EDIFIER TWS5 User manual

www.edifier.com
TWS5
Truly Wireless Stereo Earbuds

EN · Product Description and Accessories
There are different size of ear tips attached in the package, please select
the suitable ones to wear.
Note: Images are for illustrative purposes only and may differ from the
actual product.
USB charging cableEar tips x 3 PairsCharging case
Multi-function button
LED light

■ User Guide
● Charge the Earbuds
During using, if only red light flashes, it indicates the earbuds are at low
battery level, please use them after fully charged.
Charging: place the earbuds in the charging case
Red light lit = charging Red light off =fully charged
Charging time: around 2 hours for a full charging
Warning: The rechargeable batteries that provide power for this product
must be disposed properly for recycling. Do not dispose of batteries in
fire to prevent an explosion.
● Charge the Charging Case
Green lights of the charging case indicate the battery capacity:
When the green lights are all lit, the charging case can charge earbuds
three times;
When only the leftmost green light is lit, it indicates the charging case
is at low battery level, please charge it in time; the green lights will be
all lit after fully charged.
Rated input: 5V 60mA(earbuds) 5V 500mA(charging case)

● Power ON/OFF
1. Power on automatically when taken out from the charging case;
2. Power off automatically while placed in the charging case.
● TWS Pairing of the Left and Right Earbuds
The left and right earbuds have finished TWS pairing before leaving
factory. If the wireless connection fails to resume, please follow the steps
below to re-pair:
1. When there is no TWS connection, respectively double click the
multi-function button of the left and right earbuds to enter TWS
pairing state, the blue light will flash rapidly;
2. After pairing is done, blue lights of both earbuds will flash slowly.
● Bluetooth Connection
1. Two Earbuds Mode
•Open the charging case to take two earbuds out, they will automatically
turn on and make interconnection;
•Press and hold the multi-function button of the left earbud to enter
pairing state, the red and blue lights will flash rapidly;
•Set mobile phone to search and connect to “EDIFIER TWS5”, after
pairing is successful, the blue light will flash slowly.
2. One Earbud Mode
If uses one earbud only, please take the left or right earbud out of the
charging case, and refer to the procedures mentioned in
“Two Earbuds Mode”to pair it with mobile phone.

■ Functional Operation Instructions
● Music Playback
● Call
•Clear pairing records: when with no Bluetooth and TWS connection,
press and hold the multi-function button for 8 seconds.
•Disconnect from mobile phone: when the phone is connected, no
music is playing and no phone conversation, press and hold the
multi-function button for 3 seconds.
Previous track: double click the left earbud
(disabled for One Earbud Mode)
Next track: double click the right earbud
(disabled for One Earbud Mode)
Pause/play: single click
Accept a call: single click
End a call: single click
Decline a call: press and hold

Red light instead of blue light ashes.
•The earbuds are at low battery level, please recharge the earbuds.
Red light is o during charging.
•Ensure the earbuds are correctly placed in the charging case.
•When the earbuds have not been used for long periods of time, the
battery will enter sleep state, it needs to charge about 30 minutes
and then the red light will be lit.
No sound
•Check if the earbuds are operating.
•Check if the earbuds volume are at an appropriate level.
•Check if the earbuds are correctly connected with mobile phone.
•Check if the earbuds are operating within a normal working range.
The call quality of the earbuds are not good.
•Check if mobile phone is in an area with strong signal.
•Ensure the earbuds are within effective distance (10m) and no
obstacle between the earbuds and mobile phone.
When playing music, cannot control pause/play/previous track/
next track via the earbuds.
•Ensure the paired device support AVRCP (Audio Video Remote
Control Profile) profile.
■ FAQs

•Keep the product away from humid places to avoid affecting internal
circuit. Do not use the product during intense exercise or with much
sweat to prevent sweat from dropping into the product to make
damage.
•Do not put the product in places exposed to sun or with high
temperature. High temperature will shorten service life of electronic
components, damage battery and make plastic components deformed.
•Do not put the product in cold places to avoid damaging internal
circuit board.
•Do not dismantle the product. Non-professional personnel may
damage the product.
•Do not drop, strongly vibrate, strike the product with hard object to
avoid damaging internal circuit.
•Do not use drastic chemicals or cleaner to clean the product.
•Do not use sharp objects to scratch product surface to avoid
damaging shell and affecting facade.
■ Maintenance
