of
dust box and lift it to
take out.
In order to avoid dust
leaking, lift the suction up
when you take out dust
box. Please mind your
speed doing this step.
Match the bottom
with trash can and
swing dust box
gently. You can mildly
beating it along the
edge of the can to get
the dust out.
If there is too much dust
on sponge filter, you can
open the lock and take
off the cover.
Pour out the dust
on sponge filter.
Close the cover and
hear "kaca" sound
which shows that it is
placed. Put the dust
box back into the host.
Sponge filter and dust box cleaning
Open the lock at the
bottom of dust box.
Pour out the dust on
sponge filter.
If there is too much dust
along dust box, you can put
the box under running
water to get rid of the dust
(make it dry under
sunshine for 24 hours).
Put it back into the host
after the box and sponge
filter is completely dry.
Enjo y S m a r t e r Life!

17
1
1
3
4
44
5
1
2
81
9
1
26
7
2
Main brush cleaning Tips: Clean the main brush after it has operated for 4 or 5 recycles.
Undo the screw fixed on the
main brush.
Remove the hair and dust
which is in-between the belt.
Put the main brush back to the
host and take care of the
anastomosis of belt.
Fix the frame into host. Tie up the screw.
Rip off the hair on main brush
with equipped roll brush
cleaning gadget to break off
the hair on main brush along
the groove.
Take off the frame of main brush. Take out one side of main
brush from the belt.
Wipe the dust on the roller
and put it back.
Sponge Filter Replacement
1. Open the cover of the Deebot,
take out the dust box.
2. Push aside the lock catch of the
dust box ,then open the dust box
and clean it.
3. Extract the axle of the dust box’s
cover.
4. Replace the sponge filter and fix
the cover ,then put it back into
Deebot.

18
Note：
Note:
Side brush cleaning
Replace side brush
Driving wheel cleaning
Up-ground height sensor cleaning
Please replace the side brush when it is destroyed.
Please remove the screws,
and take out the side brush.
Please push the new side brush
into the correct position.
Tight the screws.
Side brush is a kind of easy wear part. We suggest you to check it every time it
takes cleaning task. Please change it if necessary.
The host will alarm when the side brush tangled and the lights.
Up-ground height sensor is on the front bottom of robot. It can detect the
height difference above 8 centimeters. We suggest you to wipe the optical
board with dry cotton cloth after it finishes task to prevent the dust piling
on it, which would affect its performance.
1. Turn off the power and remove the trash.
2. Invert the robot, and then put it on the even and clean platform.
3. Use dry cotton cloth to wipe three optical board of up-ground.
Please use the roll brush cleaning gadget to remove the dust or hair on driving
wheel.
If the wheel is tangled by hair or cloth, the host will alarm and indicator
will light.
Up-ground height sensor
Enjo y S m a r t e r Life!

19
11.Alarm function
Dust sensor cleaning
The dust sensor is located at the front of dust
entrance. It is able to detect the concentration of
dust so that it can choose efficient mode to work.
We suggest you to clean dust sensor once you
clean dust box to improve work efficiency.
1. Turn off power.
2. Take out dust box and clean it.
3. Wipe the dust sensor with dry cotton cloth.
Note:
The robot will stop working and be alarm and tip sound at the
same time. Please do as belowing to solve the problem.
Icon Cause of failure Solution Instruction
1. Dust box is not
fixed into host.
2. Dust box is not
fixed properly.
1. Put dust box back
into host.
2. Re-install dust
box and press it
down at the same
time.
1. Clean main brush.
2. Clean side brush
and put it back.
1. Main brush or
driving wheel is
tangled by hair or
cloth.
2. Side brush is
blocked.
Driving wheel is
suspended.
Low battery.
Put the robot at the
even ground.
Put the robot back
manually.
This function can prevent danger of child or
pet lifting the robot when it is operating.
Yellow indicator means that the robot starts
to look for the charging block.
Red indicator means that the lower battery
level, and please put the robot to the
charging block manually.
