ClimaRad Care H1C Manual

and
for 6 seconds
1
20 8.0011
Maintenance instructions ClimaRad Care H1C
2. Unscrew the locking screws
from the housing. The lower
housing now moves forward.
3. Remove the air distributor.
1
4. Open both valves by pulling
them towards you.
7. Put the two black filter caps
(left and right) back in position
and close both valves again.
8. Reinstall the air distributor (1),
tilt the lower housing back in
position (2), and tighten the
screws again (3).
1
2
3
Replacing air supply filters
6. Slide three new filter elements
into the device on the left side.
The old filter elements are
automatically ejected from the
right side.
Important: Only reset the filter hour counter if you have replaced the filters.
Maintenance frequency for filters
When should you replace the filters?
• vervuildWith normal use, every 2 years or earlier if the message 'Filter ' appears
on the display (for example in homes and offices).
• In the case of intensive use, after 1 year or earlier if the message 'Filter
vervuild' appears on the display (e.g. for care homes and schools).
Ordering filters
Order new filters at
www.climarad.nl/filters
Go to to view the instruction video.www.climaRad.nl/filtervervanging
1.First switch the device off by
pulling the plug out of the socket.
left right
left
right
5. Remove the black caps.
left right
9. Put the plug back into the
socket and reset the filter hour
counter (Press + and –
simultaneously for 6 seconds). The
'filter ' message will nowvervuild
disappear.
Slide 3 new filters in
3 old filters will
slide out
Press
Future comfort today

ONDERHOUD: luchtafvoerfilters
2
3
Cleaning the air output filters and coarse filter.
Replacing air output filters
Cleaning the air ducts
1
The air output filters are located at the bottom of
the device. Vacuum the visible dirt off the filters.
This guarantees the air flow. You do not need to
remove the air output filters to do this.
The coarse filter is located under the convector,
above the air distributor. First remove the air
distributor and vacuum the visible dirt off the
filter.
2.The output filters (3 pieces) are
located at the bottom of the
device, in the middle. These can
be removed by placing a finger
behind the notch.
3. Push 3 new filters into the
holders and then push the plug
back into the socket.
3x
4
1
1
8. Close the valves and re-install
the air distributor.
9. Tilt the lower housing back and
tighten the screws again. Then put
the plug back into the socket.
1
1. First switch the device off by
pulling the plug out of the socket.
First follow steps 1 to 4 of
'replacing the air supply filters'.
5. Turn both blue caps anti-
clockwise and then remove them.
6. Remove dirt from both ducts
with a vacuum cleaner or a soft
cloth (do not use water).
7. Push both blue filter caps back
in completely in order to ensure
correct operation and screw them
back into position.
left right
ClimaRad B.V. - Lübeckstraat 25 - 7575 EE - Oldenzaal - NL - [email protected] - www.climarad.co.uk - tel. [phone]
Future comfort today
