EFM OLYMPUS User manual

oLYMPUS WIRELESS
BLUETOOTH EARPHONE
PACK CONTENTS:
− 1 x EFM®OLYMPUS WIRELESS
BLUETOOTH EARPHONE
− 1 x 0.3m USB charge cable
− 1 x User manual
− 3 x Earbud hook & earbuds: small/
medium/large
SPECIFICATIONS:
− Frequency: 2.4GHz ~ 2.48GHz
− Sensitivity: 96±3dB
− Impedance: 32Ω±15%
− Driver: 12mm dynamic
FEATURES:
− IPX4 sweat proof
− Handsfree function
− Up to 8 hours of music /
talk time
− Active Noise Control

PRECAUTIONS:
1. Please read the instruction manual before using
this product.
2. Do not modify, repair or dismantle these earbuds.
Doing so may result in fire, electric shocks or a
complete breakdown of these earbuds, etc.
all of which are not covered under warranty.
3. Do not use any diluent or volatile liquids to clean
the earbuds.
4. Do not use the earbuds in a hazardous location.
TECHNICAL SPECIFICATIONS:
Parameter Value
Bluetooth®Specification Bluetooth®4.2
Bluetooth®Profile A2DP v1.3/AVRCP v1.5/
HFP v1.5
RF Range 10 M
Frequency 2.4GHz ~ 2.48GHz
Active Noise Cancelling 150Hz≥-20dB
Playback Time Up to 8 Hours
Charging Time 2 Hours
Weight 22g

CONNECTION DIAGRAM:
Prev Track/
Volume Down
Next Track/
Volume Up
LED Light
Active Noise
Cancelling
Turn On
Play / Pause
Turn O
Answer Call
End Call
Reject Call
Magnetic
earbuds
Ensure to place the
earhook correctly. Do
not cover the speaker
hole.
Earbud & Earhook sizes
Small Medium Large

GENERAL FUNCTIONS:
Desired Result Required Action
Turn on Long press MFB button for 3 seconds
when the device is o. (Blue LED
flashes)
Pairing Press and hold the ‘MFB’ button until
red and blue LED flashing
Play / Pause Short click ‘MFB’ to play when the
device is pausing and short click ‘MFB’
to pause when the device is playing
Next Track/
Volume Up
Long press the ‘ ’ button for
Next Track.
Short press the ‘ ’ button for
Volume Up
Prev Track/
Volume Down
Long press the ‘V’ button for
Previous Track.
Short press the ‘V’ button for
Volume Down
Turn O Press the MFB button for 3 second until
red LED flash then o.
Low Battery
Warning The Red LED flash once every 20 sec
Charging Plug the charger to port of the device
Answer Call Short press the ‘MFB’ button to answer
a call
End Call Short press the ‘MFB’ button end a call
Reject Call Press the ‘MFB’ button for 1 -2 seconds
to reject call when the call is ringing
Voice
Commands
Press the ‘MFB’ button for 1-2 seconds
to activate Siri or Google Assistant
Active Noise
Cancelling
Double press the ‘MFB’ button on
power on mode.
V
V

PAIRING TO MOBILE PHONE OR OTHER DEVICE:
To use your earbuds, you must first pair them with a
phone or a computer. Once your earbuds are paired to a
specific mobile phone or other device, they will remain
paired and automatically connect whenever they are
within range.
Pairing to a Phone and/or Media Device:
• Turn on your phone and ensure its Bluetooth®
function is activated.
• Turn on the earbuds to the pairing mode.
• Search your Bluetooth®devices on your phone
by following the phone’s instructions. Select EFM
Olympus and follow your phone instructions to
select this pairing.
• Blue LED will flash slowly when pairing is successful.
• You can play music; watch TV/movies and play games
with your phone while listening to music from the
device. You can also control the player by operating
the device. For example, increase the volume and
selecting the next track from you music.
Pairing to a Computer and/or Media Device:
• If there is no Bluetooth®function supported by
your computer, a Bluetooth®adapter is necessary.
Fix the adapter with your computer and ensure its
Bluetooth®function is activated.
• Turn on the device and go to the pairing mode.
• Open the Bluetooth®interface on your computer and
select ‘Search your Bluetooth®devices’ function.
Refer to the user manual of the respective device for more
information.
• After a few seconds the ‘EFM Olympus’ should
appear as a discovered device.
• Select ‘EFM Olympus’ and the device will commence
pairing with the earbuds.
• Open your media player to watch TV/movies and play
music and games. The sound will playback on your device.

CHARGING YOUR DEVICE:
The device conveniently connects to an AC charger or
a USB charger with a Micro USB port. Make sure that
your device is fully charged for at least 3 hours before
initial use. Insert one terminal of your charger into the
AC main or USB port of the PC and the other terminal
to the Micro USB. While charging, the red LED light will
display and once charging is complete the indicator LED
turns from red to blue.
WARNING:
• Use only the charging cable supplied to charge the
earbuds.
• If the earbuds have not been in use for more than 12
months they must be recharged.
• Please don’t use the USB charger on any other phone
jack device.

FAQ:
Why is there no power even when the earbuds
have the power on?
A: Ensure the battery has been charged for up to 3
hours before using for the first time. The LED is lit
once it starts charging.
There is no sound when played.
A: Check the connection between your device and
the phone or computer. If the connection is not
established, please pair again.
How do I know if the earbuds are fully charged?
A: blue LED will illuminate to indicate fully charged
earbuds.
REPLACEMENT WARRANTY REGISTRATION
INSTRUCTIONS:
1. Register your product along with your proof of
purchase (receipt) within 14 days at www.myefm.com/
register.
2. If you have any issues with your registered product
during the warranty period, complete the Warranty
Claim form, including any images of the fault, at
www.myefm.com/warranty.
3. Once submitted EFM will review your claim and, if
approved, will ask you to return your faulty product to
EFM Head Oce at your cost. Once EFM receives the
faulty item, your free replacement product will be sent
to you at zero cost within Australia.
• Please Note: Only products registered within 14 days
of purchase with a valid receipt are eligible for the EFM
Registered Warranty Program.
• This program covers EFM products only, not devices
and/or device parts. The 2 Year free replacement
warranty is limited to 1 replacement per verified proof
of purchase registration.
• This warranty is in addition to other rights and remedies
of the consumer under Australian Consumer Law for
Consumer Electronic Devices and Home Entertainment
Products.
1.
2.
3.

oLYMPUS WIRELESS
BLUETOOTH EARPHONE
myefm.com
LIMITED PRODUCT WARRANTY DETAILS:
Our goods come with guarantees that cannot be
excluded under Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and for compensation for any other reasonably
foreseeable loss or damage for up to 12 months from the
date of purchase. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure
(defective goods) within 12 months from the date of
purchase.
To claim under the warranty you need to return the
product to the place of purchase (at your expense) with
a valid receipt or other proof of purchase. If you are not
able to return the product to the place of purchase you
can contact:
EFM Service Department
61 Belmont Avenue, Belmont WA 6104
P: 1300 069 336 (1300 0 MYEFM)
E: [e-mail]
EFM REGISTERED WARRANTY PROGRAM
In addition to a standard 12 month limited warranty, all
registered EFM products are also covered by one full
replacement warranty of 2 or 5 years, dependent on the
product. This registered warranty is against defects in
the goods purchased and does not cover damage caused
by the incorrect use or installation of the goods, or by
modifications, or by accident. To be eligible for the EFM
Registered Warranty Program, follow the instructions
overleaf.
