EDIFIER R231T User manual

R231T
Multimedia Speaker
User's Manual
R231T
DIGITAL AUDIO ART
DIGITAL AUDIO ART
VOLUME
VOLUME
BASS BASS
Made in China
Edifier Enterprises Canada Inc.

Welcome!
Verythanks forchoosing Edifiermultimedia speaker,it canprovide goodsound formultimedia Computerand home
theater.Before operatingthe system,please readthis manualthoroughly and retain itfor futurereference.
IMPORTANTSAFETY INFORMATION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flashwith arrowhead, withinan equilateral
triangle, is intendedto alert theuser to thepresence of
Uninsulated "dangerous voltage"within the product's
Enclosure that maybe of sufficientmagnitude to constitute
a risk ofelectric shock topersons.
CAUTION: TOPREVENT THERISK OF
ELECTRIC SHOCK, DONOT REMOVE COVER
(OR BACK). NOUSER-SERVICEABLE PARTS
INSIDE. REFER SERVICINGTO QUALIFIED
SERVICE PERSONNEL.
The exclamation pointwithin an equilateral
triangle is intendedto alert theuser to thepresence
of important operatingand maintenance (servicing)
instructions in theliterature accompanying the
Appliance.
SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Install in accordancewith the manufacturer's
Instructions.
Do not usethe speakers nearwater, anddo not
immerse them inany liquid orpour any liquidon them.
Do not blockthe openings inthe speaker cabinets,
never push objectsinto speaker ventsor slots
because of fireor electric shockhazards, and provide
sufficient spacearound the speakersfor proper
ventilation.
The apparatus shallnot be exposedto dripping
or splashing andthat no objectsfilled with liquids,
such as vases,shall be placedon the apparatus.
Do not installnear any heatsources such asradiators,
heat registers, stoves,or other apparatus(including
amplifiers) that produceheat.
Do not defeatthe safety purposeof the polarizedplug.
A polarizedplug has twoblades with onewider than
the other.The wideblade is providedfor your safety. If
the provided plugdoes not fitinto your outlet,consult
an electrician forreplacement of theobsolete outlet.
Protect the powercord from beingwalked on or
pinched particularly atplugs, convenience receptacles,
and the pointwhere they exitfrom the apparatus.
For added protectionduring lightning storms,unplug
the speakers fromthe electrical outletand turn off the
computer.
Unplug this apparatuswhen unused forlong periods
of time.
Water andmoisture ----Do notuse the speakersnear
water, anddo not immersethem in any liquid or pour
any liquid onthem.
Heat---- Place thespeakers away fromall heat sources.
Ventilation ----Do not blockthe openings inthe
speaker cabinets, neverpush objects intospeaker
vents or slotsbecause of fireor electric shock
hazards, and providesufficient spacearound the
speakers for properventilation.
Location ---- Placethe speakers ina stable location
so they willnot fall causingdamage to thespeakers or
bodily harm.
Cleaning ---- Unplugthe speakers fromthe computer
and from theelectrical outlet beforecleaning them
with a dampcloth.
Lightning ----For addedprotection during lightning
storms, unplug thespeakers from theelectrical outlet
and turn off the computer.
Servicing is requiredwhen the apparatushas been
damaged in anyway,such as power-supplycord or
plug is damaged,liquid has beenspilled or objectshave
fallen into theapparatus, the apparatushas been
exposed to rainor moisture, doesnot operate normally,
or has beendropped. Refer allservicing to qualified
service personnel.
Please adjust theaudio to propervolume to avoid
damaging your healthand the system.
One Year LimitedWarranty
Edifier warrants tothe end userthat all ofits computer speakersystems are freefrom defects inmaterial and workmanshipin
the course ofnormal and reasonableuse for aterm of oneyear from thedate of purchase.
This warranty isthe exclusive andonly warranty ineffect relativeto Edifier multimediaspeaker systems andany other
warranties, either expressedor implied, areinvalid. Neither Edifiernor any authorizedEdifier reseller isresponsible for any
incidental damages incurredin the useof the speakers.(This limitation ofincidental or consequentialdamage is not
applicable where prohibited.)
Edifier obligation underthis warranty doesnot apply toany defect, malfunctionor failure asa result ofmisuse, abuse, improper
installation, use withfaulty or improperequipment or theuse of thespeaker systems withany equipment forwhich they werenot
intended.
The terms ofthis warranty applyonly to speakersystems when suchspeakers are returnedto the respectiveauthorized Edifier
reseller where theywere purchased.
Under the termsof this warrantythe original consumerpurchaser has certainlegal rights andmay have otherrights which vary
worldwide.
WARNING:
TO REDUCETHE RISKOF ELECTRICSHOCK,
DO NOTEXPOSE THISAPPARATUS TORAIN
OR MOISTURE.
Notice
Edifier and Edifierlogo areowned byEdifier EnterprisesCanada Inc.and maybe registered. Andother
brand namesand trademarksare theproperty oftheir owners.Edifier assumes no responsibilityfor any
errors thatmay appearin thismanual. Informationcontained hereinis subjectto changewithout notice.
Copyright 2005
All Rights Reserved.
Manual Edition 1.1, Jun 2005
Printed in CHINA

Introduction
Openthepacking
Overview
Please checkthe speakerpattern markedon thepackage (checkedbox beforethe pattern), Please contactthe
seller as soonas if youfind the speakeris not thepattern you want.
Introductionofbackpanel
R231T packinglist:
1 xSub Woofer
2 xsatellite Speakers(withcord)
1 xAudioConnecting Cord
1 xUser's Manual
1 Sub Woofer
2 Satellite Speakers(left andright)
3
4 VolumeControl
5 Power Indicator
6
7 Line InPort
8 Satellite SpeakersC
9 Power Switch
10 Power Cord
11
12 User's Manual
Inverse-phase hole
Super BassControl
onnector
Audio connectingcord
Completely MDFwooden case.
5 Long-throw subwooferdriver.
2 3/4 full rangesatellite speaker.
Power indicate.
Bass andvolume controllers.
Magnetically shieldspeakers.
R231TR231T
Multimedia speaker
Speaker Output
DIGITAL AUDIO ARTDIGITAL AUDIO ART
VOLUME
VOLUME
BASS
BASS

L
CONNECTING
1
2
3 Playing theaudio device
CONNECTING
Connect thesatellite speakersto theoutput splintson theback panelof theSub-woofer.Please noteto match
the color, redto redand whiteto white.
Connect thesubwoofer totheAudio device.
Using Audio connectingcord ,connect theLine-input portof thesubwoofer toLine-out oftheAudio Device
(Such asthe computer, Discman,etc).
Plug theACpower pluginto thewall outletand turnon thepower switch,Now yourspeaker systemis readyfor
Use. Adjusting thevolume controland theSuper bass,thenyou canenjoy themusic.
SPECIFICATIONS:
Total Power Output :
Input Impedance:
Input Sensitive:
Bass Unit:
Tweeter Unit:
Frequency Response:
Dimension(Subwoofer):
Dimension(Satellite):
Gross Weight:
RMS 8W x 2 + 12W
10K Ohm
450 mV
5 Aluminum coil, 4 Ohm
Paper coil, 4 Ohm
48 Hz ~ 20KHz
158(W) x 194(H) x 302(D)mm
86(W) x 162(H) x 121(D)mm
About 5.1 Kg
2 3/4
R
Connected
with AC power
R231TR231T
Multimedia speaker
Speaker Output
WHITE
RED
SOUNDCARDSOUNDCARD
Line InLine In
Spk OutSpk Out
Sound Card
