Eelink GPT12-L User manual

Standby for 3 Years
Quick Start Guide
GPT12-L

① A Standard GSM SIM Card needed，do not support
CDMA2000 ；
NOTICE
② GPRS of Sim Card must be opened；
Traffic, SMS, Calls and other SIM card service fee charged by operators;
③ Positioning / Remote Power off / Remote command fucntion rely on
the network of base station. Device may not work well if the network
signal is not very good;
④ Product should stay away from fire, high temperature, heat and other
extreme environments;
SIM
Micro SIM
Nano SIM
CDMA2000 WCDMA
GSM

INTRODUCTION
GPS (GPS Satellite signal,Blue)
Quick flash: Searching for GPS
Satellite signals (Not positioned);
Slow flash: Found GPS signals ;
( Positioned by GPS )
Blue LED Long light after charging.
GSM LED ( LBS / Base signal, Red )
Quick flash: Searching for base signals
( Not connect yet) ;
Slow flash: Found base signals ;
( Base Connected and LBS start )
Red LED Long light when charging.
Battery
GPT12-L General View
LED Indicator
IMEI
SIM Slot
Power On/Off

Func�on/Parameter
GPS/LBS double-Positioning mode, support A-GPS
5000mAh Battery , standby for 3 years.
Long Standby mode, wake up for 5 mins a day, then sleep.
Turn to Emergency mode for real time tracking after wake up.
GEO-Fence Alarm, Low battery Alarm.
Track and config device by PC & APP online.
OTA upgrade firmware.
Supports quad bands, i.e. 850/900/1800/1900MHz
LTE TDD: B39(For LTE-M only)
LTE-M/NB-IOT
LTE FDD: B1/B2/B3/B/B5/B8/B12/B13/B18/B19/B20/B26/B28

GPS Positioning Accuracy 5-15m (Depend GPS signal)
About 200m (Depend Bases Density)
1575 MHz
5000 mAh
70 g
96(L)×50(W)×11.2(H)
20%~80%RH
-20℃~65℃
850/900/1800/1900 MHz
<3s，<15s，<60s
LBS Positioning Accuracy
GPS Frequency
GSM Frequency
Hot/Warm/Cold Start Time
Battery Capacity
Dimensions (mm)
Temperature
Humidity
Weight

Q & A
Q：Positioned by GPS / LBS ?
A：GPS called“Global Positioning System”,GPS device can be positioned by GPS
satellite outdoor. Device also can be positioned by base stations of operator
which call LBS ,mainly for assistance positioning.
Q：Location is not accurate?
A：If need accurate positioning, use device outdoor where GPS signal is good and
start GPS tracking mode.
Device indoor mainly positioned by LBS, the accuracy lower than GPS
Q：Standby time can be longer?
A：Device need Internet connection. Standby time will be different by different
using environment and working mode.
Q：Device offline?
A：The conditions below results in offline.
① No balance or No SIM ② No GSM or GSM signal is weak ③ Battery runs out

Insert SIM, Power on, Installaon
Begin Experience of GPS tracker
1
Open cover and insert SIM to device, notice direction.
Lift SIM Slot to remove SIM card.
Stick on board with 3M Velcro.
Turn switch to power on, observe GSM / GPS LED untill it works
fine（See LED explaination）, Close cover.
3M Velcro

Install KEELIN APP, Acvate Device
2
可依恋
®
Scan QR below to download Keelin APP
Launch APP , Scan QR on Label to register & activate device
Begin Experience of Keelin APP
Long Standby GPS Tracker
三年超长待机定位器
GPT12
IMEI：15 digits IMEI SN：6 digits KEY

Long Standby GPS Tracker
EELINK Communication Technology CO.LTD
Address: 5 Floor, Building 10, Changyuan New Material Port, Gaoxin Middle 1st Rd
Mail : [email protected]
Link
e
2
Nanshan District, Shenzhen, Guangdong, CHINA
