Edimax EA-IO5D User manual

Indoor Omni
Indoor Omni- -Directional Antenna Directional Antenna
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
China
Beijing Edimax Science &
Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
U.S.A.
Edimax Computer Company
TEL:[phone]
FAX:[phone]
[e-mail]
Latin America
TEL:[phone]
FAX:[phone]
sales_latinameri[email protected]
Europe
Edimax Technology Europe B.V.
TEL:[phone]
FAX:[phone]
[e-mail]
U.K.
Edimax Technology (UK) Ltd.
TEL:[phone]
FAX:[phone]
[e-mail]
5dBi Omni Desktop Antenna
5dBi Omni Desktop Antenna
Detachable Designed for 802.11a/b/g WLAN
Detachable Designed for 802.11a/b/g WLAN
Model NO. ED-IO5D
Frequency Range 2.4 GHz - 2.5GHz ; 4900MHz – 5875MHz
Gain 5 dBi at 11b/g ; 7dBi at 11a
VSWR 2.0 : 1 Max
Impedance 50 Ohms
Power Handling 2 W (cw)
Dimension 219 x 23 x 14 mm (w/o antenna base)
Weight 30 g (w/o antenna base)
Antenna base cable GDC-101B (Black); Length: 1M
Antenna Interface RP SMA Plug
Specification
Features
•Increase wireless signal range 50% and more - up to 40 meter
•Complies with 802.11a/b/g wireless LAN for reduce “dead-spots”
•Direct contact to AP/Router without cable loss, pure gain performance
•Antenna base included 1 meter pigtail for connect to the PC or AP
•The antenna base for PC/AP re-location to pick up the best link quality
•Magnetic designed for office partition and hangable bottom for ceiling
EA-IO5D
Revision 2
Vertical (V Plane)
Horizontal (H Plane)
Notes: Specifications are subjected to change at any time without notice.
