Assembly Instructions
Tools Needed: No tools are needed to assemble the Model 102.
Please read all instructions before assembling
Step 1: Place (B) gas spring
into (C) base and apply pressure
downward.
Step 2: Loosen footring knob
enough to slide (D) footring over and
down 2/3’s of (B) gas spring.Hand
tighten the footring knob.
Step 4: Attach (E) back
rest assembly to (A) seat
mechanism and tighten
backrest adjustment knob.
Step 5: Apply weight by
sitting on the seat (A) and
then enjoy your new Eidos
Ergonomics Model 102.
Step 3: Attach (A) seat to
(B) gas spring by placing and
pressing into place.
A) Seat
B) Gas Spring
C) Base
Optional Casters
D) Footring
E) Backrest Assembly
