Eizo FlexScan S2100 User manual

Important
Please read PRECAUTIONS, this User’s
Manual, and the Setup Manual (separate
volume) carefully to familiarize yourself with safe
and effective usage.
CONTENTS
Chapter 1 Features and Overview
1-1 Features
1-2 Buttons and Indicators
1-3 Functions and Basic Operation
Chapter 2 Settings and Adjustments
2-1 Utility Disk
2-2 Screen Adjustment
2-3 Color Adjustment
2-4 Off Timer Settings
2-5 Screen Size Selection
2-6 Power Indicator/EIZO Logo Display Setting
2-7 Locking Buttons
2-8 Setting Adjustment menu Display
2-9 Viewing Information/Setting Language
2-10 Setting BrightRegulator
2-11 Resumption of Default Setting
Chapter 3 Connecting Cables
3-1 Connecting Two PCs to the Monitor
3-2 Connecting Peripheral USB Devices
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm
5-2 Power Saving Mode
5-3 Cleaning
5-4 Specifications
5-5 Glossary
5-6 Preset Timing
• Please refer to the Setup Manual
for basic information ranging from
connection of the monitor to a PC to
using the monitor.
• The latest User’s Manual is available
for download from our web site:
http://www.eizo.com

2
This product has acquired the TCO standard that relates to the safety, ergonomics, environment and so forth of office
equipment. For an overview of the TCO, refer to our web site.
http://www.eizo.com
This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside
this region, the product may not perform as stated in the specifications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior
arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been
made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are
subject to change without notice.
VESA is a registered trademark or a trademark of the Video Electronics Standards Association in the United States and other countries.
Windows, Windows Vista, Windows Media, SQL Server, and Xbox 360 are registered trademarks of Microsoft Corporation in the United
States and other countries.
Apple, Mac, Macintosh, iMac, eMac, Mac OS, MacBook, PowerBook, ColorSync, QuickTime, and iBook are registered trademarks of
Apple Inc.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiForce, RadiCS, RadiNET, Raptor, and ScreenManager are
registered trademarks of EIZO Corporation in Japan and other countries.
All other company and product names are trademarks or registered trademarks of their respective owners.

3
Notice for this monitor
This product is suited to general purposes like creating documents, viewing multimedia content.
This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used
outside the region, it may not operate as specified in the specifications.
This product may not be covered by warranty for uses other than those described in this manual.
The specifications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specified by us
Only use optional products manufactured or specified by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” on page 24).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact
your dealer.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt to
brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until the
dew condensation disappears, otherwise it may cause some damage to the monitor.
To use the monitor comfortably
An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the
environmental conditions.
Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

4CONTENTS
CONTENTS
Notice for this monitor .............................................. 3
To use the monitor comfortably ............................... 3
CONTENTS ............................................................. 4
Chapter 1 Features and Overview ..................... 5
1-1 Features ............................................................ 5
1-2 Buttons and Indicators .................................... 5
1-3 Functions and Basic Operation
...................... 6
Chapter 2 Settings and Adjustments ................ 8
2-1 Utility Disk ........................................................ 8
● Disk contents and software overview
................. 8
● To use ScreenManager Pro for LCD .................. 8
2-2 Screen Adjustment .......................................... 9
Digital Input
............................................................ 9
Analog Input .......................................................... 9
2-3 Color Adjustment ........................................... 12
Simple adjustment [FineContrast mode] .......... 12
● FineContrast Mode
........................................... 12
● To select FineContrast mode name .................. 12
Advanced Adjustments [Adjustment menu] ..... 13
● To select an appropriate mode for images ....... 13
● To set/adjust color ............................................ 14
2-4 Off Timer Settings .......................................... 14
● To set monitor power-off time [Off Timer] ......... 14
2-5 Screen Size Selection .................................... 15
● To change screen size [Screen Size] ............... 15
● To adjust brightness of non-display area
[Border Intensity] .............................................. 15
2-6 Power Indicator/EIZO Logo Display Setting 16
● To turn off the Power indicator while a screen is
displayed [Power Indicator] .............................. 16
● To display EIZO logo
[EIZO Logo Appearing Function] ...................... 16
2-7 Locking Buttons ............................................ 16
● To lock operation [Adjustment Lock] ................. 16
2-8 Setting Adjustment menu Display ................ 17
● To update menu settings [Menu Size/Menu
Position/Menu Off Timer/Translucent/
Orientation] ....................................................... 17
2-9 Viewing Information/Setting Language ....... 18
● To check settings, usage time, etc.
[Information] ..................................................... 18
● To set a language to be displayed
[Language] ....................................................... 18
2-10 Setting BrightRegulator ................................ 18
● To set automatic brightness adjustment
[BrightRegulator] .............................................. 18
2-11 Resumption of Default Setting ..................... 18
● To reset color adjustment [Reset] ..................... 18
● To reset all settings [Reset] .............................. 18
Chapter 3 Connecting Cables .......................... 19
3-1 Connecting Two PCs to the Monitor ............ 19
● To set auto-switching of input signals
[Input Signal] .................................................... 20
3-2 Connecting Peripheral USB Devices ........... 20
Chapter 4 Troubleshooting ............................... 21
Chapter 5 Reference ......................................... 23
5-1 Attaching an Arm ........................................... 23
5-2 Power Saving Mode
....................................... 24
5-3 Cleaning .......................................................... 24
5-4 Specifications ................................................ 25
5-5 Glossary ......................................................... 27
5-6 Preset Timing ................................................. 29

5
Chapter 1 Features and Overview
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• Dual-input compliant (DVI-I and D-sub mini 15-pin connectors)
• DVI digital input (TMDS) compliant
• Horizontal scan frequency: Analog: 24 - 80 kHz, Digital: 31 - 76 kHz
• Vertical scan frequency: Analog: 49 - 76 Hz (1600 × 1200: 49 - 61 Hz)
Digital: 59 - 61 Hz (VGA text: 69 - 71 Hz)
Resolution: 1600 dots × 1200 lines
• Compatible with frame synchronization mode (59 - 61 Hz)
• Smoothing (soft - sharp) function for adjustment of enlarged images
• BrightRegulator function incorporated
• FineContrast mode to allow the best mode for screen display
• The utility software “ScreenManager Pro for LCD” (for Windows) to control
the monitor from a PC with mouse/keyboard is included (refer to the EIZO
LCD Utility Disk).
• Height adjustable stand
• Ultra slim bezel
• Portrait/Landscape display available
1-2 Buttons and Indicators
Buttons
1. Adjustment menu (*ScreenManager ® )
2. Senser (BrightRegulator)
3. Input signal selection button
4. Mode button
5. Auto adjustment button
6. Enter button
7. Control buttons (Left, Down, Up, Right)
8. Power button
9. Power indicator
Indicator status Operation status
Blue The screen is displayed
Yellow Power saving
Off Power off
* ScreenManager ® is an EIZO’s nickname of the Adjustment menu.
NOTE
• While a screen is displayed, the blue
power indicator can be turned off (see
“To turn off the Power Indicator while
a screen is displayed,” on page 16).
• For the power indicator status with
“Off Timer” set, refer to “To set
monitor power-off time” on page 14.
NOTE
• This monitor supports the Portrait/
Landscape display. (The panel can be
turned 90 degrees clockwise.)
• The stand of the unit can be replaced
with an arm or another stand. (Refer
to “5-1 Attaching an Arm” on page
23.)
• Select “Portrait” for <Orientation>
on <Others> menu of the Adjustment
menu to turn the menu 90 degrees.

6Chapter 1 Features and Overview
1-3 Functions and Basic Operation
To adjust the screen and color
1 Screen Adjustment
(Automatic Adjustment)
Press .
Press again while the message window
is displayed.
Adjustment menu (Refer to page 9 for operation)
• The Adjustment menu and the FineContrast mode name
cannot be displayed at the same time.
Color Adjustment
Simple Adjustment [FineContrast mode]
This function allows easy selection of a desired mode
from five modes according to monitor application.
FineContrast mode
Page 12
Brightness Adjustment
Press or to adjust brightness.
Page 9
2 Screen Adjustment
(Advaced Adjustment)
[Adjustment menu]
[At analog signal input] [At digital signal input]
● To eliminate vertical bars [Clock*] … see page 10
● To remove flickering or blurring
[Phase*] ……………………………… see page 10
● To correct screen position
[Position*] …………………………… see page 10
● To adjust color gradation automatically
[Range Adjustment*] ……………… see page 11
● To modify blurred characters/lines
[Smoothing] ………………………… see page 11
● To set when a noise appears on the screen
[Signal Filter*] ……………………… see page 22
* Items marked with * can be adjusted with analog
input.
Page 9
Color Adjustment
Advanced Adjustment [Adjustment menu]
● “Brightness,” “Temperature,” “Gamma,”
“Saturation,” “Hue,” and “Gain” can be set for
each mode (Custom/sRGB/Text/Picture/Movie).
Settable functions vary with the display mode.
Resuming the default settings
● To reset color adjustment [Reset] … see page 18
Page 13
Analog input only
Page 13

7
Chapter 1 Features and Overview
To make useful settings/adjustments
Basic operation of Adjustment menu
[Displaying Adjustment menu and selecting function]
(1) Press . The main menu appears.
(2) Select a function with / / / , and press . The sub menu appears.
(3) Select a function with / / / , and press . The adjustment/setting menu appears.
(4) Adjust the selected item with / / / , and press . The setting is saved.
[Exiting Adjustment menu]
(1) Choose <Return> from the sub menu and press .
(2) Choose <Exit> from the main menu and press .
NOTE
• The Adjustment menu can also be exited by pressing twice quickly.
• <Exit> or <Return> can also be selected by pressing the button twice in the Main menu or Sub menu.
Adjustment menu (Refer to below for operation)
Set the off timer
● To set monitor power-off time [Off Timer]
…………………………………… see page 14
Change the screen size
● To change screen size [Screen Size]
…………………………………… see page 15
● To adjust brightness of non-display area
[Border Intensity] ………………… see page 15
Power Indicator Setting
● To turn off the Power indicator while a screen is
displayed [Power Indicator] …… see page 16
Adjustment menu settings
● To update menu settings [Menu Size/Menu
Position/Menu Off Timer/Translucent/
Orientation] ……………………… see page 17
BrightRegulator Setting
● To set automatic brightness adjustment
[BrightRegulator] ………………… see page 18
Resume the factory default settings
● To reset all settings [Reset] …… see page 18
Connect two PCs
● To set auto-switching of input signals
[Input Signal] ……………………… see page 20
Locking Adjustment
● To lock operation [Adjustment Lock]
…see page 16
EIZO Logo Display Setting
● To display EIZO logo [EIZO Logo Appearing
Function] ………………………………see page 16
Connecting Cables
● Connecting Two PCs to the Monitor … see page 19
●
Connecting Peripheral USB Devices …see page 20
Information/Language
● To check settings, usage time, etc. [Information]
● To set a language to be displayed [Language]
Page 18

8Chapter 2 Settings and Adjustments
2-1 Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and
the overview of the application software programs.
● Disk contents and software overview
The disk includes a monitor information file, application software programs for adjustment, and User’s Manual. Refer to
Readme.txt file on the disk for software startup procedures or file access procedures.
Item Overview For Windows For Macintosh
Readme.txt file √ √
Screen adjustment pattern files Used when adjusting the image of
analog signal input manually.√ √
ScreenManager Pro for LCD
(for Windows)
A utility software program to control
monitor adjustments from a PC using
its mouse and keyboard.
(A PC must be connected to the
monitor with the supplied USB cable.)
Refer to the description later.√−
WindowMovie Checker Software WindowMovie is a function of
ScreenManager Pro for LCD.
For more information, refer to the
User’s Manual of ScreenManager Pro
for LCD on the disk.
User’s Manual of this monitor (PDF file)
● To use ScreenManager Pro for LCD
For the installation and use of ScreenManager Pro for LCD, refer to its User’s Manual on the disk.
To adjust the monitor using ScreenManager Pro for LCD, connect a PC to the monitor with the supplied USB cable.
[Connection]
(1) Connect the USB port (downstream) of a USB compatible PC (or other USB hub) and the monitor’s USB port
(upstream) with the supplied USB cable.
Upstream
(2) The USB function is set up automatically upon connection of the USB cable.
Chapter 2 Settings and Adjustments

9
Chapter 2 Settings and Adjustments
2-2 Screen Adjustment
Digital Input
When digital signals are input, images are displayed correctly based on the
preset data of the monitor.
Analog Input
The monitor screen adjustment is used to suppress flickering of the screen or
adjust screen position and screen size correctly according to the PC to be used.
To use the monitor comfortably, adjust the screen when the monitor is set up for
the first time or when the settings of the PC in use are updated.
[Adjustment Procedure]
• Automatic Adjustment
1 Press .
A message “Your setting will be lost if you press again now” appears for
five seconds.
2 Press again while the message is displayed.
The Auto Adjustment function begins (showing a running status message)
to adjust clock, phase, display position, and resolution automatically.
If satisfactory adjustment cannot be obtained with the button,
perform the adjustment following the procedure below. When the
screen is displayed correctly, go to step 5 “Range Adjustment”.
• Advaced Adjustment
3 Prepare to use analog screen adjustment patterns.
Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen
adjustment pattern files”.
Attention
• Wait 20 minutes or more from
monitor power on before starting
adjustments.
Attention
• This function works correctly when
an image is fully displayed over the
Windows or Macintosh display area.
It does not work properly when an
image is displayed only on a part of
the screen (DOS prompt window, for
example) or when a black background
(wallpaper, etc.) is in use.
• This function does not work correctly
with some graphics boards.
NOTE
• Auto adjustment is available using
. If satisfactory adjustment
cannot be obtained with this button,
perform advanced adjustments using
the Adjustment menu.
NOTE
• For details and instructions on opening
the “Screen adjustment pattern files”,
refer to the Readme.txt file.

10 Chapter 2 Settings and Adjustments
NOTE
• Press the control button slowly so as
not to miss the adjustment point.
• When blurring, flickering or bars
appear on the screen after adjustment,
proceed to [Phase] to remove
flickering or blurring.
Attention
• Flickering or blurring may not be
eliminated depending on your PC or
graphics board.
4 Perform advanced adjustments for the following using the
<Screen> menu of the Adjustment menu.
● To eliminate vertical bars [Clock]
(1) Display Pattern 1 in full screen on the monitor using the “Screen
adjustment pattern files”.
(2) Choose <Clock> from the <Screen> menu, and press .
The <Clock> menu appears.
(3) Adjust the clock with or , and press .
The adjustment is completed.
● To remove flickering or blurring [Phase]
(1) Choose <Phase> from the <Screen> menu, and press .
The <Phase> menu appears.
(2) Adjust the phase with or , and press .
The adjustment is completed.
● To correct screen position [Position]
Since the number of pixels and the pixel positions are fixed on
the LCD monitor, only one position is provided to display images
correctly. The position adjustment is made to shift an image to the
correct position.
(1) Choose <Position> from the <Screen> menu, and press .
The <Position> menu appears.
(2) Adjust the position with / / / to display the image
properly in the display area of the monitor.
(3) Close Pattern 1.
NOTE
• When vertical bars appear on the
screen after adjustment, go back to
“To eliminate vertical bars [Clock].”
(Clock → Phase → Position)

11
Chapter 2 Settings and Adjustments
5 Adjust the signal output range.
● To adjust color gradation automatically [Range Adjustment]
Every color gradation (0 to 255) can be displayed by adjusting the
signal output level.
(1) Display Pattern 2 in full screen on the monitor using the “Screen
adjustment pattern files”.
(2) Choose <Range Adjustment> from the <Screen> menu, and press
.
A message “Your setting will be lost it you press AUTO button” appears.
(3) Press while the message is displayed.
The output range is adjusted automatically.
(4) Close Pattern 2.
6 Change the smoothing setting.
● To modify blurred characters/lines [Smoothing]
When a low-resolution image is displayed, the characters or lines of
the displayed image may be blurred.
(1) Choose <Screen> from the Adjustment menu, and press .
(2) Choose <Smoothing> from the <Screen> menu, and press .
The <smoothing> menu appears.
(3) Select a suitable level from 1 to 5 (where 1 = soft and 5 = sharp)
with or , and press .
The smoothing adjustment is completed.
Attention
• Smoothing setting may not be required
depending on the display resolution.
(You cannot choose the smoothing
icon.)

12 Chapter 2 Settings and Adjustments
2-3 Color Adjustment
Simple adjustment [FineContrast mode]
This function allows you to select the best display mode for monitor brightness,
etc.
● FineContrast Mode
An appropriate display mode is selectable out of five modes.
Mode Purpose
Custom Available for making desired setting.
sRGB Suitable for color matching with sRGB compatible
peripherals.
Text Suitable for displaying texts for word processing or
spreadsheets.
Picture Suitable for displaying images such as photos or picture
images.
Movie Suitable for playing back animated images.
FineContrast mode name
Example: Custom
Displays current mode.
● To select FineContrast mode name
(1) Press .
The FineContrast menu appears at the lower left of the screen.
(2) One of five modes is displayed in turn each time is pressed.
(3) Press to quit the operation.
NOTE
• The Adjustment menu and the
FineContrast mode name cannot be
displayed at the same time.
• This menu ends automatically when 2
seconds pass after the button is
pressed.

13
Chapter 2 Settings and Adjustments
Advanced Adjustments [Adjustment menu]
Independent setting and saving of color adjustment are available for each
FineContrast mode.
● To select an appropriate mode for images
√: Adjustment/setting available −: Factory setting
Icon Function FineContrast mode
Custom sRGB Text Picture Movie
Brightness √ √ √ √ √
Temperature √−√ √ √
Gamma √−√− −
Saturation √−√ √ √
Hue √−√ √ √
Gain √− − − −
Reset √−√ √ √
Menu Description Adjustment range
Brightness To adjust the full screen
brightness as desired
0 to 100%
NOTE
• You can also adjust the brightness by pressing or
button while the adjustment menu is not displayed.
• Press after adjustment.
• The values shown in the “%” are available only as reference.
Temperature To select a color
temperature
4000K to 10000K in units of 500K
(including 9300K).
NOTE
• Setting the value to “Off” presents the natural color
temperature of the panel.
• The values shown in the Kelvin (K) are available only as
reference.
Gamma To set a gamma value 1.8/2.0/2.2
NOTE
• Digital signal input is recommended for gamma value setting.
Saturation To adjust color saturation –128 to 127
Setting the minimum (–128) turns
the image to a monochrome
screen.
Attention
• This function does not enable to display every color gradation.
Hue To change the flesh color,
etc.
–32 to 32
Attention
• This function does not enable to display every color gradation.
NOTE
• The Adjustment menu and the
FineContrast mode name cannot be
displayed at the same time.
• Adjustable functions vary depending
on the type of FineContrast mode.
Attention
• Perform [Range Adjustment] before
starting color adjustment for analog
input signals.
Refer to “To adjust color gradation
automatically” on page 11.
• The FineContrast mode cannot be
changed during color adjustment. Set
the FineContrast mode in advance
with .
• Wait 20 minutes or more from
monitor power on before starting the
color adjustment.
• Choose [Reset] from the Color menu
to revert to the default setting (factory
setting) of the color tone of the
FineContrast mode selected.
• The same image may be seen in
different colors on multiple monitors
due to their monitor-specific
characteristics. Make fine color
adjustment visually when matching
colors on multiple monitors.

14 Chapter 2 Settings and Adjustments
Menu Description Adjustment range
Gain To adjust red, green, and
blue to a desired color tone
respectively
0 to 100%
Adjust the respective brightness of
red/green/blue to make a desired
color tone. Display an image with
white or gray background for
adjustment.
NOTE
• The values shown in the “%” are available only as reference.
• When using the <Gain> setting, the <Temperature> setting is
set to “Off.”
Reset To reset the color settings of the selected FineContrast mode to
the default settings.
● To set/adjust color
(1) Choose <Color> from the Adjustment menu, and press .
(2) Select a desired function from the <Color> menu, and press .
The selected function menu appears.
(3) Adjust the selected item with / / / , and press .
The adjustment is completed.
2-4 Off Timer Settings
● To set monitor power-off time [Off Timer]
This function allows the monitor to automatically turn off after a specified time
has passed. This function serves to reduce afterimages caused when the monitor
screen is left on for a long time period without use. Use this function when an
image is displayed throughout the day.
[Off Timer System]
Timer Monitor Power Indicator
ON time (1H - 23H) Operating Blue
Last 15 min. in “ON time” Advance Notice*1Flashing blue
“ON time” expired Power Off Off
*1 When is pressed during the advance notice period, the monitor continues to operate for
additional 90 minutes. Extension of operation time can be set without limitation.
[Procedure]
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Off Timer> from the <Others> menu, and press .
The <Off Timer> menu appears.
(3) Select “Enable” with or .
(4) Set a monitor ON time (1 to 23 hours) with or , and press .
The Off Timer setting is completed.
[Resumption Procedure]
Press .
Attention
• The Off Timer functions even in the
power saving mode, but the advance
notice is disabled. The monitor power
is turned off without advance notice.

15
Chapter 2 Settings and Adjustments
2-5 Screen Size Selection
● To change screen size [Screen Size]
This function allows you to change the screen size when a low-resolution image
is displayed.
Menu Function
Full (default setting)
Displays an image in full screen. Images are distorted in
some cases because the vertical rate is not equal to the
horizontal rate.
Enlarged
Displays an image in full screen. In some cases, a blank
horizontal or vertical border appears to equalize the
vertical rate and the horizontal rate.
Normal Displays images with the specified resolution.
Example: Image size 1280 × 1024
(1600×1200)
Full
(Default setting)
Enlarged Normal
(1280×1024)(1500×1200)
[Procedure]
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Screen Size> from the <Others> menu, and press .
The screen size setting window appears.
(3) Select “Full,” “Enlarged,” or “Normal” with or , and press .
The screen size setting is completed.
● To adjust brightness of non-display area [Border Intensity]
A border (black area with no image) around the image appears in the “Normal”
or “Enlarged” mode.
Border
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Border Intensity> from the <Others> menu, and press .
The <Border Intensity> menu appears.
(3) Adjust border intensity with or , and press .
The border intensity adjustment is completed.

16 Chapter 2 Settings and Adjustments
2-6 Power Indicator/EIZO Logo Display
Setting
● To turn off the Power indicator while a screen is displayed
[Power Indicator]
This function enables to turn off the Power indicator (blue) while a screen is
displayed.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Power Indicator> from the <Others> menu, and press .
The <Power Indicator> menu appears.
(3) Select “Disable” with or , and press .
The Power Indicator setting is completed.
● To display EIZO logo [EIZO Logo Appearing Function]
When this unit is turned on, the EIZO logo appears at the center of the screen.
Selection to display or not to display the logo is available with this function.
[Procedure]
(1) Press to power off the unit.
(2) Press again while pressing .
The EIZO logo does not appear on the screen.
[Resetting]
(1) Press to power off the unit.
(2) Press again while pressing .
The logo appears again.
2-7 Locking Buttons
● To lock operation [Adjustment Lock]
This function locks the buttons to retain the status adjusted or set once.
Buttons that can be
locked
• (Enter button) Adjustments/settings using
Adjustment menu
• (Auto adjustment button)
Buttons that cannot
be locked
• (Power button)
• (Input signal selection button)
• (Mode button) FineContrast mode name selection
• / (Control buttons) Brightness adjustment
[Procedure]
(1) Press to turn off the unit.
(2) Press again while pressing .
The screen is displayed with the adjustment lock.
[Unlocking]
(1) Press to turn off the unit.
(2) Press again while pressing .
The screen is displayed with the adjustment lock released.
NOTE
• The logo appears with the default
setting.

17
Chapter 2 Settings and Adjustments
2-8 Setting Adjustment menu Display
● To update menu settings [Menu Size/Menu Position/
Menu Off Timer/Translucent/Orientation]
Menu Size
Change the Adjustment menu size using the following procedure.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Menu Settings> from the <Others> menu, and press .
(3) Choose <Menu Size> from the <Menu Settings> menu, and press
The <Menu Size> menu appears.
(4) Select “Enlarged” using or , and press .
The menu size setting is completed.
Menu Position
Adjust the menu position using the following procedure.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Menu Settings> from the <Others> menu, and press .
(3) Choose <Menu Position> from the <Menu Settings> menu, and press .
The <Menu Position> menu appears.
(4) Select a menu position with / / / , and press .
The menu position setting is completed.
Menu Off Timer
Set the menu display time using the following procedure.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Menu Settings> from the <Others> menu, and press .
(3) Choose <Menu Off Timer> from the <Menu Settings> menu,
and press .
The <Menu Off Timer> menu appears.
(4) Choose “Enable” with or .
(5) Choose an Off Time (15/30/45/60 seconds) with or ,
and press .
The menu off timer setting is completed.
Translucent
Set the transparency for menu display using the following procedure.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Menu Settings> from the <Others> menu, and press .
(3) Choose <Translucent> from the <Menu Settings> menu, and press .
The <Translucent> menu appears.
(4) Adjust the transparency for menu display with or , and press .
The transparency setting is completed.
Orientation
The orientation of the Adjustment menu can be turned 90 degrees.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Orientation> from the <Others> menu, and press .
The <Orientation> menu appears.
(3) Select “Landscape” or “Portrait” with or , and press .
The orientation setting is completed.
NOTE
• The display time of the FineContrast
mode name remains unchanged.

18 Chapter 2 Settings and Adjustments
NOTE
• The usage time is not always “0”
when you purchase the monitor due
to factory inspection.
NOTE
• For default settings, refer to “Main
default settings (factory settings)” on
page 26.
2-9 Viewing Information/Setting Language
● To check settings, usage time, etc. [Information]
This function allows you to check settings, model name, serial number, and
usage time of the monitor.
(1) Choose <Information> from the Adjustment menu, and press .
The <Information> menu appears.
(2) Then, press to check settings, etc.
● To set a language to be displayed [Language]
Select the Adjustment menu language.
Selectable languages
English/German/French/Spanish/Italian/Swedish/Japanese
(1) Choose <Language> menu from the Adjustment menu, and press .
The <Language> menu appears.
(2) Select a language with / / / , and press .
The language setting is completed.
2-10 Setting BrightRegulator
● To set automatic brightness adjustment [BrightRegulator]
The sensor on the front side of the monitor detects the environmental brightness
to adjust the screen brightness automatically and comfortably.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose < BrightRegulator> from the <Others> menu, and press .
The BrightRegulator setting window appears.
(3) Select “Enable” or “Disable” with or , and press .
The BrightRegulator setting is completed.
2-11 Resumption of Default Setting
● To reset color adjustment [Reset]
Resume the default settings (factory settings) for color adjustment.
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Reset> from the <Color> menu, and press .
The <Reset> menu appears.
(3) Select <Reset> with or , and press .
The reset operation is completed.
● To reset all settings [Reset]
Reset all adjustments/settings to the factory default settings.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Reset> from the <Others> menu, and press .
The <Reset> menu appears.
(3) Select <Reset> with or , and press .
The reset operation is completed.
NOTE
• Be careful not to block the sensor on
the lower side of the monitor when
using the BrightRegulator function.

19
Chapter 3 Connecting Cables
3-1 Connecting Two PCs to the Monitor
Two PCs can be connected to the monitor through the DVI-I and the D-Sub
mini 15 pin connector on the back of the monitor.
Connection examples
DIV-I connector
(SIGNAL1)
D-sub mini
15-pin Connector
(SIGNAL2)
PC 1 PC 2
Example 1
Digital
DVI Signal cable
(supplied with
FD-C39)
Signal cable
(supplied
MD-C87)
D-sub mini 15-pin
Analog
Example 2
Analog
D-sub mini
15-pin
Signal cable
(FD-C16 option)
Signal cable
(supplied
MD-C87)
D-sub mini 15-pin
Analog
Selecting input signal
Input Signal Selection button
Switch the input signal with . Input signal switches each time is
pressed. When the signal is switched, the active signal type (Analog or Digital)
appears at the top right corner of the screen for two seconds.
Chapter 3 Connecting Cables
Attention
• When using an optional signal cable
(FD-C16), be sure to connect the
D-sub mini 15-pin connector to the
PC, and the DVI-I connector to the
monitor. Wrong connection may
result in no picture display.

20 Chapter 3 Connecting Cables
● To set auto-switching of input signals [Input Signal]
The monitor recognizes the connector through which PC signals are input.
When either PC is turned off or enters the power-saving mode, the monitor
automatically displays signals of another PC.
Priority setting Function
Auto When either PC is turned off or enters
the power-saving mode, the monitor
automatically displays signals of
another PC.
Manual The monitor does not detect the PC’s
signals automatically. Select an active
input signal with .
[Input signal setting]
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Input Signal> from the <Others> menu, and press .
The <Input Signal> menu appears.
(3) Select “Auto” or “Manual” with or , and press .
The Input Priority setting is completed.
3-2 Connecting Peripheral USB Devices
This monitor has a hub compatible with USB. Connected to a PC compatible
with USB or another USB hub, this monitor functions as a USB hub allowing
connection to peripheral USB devices.
● Required System Environment
(1) A PC equipped with a USB port or another USB hub connected to
a USB compatible PC
(2) Windows 98/Me/2000/XP/Vista/7/8 or Mac OS 8.5.1 or later
(3) EIZO USB cable (MD-C93)
● Connection Procedure (Setup of USB Function)
(1) Connect the monitor first to a PC using the signal cable, and run
the PC.
(2) Connect the supplied USB cable between the downstream USB
port of a USB compatible PC (or another USB hub) and the
monitor’s upstream USB port.
(3) When the USB function setup is completed, the monitor functions
as a USB hub allowing connection to various peripheral USB
devices through its downstream USB ports.
The USB function is set up automatically upon connection of the
USB cable.
Attention
• This monitor may not work depending
on PC, OS or peripheral devices to be
used.
For USB compatibility of peripheral
devices, contact their manufactures.
• If the monitor is in the power saving
mode, or if the monitor is connected
to the power outlet with the monitor
turned off, all the devices connected
to the USB ports (upstream and
downstream) work. Therefore, power
consumption of the monitor varies
with connected devices even in the
power saving mode.
