Eidos 106-T User manual

Model 106-T
ChairMaster with Toolbox
www.eidosergonomics.com
Warranty: Eidos products are covered by a
limited warranty for a period of ve years from
date of purchase.
*Online Product Registration :
http://www.eidosergonomics.com/product-registration.html
GS-07F-0033U
www.eidosergonomics.com
Eidos Corporation
4755 N. 48th Street, P.O. Box 29666, Lincoln,NE 68504
Telephone: [phone] FAX [phone]
E-mail: [email protected]
Web : www.eidosergonomics.com
Assembly Instructions
Tools Needed: 1/4” wrench or socket
Please read all instructions before assembling
Step 1: Attach toolbox to side mount bracket
with the two 1/4” x .20 x 1/2” bolts and 1/4” nuts.
(They are shipped attached to the toolbox).
Tighten with 1/4” wrench or socket.
Step 2: Attach Toolbox and
Side mount to seat. Align 4 hole pattern from
side mount to seat and tighten 1/4” bolts with
1/4” wrench or socket.
Step 3: The Model 106 standpipe collar placement will determine
the overall seat height. The higher the collar is placed on the standpipe, the lower
the seat height and vice versa. Note: 7.5” measured from the bottom of the standpipe
to the top lip of the collar Is the lowest position ensuring the
standpipe will not touch the ground.
Do not apply weight until the desired position has been congured.
Continued on back

Model 106-T
ChairMaster with Toolbox
www.eidosergonomics.com
Warranty: Eidos products are covered by a
limited warranty for a period of ve years from
date of purchase.
*Online Product Registration :
http://www.eidosergonomics.com/product-registration.html
GS-07F-0033U
www.eidosergonomics.com
Eidos Corporation
4755 N. 48th Street, P.O. Box 29666, Lincoln,NE 68504
Telephone: [phone] FAX [phone]
E-mail: [email protected]
Web : www.eidosergonomics.com
Step 4: Apply weight and enjoy your
Eidos Ergonomics Model 106.
Step 4: Place the standpipe and collar
into the pan by holding the top of the
collar (minimize vertical movement of
collar) apply pressure downward.
Step 3: Place the round, contour or
wide-prole seat onto the gas spring.
