Ecox EDCM series User manual

EDCM
OWNER´S MANUAL
SPLIT-TYPE ROOM AIR CONDITIONER
Thank you for purchasing this ecox product
Before using this machine, please read this manual and retain it for future reference.
EDCM / EACM
EDCM

2
SPLIT-TYPE ROOM AIR CONDITIONER
EDCM
SAFETY PRECAUTIONS
CAUTION
NAMES OF PARTS
INDICATION LAMP
SPECIAL FUNCTIONS
OPERATING INSTRUCTIONS
Operating temperature
Manual operation
Airflow direction control
How the air conditioner works
CARE AND MAINTENANCE
Cleaning the unit
Cleaning the air filter and air freshening filter
Replacement of the air filter and air freshening filter
Preparation for extended non-operation
Pre-season inspection
TROUBLESHOOTING TIPS
Normal function of the air conditioner
Troubleshooting guide
CONTENT
READ THIS MANUAL
Keep this manual where the operator can easily nd them.Inside
you will nd many helpful hints on how to use and maintain your
air conditioner properly. Just a little preventative care on your part
can save you a great deal of time and money over the life of your
air conditioner. You'll nd many answers to common problems
in the chart of troubleshooting tips. If you review the chart of
Troubleshooting Tips rst, you may not need to call for service.
3
5
5
5
4
6
6
6
7
7
9
9
9
9
9
10
10
11
8
When using this air conditioner in the European countries,
please read the following information:
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
DISPOSAL: Do not dispose of this product as unsorted municipal
waste. Collection of such waste separately for special treatment is
necessary.
It is prohibited to dispose of this appliance in domestic household
waste. For disposal, there are several possibilities:
The municipality has established collection systems, where
electronic waste can be disposed of at least free of charge to the
user.
When buying a new product, the retailer will take back the old
product at least free of charge.
The manufacturer will take back the old appliance for disposal at
least free of charge to the user.
As old products contain valuable resources, they can be sold to
scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your
health when hazardous substances leak into the ground-water
and nd their way into the food chain.
A
B
C
D
Keep running condition your air conditioning performing at least
every six months clean the lters, coils and fans.
Keep in good working control systems, such as the thermostat.
The comfort temperature is between 21° C and 23° C, holding the
temperature within this range will help the team save more energy.
Do not place the thermostat near spotlights, lamps or heat-
producing appliances and the operation of the system may be
inadequate and / or poor.
When using the air conditioner keep doors and windows closed in
conditioned environments in order to keep out hot outside air.
If the area where the air conditioner is going to remain idle, shut
down your computer for saving energy.
In unconditioned spaces should reduce the heat load introduced
by excessive lighting or equipment remain on unnecessarily.
FEATURES
Less
Noise
Washable
Filter
Auto
Restart
Less
Vibration
Carbon
Filter
Mode
“Sleep”
Timer
Easy
Installation
3 in 1
Digital
Panel

3
SPLIT-TYPE ROOM AIR CONDITIONER EDCM
SAFETY PRECAUTIONS
To prevent injury to the user or other people and property damage,
the following instructions must be followed. Incorrect operation
due to ignoring of instructions may cause harm or damage.
The seriousness is classied by the following indications.
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to
property.
Meanings of symbols used in this manual are as shown
below.
Never do this.
Always do this.
Do not extend the cable and never use multiple plugs. A poor
electrical connection, poor insulation or voltage which is
higher than permitted can cause re.
Do not expose your body directly to the cool air for prolonged
period.
Never poke ngers, sticks or other objects in the air inlet and
outlet vents.
Never attempt to repair, relocate, modify the air conditioner
yourself. Always contact your service partner if it requires.
Never pull the plug out by pulling on the cable. Hold the plug
rmly and pull it out of the plug socket, otherwise there is a
risk of damaging the cable.
Do not operate your air conditioner in a wet room such as a
bathroom or laundry room.
Remove all dirt from the power plug and plug it rmly. Soiled
plugs can cause re or an electric shock.
In the event of any abnormalities such as smell of burning,
immediately switch o the device and pull the plug. Contact
your service partner.
Always switch o the device and pull the plug before you
start to clean it.
Use specied power cord.
Contact the authorized installer for installation of this unit.
Contact an authorized service technician for repair or
maintenance of this unit.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the air conditioner.
WARNING
WARNING
CAUTION

4
SPLIT-TYPE ROOM AIR CONDITIONER
EDCM
Never actuate any switches with a wet hand. It may cause
an electric shock.
Never use the device for any other purpose than the intended
use. Never place food, precision instruments, plants, animals,
paint, etc. on the unit.
Do not expose plants or animals directly to the air ow.
Never clean the air conditioner with water.
Never use combustible cleaning agents as these could cause
a re or deformation.
Never place any burning objects close to the device if they
could be directly aected by the emitted air.
Never step onto the outdoor device and never place anything
on it.
Never use an unsteady or rusty base.
Never install the air conditioner in places where combustible
gas can be emitted.
Emitted gas may collect and cause an explosion.
Never allow the air conditioner to run for too long with the
doors or windows open, or if the humidity is very high.
If the air conditioner is to be used in conjunction with other
heaters, the air should be refreshed periodically, otherwise
there is a risk of lack of oxygen.
Always pull out the power plug if the unit is not going to be
used for any lengthy period of time. Collections of dust can
cause re.
Always switch o the air conditioner and pull out the power
plug during a storm. Electrical parts may get damaged.
Check that the drainage line is correctly connected. If not,
water will escape.
Check that the condensation water can run o unhindered.
It may cause water damage if the condensation water
cannot run o properly.
The air conditoner must be earthed in accordance with the
local codes.
For electrical safety purposes we recommend that you install
an earthleakage circuit-breaker.
If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similary qualied persons
in order to avoid a hazard.
CAUTION

5
SPLIT-TYPE ROOM AIR CONDITIONER EDCM
NAMES OF PARTS
9
8
10
All the pictures in this manual are for explanation purposes only.
The actual shape of the indoor unit you purchased may be slight
dierent on front panel and display window. The actual shape
shall prevail.
Connecting pipe
Connecting cable
Stop valve
INDOOR UNIT
OUTDOOR UNIT
SPECIAL FUNCTIONS
1
1
2
2
33
4
4
5
6
7
Front panel
Air inlet
Air lter
Air outlet
Refrigerant Leakage Detection
With this new technology, the display area will appear "EC" and
the indication lamps continue ashing when the outdoor unit
detects refrigerant leakage.
Louver Angle Memory Function (optional):
Within the scope of safety angle, it will memorize the open
angle of horizontal louver.
If it exceeds, it will memorize the boundry of safety angle. In
the following circumstances, it will return to standard angle:
1) pressing the manual switch, 2) unplug and then plug in
the machine. So we strongly suggest that the open angle of
the horizontal louver should not be set too small, in case the
condensed water forms and drops from the horizontal louver.
SELF CLEAN function Optional
Function used after the Shut Down of cooling operation to
clean the Evaporator and keep it as fresh for the next operation.
The unit will operate as following sequence : FAN ONLY mode
at Low fan speed--Heating operation with LOW fan speed
(applicable to cooling & heating models only) ---FAN ONLY
operation--Stop Operation---Turn o.
RUN indication lamp
This lamp illuminates when the air conditioner is in operation
TIMER indication lamp
Lights up during timer operation
DEFROST indication lamp
(Enabled on cooling and heating models only):
Lights up when the air conditioner starts defrosting
automatically or when the warm air control feature is
activated in heating operation.
Temperature indication
Display the temperature settings when air conditioner
is operational.
Displays the malfunction code.
Horizontal air ow grille
Vertical air ow louver(inside)
Display panel
NOTE
1 2 3
4
Receptor de señal

6
SPLIT-TYPE ROOM AIR CONDITIONER
EDCM
TEMPERATURE
Room Temperature
Outdoor Temperature
MODE COOLING
OPERATION
HEATING
OPERATION
DRYING
OPERATION
17 ºC ~ 32º C
(62º F~ 90º F)
0º C~ 30º C
(32ºF ~ 86º F)
10º C~32º C
(50º F~ 90º F )
0º C ~ 50º C
(32º F ~ 122º F)
0 ºC ~ 50 ºC
(32º F ~ 122 ºF)
(-15 ºC ~ 50 ºC
5º F ~ 122º F:
for models with low
temperature cooling
system)
-15 ºC ~ 30 ºC
(5º F ~ 86ºF)
This function is only available under COOL (AUTO COOL, FORCED
COOL) and DRY mode.
Before select the function, it is recommended to run the air
conditioner under Cooling operation for about half an hour.
Once the Self Clean function is activated, all TIMER setting will be
cancelled.
During Self Clean operation, when press the SELF CLEAN button on
the remote controller again will stop the operation and turn o the
unit automatically.
CLEAN AIR function (on some models)
This air conditioner is equipped with ionizer or Plasma Dust
Collector (Depending on specic conguration of the model).
With the anions generated by Ionizer, the air circulation of
the air conditioner lls the room with refreshing, natural and
healthy air. The Plasma Dust Collector generates a high voltage
ionization zone, through which the air is converted to plasma.
Inside the air most of the dust, smoke, and pollen particles are
captured by the electrostatic lter.
Anti-mildew function (Optional)
When turns o the unit on COOL, DRY, AUTO (Cool) mode, the
air conditioner will continue operating for about 7-10 minutes
(depending on models) at LOW fan speed. If turns o on HEAT
mode, the unit will continue operating for about 30 seconds at
LOW fan speed. This will help to dry up the condensed water
inside the evaporator, and prevent the breeding of mildew.
Under Anti-mildew operation, do not restart the air conditioner
until the unit is completely o.
Vertical swing function (Optional)
After the AC starts up, users can control the vertical louver
swing by the remote controller.
This manual does not include Remote Controller Operations, see the <<Remote
Controller Instruction>> packed with the unit for details.
Optimum performance will be achieved within these operating
temperatures. If air conditioner is used outside of the above
conditions, certain safety protection features
might come into operation and cause the unit to function
abnormally.
If the air conditioner runs for a long time in cooling mode and the
humidity is high(over 80%) , condensed water may drip out of the
unit. Please sets the vertical air ow louver to its maximum angle
(vertically to the oor), and set HIGH fan mode.
Suggestion: For the unit adopts an Electric Heater, when the
outside ambient temperature is below 0OC(32OF), we strongly
recommend you to keep the machine plugged in order to
guarantee it running smoothly.
MANUAL OPERATION
OPERATING TEMPERATURE
Units are equipped with a switch to run emergency operation
mode. It can be accessed by opening the front panel. This switch
is used for manual operation in case the remote controller fails
to work or maintenance necessary.
The unit must be turned o before operating the manual control
button. If the unit is operational, continue pressing the manual
control button until the unit is o.
1
2
1
2
3
Open and lift the front panel up to an angle until it remains xed
with a clicking sound. For some models, please use suspension bars
to prop up the panel.
One press of the manual control switch will lead to the forced AUTO
operation. If press the switch twice within ve seconds, the unit will
operate under forced COOL operation.
Close the panel rmly to its original position.
CAUTIONS
This switch is used for testing purposes only. You had better not
choose it.
To restore the remote controller operation, use the remote
controller directly.
AUTO/COOL
AUTO/COOL
OPERATING INSTRUCTIONS
NOTES
NOTE
NOTE
NOTE

7
SPLIT-TYPE ROOM AIR CONDITIONER EDCM
AIRFLOW DIRECTION CONTROL
HOW THE AIR CONDITIONER WORKS
CAUTIONS
Adjust the air ow direction properly otherwise it might cause
discomfort or cause uneven room temperatures.
Adjust the horizontal/vertical louver using the remote
controller. For some models, the vertical louver can only be
adjusted manually.
To set the horizontal/vertical air ow direction
Perform this function while the unit is in operation.
Use the remote controller to adjust the air ow direction. The
vertical/horizontal louver changes 6 degree in angle for each
press, or swing up and down automatically. Please refer to the
REMOTE CONTROLLER OPERATION MANUAL for details.
For some models, the vertical louver can only be adjusted
manually. Move the deector rod manually to adjust the air ow
in the direction you prefer.
IMPORTANT: Do not put your ngers into the panel of blower
and suction side.The high-speed fan inside may cause danger.
Deector rod
Do not operate the air conditioner for long periods with the
air ow direction set downward in cooling or dehumidifying
mode. Otherwise, condensation may occur on the surface of the
horizontal louver causing moisture to drop on to the oor or on
furnishings.
When the air conditioner is started immediately after it was
stopped, the horizontal louver might not move for approximately
10 seconds.
Open angle of the horizontal louver should not be set too small,
as COOLING or HEATING performance may be impaired due to too
restricted air ow area.
Do not move the horizontal louver manually, otherwise the
horizontal louver will be out of sync. Please cease operating,
unplug power for a few seconds,then restart the air conditioner.
Do not operate unit with horizontal louver in closed position.
SLEEP operation
Cooling
Heating
SLEEP operation
Set Temperature
Set Temperature
7 hours timer o
7 hours timer o
1 hour
1 hour
1º C/2º F
1º C/2º F
1º C/2º F
1º C/2º F
1 hour
1 hour
AUTO operation
When you set the air conditioner in AUTO mode, it will
automatically select cooling, heating(cooling/heating models
only), or fan only operation depending on set temperature and
the room temperature.

8
SPLIT-TYPE ROOM AIR CONDITIONER
EDCM
The air conditioner will control room temperature automatically
to the temperature point you set.
If you feel uncomfortable in the AUTO mode, you can set your
desired temperature.
SLEEP operation
When you push SLEEP button on remote controller during
cooling, heating(cooling & heating models only), or AUTO
operation , the air conditioner will automatically increase
(cooling) or decrease (heating) 1º C / 2º F per hour for the rst
2 hours, then hold steadily for the next 5 hours, after that it will
switch o.
This mode saves you energy and brings you comfort at night.
DRYING operation
The fan speed will be automatically controlled under dry
operation.
During the dry operation, if the room temperature is lower than
10º C (50º F), the compressor stops operation and restarts until
the room temperature is above 12º C (54º F).
To achieve optimal performance, please note the following:
Adjust the air ow direction correctly so that it is not forwards
people.
Adjust the temperature to achieve the highest comfort level. Do
not adjust the unit to excessive temperature levels.
Close doors and windows on COOL or HEAT modes, or
performance may be reduced.
Use TIMER ON button on the remote controller to select a time
you want to start your air conditioner.
Do not put any object near air inlet or air outlet, as the eciency
of the air conditioner may be reduced and the air conditioner
may stop running.
Clean the air lter periodically, otherwise cooling or heating
performance may be reduced.
Do not operate unit with horizontal louvre in closed position.
Before mainatenance
Turn the system o before cleaning. To clean, wipe with a soft,
dry cloth. Do not use bleach or abrasives.
Power supply must be disconnectd before cleaning the indoor
unit.
A cloth dampened with cold water may be used on the indoor unit
if it is very dirty. Then wipe it with a dry cloth.
Do not use a chemically treated cloth or duster to clean the unit.
Do not use benzine, thinner, polishing powder, or similar solvents
for cleaning. These may cause the plastic surface to crack or
deform.
Never use water hotter than 4º C/104 F to clean the front panel, it
could cause deformation of discoloration.
CAUTIONS
CARE AND MAINTENANCE
NOTE
OPTIMAL OPERATION

9
SPLIT-TYPE ROOM AIR CONDITIONER EDCM
Cleaning the unit
Wipe the unit with a soft dry cloth only. If the unit is very dirty,
wipe it with a cloth soaked in warm water.
Cleaning the air lter and air freshening lter
A clogged air lter reduces the cooling eciency of this unit.
Please clean the lter once every 2 weeks.
Lift the indoor unit panel up to an angle until it stops with a
clicking sound. For some models, please use suspension bars to
prop up the panel.
Take hold of the handle of the air lter and lift it up slightly to
take it out from the lter holder, then pull it downwards.
Remove the AIR FILTER from the indoor unit.
Clean the AIR FILTER once two weeks.
Clean the AIR FILTER with a vacuum cleaner or water, then dry
it up in cool place.
Remove the Air Freshening Filters from its supporting frame
(The solution to disassemble may dier from each other for
dierent lters. Refer to (1) and (2) ). Clean the air freshening
lter at least once a month, and replace it every 4-5 months.
Clean it with vacuum cleaner, then dry it in cool place.
For the models with plasma, do not touch the plasma within 10
minutes after you open the panel.
Install the air freshening lter back into position.
Insert the upper portion of air lter back into the
unit, taking care that the left and right edges line up
correctly and place lter into position.
Replacement of air lter and air freshening lter
Remove the air lter.
Remove the air freshening lter.
Install a new air freshening lter.
Reinstall the air lter and securely close the front panel.
Preparation for extended non-operation
If you plan to idle the unit for a long time, perform the following:
Clean the indoor unit and lters.
Operate the fan for about half a day to dry the inside of the unit.
Stop the air conditioner and disconnect power.
Remove the batteries from the remote controller.
The outdoor unit requires periodic maintenance and cleaning.
Do not attempt to do this yourself.
Contact your dealer or service provider.
Pre-season inspection
Check that the wiring is not broken o or disconnected.
Clean the indoor unit and lters.
Check that the air lter is installed.
Check if the air outlet or inlet is blocked after the air conditioner
has not been used for a long time.
1
2
3
4
5
6
1
1
2
2
3
3
4
4

10
SPLIT-TYPE ROOM AIR CONDITIONER
EDCM
10
Do not touch the metal parts of the unit when removing the lter.
Injuries can occur when handling sharp metal edges.
Do not use water to clean inside the air conditioner. Exposure to water
can destroy the insulation, leading to possible electric shock.
When cleaning the unit, rst make sure that the power and circuit
breaker are turned o.
Do not wash air lter with hot water at more than 40º C / 104º
F. Shake o moisture completely and dry it in the shade. Do not
expose it directly to the sun, it may shrink.
NORMAL FUNCTION OF THE AIR CONDITIONER
The following events may occur during normal operation.
Protection of the air conditioner.
Compressor protection
The compressor can't restart for 3-4 minutes after it stops.
Anti-cold air (Cooling and heating models only)
The unit is designed not to blow cold air on HEAT mode, when
the indoor heat exchanger is in one of the following three
situations and the set temperature has not been reached.
When heating has just started.
Defrosting.
Low temperature heating.
The indoor or outdoor fan stop running when defrosting
(Cooling and heating models only).
Defrosting (Cooling and heating models only)
Frost may be generated on the outdoor unit during heat cycle
when outdoor temperature is low and humidity is high resulting
in lower heating eciency of the air conditioner.
During this condition air conditioner will stop heating operation
and start defrosting automatically.
The time to defrost may vary from 4 to 10 minutes according to
the outdoor temperature and the amount of frost built up on
the outdoor unit.
A white mist coming out from the indoor unit
A white mist may generate due to a large temperature
dierence between air inlet and air outlet on COOL mode in an
indoor environment that has a high relative humidity.
A white mist may generate due to moisture generated from
defrosting process when the air conditioner restarts in HEAT
mode operation after defrosting.
Low noise of the air conditioner
You may hear a low hissing sound when the compressor is
running or has just stopped running.
It is the sound of the refrigerant owing or coming to a stop.
You can also hear a low "squeak" sound when the compressor
is running or has just stopped running. This is caused by heat
expansion and cold contraction of the plastic parts in the unit
when the temperature is changing.
A noise may be heard due to louver restoring to its original
position when power is turned on.
Dust is blown out from the indoor unit.
This is a normal condition when the air conditioner has not
been used for a long time or during rst use of the unit.
A peculiar smell comes out from the indoor unit.
This is caused by the indoor unit giving o smells permeated
from building material, from furniture, or smoke.
The air conditioner turns to FAN only mode from COOL or
HEAT (For cooling and heating models only) mode.
When indoor temperature reaches the temperature setting on
air conditioner, the compressor will stop automatically, and the
air conditioner turns to FAN only mode. The compressor will
start again when the indoor temperature rises on COOL mode
or falls on HEAT mode (For cooling and heating models only) to
the set point.
The air conditioner runs Anti-mildew function after turning
o the unit.
When turning o the unit under COOL(AUTO COOL, FORCED
COOL) and DRY mode, the air conditioner will run Anti-mildew
function for 7-10 minutes, if turns o on HEAT mode, the unit
will then stop the operation continue operating for about 30
seconds at LOW fan speed and turn o the unit automatically.
Dripping water may generate on the surface of the indoor unit
when cooling in a high relatively humidity (relative humidity
higher than 80%). Adjust the horizontal louver to the maximum
air outlet position and select HIGH fan speed.
Heating mode (For cooling and heating models only)
The air conditioner draws in heat from the outdoor unit
and releases it via the indoor unit during heating operation.
When the outdoor temperature falls, heat drawn in by the
air conditioner decreases accordingly. At the same time, heat
loading of the air conditioner increases due to larger dierence
between indoor and outdoor temperature. If a comfortable
temperature can't be achieved by the air conditioner, we
suggest you use a supplementary heating device.
Auto-restart function
Power failure during operation will stop the unit completely.
For the unit without Auto-restart feature, when the power
restores, the OPERATION indicator on the indoor unit starts
ashing. To restart the operation, push the ON/OFF button on
the remote controller. For the unit with Auto-restart feature,
when the power restores, the unit restarts automatically with
all the previous settings preserved by the memory function.
1
4
5
6
7
8
9
2
3
A
B
C
TROUBLESHOOTING GUIDE
CAUTIONS

11
SPLIT-TYPE ROOM AIR CONDITIONER EDCM
TROUBLESHOOTING GUIDE
MALFUNCTION CAUSE WHAT SHOULD BE DONE?
OPERATION (RUN) indicator or other
indicators continue ashing.
If one of the following code appears on the
display area: E0, E1, E1, E2, E3..... or P0, P1, P2, P3...
( go to www.ecoxline.com)
Fuse blows frequently or circuit breaker trips
frequently .
Other objects or water fall into the air conditioner.
Terrible odors are smelled or abnormal sounds
are heard.
The unit may stop operation or continue to run in a safety
condition(depending on models). Waiting for about 10
minutes, the fault may be recovered automatically, if not,
disconnect the power and then connect it in again. If the
problem still exists, disconnect the power and contact the
nearest customer service center.
Stop the air conditioner immediately, disconnect the power
and contact the nearest customer service center.
Power cut.
Unit may have become unplugged.
Fuse may have blown.
Battery in remote controller may have been
exhausted.
The time you have set with timer is incorrect.
Inappropriate temperature setting.
Air lter is blocked.
Doors or windows are open.
Air lter or outlet of indoor or outdoor unit has been
blocked.
Compressor 3 minutes protection has been activated.
Wait for power to be restored.
Check that plug is securely in wall receptacle.
Replace the fuse.
Replace the battery.
Wait or cancel timer setting.
Set temperature correctly. Fopr detailed method
please refer to "Using remote control" section.
Clean the air lter.
Close the doors or windows.
Clear obstructions away rst, then restart the
unit.
Wait.
Trouble
Unit does not
start
Unit not cooling
or heating
(Cooling/Heating
models only
room very well
while air owing
out from the air
conditioner
If the troble has not been corrected, please contact a local dealer or the nearest customer service center. Be sure to inform
them of the detailed malfunctions and unit model.
Do not attempt to repair the unit yourself.
Always consult an authorised service provider.
NOTE

EDCM
AF_ECX_ING_EDCM_MU_141114
