- 2 -
1
4
6
7
15
3
2
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 2 31.01.2019 07:16:20

GB
- 15 -
Danger! - Read the operating instructions to reduce the risk of inquiry
This equipment can be used by children of 8 years and older and by
people with limited physical, sensory or mental capacities or those
with no experience and knowledge if they are supervised or have re-
ceived instruction in how to use the equipment safely and understand
the dangers which result from such use. Children are not allowed to
play with the equipment. Unless supervised, children are not allowed
to clean the equipment and carry out user-level maintenance work.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 15 31.01.2019 07:16:22

GB
- 16 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
2. Layout and items supplied
2.1 Layout (Fig. 1)
1. Pressure connector
2. Water drain screw
3. Pressure gauge
4. Suction connector
5. Water ller screw
6. Pressure switch
7. Power switch
2.2 Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suffocating!
• Domestic waterworks
• Original operating instructions
• Safety instructions
3. Proper use
Applications
• Irrigation and watering of green areas, vege-
table beds and gardens.
• Operation of lawn sprinklers.
• For drawing water from ponds, streams, rain-
water butts, rainwater cisterns and springs
• For supplying service water
Transport media:
• For the pumping of clear water (fresh water),
rainwater or light suds/service water.
• The maximum temperature of the fluid must
not exceed +35°C if the equipment is opera-
ted permanently.
• Do not use the equipment to pump inflamma-
ble, gassing or explosive fluids.
• The pumping of aggressive liquids (acids, al-
kalis, silo seepage etc.) as well as liquids with
abrasive substances (sand) must likewise be
avoided.
• This equipment is not designed to convey
drinking water.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse.The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 16 31.01.2019 07:16:22

GB
- 17 -
4. Technical data
GC-WW 1046 N
Mains connection: ..................220-240 V ~ 50 Hz
Power consumption: ................................ 1050 W
Pumping rate max.: ................................ 4600 l/h
Delivery head max.: .................................... 48 m
Delivery pressure max.: ..........0.48 MPa (4,8 bar)
Suction height max.: ...................................... 8 m
Suction
connection: ................. approx. 42 mm (1¼״) AG
Pressure
connection: ................... approx. 33.3 mm (1״) IG
Water temperature max.: ............................ 35°C
Tank capacity: ............................................... 20 l
Cut-in pressure approx.: ........ 0.15 MPa (1.5 bar)
Cut-out pressure approx.: ........... 0.3 MPa (3 bar)
Protection type: ........................................... IPX4
GC-WW 1250 NN
Mains connection: ................. 220-240 V ~ 50 Hz
Power consumption: ................................ 1200 W
Pumping rate max.: ................................ 5000 l/h
Delivery head max.: .................................... 50 m
Delivery pressure max.: ............0.5 MPa (5.0 bar)
Suction height max.: ...................................... 8 m
Suction
connection: .................. approx. 42 mm (1¼״) AG
Pressure
connection: .................... approx. 33.3 mm (1״) IG
Water temperature max.: ............................. 35°C
Tank capacity: ................................................20 l
Cut-in pressure approx.: .........0.15 MPa (1.5 bar)
Cut-out pressure approx.: ........... 0.3 MPa (3 bar)
Protection type: ........................................... IPX4
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
As a basic principle, we recommend the use of
a preliminary filter and a suction set with suction
hose, intake cage and non-return valve, in order
to prevent long priming periods and unnecessary
damage to the pump as a result of stones and
solid foreign bodies.
5.1 Connecting the intake line
• Fasten the suction hose (at least approx. 19
mm (¾“) plastic hose with spiral reinforce-
ment) to the suction connection approx. 42
mm (1¼״) AG of the equipment either directly
or via a threaded nipple.
• The suction hose used should be equipped
with an intake valve. If the intake valve cannot
be used, a non-return valve should be ins-
talled in the intake line.
• Position the intake line so that it rises from
the water withdrawal point to the equipment.
Avoid positioning the intake line higher than
the pump, as this would delay the escape of
air bubbles from the intake line and impede
the priming process.
• Install the intake and discharge lines in such
a way that they do not exert any mechanical
pressure on the equipment.
• The intake valve should be low enough in the
water to ensure that if the water level falls, the
unit will not run dry.
• A leaking intake line will draw in air and there-
fore not draw in any water.
• Prevent the intake of foreign bodies (sand,
etc.). If necessary, install a coarse filter for
this purpose.
5.2 Connecting the discharge line
• The discharge line (min. 19 mm (¾“)) must
be connected to the approx. 33.3 mm (1״) IG
female thread discharge line connector of the
equipment either directly or with the aid of a
threaded nipple.
• With the right couplings it is also possible, of
course, to use a 13 mm (½“) delivery hose.
The smaller delivery hose results in a lower
delivery rate.
• During the priming operation, fully open any
shut-off mechanisms (spray nozzles, valves,
etc.) in the pressure line so that the air can
escape without obstruction.
5.3 Electrical connections
• Connect the appliance to a 220-240 V ~ 50
Hz socket-outlet with earthing contact. Mini-
mum fuse 10 ampere.
• A built-in thermostat protects the motor from
overloading and blocking. The pump is swit-
ched off automatically by the thermostat if
overheating occurs and is switched on again
automatically after cooling.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 17 31.01.2019 07:16:22

GB
- 18 -
6. Operation
• Install the equipment on a solid and level
surface.
• Fill the pump housing with water via the water
filler screw (5). Filling the intake line will acce-
lerate the priming process.
• All the shut-off devices in the discharge line
(spray nozzle, valves etc.) must be fully ope-
ned during intake in order to permit all air to
escape from the intake line.
• Connect the mains cable.
• Switch on the equipment with the power
switch (7) - water can be suctioned in for up
to 5 minutes (maximum suction height).
• The equipment will shut down when the cut-
out pressure of 3 bar is reached.
• After a loss of pressure due to water con-
sumption the equipment will cut in again auto-
matically (cut-in pressure approx. 1.5 bar).
• After finishing the work, switch off the equip-
ment with the power switch (7).
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
The equipment is almost completely maintenance
free. In order to ensure a long service life, howe-
ver, we recommend that you regularly check and
care for the product.
Danger!
The equipment must be disconnected from the
power supply (pull the power plug) prior to perfor-
ming any maintenance.
8.1 Servicing
• If the equipment becomes clogged, connect
the discharge line to the water line and dis-
connect the suction hose. Open the water
line. Switch on the equipment several times
for approx. two seconds. This should resolve
the majority of clog-related problems.
• Inside the pressure tank is an expandable
water sack and an air compartment whose
maximum pressure should lie at approx. 1.5
bar. Pumping water into the water sack cau-
ses the sack to expand so that the pressure in
the air compartment rises to switch-off level. If
the air pressure is too low, you should raise it.
To do so, unscrew the plastic lid from the tank
and top up the pressure to the correct level
using a tyre pump with meter at the valve.
Important: Be sure to completely empty
the water bag first using the water drain
screw (2).
• Replacing the mains cable: Important:
Disconnect the equipment from the power
supply! A defective mains cable may only be
replaced by a qualified electrician.
• There are no parts inside the equipment
which require additional maintenance.
8.2 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
• Type of machine
• Article number of the machine
• Identification number of the machine
• Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 18 31.01.2019 07:16:22

GB
- 19 -
9. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled.The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should be
taken to a suitable collection center for proper dis-
posal. If you do not know the whereabouts of such
a collection point, you should ask in your local
council offices.
10. Storage
Store the equipment and accessories in a dark
and dry place at above freezing temperature. The
ideal storage temperature is between 5 and 30 °C.
Store the electric tool in its original packaging.
• If the pump is not going to be used for a long
time or has to be removed for the winter
months, rinse it out with water, empty it com-
pletely and allow it to dry.
• The equipment must be completely drained
before it is subjected to frost.
• After long stoppages, make sure the rotor
turns correctly by briefly switching the pump
on and off.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 19 31.01.2019 07:16:22

GB
- 20 -
11. Troubleshooting guide
Faults Cause Remedy
Motor fails to start
up
- No mains voltage
- Pump rotor blocked -thermostat
switched off
- Check voltage
- Dismantle and clean pump
No intake - Intake valve not in water
- Pump chamber without water con-
nection
- Air in intake line air-tight
- Intake valve leaks
- Strainer (intake valve) blocked
- Max. suction height exceeded
- Immerse intake valve in water
- Fill water into intake
- Make sure intake line is close
- Clean intake valve
- Clean strainer
- Check suction height
Inadequate delivery
rate
- Suction height too high
- Strainer dirty
- Water level falling rapidly
- Pump performance diminishedby
contaminants part
- Check suction height
- Clean strainer
- Place the suction hose at a deeper
level
- Clean pump and replace wearing
Thermostat swit-
ches pump off
- Motor overloaded - friction caused
by foreign substances too high
- Dismantle and clean pump. Prevent
intake of foreign substances (lter)
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 20 31.01.2019 07:16:22

GB
- 21 -
For EU countries only
Never place any electric power tools in your household refuse.
To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and
its implementation in national laws, old electric power tools have to be separated from other waste and
disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to the manufacturer, the owner of the electrical equipment
must make sure that the equipment is properly disposed of if he no longer wants to keep the equipment.
The old equipment can be returned to a suitable collection point that will dispose of the equipment in
accordance with the national recycling and waste disposal regulations.This does not apply to any ac-
cessories or aids without electrical components supplied with the old equipment.
The reprinting or reproduction by any other means, in whole or in part, of documentation and papers
accompanying products is permitted only with the express consent of the iSC GmbH.
Subject to technical changes
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 21 31.01.2019 07:16:22

GB
- 22 -
Service information
We have competent service partners in all countries named on the guarantee certicate whose contact
details can also be found on the guarantee certicate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* Coarse lter, lter cartridge, water bag (memb-
rane)
Consumables*
Missing parts
* Not necessarily included in the scope of delivery!
In the effect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Ple-
ase ensure that you provide a precise description of the problem and answer the following questions in
all cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 22 31.01.2019 07:16:22

GB
- 23 -
Warranty certicate
Dear Customer,
All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the
unlikely event that your device develops a fault, please contact our service department at the address
shown on this guarantee card. You can also contact us by telephone using the service number shown.
Please note the following terms under which guarantee claims can be made:
1. These guarantee terms apply to consumers only, i.e. natural persons intending to use this product
neither for their commercial activities nor for any other self-employed activities. These warranty
terms regulate additional warranty services, which the manufacturer mentioned below promises to
buyers of its new products in addition to their statutory rights of guarantee.Your statutory guarantee
claims are not affected by this guarantee. Our guarantee is free of charge to you.
2. The warranty services cover only defects due to material or manufacturing faults on a product which
you have bought from the manufacturer mentioned below and are limited to either the rectication of
said defects on the product or the replacement of the product, whichever we prefer.
Please note that our devices are not designed for use in commercial, trade or professional applica-
tions. A guarantee contract will not be created if the device has been used by commercial, trade or
industrial business or has been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly instructions or due to incorrect
installation, a failure to follow the operating instructions (for example connecting it to an incorrect
mains voltage or current type) or a failure to follow the maintenance and safety instructions or by ex-
posing the device to abnormal environmental conditions or by lack of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example overloading the device or the
use or unapproved tools or accessories), ingress of foreign bodies into the device (such as sand,
stones or dust, transport damage), the use of force or damage caused by external forces (for ex-
ample by dropping it).
- Damage to the device or parts of the device caused by normal or natural wear or tear or by normal
use of the device.
4. The guarantee is valid for a period of 24 months starting from the purchase date of the device. Gu-
arantee claims should be submitted before the end of the guarantee period within two weeks of the
defect being noticed. No guarantee claims will be accepted after the end of the guarantee period.
The original guarantee period remains applicable to the device even if repairs are carried out or
parts are replaced. In such cases, the work performed or parts tted will not result in an extension
of the guarantee period, and no new guarantee will become active for the work performed or parts
tted. This also applies if an on-site service is used.
5. To make a claim under the guarantee, please register the defective device at: www.isc-gmbh.info.
Please keep your bill of purchase or other proof of purchase for the new device. Devices that are
returned without proof of purchase or without a rating plate shall not be covered by the guarantee,
because appropriate identication will not be possible. If the defect is covered by our guarantee,
then the item in question will either be repaired immediately and returned to you or we will send you
a new replacement.
Of course, we are also happy offer a chargeable repair service for any defects which are not covered by
the scope of this guarantee or for units which are no longer covered.To take advantage of this service,
please send the device to our service address.
Also refer to the restrictions of this warranty concerning wear parts, consumables and missing parts as
set out in the service information in these operating instructions.
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 23 31.01.2019 07:16:22
