Windsor Chariot iVacuum CV28 Specifications

Read these instructions before using the machine.
86037810-CT
08/20/12
Operating instructions (ENG)
MODELS: CV28
10125260
CVX28
10125190
CVXCD28
10125510
CVE28
10125160
CVXE28
10125180
iVacuum™

2
OVERVIEW
The Chariot® iVacuum™ is a battery powered, stand-on, wide area vacuum intended for commercial use. The
Chariot® iVacuum™ brushes and vacuums debris from carpeted surfaces and stores in vacuum bags
86037810 Chariot iVacuum
Machine Data/Overview
Warranty Registration
Thank you for purchasing a Windsor product. Warranty registration is quick and easy.
Your registration will allow us to serve you better over the lifetime of the product.
To register you product go to :
www.windsorind.com/WarrantyRegistration.aspx
For customer assistance:
1-800-444-7654

3
Table of Contents
Machine Data/Overview . . . . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . .4
Safety
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . .5
Hazard Intensity Level . . . . . . . . . . . . . . . . . . . . . . .6
Safety Label Location . . . . . . . . . . . . . . . . . . . . . . . .7
Operations
Techincal Specifications . . . . . . . . . . . . . . . . . . . . . .8
How This machine Works. . . . . . . . . . . . . . . . . . . .10
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Drive Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Operations
Deck Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Pre-run Machine Inspection . . . . . . . . . . . . . . . . . .17
Emergency Stop Procedures . . . . . . . . . . . . . . . . .17
Normal Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . .18
To Begin Vacuuming. . . . . . . . . . . . . . . . . . . . . . . .18
To Stop Vacuuming . . . . . . . . . . . . . . . . . . . . . . . .19
Changing Vacuum Bag. . . . . . . . . . . . . . . . . . . . . .19
Maintenance
Service Schedule . . . . . . . . . . . . . . . . . . . . . . . . . .20
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Battery Maintenance. . . . . . . . . . . . . . . . . . . . . . . .22
Checking Battery Specific Gravity. . . . . . . . . . . . . .23
Charging Batteries . . . . . . . . . . . . . . . . . . . . . . . . .23
Changing Batteries . . . . . . . . . . . . . . . . . . . . . . . . .24
Brush Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Brush Installation . . . . . . . . . . . . . . . . . . . . . . . . . .26
Brush Deck Adjustment . . . . . . . . . . . . . . . . . . . . .27
Adjustment Deck Levelness Testing. . . . . . . . . . . .27
Leveling the Brush Head. . . . . . . . . . . . . . . . . . . . .27
To Replace Brush Motor. . . . . . . . . . . . . . . . . . . . .28
Brush Motor Carbon Brush Replacement. . . . . . . .28
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Vacuum Motor Carbon Brush Replacement. . . . . .30
To Remove Vacuum Motor. . . . . . . . . . . . . . . . . . .30
Drive Motor & Brake . . . . . . . . . . . . . . . . . . . . . . . .31
Electric Parking Brake Engagement . . . . . . . . . . . .32
Drive Motor Carbon Brush Replacement . . . . . . . .33
Brake Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Pushing Machine . . . . . . . . . . . . . . . . . . . . . . . . . .34
Machine Tie-downs. . . . . . . . . . . . . . . . . . . . . . . . .34
Preparation for Loading/Unloading Trailer . . . . . . .34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Propel Circuit Board Troubleshooting. . . . . . . . . . .36
Parts
Brush Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Brush Deck Linkage . . . . . . . . . . . . . . . . . . . . . . . 42
Brush Deck Motor & Nozzle . . . . . . . . . . . . . . . . . 44
Brush Deck Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Bumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Control Panel Housing . . . . . . . . . . . . . . . . . . . . . 52
Decal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Frame-lower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Frame-Upper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Pedal Platform-From Serial Number (17*) . . . . . . 62
Pedal Platform-To Serial Number (17*) . . . . . . . . 64
Pedal Platform Mounting. . . . . . . . . . . . . . . . . . . . 66
Rear Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Side Broom-Deluxe. . . . . . . . . . . . . . . . . . . . . . . . 70
Steering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Vaccum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Wheel-Front Drive-Chain . . . . . . . . . . . . . . . . . . . 76
Wheel-Front Drive-Gear . . . . . . . . . . . . . . . . . . . . 78
Wheel-Front Drive Brake . . . . . . . . . . . . . . . . . . . 80
Wheel-Rear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Wiring-Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Wiring-Components . . . . . . . . . . . . . . . . . . . . . . . 86
Wiring-Control Panel. . . . . . . . . . . . . . . . . . . . . . . 88
Wiring-Drive Motor . . . . . . . . . . . . . . . . . . . . . . . . 90
Wiring-Main Harness . . . . . . . . . . . . . . . . . . . . . . 92
Wiring-Pedal Platform-From Serial number *(17) . 94
Wiring-Pedal Platform-To Serial number *(17) . . . 96
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Suggested Spare Parts. . . . . . . . . . . . . . . . . . . . . 99
Back-Up Alarm-Option . . . . . . . . . . . . . . . . . . . . 100
Battery Cart-Option. . . . . . . . . . . . . . . . . . . . . . . 102
Seat-Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Warning Light-Option . . . . . . . . . . . . . . . . . . . . . 108
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . 110
86037810 Chariot iVacuum

4
How to Use This Manual
This manual contains the following sections:
• HOW TO USE THIS MANUAL
• SAFETY
•OPERATIONS
• MAINTENANCE
• PARTS LIST
The HOW TO USE THIS MANUAL section will tell you
how to find important information for ordering correct
repair parts.
Parts may be ordered from authorized Windsor
dealers. When placing an order for parts, the machine
model and machine serial number are important. Refer
to the MACHINE DATA box which is filled out during the
installation of your machine. The MACHINE DATA box
is located on the inside of the front cover of this manual.
The model and serial number of your machine are
located below the battery compartment of the machine.
The SAFETY section contains important information
regarding hazard or unsafe practices of the machine.
Levels of hazards are identified that could
result in product or personal injury, or severe injury
resulting in death.
The OPERATIONS section is to familiarize the operator
with the operation and function of the machine.
The MAINTENANCE section contains preventive main-
tenance to keep the machine and its components in
good working condition. They are listed in this general
order:
• Service Schedule
• Batteries
•BrushDeck
• Circuit Protection
• Vacuum Motor
• Drive Motor & Brake
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts lists
include a number of columns of information:
REF - column refers to the reference number on the
parts illustration.
PART NO. - column lists the part number for the part.
PRV NO. - reference number.
QTY - column lists the quantity of the part used in that
area of the machine.
DESCRIPTION - column is a brief description of the
part.
SERIAL NO. FROM - If this column has an (*) and a
Reference number, see the SERIAL NUMBERS page
in the back of your manual. If column has two asterisk
(**), call manufacturer for serial number. The serial
number indicates the first machine the part number is
applicable to. The main illustration shows the most
current design of the machine. When a boxed illustra-
tion is shown, it displays the older design.
NOTES - column for information not noted by the other
columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement parts
numbers needed for ordering future parts
Model:
Date of Purchase:
Serial Number:
Dealer:
Address:
Phone Number:
Sales Representative:
86037810 Chariot iVacuum

5
Safety
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer's recommended components and attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into water, return it to
an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.
This machine is not suitable for picking up hazardous dust.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this machine near
flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices
for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
Disconnect battery before cleaning or servicing.
Before the machine is discarded, the batteries must be removed and properly disposed of.
Make sure all warning and caution labels are legible and properly attached to the machine.
During operation, attention shall be paid to other persons, especially children.
Before use all covers and doors shall be put in the positions specified in the instructions.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
This appliance has been designed for use with the brushes specified by the manufacturer. The fitting of other
brushes may affect its safety.
Do not use on surfaces having a gradient of over 10% (6 degrees).
SAVE THESE INSTRUCTIONS
86037810 Chariot iVacuum

6
Safety
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY.
The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper operating
condition. Following is information that signals some potentially dangerous conditions to the operator or the equip-
ment. Read this information carefully. Know when these conditions can exist. Locate all safety devices on the
machine. Please take the necessary steps to train the machine operating personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use
Windsor approved replacement parts.
Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep battery
compartment open during charging. Keep sparks and flames away from the batteries. Do not smoke
around batteries.
Disconnect batteries before working on machine. Only qualified personnel should work inside machine.
Always wear eye protection and protective clothing when working on or near batteries. Avoid skin contact
with the acid contained in the batteries.
Never allow metal to lie across battery tops.
86037810 Chariot iVacuum

7
Safety
Safety Label Location
These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible,
promptly replace them.
CAUTION LABEL
86244310
BATTERY
CAUTION
86252520
86243830 (2)
PRV NO. 500956
PRV NO. 80885
PRV NO. 500663
86037810 Chariot iVacuum

8
Operations
Techincal Specifications
ITEM DIMENSION/CAPACITY
Nominal Power (Basic) 1548 W
Nominal Power (Deluxe) 1692 W
Rated Voltage 36 Volts DC
Rated Amperage (Basic) 43 amps
Rated Amperage (Deluxe) 47 amps
Batteries 3 X12 Volt 195-215 AH @ 20 hr. rate
Battery Compartment Dimensions 21 in. x 16 in. x 17 in. tall (533mm x 406mm x 432mm)
Propelling Motor .75 HP (560 W)
Brush Motor .75 HP (560 W)
Bag Capacity 2150 in³ (35 L)
Brushes Two 28 in. (71 cm) by 4 in. (10 cm) diameter
Brush Speed 1725 RPM
Vacuum Motor(s) .75 HP (560 W)
Maximum flow rate of vacuum motor 200 cfm (95liters per second)
Maximum suction of vacuum motor1 3.8 inches of water ( 3.43 kPa)
Mass (GVW) (Basic) 1055 lbs (478 kg)
Mass (GWB) (Deluxe) 1065 lbs (483 kg)
Weight Empty Without Batteries (Basic) 495 lbs (225 kg)
Weight Empty Without Batteries (Deluxe) 505 lbs (229 kg)
Tires 10 in. (254mm) Solid Gray non-marking
Foundation Pressure (Basic) 77 psi (530 kPa)
Foundation Pressure (Deluxe) 79 psi (544 kPa)
Maximum Speed 3.5 miles/hour (5.6 Km/hour)
Frame Construction Powder coated steel
Brake Electrical parking brake, sets automatically whenever
operator steps off platform or engages emergency stop.
Minimum Aisle U-Turn Width 56 in. (1425 mm)
Maximum Rated Climb And Descent Angle 9.5 degrees
86037810 Chariot iVacuum

9
Operations
ITEM MEASURE
Height 50.6 inches (1285 mm)
Length 52.5 inches (1330 mm)
Width without deck 26.5 inches (670 mm)
Width of deck 32.5 inches (826 mm)
Width with side broom (Deluxe only) 36.5 inches (927 mm)
86037810 Chariot iVacuum
SPECIAL NOTES:
The sound pressure level at the operator's ear was
measured to be 73 dBA (Basic) and 69 dBA (Deluxe).
This was a nearfield, broad-band measurement taken
on a carpeted floor. This appliance contains no
possible source of impact noise. The instantaneous
sound pressure level is below 63 Pa.
The weighted root mean square acceleration at the
operator's arms was measured to be below 2.5m/s2 .
This was a tri-axial, third-octave-band measurement
made during normal operation on a composite tile floor.
The measurement and related calculations were made
in accordance with ANSI S3.34-1986.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowl-
edge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety. Children should be super-
vised to ensure that they do not play with the appliance.
LENGTH
WIDTH
HEIGHT

10
Operations
How This machine Works
The Chariot® iVacuum™ is a battery powered, self-
propelled, carpet vacuum intended for commercial use.
The appliance vacuums debris and dirt from the carpet
and collects it in a disposable bag.
The machine's primary systems are the brush system,
vacuum system, and operator control system.
The function of the brush system is to brush the carpet.
The brush system consists of two cylindrical type
brushes, motor, brush deck, and controls.
The front brush turns clockwise when viewed from the
right side of the machine. The rear brush turns coun-
terclockwise. Both brushes work to agitate the carpet
and to route the debris up in to the central vacuum
nozzle.
The function of the vacuum system is to vacuum dirt
and debris into the vacuum bag. The recovery system
consists of the vacuum nozzle, vacuum motor, cloth
vacuum bag and paper vacuum bag. The vacuum
nozzle captures the dirt off the floor as the machine
moves forward. The vacuum motor provides suction to
draw the dirt into the vacuum bag. The vacuum bag
stores the dirt.
The function of the operator control system is to control
the direction and speed of the machine. The directional
control system consists of the direction control switch,
throttle pedal, speed control switch, drive reset switch,
emergency stop/brake switch, steering wheel, propel
controller, drive wheel and operator presence pedal
prior to Serial Number(17*). The directional control
switch signals forward or reverse direction. The
controller interprets signals from the throttle pedal to
command the drive wheel to propel or slow the
machine. The drive reset switch is to make sure the
operator is on platform before machine will propel. The
steering wheel points the drive wheel in the direction
desired by the operator. The parking brake automati-
cally engages when the operator steps off the platform.
The emergency stop/brake can be used to hold the
machine on slopes.
*See Serial Number page.
86037810 Chariot iVacuum

11
Operations
Components
1. Bag Access Lid
2. Brush Deck
3. Cloth Bag
4. Control Panel-Drive
5. Control Panel-Vacuum
6. Control Housing
7. Cover Lid
8. Deck Lift
9. Paper Bag
10. Pedal Platform
11. Rear Cover
12. Cover
13. Side Broom (Deluxe Only)
86037810 Chariot iVacuum
4
6
13
12
1
5
10
11
2
7
3
9
8

12
Operations
Drive Controls
4
5
9
2
10
1
3
6
7
8
11
86037810 Chariot iVacuum

13
Operations
1. KEY SWITCH
Controls the power for machine functions.
To turn the machine power on, rotate key clockwise.
To turn the machine off, rotate key counterclockwise.
2. EMERGENCY STOP/BRAKE SWITCH
This safety feature is designed to cut all power to the machine at any time and apply parking brake.
To shut the machine power off, push the Emergency Stop Switch, this will also engage the parking brake and
cause the machine to stop immediately.
To reset the machine, rotate the switch clockwise.
3. DIRECTIONAL CONTROL SWITCH
Controls the direction of travel of the vehicle. The position of the switch indicates direction of travel.
To travel forward, press the top of the switch.
To travel in reverse, press the bottom of the switch.
4. THROTTLE PEDAL
Controls the speed of the vehicle within the speed control setting selected. Pressing the pedal causes the
machine to travel in the direction selected by the Directional Control Switch.
To increase speed, increase pressure on the pedal.
To decrease speed, decrease pressure on the pedal.
86037810 Chariot iVacuum
1. Key Switch
2. Emergency Stop/Brake Switch
3. Directional Control Switch
4. Throttle Pedal
5. Operator Presence Pedal-Prior to Serial Number
(17*)
6. Speed Control Switch
7. Drive Reset Button
8. Horn Button
9. Steering Wheel
10. Battery Discharge Indicator
11. Hour Meter

14
Operations
5. OPERATOR PRESENCE PEDAL - Prior to Serial Number (17*)
This safety feature is designed to ensure that the operator has their left foot on pedal platform whenever
machine is moving. The operator must have left foot on Operator Presence Pedal for machine to move.
6. SPEED CONTROL SWITCH
Controls the maximum speed of the machine. Speed 1 is intended for vacuuming. Speed 2 is recommended
for transport only, not vacuuming.
To increase speed, press the top of the switch.
To decrease speed, press bottom of the switch. Speeds can be adjusted at any time, whether machine is
moving or not.
7. DRIVE RESET SWITCH
This safety feature is designed to ensure safe engagement of propel drive. Each time the machine power is
turned on, and each time an operator steps on to the platform, the Drive Reset Switch must be pushed before
machine will propel.
8. HORN BUTTON
The horn is activated by pressing the horn button.
9. STEERING WHEEL
The steering wheel turns the front wheel causing the machine to change direction.
*See Serial Number page.
86037810 Chariot iVacuum

15
Operations
10. BATTERY DISCHARGE INDICATOR
Indicates the charge level of the batteries.
The meter display is divided into 10 vertical bars. Bars illuminated on the far right indicate full charge. Bars
flashing near the left side indicate the batteries should be recharged. Further operation of the machine could
damage the machine or the batteries. Bars flashing near left side also indicate that machine has been left unat-
tended with key on for more that 15 minutes. Turn key off then on to reset.
When the machine is left overnight with less than a full charge, the display may initially indicate a full charge. It
will also indicate a full charge if the batteries are disconnected, then reconnected. After a few minutes of
operation the meter will give the correct charge level.
11. HOUR METER
Records the number of hours the machine has been in operation. This information is useful in determining
when to service the machine.
86037810 Chariot iVacuum

16
Operations
Deck Controls
Brush Lift Lever
Raises and lowers the brush deck and turns the vacuum motor on and off.
To lower brush deck and start vacuum motor and brushes, lift the lever from its raised position.
To raise brush deck and stop vacuum motor and brushes, lift the lever from its lowered position.
Side brush on deluxe model only.
Deluxe Model
The brush lift lever also raises and lowers the side broom.
86037810 Chariot iVacuum
Brush Lift Lever

17
Operations
Pre-run Machine Inspection
Do a pre-run inspection to find possible problems that
could cause poor performance or lost time from break-
down. Follow the same procedure each time to avoid
missing steps.
NOTE: See maintenance section for pre-run machine
inspection checklist items.
STARTING MACHINE
NOTE: Perform pre-run machine check before
operating machine.
FOR SAFETY: Before starting machine, make sure
that all safety devices are in place and operating
properly.
1. Stand on the operator platform. Throttle pedal must
be in neutral position.
Note: Prior to Serial Number (17*). Place left foot on
operator presence pedal. Throttle pedal must be in
neutral position.
2. Turn the machine power on by turning key switch
clockwise to the "ON" position.
3. Check the position of the Directional Control
Switch to make sure the machine will travel in the
direction intended.
4. Press the Drive Reset Switch.
5. Press lightly on the throttle pedal with right foot.
*See Serial Number page
Emergency Stop Procedures
1. Release the throttle pedal by lifting right foot.
2. Turn machine power off with key switch by turning
key switch counterclockwise.
3. If an electrical problem is suspected, push in
emergency stop button. This will also engage the
parking brake and cause the machine to stop
immediately.
86037810 Chariot iVacuum

18
Operations
Normal Vacuuming
Plan the vacuuming pattern in advance. The longest
track is around the perimeter of the area to be cleaned.
For efficient operation, the runs should be the longest
possible without turning or stopping.
In order to achieve the best possible results, the area
which is to be cleaned should be picked up before
vacuuming. Large debris, strings and wire must be
removed to prevent being caught in brushes.
If machine is allowed to stand in neutral with the
vacuum deck down for more than 2 seconds, the brush
motor stops. If either forward or reverse travel is
selected, the brush motor will continue once movement
of machine begins. Overlap the brush path and avoid
transporting over previously cleaned areas.
Recommended Path
To Begin Vacuuming
When operating the machine around people, pay
close attention for unexpected movement. Use
extra caution around children.
1. Stand on the operator platform. Throttle pedal must
be in neutral position.
NOTE: Prior to Serial Number (17*). Place left foot on
operator presence pedal. Throttle pedal must be in
neutral position.
2. Turn machine power on.
3. Check position of Directional Control Switch to
ensure that machine is set to travel in direction
intended.
4. Press the Drive Reset Switch.
5. Lower the Brush Deck.
6. Drive machine forward to begin vacuuming.
7. Adjust the speed of the machine as necessary.
*See Serial Number page.
86037810 Chariot iVacuum

19
Operations
To Stop Vacuuming
1. Raise the brush deck, which turns off brushes and
vacuum.
2. Allow the throttle pedal to return to neutral.
3. Turn machine power off.
FOR SAFETY: Before leaving or servicing machine:
stop on level surface, turn off machine and remove key.
FOR SAFETY: When using machine, go slow on
inclines.
Changing Vacuum Bag
A convenient bag storage is built into the lid.
1. Park machine on level area.
2. Turn the machine power off.
3. Open cover lid and vacuum box lid.
4. Unzip cloth bag.
5. Remove paper bag lip from nozzle.
6. Remove cloth bag lip from nozzle.
7. Remove cloth band and paper bag together from
vacuum box.
8. Remove paper bag from cloth bag and dispose of
properly.
9. Clean vacuum box and remove any debris from
inside screen.
10. Shake cloth bag to remove any extra debris.
11. Place cloth bag back into vacuum box and push
the rubber collar over the nozzle.
12. Retrieve a new clean paper bag from the storage
compartment in the coverlid.
13. Place a new paper bag into the cloth bag and push
the rubber collar over the nozzle.
14. Close all lids and covers.
PAPER BAG
CLOTH BAG
STORAGE
EXTRA BAG
86037810 Chariot iVacuum

20
Maintenance
Service Schedule
NOTE: A Vacuum hose cleaning brush is included with your vacuum. If debris is caught in the vacuum hose, use
brush to clear the vacuum hose. Remove vacuum bag and clear hose of debris with the brush. It may be
necessary to clear the hose at vacuum shoe connection. Disconnect vacuum hose and clear hose. Check
vacuum shoe for debris also.
MAINTENANCE BEFORE EACHWORK
PERIOD
AFTEREACH
WORK
PERIOD 50 HRS 100 HRS 200 HRS
Check water level of batteries after
charging; add distilled water if necessary *
Check that the vacuum box lid seal tightly *
Visually check for damaged or worn tires. *
Check vacuum hose connections. *
Check hoses for debris buildup. *
Check pedal(s), brake and steering for
proper operation *
Check vacuum bag fullness and change if
necessary. *
Clean brushes and check wear. *
Charge batteries. *
Clean off top of batteries. *
Check battery cells with hydrometer. (Wet
cell only) *
Check battery connections are tight. *
Clean battery cases and compartment. *
Clean and check drive tension chain for
wear and tension. *
Check parking brake. *
Clean chains, cables and pulleys for
brush deck lift. *
Check all motors for carbon brush wear. *
Check motor commutators. *
Check steering chain tensioner. *
86037810 Chariot iVacuum
