Edimax EA-OO8D User manual

Omni
Omni- -Directional Antenna 8dBi for 11b/g System Directional Antenna 8dBi for 11b/g System
EA
EA- -OO8D OO8D
8dBi Omni-Directional Antenna for 2.4GHz 802.11b/g
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
China
Beijing Edimax Science &
Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
U.S.A.
Edimax Computer Company
TEL:[phone]
FAX:[phone]
[e-mail]
Latin America
TEL:[phone]
FAX:[phone]
sales_latinameri[email protected]
Europe
Edimax Technology Europe B.V.
TEL:[phone]
FAX:[phone]
[e-mail]
U.K.
Edimax Technology (UK) Ltd.
TEL:[phone]
FAX:[phone]
[e-mail]
Specifications
Electrical
Specifications
Frequency Range 2.40 to 2.50
GHz
Gain 8dBi
Polarization Linear, Vertical
VSWR 2.0 Max : 1
Connector N Jack
Power handling 50 Watts
Mechanical
Specifications
Dimension 520 x Ø19 mm
Weight 337 gw
Radome Material Fiber glass
Radome Color Gray-white
Temperature
Storage -40 oC to +80 oC
Survival wind speed 216 km/hr
Vertical (V Plane)
Horizontal (H Plane)
Pattern (H & V Plane)
HPBW (H Plane) 360 degree
HPBW (V Plane) 15 degree
Features
• Comply with IEEE 802.11b/g system standard
• Feasible to avoid potential “dead spots”
• Quick relocation to have best Wi-Fi signal receiving and transmitting
• Provide easy installation mounting kits
Notes: Specifications are subjected to change at any time without notice.
EA-OO8D
