SD Card Install
Installation de la Carte SD
Instalación de la Tarjeta del SD
A Instalação do Cartão do SD

44302201
SD Card Installation (C610/C711)
. . . . . . . . 3
Carte SD (C610/C711) . . . . . . . . . . . . . . . . . 9
Tarjeta SD (C610/C711) . . . . . . . . . . . . . . . 15
Cartão SD (C610/C711) . . . . . . . . . . . . . . . 21
SD Card Installation (C530) . . . . . . . . . . . . 27
Carte SD (C530) . . . . . . . . . . . . . . . . . . . . . 33
Tarjeta SD (C530) . . . . . . . . . . . . . . . . . . . . 38
Cartão SD (C530) . . . . . . . . . . . . . . . . . . . . 43

C610/C711 SD Card Installation > 3
SD C ARD I NSTALLATION (C610/C711)
The optional SD card enables collating of printed pages and can
be used to store overlays and macros, fonts, and secure or
proof documents waiting to be printed.
1. Switch the printer off and disconnect the AC power
cable.
2. Press the cover release and open the printer’s top cover
fully.
WARNING!
If the printer has been powered on
recently, the fuser will be hot. This area is
clearly labelled. Do not touch.
OI

C610/C711 SD Card Installation > 4
3. Pull down the MP Tray using the depressions. Lift the
front cover release lever and lower the front cover.

C610/C711 SD Card Installation > 5
4. Loosen the screw (a) securing the right-hand side cover.
Lift the edge of the side cover slightly and pull the cover
away from the printer at the top. Lift the cover slightly
to detach it from the printer. Place it safely to one side.
a

C610/C711 SD Card Installation > 6
5. Notice that the SD card has one chamfered corner.
6. Gently push the SD card into the slot as shown.
7. Locate the retaining clips at the bottom of the side cover
into their rectangular holes near the bottom of the
printer.

C610/C711 SD Card Installation > 7
8. Close the top of the side cover up to the printer and refit
the securing screw loosened in step 4.
9. Close the front cover and the top cover, pressing down
firmly at each side to latch it closed.
10. Reconnect the AC power cable and switch the printer on.

C610/C711 SD Card Installation > 8
11. When the printer is ready, print a menu map as follows:
(a) Press the Enter button.
(b) Press the Menu down button then the Enter
button to select the Print Information menu.
(c) Select Configuration with the Enter button.
(d) Press the Enter button once more to execute the
Configuration menu.
(e) When the Configuration map is printed, press On
Line to exit the menu system. Examine the first
page of the menu map. This should now indicate
that the SD card is installed.

C610/C711 installation de la carte SD > 9
C ARTE SD (C610/C711)
La carte SD optionnelle permet d’assembler les pages
imprimées et peut servir à enregistrer les superpositions, les
macros, les polices mais également à sécuriser l’impression des
documents en attente ou bien à effectuer un tirage d’épreuve
de ces derniers.
1. Mettez l’imprimante hors tension et débranchez le câble
secteur.
OI

C610/C711 installation de la carte SD > 10
2. Appuyez sur le bouton d’ouverture, puis ouvrez le capot
complètement.
3. Tirez le bac MF vers le bas à l’aide des parties creuses.
Soulevez le loquet du capot avant et abaissez le capot
avant.
AVERTISSEMENT !
Si l’imprimante a été mise sous tension
récemment, l’unité de fusion sera très chaude.
Une étiquette est apposée clairement sur cette
partie. Ne pas toucher.
