EF HB BI 2721 A User manual

EMBRACING FINEST MOMENT
BUILT-IN INDUCTION HOB
Model:
HB BI 2721 A
USER MANUAL

Dear Customer,
Thank you for having purchased and given your preference to our product. This manual
provides a means to make full use of the features of this product. The safety
precauons and recommendaons are also featured in this manual. We recommend
that you read this manual for best performance and to extend the life of your appliance.
Please preserve this manual for future use, in the event that doubts arise relang to
the operaon.
Installaon
Electrical Shock Hazard
•Disconnect the appliance from the mains electricity supply before carrying
out any work or maintenance on it.
•Connecon to a good earth wiring system is essenal and mandatory.
•Alteraons to the domesc wiring system must only be made by a qualied
electrician.
•Failure to follow this advice may result in electrical shock or death.
Cut Hazard
•Panel edges are sharp – be careful
•Failure to use cauon could result in injury or cuts.
Important Safety Instrucons
•Aer having unpacked the appliance, check to ensure that it is not
damaged.
•No combusble material or products should be placed on this appliance at
any me.
IMPORTANT: This appliance is designed and manufactured solely for the cooking
of domestic (household) food and is not suitable for any non-domestic application
and therefore should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used within a non-domestic
environment i.e. A semi commercial, commercial or a communal environment.
SAFETY GUIDELINES

•In order to avoid hazard, this appliance must be installed according to the
instrucons for installaon.
•This appliance is to be properly installed and earthed only by a suitably
qualied person.
•Do not aempt to modify the technical characteriscs of the appliance as
this may become dangerous to use.
•This appliance should be connected to a circuit which incorporates an
isolang switch providing full disconnecon from the power supply.
•WARNING: Use only hob guards designed by the manufacturer of this
appliance on the instrucons for use. The use of inappropriate guards can
cause accidents.
•Failure to install the appliance correctly could invalidate any warranty or
liability claims.
•Regarding the details of installaon, thanks to refer to the secon
<Installaon>.
Operaon and Maintenance
Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop surface is
broken or cracked, switch the appliance o immediately at the main power
supply (wall switch) to avoid the possibility of electric shock, for hob
surfaces of glass-ceramic or similar material which protect live parts and
contact customer service center.
•Switch the cooktop o at the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
Health Hazard
•This appliance complies with electromagnec safety standards for
domesc cooking. It should not interfere with other electronic unit.
•WARNING: Persons with cardiac pacemakers or any other electrical
implants must check with their doctor if they can use the inducon cooking
system.

Hot Surface Hazard
•During use, the appliance and its accessible parts will become hot. Care
should be taken to avoid touching the heang elements.
•Do not let your body, clothing or any item other than suitable cookware
contact the ceramic glass unl the surface is cool down.
•Children less than 8 years of age shall be kept away unless connuously
supervised.
•Metallic objects such as knives, forks, spoons and lids should not be placed
on the hob surface since they can get hot.
•Failure to follow this advice could result in burns and scalds.
Important Safety Instrucons
•Never use the appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Never use the appliance for warming or heang the room.
•Aer use, always turn o the cooking zones and the cooktop as described
in this manual (i.e. by using the touch controls).
•The appliance is not intended to be operated by means of an external mer
or separate remote-control system.
•Do not allow children to play with the appliance or sit, stand, or climb on
it.
•Do not leave children alone or unaended in the area where the appliance
is in use.
•Do not stand on the appliance.
•Do not repair or replace any part of the appliance unless specically
recommended in the manual. All other servicing should be done by a
qualied technician.
•Do not use a steam cleaner to clean your cooktop as the moisture can get
into the appliance therefore making it unsafe
•Do not place or drop heavy or sharp objects on the glass ceramic hob
•Do not use pans with jagged edges or drag pans across the glass surface as
this can scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents to clean
your cooktop, as these can scratch the ceramic glass.
•Please use suitable cookware meant for inducon cooking.
•Please use pans of recommended size (see minimum pan diameter in page
8). It is not advisable to use pans smaller than the cooking zone.

•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid hazard.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilies or lack of
experience and knowledge if they have been given supervision or
instrucon concerning use of the appliance in a safe way and understand
the hazards involved.
•WARNING: Unaended cooking on a hob with fat or oil can be dangerous
and may result in re. NEVER try to exnguish a re with water, but switch
o the appliance and then cover ame e.g. with a lid or a re blanket.
•WARNING: Danger of re: do not store items on the cooking surfaces.
PRODUCT OVERVIEW
1. Ø180mm / 1800-2100 W zone
2. Ø180mm / 1800-2100 W zone
3. Control panel
HB BI 2721 A
CONTROL PANEL
1. ON/OFF Key 2. Power Level Selection
3. Timer Key 4. Key Lock
5. Heating Zone Selection 6. Booster Key
HB BI 2721 A

Before using the induction hob, read this manual carefully and take note on the “Safety
Guidelines” section.
Remove any protective film that may still be on the induction hob.
Induction Cooking System
Inducon cooking is a safe, advanced, ecient, and economical cooking technology.
When cooking zone is selected, the electromagnec circuit produce induced currents
that instantly heat the boom of the cookware which then transfer heat directly to
the food. Cooking takes place with hardly any energy loss between the inducon hob
and food. The glass becomes hot only when the cookware eventually heats it up.
Inducon hob operates only if a correct pan with right features and dimension is placed
on the cooking zone – refer to cookware selecon for inducon cooking.
Cookware for Induction Cooking
•Only use cookware with a base suitable for inducon cooking.
Look for the inducon symbol “ ” on the packaging or at
the boom of the pan.
•Cookware made from the following materials is not suitable
•Pure stainless steel, aluminum or copper without a
magnec base, glass, wood, porcelain, ceramic, and
earthenware.
•To check if the cookware is suitable for inducon,
•Use a magnet. Put the magnet at the boom of the base and if the magnet
scks, the cookware is suitable.
•If you do not have a magnet, put some water in the cookware you want to check
and place on the cooking zone. Follow the steps under ‘To start cooking’. If the
symbol “ ” does not appear on the display and the water is heang, the pan is
suitable.
USE OF INDUCTION HOB
Iron pot
Magnetic circuit
Ceramic glass plate
Induction coil
Induced currents

•The cooking zone will not operate if the cookware diameter is too small (the
symbol “ ” will appear on the display. Follow the recommended cookware
diameter given in the following table to correctly use the cooking zone.
Cooking Zone (mm)
Minimum cookware diameter recommended
Ø 180
140 mm
Note: Some cookware available in the market is not in good quality or has an eecve
ferromagnec area which is smaller than the diameter of the cookware itself. Avoid using
this cookware as the inducon cooktop may not funcon properly or it may cause damage
to the cooktop.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at against the glass, and is the
same size as the cooking zone. Always center your pan on the cooking zone.
Always li pans o the ceramic hob – do not slide, or they may scratch the glass.
Note: Some type of cookware may cause noise during cooking – the noise is normal and does
not mean any malfuncon of the appliance.
Some inducon cookware doesn’t have a complete ferromagnec base:
⚫If the material of the boom of the cookware contains aluminum, the
ferromagnec area will also be reduced. This may mean that the cookware will
not become hot enough or even be detected.

Touch Control
The hob is fitted with induction cooking zones. These zones, shown by the painted
disks on ceramic surface, are controlled by touch control system
Notes:
•The control responds to touch, so you don’t need to apply any pressure.
•Use the ball of your nger, not the p.
•You will hear an acousc sound each me a touch is registered.
•Make sure the control area is always clean, dry and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin lm of water may make the control
dicult to operate.
TO START COOKING
Turn on the main power supply, the buzzer beeps once and all the indicators light up
for 1 second then goes o, indicang that the hob has entered the state of standby
mode.
1. Touch the ON/OFF control. All the indicators
show “- “
2. Place a suitable pan on the desired cooking zone (make sure the boom
of the pan and the surface of the cooking zone is clean and dry.)
3. Select the cooking zone by touching the relevant heang zone,
the indicator next to the selected zone will ash. The default power
level seng is 5.
4. Select a heat seng by touching the slider control (between minimum
“1” and maximum “9”) – slider your nger along the selector or touch at
one point to “jump” to a specic seng. You can modify the heat seng
at any me during cooking.
Note: If a cooking zone is not turned on within 1 minute, the inducon hob will automacally
switch o. You will need to start again at step 1.
OPERATION

TO END COOKING
1. Select desired heang zone.
2. Turn the cooking zone o by scrolling down or direct select
the power level to “0”. Make sure the display shows“0”.
3. Turn the whole cooktop o by touching the ON/OFF control.
Note: Beware of hot surfaces
“H” will be lighted for cooking zone which is hot to touch. It will be turned o when the
cooking zone temperature drops below a preset temperature. It can also be used as an
energy saving funcon as you can heat up the pans by using the residual heat.
BOOSTER FUNCTION
This funcon allows the cooking zone to operate at the BOOSTER maximum power
for maximum of 5 minutes. It could be used, for example, to rapidly heat up large
amount of water.
1. Select the desired zone for booster power
2. Touch the booster control key unl power level display shows “ ”
Deacvate Booster funcon
•Set a dierent power level on the selected cooking zone with booster
acvated.
•Switch o the hob
Note: Booster last for 5 minutes and the cooking zone is automacally set to the power level 9
at the end of the booster funcon

POWER MANAGEMENT
Power sharing funcon limits the maximum power used. The maximum available
power (preset) is shared between the cooking zones. If all zones are turned on, the
power management will not allow all zones to operate at full power but will alternate
the power among all zones so the total power will be equal to the preset maximum
power. The change will be visible on power level displays. The last command given to
a cooking zone takes priority on the power seng.
SAFETY KEY LOCK
This funcon locks the touch control key to prevent unintended use, for example, to
prevent children accidentally switch on the cooking zones.
When the safety key lock is acvated, all the controls except the ON/OFF key are
disabled.
To acvate the key-lock
Touch the key lock control once, the mer indicator will show “Lo” and the key-
lock is acvated.
To deacvate the key-lock, touch and hold the key lock control for 3 seconds
unl the display “Lo” disappears.
When the hob is in lock mode, all the controls are disabled except the ON/OFF key, you can
always turn o the hob with the ON/OFF control. To use the cooktop aer it is switched o,
key-lock protecon has to be deacvated rst.
RESIDUAL HEAT WARNING
When the temperature of the cooking zone is sll hot aer the hob is switched o, the
relevant leer “ ” will be shown on the display as a warning of hot surface. Avoid touching
the cooking zone unl the temperate drops to a safe temperature and the leer “ ” is turned
o.
OVERHEAT PROTECTION
When overheang occurs, the cooking zone will display error code:
E6 – Overheang of cooking zone
E9 – Overheang of IGBT sensor
The inducon hob will stop heang and no power will be delivered to the cooking zone.
Let the cooking zone cool down before using.

OVERFLOW PROTECTION
When the liquid ows to the control panel, the hob will automacally shut down within
10 seconds.
To restart, turn o the power and wipe the area with a clean towel before using.
OPERATION TIME LIMIT OF THE COOKING ZONE
Each cooking zone is switched o automacally aer a maximum preset me if no
further operaon is performed. The maximum preset me limit depends on the set
power level and the default cooking mes are shown in the table below:
Power Level
1
2
3
4
5
6
7
8
9
P
Operaon Time Limit
(hour)
8
8
8
4
4
4
2
2
2
5min
Each touch on the control key will reset the maximum operation time as initial default
value.
TIMER FUNCTION
The mer can be used in two dierent ways:
•As a minute minder. In this case, the mer will not turn any cooking zone o when
the set me is up. It is funcon as a reminder or alarm.
•As an automac switch o mer - to turn one or more cooking zones o aer the
set me is up.
•In both ways, the mer can be set from “01” to “99” minutes.
Using the Timer as a Minute Minder
The minute minder can be acvated if there is no cooking zone selected
1. Make sure that the cooktop is turned on.
Note: The minute minder can be acvated before or aer cooking zone seng is nished.
2. Touch the mer control, the mer display will show “00”,
and the second digit “0”will ash.

3. Set the me by touching the slider control (e.g. set the second digit as“5”)
4. Touch mer control again, the rst digit “0” will ash.
5. Set the me by touching the slider control (e.g. set the rst digit as“9”) and the mer will
be set at 95 minutes.
6. When the me is set, it will begin to count down immediately. The display will show the
remaining me.
7. Buzzer will beep for 30 seconds and the me display will show “- -“
when the seng me is up. The cooking zone will keep operang.
Using the Timer as Cooking Timer
If the mer is set on one zone:
1. Select the heang zone and set the desired power level.
2. Touch the mer control, the mer display will show “00” and the second
digit “0” will ash.
3. Set the me by touching slider control (e.g. set the second digit as“5”)

4. Touch the mer control again, the rst digit “0” will ash.
5. Set the me by touching the slider control (e.g. set the rst digit as“9”), and the me is set
at 95 minutes.
6. When the me is set, it will begin to count down immediately. The display will show the
remaining me.
NOTE: The red dot next to the power level indicator
will be lighted, indicang that relevant zone is selected for mer
7. When cooking mer is ended, the relevant cooking zone will
switch o automacally and other cooking zones will keep operang if
they are turned on previously.
NOTE: The me can be changed at any me by touching the mer control key.
If the mer is set on mulple cooking zone:
•It is possible to set the cooking mer for mulple cooking zone simultaneously. To program
the mer on another cooking zone, repeat the steps as described above.
•When mulple mer is acvated, there will be red dot shown on each relevant cooking
zones. The mer display will show the shortest or minimum me set among the cooking
zones and the red dot of the corresponding zone will ash. For example, if the cooking mer

is set to 15 minutes for one zone and 45 minutes for the other zone, the mer display will
show 15 minutes (shortest between the 2 set zones) and the red dot of the corresponding
zone will ash.
(set to 15 minutes)
(set to 45 minutes)
•Once the countdown is ended, the corresponding zone will switch o automacally. The
mer display will show the next minimum me set (in this case, 30 minutes) and the red
dot of the corresponding zone will ash.
NOTE：Touch the heang zone selecon control at any me, the corresponding mer for the
selected zone will be shown in the mer display
Cancel the mer
•Select the relevant cooking zone.
•Touch the mer control, the power indicator will ash
•Reset the me to “00” using the slider control and the mer will be cancelled

HEAT SETTING
Heat Seng
Suitability
1 - 2
• delicate warming for small amounts of food
• melng chocolate, buer and food that burn quickly
• gentle simmering
3 - 4
• reheang
• simmering
5 - 6
• slow boiling
• Steaming
7 - 8
• frying
• browning of meats
• boiling of water
9
• fast frying
• fast boiling
• grilled steaks

WARNING:
When correctly installed, the product meets all safety requirements laid down for this type of product
category. However, special care should be taken around the underneath of the product as this area is not
designed or intended to be touched and may contain sharp or rough edges that may cause injury
Problem
Acon
Remarks
Soiling on glass
(ngerprints, marks,
stains le by food or
non-sugary spillovers
on the glass)
1. Switch o the main power of
the cooktop o.
2. Apply a cooktop cleaner while
the glass is sll warm (but not
hot!)
3. Rinse and wipe dry with a
clean cloth or paper towel.
•When the power of the cooktop is
switched o, there will be no ‘hot
surface’ indicaon but the cooking
zone may sll be hot! Take extreme
care.
•Heavy-duty scourers, some nylon
scourers and harsh/abrasive cleaning
agents may scratch the glass. Always
read the label to check if the cleaner
or scourer is suitable.
•Never leave cleaning residue on the
cooktop: the glass may become stain
Boil overs, melts, and
hot sugary spills on
the glass
Remove these immediately with a
sh slice, palee knife or razor
blade scraper suitable for ceramic
glass cooktops, but beware of hot
cooking zone surfaces:
1. Switch o the main power
2. Hold the blade or utensil at a
30° angle and scrape the
soiling or spill to a cool area of
the cooktop.
3. Clean the soiling or spillages
with a dish cloth or paper
towel.
4. Follow steps 2 to 4 for ‘Soiling
on glass as above.
•Stains must be removed as soon as
possible. If the stain remains unclean
and become harden, it will be dicult
to remove or even permanently
damage the glass surface.
•Cut hazard: when the safety cover
is retracted, the blade in a scraper
is razor-sharp. Use with extreme
care and always store safely and keep
out of reach of children.
Spillovers on the
touch controls
1. Switch o the main power.
2. Wipe the touch control area
with a clean damp sponge or
cloth.
4. Wipe the area completely dry
with a paper towel.
5. Switch the power on.
•The cooktop may beep and turn itself
o. The touch controls may not
funcon while there is liquid on it.
Make sure you wipe the touch control
area dry before turning the cooktop
power on.
CARE AND MAINTENANCE

Problem
Possible causes
Acon
The cooktop cannot be
turned on.
•No power.
•Make sure the cooktop is
connected to the power
supply and is switched on.
•Check whether there is
power outage
The touch controls are not
responsive.
•The controls are locked.
•Unlock the controls. See
secon ‘Safety Key-lock” for
instrucons.
The touch control is dicult
to operate.
•There may be a spillage of
water over the controls or you
may be using the p of your
nger when touching the
controls.
•Make sure the touch control
area is dry
•Use the ball of your nger
when touching the controls.
Scratch mark on the surface
•Rough-edged cookware.
•Unsuitable, abrasive scourer or
cleaning products being used.
•Use cookware with at and
smooth base. See ‘Choosing
the right cookware’.
•See ‘Care and cleaning’.
Some cookware make
crackling or clicking noises.
•This may be caused by the
construcon of your cookware
(layers of dierent metals
vibrang dierently).
•This is normal and does not
indicate a fault.
The inducon hob makes a
low humming noise when
used on a high heat seng.
•This is due to the normal
operaon of the electronic
control system
•This is normal but the noise
should be reduced or
disappear completely when
heat seng is reduced.
Fan noise coming from the
inducon hob.
•A cooling fan built into your
inducon hob is acvated to
prevent the electronics from
overheang. It may connue to
run even aer you’ve turned
o the inducon hob.
•This is normal and needs no
acon. Do not switch o the
main power while the fan is
running.
Pans do not heat up and
appears in the display.
•Pan cannot be detected as it is
not suitable for inducon
cooking.
•Pan is too small for the cooking
zone or not properly centered
•Use cookware suitable for
inducon cooking. See
secon ‘Choosing the right
cookware’.
•Centre the pan and make
sure that its base matches
the size of the cooking zone.
The inducon hob or a
cooking zone switch o
unexpectedly, an acousc
signal sounded and an error
code is displayed (typically
alternang with one or two
digits in the cooking mer
display).
•Technical fault.
•Please note down the error
code, switch o the main
power of the inducon hob
and contact customer
service center.
TROUBLE SHOOTING

The cooktop is ed with safety devices to protect the electronic system and if an
abnormality occurs, the cooktop will enter into protecve state automacally and
the following error codes will show:
Problem
Possible causes
Acon
E4/E5
Temperature sensor failure
Contact customer service center
E7/E8
Temperature sensor of IGBT failure.
Contact customer service center.
E2/E3
Abnormal supply voltage
Check the incoming power supply.
Turn on power aer the power
supply is back to normal.
E6/E9
Bad inducon hob heat radiaon
Let the cooking zone cool down
before restart the cooking
NOTE: Please do not disassemble the unit by yourself to avoid any dangers and damages to the
inducon hob.
Combi Hob
HB BI 2721 A
Cooking Zones
2 Zones
Supply Voltage
220-240V~
Installed Electric Power
2900W
Product Dimensions L×W×H(mm)
730×420×58
Built-in Dimensions L×W (mm)
680x380
FAILURE DISPLAY AND INSPECTION
TECHNICAL SPECIFICATION

Advice for the Installer
IMPORTANT:
•The cooktop is to be installed only by authorized person according to the current local
regulaons and in observaon of the manufacturer’s instrucons.
•Incorrect installaon, for which the manufacturer accepts no responsibility, may cause
personal injury of damage.
•Always disconnect the cooktop from mains power supply before carrying out any
maintenance operaons or repairs
Product Dimensions
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
HB BI 2721 A
730
420
58
54
680
380
Min 50
Selecon of Installaon Equipment
•The cooktop must be housed in heat-resistant work surface to avoid large deformaon
caused by the heat radiaon.
•Cut the work surface according to the dimension shown in the above table (Fig.1)
•A minimum of 50mm space shall be kept around the hole (refer to “X” in Fig.1)
•Be sure the thickness of the work surface is at least 30mm.
•The base of the cooktop must have direct unrestricted venlaon to the room where the
cooktop is installed. Follow the requirement of gure 2.
Under any circumstances, make sure the cooktop is well venlated and the air inlet and
outlet are not blocked. Ensure the cooktop is in good work state.
Fig.1
INSTALLATION

A
B
C
D
E (Air Exit)
600 mm
Min 50 mm
Min 20 mm
Air Intake
Min 5mm
Note: The safe distance between the cooktop and any wall cupboard or cookerhood
posioned immediate above the cooktop should be at least 600mm.
Before installing the hob, make sure that
•The work surface is heat-resistant, square and level and no structural members interfere
with space requirements.
•If the cooktop is installed above an oven, the oven should have a built-in cooling fan. The
two appliances should be connected to the electrical supply with independent connecons.
•The cooktop cannot be installed directly above cooling equipment, dishwasher or clothes
dryers as the humidity may damage the cooktop electronic system.
•There is adequate air ow for the cooktop to fully funcon – the base of the cooktop must
have direct unrestricted venlaon to the room where the cooktop is installed.
•To use heat-resistant and easy-to-clean nishes (such as ceramic les) for the wall surfaces
surrounding the hob.
•If the hob is installed above a drawer or cupboard space, a thermal protecon barrier is
installed below the base of the hob.
•The installaon shall comply with all clearance requirements and applicable standards and
regulaons.
•An approved isolang switch providing full disconnecon from the main power supply is
incorporated in the permanent wiring, mounted and posioned to comply with the local
wiring rules and regulaons.
•The isolang switch will be easily accessible to the customer with the hob installed.
•To consult local building authories and by-laws if in doubt regarding installaon.
Fig.2
