Ecoxgear Ecoextreme User manual

Waterproof Speaker Case (Model: GDI-AQCSE100 /101/102/103/104/105/106/107/108/109/110)

Specifications

Frequency Range: 160Hz-20,000Hz Output Power: 3 Watt

Power Source: 3 x AA-size batteries Battery Life: 30 + hours with alkaline batteries

Dimensions: 7.3” (L) x 4.7” (W) x 2.6” (H)

Weight: 1.06lb Floating payload (MP3 player, keys, documents etc) maximum: 8 ounces

Temperature (Operating): 23°F to 104°F IPX7 Waterproof Rating: water submersion not to exceed 3’ depth for 30 minutes

Temperature (Storage): 14°F to 131°F

FCC Compliance Statement & Warning: This device has been tested & found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The device generates, uses & can radiate radio

frequency energy & if not installed & used in accordance with instructions may cause harmful interference to radio communications. There is no guarantee that interference will

not occur in a particular installation IF this device causes interferecne to radio or television recpetion try one of these measures: reorient or relocate the reciving antenna,

increase seperation between device & receiver, connect the device into an outlet on a circuit different from that to which the receiver is connected, consult a dealer or

expereinced radio / TV technician for assistance. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the device and/or void the manufacturer’s limited warranty.

Introduction

Thank you for your purchase of the EcoExtreme speaker case by ECOXGEAR.

The EcoExtreme is a waterproof and dirt proof case with a built-in amplified waterproof

speaker. The case will hold your MP3 player, cell phone, keys and anything you want to

safe safe from the elements.

Location of Controls

1) Power / Volume Knob: To optimize your speaker’s sound set your audio device’s

volume (iPod, cell phone, mp3 player etc) between the 70-80% levels. Rotate

the Eco Extreme’s volume knob to the right to increase volume. To turn the Eco

Extreme ‘off’, turn the knob to the left until a ‘click’ is felt and the LED above the

volume knob turns ‘off’.

2) Power LED: The LED above the volume knob illuminates ‘on’ when the batteries are

in use, even if you do not hear sound from the speaker. To optimize the lifespan of the

batteries turn the EcoExtreme off when not listening to music.

Installing Batteries

1) Open the EcoExtreme and remove the battery door. The battery door is located on

the inside of the EcoExtreme.

2) Insert (3) AA batteries in the battery compartment. Be sure the ‘+’ and ‘-‘ of the

batteries are inserted in the same orientation per the picture below and markings on

the Eco Extreme. IMPORTANT: Use new, fully charged & commonly branded batteries.

Improper batteries may result in audio distortion or “hum” from the speaker

3) Replace the battery door.

Listening to your Music

1) Plug the EcoExtreme audio cable into the headset jack of your audio source

(MP3 player, iPod, iPhone or Smartphone)

2) Turn the volume on your audio source up to a normal listening level and choose

‘play’. NOTE: The best sound is created by turning the volume up to about the

80 – 90% level. If the volume on your audio source is too low the volume level out of

the EcoExtreme may be too low. If the volume level on your audio source is at 100%,

the EcoExtreme volume may be distorted at high volume levels.

3) Turn the volume on the EcoExtreme to the desired listening level.

ECOEXTREME

Care, Maintenance & Precautions

1. Although the product is waterproof, it is NOT designed for use under water. Do NOT intentionally submerge the unit underwater.

2. Close both safety latches properly before use, please see ‘figure 2a’ below. If the unit is placed in water without the latches properly

closed, water may enter into the battery compartment and void your warranty.

3. Dry the unit completely before opening. Do NOT open the unit when wet or in a wet environment.

4. To open the safety latch, press and hold the safety lock switch, and then pull the latch out as shown in ‘figure 4a” below.

5. Do NOT apply excessive force to any surfaces of the unit, especially when wet or in a wet environment.

6. Do NOT use or store the unit in places with high temperature (e.g.: directly exposed to

sunlight for a long period, store in a closed car, etc.), significant altitude / temperature

change or strong magnetic fields.

7. Always check the rubber sealing ring to make sure it is placed properly. Please ensure

there are no objects such as dirt, hair, sand, audio wire or particles.

8. Always clean the rubber sealing ring, the exterior and the interior of the unit with a soft

moist cloth before use. Do NOT use any oily solvent or chemicals for cleaning as this

may cause the rubber sealing ring to degrade causing the EcoExtreme to lose its

waterproof properties.

9. If used in or around salt water please rinse off with tap water and clean with a soft moist

cloth after each use.

10. Do NOT mix new and old batteries, or rechargeable and non-rechargeable batteries.

11. Alkaline batteries are recommended for best operation.

12. Always remove the batteries if the unit is not in use for a long period of time.

13. Noise and audio distortion may occur when the batteries are old. Replace the batteries with new alkaline batteries or fully charged

rechargeable batteries.

14. A dirt/ dust filter is below the filter cover in ‘figure 14a’ below. This dirt filter is used to protect the internal air equalization filter (there

is no access to the internal air filter). The internal air filter equalizes the air pressure inside and outside the box. This internal air filter

protects the speaker from damage in the event of high pressurized use such as airplanes or mountain climbing. The dirt filter only

needs to be replaced if there are large amounts of dirt or grim covering the ‘filter cover’.

Please see below for the dirt filter replacement procedure:

Safety Lock Switch

Limited Manufacturer’s Warranty

The EcoExtreme is covered by a 1 year limited warranty that covers defects in workmanship and / or materials for a period of 1 year from original

purchase date. This warranty does not apply to any products which have been abused, neglected, modified or used for a purpose other than the one

for which they were manufactured. Please refer to the above care and maintenance instructions for care details.

The warranty is valid only for the original owner who purchases the unit from an authorized dealer. Transfers do not qualify for warranty protection.

Grace Digital reserves the right to replace any out-of-stock or discontinued product with a comparable product. Discontinued products may not be

available for warranty replacement. Any contents are NOT covered by the limited manufacturer’s warranty. Warranty terms may be revised without

notification at the discretion of the manufacturer. Please visit www.ecoxgear.com for additional product & warranty information. Eco Extreme by

ECOXGEAR, a dvision of Grace Digital Inc.

Visit us on Facebook

The Trademark BlackBerry® is owned by Research In Motion Limited and is registered in the United States and may be pending or

registered in other countries. Grace Digital Inc. is not endorsed, sponsored, affiliated with or otherwise authorized by Research In Motion

Limited. iPod/ iTunes / iPhone / iPod Touch are a trademark Apple Inc. registered in the U.S. and other countries. Android and Android

Market™ are trademarks of Google, Inc. Use of this trademark is subject to Google permission

Safetly Advisory & Warning: follow all instructions. Use only as intended. CAUTION: Do NOT open to repair. A qualified technician must complete repair work.

WARNING: This product may contain chemicals listed in Proposition 65 (http//www.oehha.ca.gov/prop65/prop65_list/Newlist.html)
