EcoWater Eco Solution User manual

Eco Solution
User manual
Think green!
The ceramic filters is not pre-assembled to
avoid damage during transportation.
NOTE!
The ceramic filter must
be assemblied before use!

Take the manifold assembly (B) and ensure that the
rubber seal (A) is correctly located into the recess.
Push the center support tube (C) securely into the
recess on the underside of the manifold. Remove
each of the six ceramic lter candles (E) from the
protective wrap and check that the O-ring seal (D)
is located fully onto the threaded mount of the
lter candle. Screw the threaded mount into one of
the holes in the underside of the manifold until the
washer resistance is felt and the moulded cap just
touches the ring on the underside of the manifold.
DO NOT OVER TIGHTEN!
Repeat for all six candles. Take the base moulding
(F), ensure the rubber seal (G) is located correctly
into the recess and push the base securely onto the
support tube (C) to complete the assembly. Now
the unit is ready for the main installation.
Eco Solution water purification system is easy to assemble. However, it is
advisable to use a certified plumber to install the system. Eco Solution should
be installed on the water intake as shown below.
ASSEMBLY
CARTRIDGE ASSEMBLY
2
Water intake [2]
Main stop valve [1]
Puried water
out [3]
A
B
D
E
C
F
G

•
•
•
•
•
•
Shut o the main water intake with the main stop valve [1] or by the main tap.
Assemble the unit on to the water intake grid. There are several alternatives of how to
do this, depending on the existing grid system.
Place the unit onto the water intake (after the pump, if there is one)
NOTE; make sure there’s a 10 cm clearing underneath the unit. This space is necessary
to be able to open the units for cleaning/maintenance/changing the lters.
Open the water intake [1]. Open a tap connected to the same grid and let the water
run to waste for about ten minutes before use( in order to remove unwanted particles).
Ensure there is no leakage from the unit or it’s couplings. If there is a leakage, ensure all
O-rings are assembled correctly to make a proper seal.
For new lter candles, the maximum ow rate will be achieved once the candles are
fully saturated; to allow the lter candles to be conditioned to the source water allow
the unit to stand unused for a further 24 hours and then ush for a further 10 minutes
to waste.
The ltered water can now be used for drinking and preparing food. If the lter has
been standing unused for more than 3 days, it is recommended that the water be
run to waste for 1 minute before use.
GENERAL USE
3
USER MANUAL
UNIT ASSEMBLY
The lters in your Eco Solution water purication system must be cleaned from time to
time. Cleaning is easy – no plumber or other service personnel is necessary. The quality
of the water source decides how frequent it is necessary to clean the lters.
The lters have to be replaced if the purication system delivers no water at all, or when
the water ow is low even after cleaning the ceramic lter. Filter change will probably be
necessary after approx. 50 000 – 100 000 liters or after about 12 months of daily use
(water source dependent).
Soon after the purication system has been put to use for the rst time you will
experience a noticeable drop in the water pressure. This is expected due to residue
(from production) from the High performance lter are clogging up the ceramic lter.
A cleaning of the ceramic lter is thus necessary relatively short after put to use the rst
time, or after lter change. The system will deliver puried water in a much longer
period, after this rst removal of production residue. The quality of the water source
decides how frequent it is necessary to clean the lters.
MAINTENANCE

The High Performance lter is placed on the left hand side.
The ceramic lter is placed on the right hand side.
•
•
•
•
•
•
•
Turn of the systems water source. Release water pressure by opening a connected
tap. It’s a good idea to place a bowl or a towel under the purication system before
opening the lter houses.
Open the ceramic lter housing using the enclosed tool.
Remove the lter/lters from the lter housing(s). Handle the ceramic lter with great
care – the 6 ceramic candles can easily break.
CLEANING THE CERAMIC FILTER:
Use the enclosed cleaning brush or the pad to clean the 6 lter candles with cold
water. Do not use soap! Put the cleaning brush around each candle, one at a time,
and rub their surface a couple of times. Put the lter back in the lter housing. Make
sure to place the lter in the correct direction – the black manifold should be
upwards (as on the illustration of the cartridge assembly).
FILTER REPLACEMENT:
Replace all of the 6 ceramic candles with new ones (loosen them carefully by
unscrewing them). Replace the High Performance lter. Put the lters back in the
lter housings. Make sure to place the lter in the correct direction – the black
manifold should be upwards (as on the illustration of the cartridge assembly).
Re-attach the lter housing to the purication unit. Tighten with the enclosed tool
(it’s sucient to tighten by hand).
Make sure the housing is placed correctly. If the housing is attached askew, or the
O-ring or lter is placed incorrectly, a leak will probably occur.
Open the water ow [1] into the purication system. Turn on the water and let the
water ow for about 3 minutes (this removes dirt, particles etc).
Make sure that there are no leakages from the lter housings.
FILTER CLEANING/REPLACEMENT
NOTE! THE UNIT DOES NOT TOLERATE FROST
ECO WATER AS
Postboks 177, N-1430 Ås
Norway
Tel: [phone]
[e-mail]
