Eizo FLEXSCAN S2433W User manual

Important
Please read PRECAUTIONS, this User’s Manual and Setup Guide
(separate volume) carefully to familiarize yourself with safe and effective
usage.
• PleasereadtheSetupGuide(separatevolume)
• ThelatestUser’sManualisavailablefordownloadfromoursite:
http://www.eizo.com

2
[Location of Caution Statement]
Ex.Heightadjustablestand
As an ENERGY STAR®Partner, EIZO NANAO CORPORATION has determined that this product
meets the ENERGY STAR guidelines for energy efciency.
This product has acquired TCO standard that relates to safety, ergonomics, environment and so forth of ofce
equipment.For overview of the TCO, refer to our website.
http://www.eizo.com
Product specication may vary with sales areas.
Conrm the specication in the manual written in language of the region of purchase.
Copyright© 2010 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
ENERGY STAR is a U.S. registered mark.
Apple and Macintosh are registered trademarks of Apple Inc.
VGA is a registered trademark of International Business Machines Corporation.
DisplayPort icon and VESA are registered trademarks or trademarks of Video Electronics Standards
Association in the United States and other countries.
Windows and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries.
i•SoundisatrademarkofEIZONANAOCORPORATION.
EIZO,EIZOlogo,FlexScanandScreenManagerareregisteredtrademarksofEIZONANAOCORPORATIONinJapanandother
countries.

3
Notice for this monitor
This product is suited to creating documents, viewing multimedia content, and other general purposes.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is used
outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable for power cords and signal cables specied by us.
Use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in
lower brightness is recommended.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or timer to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime.
(Refer to “Cleaning” on the next page.)
The LCD panel is manufactured using high-precision technology. However, missing pixels or lit pixels may appear on
the LCD panel, this is not malfunction.
Percentage of effective pixels : 99.9994% or higher.
The backlight of the LCD panel has a xed life span. When the screen becomes dark or begins to icker, please contact
your dealer.
Do not press on the panel or edge of the frame strongly, as this may result in the display malfunction, such as the
interference patterns, etc. If pressure is continually applied to the LCD panel, it may deteriorate or damage your LCD
panel. (If the pressure marks remain on the LCD panel, leave the monitor with a white or black screen. The symptom
may disappear.)
Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in damage to the
panel. Do not attempt to brush with tissues as this may scratch the LCD panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation
may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation
disappears, otherwise it may cause some damages to the monitor.

4
Cleaning
Attention
• Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage
the cabinet or LCD panel.
NOTE
• Optional ScreenCleaner is recommended for cleaning the panel surface.
[LCD Panel]
• Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper.
• Remove persistent stains gently with a cloth dampened with a little water, and then clean the LCD panel again with a
dry cloth for better nishing.
[Cabinet]
Clean the cabinet with a soft cloth dampened with a little mild detergent.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the
environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
2-11 Screen Size Selection.................................... 23
●To change screen size [Screen Size]............... 23
● Toadjustbrightnessofnon-displayarea
[Border Intensity].............................................. 23
2-12 Setting Adjustment Menu Display................ 24
●To update menu settings [Menu Size/Menu
Position/Menu Off Timer/Translucent].............. 24
2-13 Setting Orientation ........................................ 25
●To set the orientation of the Adjustment menu
[Orientation]...................................................... 25
2-14 Locking Buttons ............................................ 25
2-15 Displaying Monitor Information
[Information]................................................... 25
2-16 Enabling/Disabling DDC/CI communication.. 26
2-17 Setting Power Indicator ON/OFF
[Power Indicator] ........................................... 26
2-18 Setting Language [Language]...................... 26
2-19 Setting EIZO logo display ON/OFF............... 26
2-20 Resuming the Default Setting [Reset] ......... 27
●To reset color adjustment values...................... 27
●To reset all adjustments to the factory default
settings............................................................. 27
Chapter 3 Connecting Cables..........................28
3-1 Connecting More than Two PCs to the
Monitor............................................................ 28
●To switch the input signal ................................. 28
●To set input signal selection [Input Signal] ....... 29
3-2 Adjusting the DVI Input Level
[DVI Input Level] ............................................ 29
3-3 Connecting Peripheral USB Devices............... 30
Chapter 4 Troubleshooting...............................31
CONTENTS
Notice for this monitor.............................................. 3
CONTENTS.............................................................5
Chapter 1 Features and Overview .....................7
1-1 Features............................................................ 7
1-2 Controls and Functions .................................. 8
1-3 Compatible Resolutions/Frequencies ........... 9
1-4 Functions and Basic Operation.................... 10
Chapter 2 Settings and Adjustments ..............13
2-1 Utility Disk...................................................... 13
●Disk contents and software overview............... 13
●To use ScreenManager Pro for LCD................ 13
2-2 Screen Adjustment........................................ 14
Digital Input.......................................................... 14
Analog Input ........................................................ 14
2-3 Color Adjustment........................................... 17
● Toselectthedisplaymode(FineContrastmode)...17
●To perform advanced adjustments................... 18
●Adjustment items in each mode....................... 18
● Toadjustthebrightness[Brightness] ............... 18
●To adjust the contrast [Contrast]....................... 18
●To adjust the color temperature [Temperature].. 19
●To adjust the gamma value [Gamma]............... 19
●To adjust the color saturation [Saturation]........ 19
●To adjust the hue [Hue] .................................... 20
●To adjust the gain value [Gain]......................... 20
2-4 Adjusting Volume [Volume] .......................... 20
2-5 Switching sound source during DisplayPort
signal input [Source]..................................... 20
2-6 Turning off the audio output at Power Saving
mode [Power Save]........................................ 21
2-7 Setting On/Off for the automatic brightness
adjustment function [Auto EcoView]........... 21
2-8 Setting On/Off for Power Saving mode
[Power Save] .................................................. 21
2-9 Turning off the monitor automatically
[Off Timer] ...................................................... 22
2-10 Displaying the level of power saving by
EcoView Index................................................ 22

6CONTENTS
Chapter 5 Reference .........................................34
5-1 Attaching an Arm........................................... 34
5-2 Folding the EZ-UP stand............................... 35
5-3 Specications ................................................ 36
5-4 Glossary ......................................................... 42
5-5 Preset Timing................................................. 44
FCC Declaration of Conformity..........................45
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor.........................46
Hinweis zur Ergonomie.......................................46
CONTENTS

7
Chapter1FeaturesandOverview
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• 24” wide format LCD Applicable to WUXGA (1920×1200)
• Built-in speakers and headphone jack
1-2 “Controls and Functions” (page 8)
• Power saving function
Suppressing the power consumption*1 reduces the carbon dioxide emissions.
This product is equipped with various power saving functions.
– Power Consumption when main power switch is Off: 0W
Equipped with main power switch.
Turning off the main power switch completely shuts off power supply to the monitor while the monitor is not used.
– Auto EcoView function
The sensor on the front side of the monitor detects the environmental brightness to adjust the screen brightness automatically
and comfortably.
Excessively high brightness may lead a damage to the natural environment as well as to your eyes. Suppressing the excessively
high brightness will be helpful to reduce the power consumption and the damage to your eyes.
2-7 “Setting On/Off for the automatic brightness adjustment function [Auto EcoView]” (page 21)
– EcoView Index function
The green indicator shows the power consumption ratio responding to the brightness of the monitor. You can realize the power
consumption reduction by taking consideration in the ratio of power saving.
2-10 “Displaying the level of power saving by EcoView Index” (page 22)
• FineContrast function
2-3 “To select the display mode (FineContrast mode)” (page 17)
• Applicable to DisplayPort (applicable to 8 bit)*2
The image signal and audio signal can both be transmitted via a single DisplayPort cable (option).
• Applicable to DVI long cable
3-2 “Adjusting the DVI Input Level [DVI Input Level]” (page 29)
• Portrait/Landscape display available
• The software “ScreenManager Pro for LCD” to adjust the screen using the mouse and keyboard is included
2-1 “Utility Disk” (page 13)
• HDCP (High-bandwidth Digital Content Interface)
*1Reference values:
Maximum power consumption: 90W (Luminance Max., at default settings)
Standard power consumption: 40W (Luminance 120cd/m2, at default settings)
*2 When transmitting an audio signal using the DisplayPort cable, the graphics board must be compatible with audio
output. (page 36)
NOTE
• This monitor supports the Portrait/Landscape display. This function allows you to change the orientation of the Adjustment menu
when using the monitor screen in vertical display position. (Refer to “To set the orientation of the Adjustment menu [Orientation]”
on page 25.)
• For using the monitor with “Portrait” position, the graphics board supporting portrait display is required. When using the monitor
with “Portrait” position, the setting needs to be changed depending on the graphics board used in your PC. Refer to the manual of
the graphics board for details.
• The stand of the unit can be replaced with an arm or another stand. (Refer to “5-1 Attaching an Arm” on page 34.)

8Chapter1FeaturesandOverview
1-2 Controls and Functions
Ex.Heightadjustablestand
1 2 3 4 5 6 7 98 11 19
12 1413 1510
17
20 21
18
16
Adjustment menu
(*ScreenManager ®)
1 Sensor Detectsambientbrightness.AutoEcoViewfunction(page 21).
2 Auto EcoView button Allows you to switch the Auto EcoView function On or Off (page 21).
3 EcoView Index button Displays the EcoView index (page 22).
4 Input Signal Selection button Switches input signals for display when more than two PCs are connected to
the monitor. (page 28).
5 Mode button Allows you to switch the display mode (page 17).
6 Enter button Displays the Adjustment menu, determines an item on the menu screen, and
saves values adjusted (page 12).
7 Control buttons (Left, Down,
Up, Right) • Choosesanadjustmentitemorincreases/decreasesadjustedvaluesfor advanced adjustments using the Adjustment menu (page 12).
• or button:Displaysthevolumeadjustmentmenu(page 10).
• or button:Displaysthebrightnessadjustmentmenu(page 10).
8 Power button Turns the power on or off.
9 Power indicator Indicates monitor’s operation status.
Blue:Operating Orange:Powersaving Off:Poweroff
10 Speaker Outputs audio source.
11 Main Power Switch Turns the main power on or off.
12 Power connector Connects the power connector.
13 Stereo mini jack Connectsthestereominijackcable.
14 Input signal connectors Left:DisplayPortConnector/Center:DVI-IConnector/Right:D-Submini
15-pinconnector
15 USB port (Up) ConnectstheUSBcabletousethesoftwarethatneedsUSBconnection,or
touseUSBHubfunction.(page 30)
16 USB Port (Down) Connects a peripheral USB device.
17 Stand Used to adjust the height and angle of the monitor screen.
18 Cable holder Coversthemonitorcables.
19 Headphone jack Connects the headphones.
20 Security lock slot Complies with Kensington’s MicroSaver security system.
21 Option speaker (i·Sound L3)
mounting holes Used to attach the option speaker (i·Sound L3). (May not allowed to attach
the option speaker depending on the stand type.)
* ScreenManager ® is an EIZO’s nickname of the Adjustment menu. See page 10 for how to use.

9
Chapter1FeaturesandOverview
1-3 Compatible Resolutions/Frequencies
The monitor supports the following resolutions.
Analog Input (D-Sub)
Resolution Frequency Mode Dot Clock ~202.5MHz
640 × 480 ~75 Hz VGA, VESA √
720 × 400 70 Hz VGATEXT √
800 × 600 ~75 Hz VESA √
1024 × 768 ~75 Hz VESA √
1152 × 864 75 Hz VESA √
1280 × 960 60 Hz VESA √
1280 × 1024 ~75 Hz VESA √
1600 × 1200 ~75 Hz VESA √
*1 1680 × 1050 60 Hz VESA CVT √
*1 *2 1920 × 1200 60 Hz VESA CVT, VESA CVT RB √
Digital Input (DVI-D)
Resolution Frequency Mode Dot Clock ~162MHz
640 × 480 60 Hz VGA √
720 × 400 70 Hz VGATEXT √
800 × 600 60 Hz VESA √
1024 × 768 60 Hz VESA √
1280 × 960 60 Hz VESA √
1280 × 1024 60 Hz VESA √
1600 × 1200 60 Hz VESA √
*1 1680 × 1050 60 Hz VESA CVT √
*1 1680 × 1050 60 Hz VESA CVT RB √
*1 *2 1920 × 1200 60 Hz VESA CVT RB √
Digital Input (DisplayPort)
Resolution Frequency Mode Dot Clock ~162MHz
640 × 480 60 Hz VGA, CEA √
720 × 400 70 Hz VGATEXT √
720×400(4:3) 60 Hz CEA √
720×400(16:9) 60 Hz CEA √
800 × 600 60 Hz VESA √
1024 × 768 60 Hz VESA √
1280 × 720 60 Hz CEA √
1280 × 960 60 Hz VESA √
1280 × 1024 60 Hz VESA √
1600 × 1200 60 Hz VESA √
*1 1680 × 1050 60 Hz VESA CVT √
*1 1680 × 1050 60 Hz VESA CVT RB √
*1 *2 1920 × 1200 60 Hz VESA CVT RB √
*1 When displaying the wide format input signal, a graphics board in conformance with VESA CVT standard is required.
*2 Recommended resolution (Set this resolution)

10 Chapter1FeaturesandOverview
1-4 Functions and Basic Operation
To adjust the screen and color
1 Screen Adjustment
(Automatic Adjustment)
●To adjust flickering and position
[Screen]………………………………see page 14
●To adjust color gradation automatically
[Range] ………………………………see page 16
Page 14
Analog input only
2 Screen Adjustment
(Advanced Adjustment)
[At digital signal input][At analog signal input]
●Toeliminateverticalbars[Clock*] …see page 15
●Toremoveflickeringorblurring
[Phase*]………………………………see page 15
●To correct screen position
[Position*]……………………………see page 16
●Tomodifyblurredcharacters/lines
[Smoothing] …………………………see page 16
●To set when a noise appears on the screen
[SignalFilter*] ………………………see page 32
* Itemsmarkedwith*canbeadjustedwithanalog
input.
Page 15
Color Adjustment
Advanced Adjustment
●“Brightness”, “Contrast”, “Temperature”,
“Gamma”,“Saturation”,“Hue”and“Gain”canbe
set for each mode (Custom/EyeCare/sRGB/Text/
Picture/Movie).
SettablefunctionsvarywiththeFineContrast
mode.
Resuming the default settings
●To reset color adjustment values
[Reset] ………………………………see page 27
Page 18
Main menu (Refer to page 12 for operation)
• The Adjustment menu and the FineContrast mode
name cannot be displayed at the same time.
Color Adjustment
Simple Adjustment [FineContrast mode]
This function allows easy selection of a desired mode
from six modes according to monitor application.
FineContrast mode
Page 17
●Toadjustthebrightness[Brightness]
Press or toadjustbrightness.
●Adjusting Volume [Volume]
Press or to adjust volume.
●SettingOn/Offfortheautomaticbrightness
adjustment function [Auto EcoView]
Press to switch the setting.
●DisplayingthelevelofpowersavingbyEcoView
Index
Press to display the level of power saving mode.
[At digital signal input]
[At analog signal input]

11
Chapter1FeaturesandOverview
Information
●Displaying Monitor Information [Information]
To make useful settings/adjustments
Power-save Settings
●Setting On/Off for Power Saving mode
[Power Save] ………………………see page 21
●Turning off the monitor automatically
[Off Timer] …………………………see page 22
●DisplayingthelevelofpowersavingbyEcoView
Index [EcoView Index] ……………see page 22
Adjustment menu (Refer to page 12 for operation)
[At analog signal input]
[At digital signal input]
Other Settings
●To change screen size [Screen Size]
………………………………………see page 23
●Toadjustbrightnessofnon-displayarea
[Border Intensity] ……………………see page 23
●To set input signal selection
[Input Signal] ………………………see page 29
●To update menu settings
[Menu Size/Menu Position/Menu Off Timer/
Translucent] …………………………see page 24
●To set the orientation of the Adjustment menu
[Orientation] …………………………see page 25
●SettingPowerIndicatorON/OFF
[Power Indicator] ……………………see page 26
●To reset all adjustments to the factory default
settings [Reset] ……………………see page 27
Language
●Setting Language [Language]
Page 26
●Locking Buttons ……………………… see page 25
●Enabling/DisablingDDC/CIcommunication
[DDC/CI] ……………………………… see page 26
●SettingEIZOlogodisplayON/OFF … see page 26
●Adjusting the DVI Input Level
[DVI Input Level] ……………………… see page 29
Sound Settings
[At DisplayPort signal input]
[At D-Sub/DVI-D signal input]
●Adjusting Volume [Volume]…………see page 20
●Switching sound source during DisplayPort
signalinput[Source*] ………………see page 20
●Turning off the audio output at Power Saving
mode [Power Save]…………………see page 21
* Anitemmarkedwith*canbeadjustedwith
DisplayPort input.
Page 25

12 Chapter1FeaturesandOverview
Basic operation of Adjustment menu
[Displaying Adjustment menu and selecting function]
(1) Press . The Main menu appears.
(2) Select a function with / / / , and press . The Sub menu appears.
(3) Select a function with / / / , and press . The adjustment/setting menu appears.
(4) Adjust the selected item with / / / , and press . The setting is saved.
[Exiting Adjustment menu]
(1) Choose <Return> from the Sub menu and press . The Main menu appears.
(2) Choose <Exit> from the Main menu and press . The Adjustment menu quits.
NOTE
• The Adjustment menu can also be exited by pressing twice quickly.
• <Exit> or <Return> can also be selected by pressing twice in the Main menu or Sub menu.

13
Chapter 2 Settings and Adjustments
2-1 Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and
the overview of the software programs.
● Disk contents and software overview
The disk includes application software programs for adjustment, and User’s Manual. Refer to “Readme. txt” file on the
disk for software startup procedures or file access procedures.
Item Overview OS
A“Readme.txt”le
Screenadjustmentpatternles Used when adjusting the image of the
analog signal input manually.
ScreenManager Pro for LCD
* WindowMovieCheckerSoftware
A software for adjusting the screen using
themouseandkeyboard.
Connect the monitor to the PC with the
suppliedUSBcablebeforeinstallation.
WindowMovie is a function of
ScreenManagerProforLCD.Formore
information, refer to the User’s Manual
of ScreenManager Pro for LCD on the
disk.
Windows XP/Vista
EIZOScreenSlicer A software that divides a screen and
laysoutmultiplewindowsefciently. Windows XP/Vista
User’sManualofthismonitor(PDFle)
● To use ScreenManager Pro for LCD
For the installation and use of ScreenManager Pro for LCD, refer to its User’s Manual on the disk.
To adjust the monitor using ScreenManager Pro for LCD, connect a PC to the monitor with the supplied USB cable.
For more information, refer to the “Chapter 3 3-3 Connecting Peripheral USB Devices” (page 30).
Chapter 2 Settings and Adjustments

14 Chapter 2 Settings and Adjustments
2-2 Screen Adjustment
Digital Input
When digital signals are input, images are displayed correctly based on the
preset data of the monitor, but if characters and/or lines appear blurred, go to
step 6 “To modify blurred characters/lines [Smoothing]”. When performing
more advanced adjustment, see “2-3 Color Adjustment” (page 17) and
subsequent pages.
Analog Input
The monitor screen adjustment is used to suppress ickering of the screen or
adjust screen position and screen size correctly according to the PC to be used.
The auto adjust function works in the following cases:
• Whenasignalisinputintothemonitorforthersttime
• WhentheresolutionorVertical/HorizontalFrequencynot
displayedbeforeisset
If the screen is not displayed correctly even after performing the auto
adjustment, perform the screen adjustments according to the procedures on the
following pages to use the monitor comfortably.
[Adjustment Procedure]
1Perform the auto adjustment.
● Toadjustickering,screenposition,andscreensize
automatically [Screen]
(1) Choose <Screen> from the <Auto Adjustment> menu, and press
.
The <Auto Adjustment> menu appears.
(2) Choose <Execute> with or , and press .
Flickering, screen position, and screen size are corrected by the auto-
adjustment function.
Ifthescreenisnotdisplayedcorrectlyevenafteradjustinginstep
1above,performtheadjustmentsaccordingtotheprocedureson
thefollowingpages.Whenthescreenisdisplayedcorrectly,goto
step5“Toadjustcolorgradationautomatically[Range]”.
2Prepare the display pattern for the analog display adjustment.
Load the “EIZO LCD Utility Disk” to your PC, and then open the screen
adjustment pattern les.
Attention
• This function works correctly when
an image is fully displayed over the
Windows or Macintosh display area.
It does not work properly when an
image is displayed only on a part of
the screen (command prompt window,
for example) or when a black
background (wallpaper, etc.) is in use.
• This function does not work correctly
with some graphics boards.
• “Auto in Progress” appears on the
screen during auto adjustment.
NOTE
• For how to open and contents of the
screen adjustment pattern les, refer
to “Readme.txt”.
Attention
• Wait 30 minutes or more from
monitor power on before starting
adjustments.
• Auto adjust function does not work
for the images under the resolution of
800 × 600 (SVGA).

15
Chapter 2 Settings and Adjustments
3Perform the auto adjustment again with the analog screen
adjustment pattern displayed.
● Toadjustickering,screenposition,andscreensize
automatically [Screen]
(1) Display Pattern 1 of the screen adjustment pattern les in full
screen on the monitor.
(2) Choose <Screen> from the <Auto Adjustment> menu, and press
.
The <Auto Adjustment> menu appears.
(3) Choose <Execute> with or , and press .
Flickering, screen position, and screen size are corrected by the auto-
adjustment function.
Ifthescreenisnotdisplayedcorrectlyevenafteradjustinginstep
3above,performtheadjustmentsaccordingtotheprocedureson
thefollowingpages.Whenthescreenisdisplayedcorrectly,goto
step5“Toadjustcolorgradationautomatically[Range]”.
4Perform advanced adjustments for the following using the
<Screen> menu of the Adjustment menu.
Adjust the clock, phase and position, in this order.
●To eliminate vertical bars [Clock]
(1) Choose <Clock> from the <Screen> menu, and press .
The <Clock> menu appears.
(2) Adjust the clock with or , and press .
The adjustment is completed.
● Toremoveickeringorblurring[Phase]
Adjustable range: 0 to 63
(1) Choose <Phase> from the <Screen> menu, and press .
The <Phase> menu appears.
(2) Adjust the phase with or , and press .
The adjustment is completed.
NOTE
• Press the control button slowly so as
not to miss the adjustment point.
• When blurring, ickering or bars
appear on the screen after adjustment,
proceed to [Phase] to remove
ickering or blurring.
Attention
• Flickering or blurring may not be
eliminated depending on your PC or
graphics board.
NOTE
• When vertical bars appear on the
screen after adjustment, go back to
“To eliminate vertical bars [Clock]”.
(Clock → Phase → Position)

16 Chapter 2 Settings and Adjustments
●To correct screen position [Position]
(1) Choose <Position> from the <Screen> menu, and press .
The <Position> menu appears.
(2) Adjust the position with / / / to display the image
properly in the display area of the monitor, and press
The adjustment is completed.
5Adjust the color gradation.
●To adjust color gradation automatically [Range]
Every color gradation (0 to 255) can be displayed by adjusting the
signal output level.
(1) Display Pattern 2 of the screen adjustment pattern les in full
screen on the monitor.
(2) Choose <Range> from the <Auto Adjustment> menu, and press
.
(3) Choose “Execute” with or , and press .
The output range is adjusted automatically.
(4) Close the Pattern 2.
6Modify blurred characters or lines.
●To modify blurred characters/lines [Smoothing]
When a image is displayed with a resolution other than the
recommendation, the characters or lines of the displayed image may be
blurred.
Adjustable range: 1 to 5
(1) Choose <Screen> from the Adjustment menu, and press .
(2) Choose <Smoothing> from the <Screen> menu, and press .
The <Smoothing> menu appears.
(3) Adjust the characters/lines with or , and press .
The adjustment is completed.
NOTE
• Since the number of pixels and the
pixel positions are xed on the LCD
monitor, only one position is provided
to display images correctly. The
position adjustment is made to shift
an image to the correct position.
Attention
• Smoothing setting may not be required
depending on the display resolution.
(You cannot choose the smoothing
icon.)

17
Chapter 2 Settings and Adjustments
2-3 Color Adjustment
● To select the display mode (FineContrast mode)
FineContrast allows you to select the best display mode easily according to the
monitor’s application.
FineContrast mode
Mode Purpose
Custom Availabletochangeallsettingvalues.
EyeCare Allowsthebrightnesstobesetlowerthanpossiblewith
other modes.
sRGB SuitableforcolormatchingwithsRGBcompatible
peripherals.
Text Suitablefordisplayingtextsforwordprocessingor
spreadsheets.
Picture Suitablefordisplayingimagessuchasphotosorpicture
images.
Movie Suitableforplayingbackanimatedimages.
Displays the
current mode.
(1) Press .
The FineContrast mode name appears at the lower left of the screen.
(2) One of five modes is displayed in turn each time is pressed.
Custom sRGB Text Picture MovieEyeCare
NOTE
• The Adjustment menu and the
FineContrast mode name cannot be
displayed at the same time.
• “ScreenManager Pro for LCD”
allows you to select the FineContrast
mode automatically according to the
application used.
(Refer to “Chapter 3 Auto
FineContrast” on the User’s Manual
for “ScreenManager Pro for LCD”.)

18 Chapter 2 Settings and Adjustments
● To perform advanced adjustments
Independent setting and saving of color adjustment are available for each
FineContrast mode.
● Adjustment items in each mode
According to the FineContrast mode selected, the adjustable function differs.
√: Adjustment available −: Invalid for adjustment
Icon Function FineContrast mode
Custom EyeCare sRGB Text Picture Movie
Brightness √ √ √ √ √ √
Contrast √ − − √ √ √
Temperature √ √ −√ √ √
Gamma √ √ −√ − −
Saturation √ √ −√ √ √
Hue √ √ −√ √ √
Gain √ √ − − − −
Reset √ √ √ √ √ √
● To adjust the brightness [Brightness]
The screen brightness is adjusted by changing the brightness of the backlight
(Light source from the LCD back panel).
Adjustable range: 0 to 100%
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Brightness> from the <Color> menu, and press .
The <Brightness> adjustment menu appears.
(3) Adjust the brightness with or , and press .
The adjustment is completed.
● To adjust the contrast [Contrast]
The luminance of the screen is adjusted by varying the video signal level.
Adjustable range: 0 to 100%
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Contrast> from the <Color> menu, and press .
The <Contrast> adjustment menu appears.
(3) Adjust the contrast with or , and press .
The adjustment is completed.
Attention
• Wait 30 minutes or more from
monitor power on before starting the
color adjustment.
• Perform the range adjustment rst
when adjusting color for analog input
signals.
(Refer to “To adjust color gradation
automatically [Range]” on page 16).
• The same image may be seen in
different colors on multiple monitors
due to their monitor-specic
characteristics. Make ne color
adjustment visually when matching
colors on multiple monitors.
NOTE
• The values shown in “%” or “K” are
available only as reference.
• Using the “ScreenManager Pro for
LCD” allows you to perform the color
adjustment by using the mouse and
keyboard of your PC. The adjusted
status can be registered as a color data
and restore the data later. (Refer to
“Chapter 4 Color Adjustment” on the
User’s Manual for “ScreenManager
Pro for LCD”.)
NOTE
• You can also adjust the brightness
by pressing or without
displaying the adjustment menu.
• When FineContrast is set to the
[EyeCare] mode and Brightness is
lowered to its minimum value, any
further adjustments will automatically
be transfered to Contrast. When
transferred to Contrast adjustment the
color of the value in the adjustment
menu will change.
NOTE
• In the contrast of 50%, every color
gradation is displayed.
• When adjusting the monitor, it
is recommended to perform the
brightness adjustment which may
not lose the gradation characteristics,
prior to the contrast adjustment.
Perform the contrast adjustment in the
following cases.
– When you feel the image is dark
even if the brightness is set to
100%. (Set the contrast to higher
than 50%).
– When you feel the image is bright
even if the brightness is set to 0%.
(Set the contrast to lower than
50%).

19
Chapter 2 Settings and Adjustments
● To adjust the color temperature [Temperature]
The color temperature can be adjusted. The color temperature is normally used
to express the hue of “White” and/or “Black” by a numerical value. The value
is expressed in degrees “K” (Kelvin).
In the same way as the ame temperature, the image on the monitor is displayed
reddish if the color temperature is low and is bluish if the color temperature is
high. The gain preset values are set for each color temperature setting value.
5000K The white color image is displayed reddish. The 5000K or 6000K
is usually used in the printing industry.
6500K The white color image is displayed in warm white like paper white.
Thetemperatureissuitabletodisplayphotographsorvideo
images.
9300K Thewhitecolorimageisdisplayedslightlybluishwhite.
Adjustable range: Off, 4000K-10000K (specied by every 500K unit,
including 9300K)
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Temperature> from the <Color> menu, and press .
The <Temperature> adjustment menu appears.
(3) Adjust the color temperature with or , and press .
The adjustment is completed.
● To adjust the gamma value [Gamma]
The gamma value can be adjusted. The luminance of the monitor varies
depending on the input signal, however, the variation rate is not proportional to
the input signal. To keep the balance between the input signal and the luminance
of the monitor is called as “Gamma correction”.
Adjustable range: 1.8, 2.0, 2.2
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Gamma> from the <Color> menu, and press .
The <Gamma> adjustment menu appears.
(3) Adjust the gamma value with or , and press .
The adjustment is completed.
● To adjust the color saturation [Saturation]
This function allows you to adjust the saturation of the color on the monitor.
Adjustable range: -128 to 127
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Saturation> from the <Color> menu, and press .
The <Saturation> adjustment menu appears.
(3) Adjust the saturation of the color with or , and press .
The adjustment is completed.
NOTE
• You cannot adjust the value if the
icon is not displayed, depending on
the FineContrast mode selected. (See
“Adjustment items in each mode” on
page 18.)
• [Gain] allows you to perform more
advanced adjustment (See “To adjust
the gain value” on page 20).
• If you set to [Off], the image is
displayed in the preset color of the
monitor (Gain: 100% for each RGB).
• When changing the gain value, the
color temperature adjusting range is
changed to “Off”.
NOTE
• You cannot adjust the value if the
icon is not displayed, depending on
the FineContrast mode selected. (See
“Adjustment items in each mode” on
page 18.)
Attention
• This function does not enable to
display every color gradation.
NOTE
• You cannot adjust the value if the
icon is not displayed, depending on
the FineContrast mode selected. (See
“Adjustment items in each mode” on
page 18.)
• Setting the minimum (-128) turns the
image to a monochrome screen.

20 Chapter 2 Settings and Adjustments
● To adjust the hue [Hue]
This function allows you to adjust the hue. If you set the hue to a high value,
the image turns greenish. If low, the image turns purplish.
Adjustable range: -32 to 32
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Hue> from the <Color> menu, and press .
The <Hue> adjustment menu appears.
(3) Adjust the hue with or , and press .
The adjustment is completed.
● To adjust the gain value [Gain]
Each luminance of red/green/blue composing the color is called “Gain”. The
gain adjustment may change the color tone of the “White” (when the max input
signal for each color is obtained)
Adjustable range: 0 to 100%
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Gain> from the <Color> menu, and press .
The <Gain> adjustment menu appears.
(3) Adjust the respective value of Red, Green or Blue with or , and press
.
The adjustment is completed.
2-4 Adjusting Volume [Volume]
This function allows you to adjust volume up or down.
Adjustable range: 0 to 20
(1) Choose <Sound> from the Adjustment menu, and press .
(2) Choose <Volume> from the <Sound> menu, and press .
The volume adjustment menu appears.
(3) Adjust the volume with or , and press .
The adjustment is completed.
2-5 Switching sound source during
DisplayPort signal input [Source]
This function allows you to switch sound source during DisplayPort signal
input. You can select the DisplayPort or Stereo Mini Jack.
(1) Choose <Sound> from the Adjustment menu, and press .
(2) Choose <Source> from the <Sound> menu, and press .
The Source adjustment menu appears.
(3) Select “DisplayPort” or “Stereo Mini Jack” with or , and press .
The setting is completed.
Attention
• This function does not enable to
display every color gradation.
NOTE
• You cannot adjust the value if the
icon is not displayed, depending on
the FineContrast mode selected. (See
“Adjustment items in each mode” on
page 18.)
Attention
• This function does not enable to
display every color gradation.
NOTE
• You cannot adjust the value if the
icon is not displayed, depending on
the FineContrast mode selected. (See
“Adjustment items in each mode” on
page 18.)
• The gain value may change depending
on the value of the color temperature.
• When changing the gain value, the
color temperature adjusting range is
changed to “Off”.
NOTE
• You can also adjust volume by
pressing or without
displaying the adjustment menu.
• The volume for the DisplayPort
and the stereo mini jack can be set
individually.
NOTE
• This function is available with
DisplayPort input.
