ednet.power
Quick Installation Guide
84290 • 84291 • 84292
84290 – ednet.power Start Kit
(1x WiFi Central Unit + 1x Indoor Smart Plug)
WiFi Central Unit Indoor Smart Plug
84291 – Indoor Smart Plug 84292 – Outdoor Smart Plug

1. Installation
* Please make sure that the WiFi Central Units and Smart phones
are connected to Internet in order to install and control POWER
ON/OFF via Smart Phone anytime anywhere.
Interne
t
WiFi Central Unit
Route
r
Smart Plug 2 Smart Plug 3 Smart Plug 4
Smart Plug 1
I
n
t
erne
t
Smartphone
WiFi
Tablet

2. APP Configuration
2.1 Install APP
iOS V6.0 and above
1. Search and install
“ednet.power” APP to your
iOS devices via APP store
Android V4.0 and above
2. Search and install
“ednet.power” APP to your
Android devices via Google
Play store
3. After APP installation, this
APP icon would be shown
on your smart phone.

2.2 Account sign up, log in, find password, change
password and main interface
1. For the first time, please
click “Sign up” icon.
2. Fill in your e-mail address
and Password, then select
“Sign Up” icon.
ATTN: password is at least 6
words.

3. Fill in your e-mail address
and Password after Sign
Up, then click “Log In” icon.
Please select “forget
password” if you forget your
password.
4. Fill in your e-mail address,
then select “OK”, you can
re-set your password
according to the link in your
mail box.

5. According to the left menu
items are “Main page”,
“Settings” and “About” menu
buttons.
6. Select “Main page” to show
the Scene and Master
device.

7. Select “Settings” to “Change
Password”; or select “Log
Out” to change other
account.
8. On “Change Password”
menu, you can change your
password
[email protected]

2.3 How to Add the “WiFi Plug” to connect to your network
1. Plug in the WiFi Power Plug
into the power socket and
then long press the “Power”
button for more than
5 seconds. Then you will
see the fast red blinking
LED indication while
entering the pairing mode.
2. Then open the ednet.power
APP and press Master
device and go to “+” to add
a new device. Please input
your WiFi network and
password of your router or
Access point at home, and
then select “Start”.

3. You will need to input your
WiFi information, and click
Start button to connect to
your device.
4. You will see “waiting……”
Then when the red LED on the
WiFi plug changes to blue color,
it means the WiFi plug is now
connected to Internet via your
home network.

5. The added item will appear
to your list of Master device.
Then you can control the
Power Plug On or Off as
remote control from your
smart phone.
6. You can also edit the item
by clicking the right Edit
icon.
7. You can edit the item name
here, and click “Save” to
finish or “Cancel” to exit.

8. Long press the device icon
on the APP, then you can
delete the device by
selecting the desired one
and press the bin icon to
“OK”. Please press “OK” to
confirm the deletion.

2.4 Add WiFi Plug to Scene for grouping
1. Click the Scene icon in Main
page, then you can create a
scene by pressing the “+”
sign.
2. First please create the name
of the Scene and select the
related icon or by creating
your own icon by taking a
picture using the “+” sign.

3. Then you will see a new
scene created.
4. Press to enter the new
created Scene for setting
5. Then you can start to group
the WiFi plug and RF plugs
into this Scene together.
First select the WiFi Device
from the list to add into your
Scene. Click “Bind” to
complete this process.

6. For the WiFi plug, you can
also define Timer and Count
Down for scheduled on/off
control.

2.5 Add RF device to Scene
1. Enter from the Main page to
select the Scene icon you
just created.
2. Select RF switch from the list
to add your RF Smart Power
Plug into the Scene. Then
click “Bind”.

3. On the RF Smart Plug side,
please long press the “Learn”
button for 5 seconds.
The RF Smart Plug would
show blinking LED to indicate
ready for pairing.
Then press the “Learn” icon
on the App side to trigger the
learning. You should hear the
power plug on/off clicking
sound to indicate learning
successful.
4. Then you can enter the RF
device now to control power
On/Off remotely.

Technical description Wi-Fi Plug
Frequency Range WiFi 2412 – 2472 MHz
Transmit Power WiFi 15.8 dBm EIRP
Hardware Version V1.0
Software Version V1.0
Technical description RF Plug
Frequency Range 433.92MHz (Rx)
Transmit Power --
Hardware Version V3.2
Software Version V1804
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the
shipping content. If the Declaration of Conformity is missing, you can request it by post under
the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
