EFI KM-C1530 Programming manual

Fiery X3e
JOB MANAGEMENT GUIDE

This manual is part of a set of Fiery X3e
™
documentation that includes the following
manuals for users and system administrators:
• The Quick Start Guide summarizes the steps for configuring the Fiery X3e and
printing. It also describes how to access the online documentation.
• The User Software Installation Guide describes how to install software from the
User Software CD to enable users to print to the Fiery X3e, and also describes
setting up printing connections to the Fiery X3e.
• The Configuration Guide explains basic configuration and administration of the
Fiery X3e for the supported platforms and network environments. It also includes
guidelines for setting up UNIX, Windows NT 4.0/2000, and Novell NetWare
servers to provide printing services to users.
• The Printing Guide describes the printing features of the Fiery X3e for users who
send jobs from their computers.
• The Color Guide provides information on managing the color output of the
Fiery X3e. It explains how to calibrate your copier and take advantage of the Fiery
ColorWise
®
color management system, as well as features in ColorWise Pro Tools
™
.
• The Fiery Color Reference addresses concepts and issues associated with managing
color output of the Fiery X3e and outlines key workflow scenarios. In addition, it
offers information on printing color documents from popular Microsoft Windows
and Apple Mac OS applications.
• The Job Management Guide explains the functions of job management utilities,
including Command WorkStation
™
and Fiery DocBuilder Pro
™
, and how you can
use them to monitor and manage jobs on the Fiery X3e. This manual is intended for
an operator, administrator, or a user with the necessary access privileges, to monitor
and manage job flow, and troubleshoot problems that may arise.
• Release Notes provide last-minute product information and workarounds for some of
the problems you may encounter.
About the
Documentation
