EFX FLAME 1X User manual

FLAME 1X USER INSTRUCTIONS
Pleasecheck thefixturesappearance andreportanydamagesto yourretailer
immediately.
Set up instructions
1. The Flame 1X is a fire ball spray machine, place the fixture on flat ground
ensuring there is 8-meter distance between the machine and any objects,
height clearance should be at least 3 meters, the whole space around the
fixtureshouldbehavenotanycombustibleobjects.
2. After placing the machine on the ground, attach the power lead and DMX
cable to the machine ensuring thespurt mouthis facingupwards.
3. Use a compatible flame liquid with the fixture. Install the liquid cannister into
the machine using the door to access the flame liquid cannister holder.
Please speak with your retailer for suggested flame liquids compatible with
this fixture.
4. To operate the machine in DMX mode, press the power button up to DMX. If
you want to operate the fixture manually then press the power button down,
WARNING: activating the machine in manual mode can cause injury. It is
advisabletouseDMXcontrol.
DMX 512 mode
The address dialing switch is located on the rear of the fixture. Numbers 1
2 3 4 5 6 7 8 in theaddressdialing switch corresponding with 1 2 4 16
b32 64 128 in DMX 512 controller, use picture belowfor guidance:
To set the DMX address, toggle the switch up according to the DMX
address you wish to set on the fixture.
Forexample,tosetthemachineonDMXaddress1 pushswitch No.1 up.
To setthe machinetoDMXaddress7pushswitchNo.1, 2,3 to upto
“ON”, thiswillset theDMXaddressto“7”.
After connectingtheDMX512controller,pushup channel1 toactivate a fire
ballaction, pushup channel1and2 at thesame timeto createaflamerod
action. This product has automaticpower-down functionafter3 secondsof
firetime.
Manual mode
Press down the power button to ‘manual’, this will activate the flame, this
operation is dangerous and can cause injury.This type ofspray fire, it can
not pass 5sec.)

Technical parameters:
Voltage: AC220V, 10%, 50Hz-60Hz
Fire Height: 1-2m
Power:200W
Coverage: 1 m3
FLAME 1X
USER MANUAL
FIRE SPRAY MACHINE
(DMX 512)
Please read over this manual before operating the fixture.
For technical assistance please contact your retailer or our
technical team on:
[e-mail]
www.efxeurope.com
