Eizo DuraVision FDX1502T User manual

Important
Please read this “User’s Manual”, and “Setup Manual” (separate
volume) carefully to familiarize yourself with safe and e󰀨ective
usage.
•Refer to the “Setup Manual” for information on the installation /
connection of the monitor.
•For the latest product information including the “User’s Manual”,
refer to our web site :
www.eizoglobal.com
Touch Panel Color LCD Monitor
User’s Manual

This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
e󰀨ort has been made to ensure that this manual provides up-to-date information, please note that EIZO
product specications are subject to change without notice.
2

CONTENTS
CONTENTS............................................................. 3
Chapter 1 Introduction....................................... 4
1-1. Features ......................................................... 4
Chapter 2 Basic Adjustment / Setting .............. 5
2-1. Adjusting Volume.......................................... 5
2-2. Switching the Input Signal........................... 5
2-3.
Switching the Display Mode (Color Mode) ... 5
2-4. Adjusting Brightness ................................... 6
Chapter 3 Advanced Adjustment / Setting ...... 7
3-1. Basic Operation of the Setting Menu ......... 7
3-2. Setting Menu Functions ............................... 8
●Color Adjustment ............................................. 8
●Signal Settings ...............................................10
●Preference Settings .......................................13
●Language .......................................................14
●Information .....................................................14
Chapter 4 Administrator Settings................... 15
4-1. Basic Operation of the "Administrator
Settings" Menu.............................................15
4-2. Functions of the "Administrator
Settings" Menu.............................................16
Chapter 5 Troubleshooting.............................. 17
5-1. No Picture .....................................................17
5-2. Imaging Problems (for both digital and
analog)...........................................................18
5-3. Imaging Problems (for analog only) ..........19
5-4. Touch Panel Problems ............................... 20
5-5. Other Problems........................................... 20
Chapter 6 Reference ........................................ 21
6-1. Connecting Multiple PCs ............................21
●Connection examples ....................................21
6-2. Compatible Resolutions ............................ 22
Appendix.............................................................. 23
Trademark ............................................................... 23
License .................................................................... 23
3
CONTENTS

Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 15″ LCD
• Supports a resolution of 1024 × 768
• LED backlight LCD panel
The LED backlight provides better power e󰀩ciency and reduced power consumption compared to
existing uorescent backlight LCD panels. No mercury, a hazardous substance, is used.
• A design without ventilation holes in the main unit makes dust penetration di󰀩cult.
• Built-in stereo speaker (*For the panel mount type, this is not built-in.)
• Supports a wide range of operating temperatures and operating humidity
- Operating temperature : 0°C to 50°C (32°F to 122°F)
- Operating humidity: 20% to 90% R.H. (no condensation)
• A 3-year long-term warranty for 24-hour continuous use
• Displays HDCP (High-bandwidth Digital Protection) protected contents
• Touch Panel provided
- Detection method: Analog resistive technology
- Communication: USB, RS-232C (* Cannot be used at the same time.)
Attention
• In the default settings, RS-232C serial transfer is disabled. To connect a RS-232C cable and use the
touch panel, you need to change the settings (page 16).
4Chapter 1 Introduction

Chapter 2 Basic Adjustment / Setting
2-1. Adjusting Volume
This function allows you to adjust the volume.
Attention
• For the panel mount type, this cannot be adjusted.
Adjustable range
0 to 30
Procedure
1. Press .
The sound volume menu appears.
2. Use or for adjustment.
3. Press to exit the adjustment.
2-2. Switching the Input Signal
When a monitor has multiple signal inputs, the signal to display on-screen can be changed.
Setting method
1. The input signal switches each time you press .
When the signal is switched, the active input port name appears at the top right corner of the screen.
2-3. Switching the Display Mode (Color Mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
User1 Select this to dene a desired set of parameter settings.
User2
sRGB Suitable for color matching with sRGB compatible peripherals.
Procedure
1. Press .
The mode menu appears at the bottom left of the screen.
2. The mode among the list is highlighted in turn each time is pressed.
You can switch the mode with or while the mode menu is displayed.
User1←→User2←→sRGB
3. Press when you are nished with the settings.
5
Chapter 2 Basic Adjustment / Setting

2-4. Adjusting Brightness
The brightness of the screen can be adjusted to suit the installation environment or personal preference.
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD
back panel).
Adjustable range
0 to 100
Procedure
1. Press .
The brightness adjustment screen appears.
2. Use or for adjustment.
3. Press to exit.
6Chapter 2 Basic Adjustment / Setting

Chapter 3 Advanced Adjustment / Setting
This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu.
For basic functions, see "Chapter 2 Basic Adjustment / Setting" (page 5).
3-1. Basic Operation of the Setting Menu
1.
Displaying the Setting menu
1. Press .
The Setting menu appears.
2.
Adjustment / Setting
1. Use to select a menu to adjust or set, and press .
The Sub menu appears.
2. Use to select an item to adjust or set, and press .
The adjustment / setting menu appears.
3. Use to perform adjustment / setting, and press to apply the setting.
The Sub menu appears
7
Chapter 3 Advanced Adjustment / Setting

3.
Exiting
1. Select "Return" from the Sub menu, and press .
The Setting menu appears.
2. Select "Exit" in the Setting menu, and press .
The Setting menu exits.
Note
• The Setting menu can also be exited by pressing twice quickly.
3-2. Setting Menu Functions
●Color Adjustment
The color mode settings can be adjusted according to personal preference. The adjusted settings are
saved for each color mode.
Functions that can be adjusted di󰀨er depending on the color mode.
√: Adjustable -: Not adjustable
Function
Color Mode
User1
User2 sRGB
Brightness √ √
Temperature √-
Gamma √-
Advanced
Settings
Hue √-
Saturation √-
Gain √-
Reset √ √
Attention
• It takes about 30 minutes for the monitor display to stabilize. Please wait 30 minutes or more after power to
the monitor has been turned on before adjusting the monitor.
• The same image may be observed in di󰀨erent colors on multiple monitors due to monitor-specic
characteristics. Make ne color adjustments visually when matching colors across multiple monitors. Follow
the procedure below to adjust and match colors across multiple monitors.
1. Display a white screen on each monitor.
2. Use one of the monitors as a visual reference point to make adjustments to the "Brightness",
"Temperature", and "Gain" of the other monitors.
8Chapter 3 Advanced Adjustment / Setting

Setting
Value Description
Brightness 0 to 100 The screen brightness is adjusted by changing the brightness of the
backlight (light source from the LCD back panel).
Temperature O󰀨
4000 K to
10000 K
(in
increments of
500 K. 9300 K
is included.)
Adjust the color temperature.
The color temperature is normally used to express the hue of "White"
and/or "Black" with a numerical value. The value is expressed in
degrees "K" (Kelvin).
The screen becomes reddish at low color temperatures and bluish at
high color temperatures, similar to the temperatures of a ame. A gain
preset value is set for each color temperature setting value.
Note
• The value shown in "K" is available only as a reference.
• "Gain" allows you to perform more advanced adjustment.
• If set to "O󰀨", the image is displayed in the preset color of the
LCD panel (Gain: 100 for each RGB channel).
• When the gain is changed, the color temperature setting changes
to "O󰀨".
Gamma 1.8
2.0
2.2
Adjust the gamma.
While the brightness of the monitor varies depending on the video
level of the input signal, the variation rate is not directly proportional
to the input signal. Maintaining the balance between the input signal
and brightness of the monitor is referred to as "Gamma correction".
Note
• If "sRGB" is selected for the color mode, "sRGB" is displayed for
the gamma value.
Advanced
Settings
Hue -50 to 50 Adjust the hue.
Note
• Using this function may prevent some color gradations from being
able to be displayed.
Saturation -50 to 50 Adjust the color saturation.
Note
• Using this function may prevent some color gradations from being
able to be displayed.
• The minimum value (-50) changes the screen to monochrome.
Gain 0 to 100 The brightness of each red, green, and blue color component is
referred to as "Gain". The hue of "white" can be changed by adjusting
the gain.
Note
• Using this function may prevent some color gradations from being
able to be displayed.
• The gain value changes according to the color temperature.
• When the gain is changed, the color temperature setting changes
to "O󰀨".
Reset - Reset any color adjustments for the currently selected color mode
back to the default settings.
9
Chapter 3 Advanced Adjustment / Setting

●Signal Settings
Set the details regarding input signal, such as the screen display size and color format.
• For D-Sub input
• For HDMI / DisplayPort input
Function Setting Value Description
Picture Expansion Auto *1
Full Screen
Aspect Ratio
Dot by Dot
The screen size of the monitor display can be changed.
• "Auto"
The monitor automatically changes the screen size
according to the aspect ratio and resolution information
from the PC.
• "Full Screen"
Images are stretched to full screen. Since aspect ratios are
not maintained, images may be distorted in some cases.
• "Aspect Ratio"
Images are enlarged to full screen without changing the
aspect ratio. Since aspect ratios are maintained, blank
horizontal or vertical borders may appear.
• "Dot by Dot"
Displays the image at the set resolution or size specied by
the input signal.
Note
• Example settings
- Full Screen
- Aspect Ratio
- Dot by Dot
(input signal)
10 Chapter 3 Advanced Adjustment / Setting
