Edison MH-N Series Operating manual

HU10511
MH-80-N
MH-60-N
HU10509
www.mundoclima.com
User and installation manual
English
DESHUMIDIFIER MH-N

1
SAFETY INFORMATION
1. Please read the operating instructions carefully before using your
dehumidifier for the first time and keep them in a safe place.
2. Never immerse the appliance in water or other liquids.
3. Never operate the appliance if a cable or connector has been
damaged, after appliance malfunction or if the appliance was dropped
or otherwise damaged.
4. Electric appliance may only be repaired by qualified personal,
improper repair work can be a source of considerable danger for the
users.
5. Children are not aware of the hazards of electric appliance. Therefore,
never allow children to manipulate electric appliance unless properly
supervised.
6. Disconnect the appliance from mains power whenever it is not in use,
before relocating it, and before cleaning,
7. Operate the appliance only at the voltage specified on the type plate.
8. Use the appliance only in the household, and only for the purpose it
was designed for.
9. Do not place heavy objects on the appliance.
10. To prevent spillage, empty the water tank before relocating the
appliance.
11. Do not tip the appliance to any side as escaping water could damage
the appliance.
12. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the appliance.
13. When the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
14. The devices should be installed at minimum distant of 50CM from
the wall or other obstacle.
15. Unplug the appliance before cleaning.

2
OPERATING INSTRUCTIONS
1. Control panel
2. Air outlet
3. Handle
4. Front panel
5. Back panel
6. Water out hole
7. Water tank

3
CONTROL PLATE DESCRIPTION
OPERATION INSTRUCTION
Starting the unit
1. Firstly, turn the humidity control switch to the “OFF” position.
2. Plug in the dehumidifier.
3. Turn on the humidity control switch(to right side) and turn the same switch
to the reading of the desired humidity(60% in general as shown on
position”4”).
Turning off the unit
1. Turn the humidity control switch to the left side to the “OFF” position and
the power supply is cut off and the unit stops in operation.
2. If the dehumidifier is not in use for a long time, please disconnect the
power cord plug from the outlet.
PRECAUTIONS
1. The dehumidifier shall not operate if the humidity setting is higher than the
ambient humidity.
2. Drain the water in the water storage tank when the water in the tank is full
and the water level indicator light illuminates. And then install the empty
water tank back to its position, so the unit can continue its operation.
3. When the unit stops, you have to wait for 3 minutes before you can restart
the unit to protect the compressor from damage.
4. The humidify and its related position number on the humidity control
switch:

4
CONTROL SWITCH
POSITION NO.
APPROXIMATE
HUMIDITY SETTING
8 20﹪
7 30﹪
6 40﹪
4 60﹪
2 80﹪
5. The operational temperature range for this unit 
6. If the dehumidifier does not start (the operational light does not
illuminate) or the dehumidifier makes intermediate stop on unknown
reasons, please check the plug and power supply for poor connection. If
the plug and power supply are in normal condition, wait for 10 minutes
and restart the unit (because take about 10 minutes to reposition). If the
unit still does not starts in 10 minutes, please contact your local
distributor service station for repair.
7. When the dehumidifier is in operation, the running compressor will
produce heat and make the room temperature higher. This is normal
condition.
8．defrost light on is to indicate the operation of defrost is start. During this
operation mode, compressor will be switched off and air motor will be
turned on.
DRAINAGE INSTRUCTION
The extracted water can be collected by water tank, or drained continuously
with a PVC hose (not available):
is 5-32 .
°C

5
USE OF WATER TANK:
When the water full indicator illuminates, the tank is full, and the compressor
and the fan will stop operation, please empty
the water tank:
1. Remove the water tank as Fig 01. and
empty it.
2. Insert gently the water tank into the unit
reach to its original position.
CONTINUOUS DRAINAGE
1. When you want to use this function,
please Pull out the water tank, and plug
the discharge water pipe in “Water out
hole” (See Fig.02). replace the water tank
into the unit, then you can operate the unit.
Filter Removal
•The filter can be removed from its slot by gripping the filter handle and
sliding it out from the back of the appliance.
• Every 2 weeks, remove the filter and
clean it with warm water, below 40°C.
Allow it to dry naturally and then
replace.
Fig 01
Fig 02

6
Maintenance Instruction
1. The unit is not allow to be located on the floor of soft and uneven surface
when the unit is in operation to avoid occurrence of vibration and noise.
2. Never insert any slim rod and hard object into the unit body to avoid
occurrence of hazard or unit failure.
3. During power off or when not in use for a long time, please pull out the
power cord from the outlet.
4. For a better dehumidifying effect, the areas in front and rear of the unit
should be clear and free from obstacles, which will block the air flow for
the unit.
5. Clean the filtering net once every two weeks (never use alcohol,
gasoline, on or hot water with a temperature of 40 degrees C.

7
SPECIFICATIONS
(CE) N 842/2006:
R410A is a kind of fluorinated greenhouse gases covered by
the Kyoto Protocol.
Its total global warming potential (GWP) is 2088
This marking indicates that this product should not bedisposed with other
household wastes throughout the EU. To pre ent possible harmto the
en ironment or human health from uncontrolled waste disposal, recycle
itresponsibly to promote the sustainable reuse of material resources. To
returnyour used de ice, please use the return and collection systems or
contact theretailer where the product was purchased. They can take this
product foren ironmental safe recycling.
23Kg
6.2A
1350W
MODEL
220-240V~50Hz
80 L/day
5℃-32 ℃
MH-80-N
22,5Kg
5.1A
1150W
60 L/day
MH-60-N
SPECIFICATION
POWER SOURCE
DIMENSION (W x D x H) 481 x 286 x 628mm
TEMP. RANGE FOR USE
MOISTURE REMOVAL
( 30℃RH 80%)
WATER TANK CAPACITY 7.2L
NET WEIGHT
RUNNING CURRENT
RATED POWER
INPUT(EN60335)
