Eizo FlexScan EV2313W User manual

Important
Please read PRECAUTIONS, this User’s Manual and Setup Guide
(separate volumes) carefully to familiarize yourself with safe and effective
usage.
• Please read to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User’s Manual is available for download from our site:
http://www.eizo.com
Cover

2
[Location of Caution Statement]
Ex. FlexStand
As an ENERGY STAR®Partner, EIZO NANAO CORPORATION has determined that this product
meets the ENERGY STAR guidelines for energy efciency.
This product has acquired TCO standard that relates to safety, ergonomics, environment and so forth of ofce
equipment. For overview of the TCO, refer to our website.
http://www.eizo.com
Product specication may vary with sales areas.
Conrm the specication in the manual written in language of the region of purchase.
Copyright© 2009-2010 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
Apple and Macintosh are registered trademarks of Apple Inc.
ENERGY STAR is a U.S. registered trademark of the United States Environmental ProtectionAgency.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
DisplayPort icon and VESA are registered trademarks or trademarks of Video Electronics Standards
Association in the United States and other countries.
EIZO ScreenSlicer is a trademark of EIZO NANAO CORPORATION. EIZO, EIZO Logo, FlexScan and
ScreenManager are registered trademarks of EIZO NANAO CORPORATION in Japan and other countries.
All other trademarks are the properties of their respective owners.

3
Notice for this monitor
This product is suited to creating documents, viewing multimedia content, and other general purposes.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is used
outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable for power cords and signal cables specied by us.
Use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in
lower brightness is recommended.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime.
(Refer to “Cleaning” on the next page.)
The LCD panel is manufactured using high-precision technology. However, missing pixels or lit pixels may appear on
the LCD panel, this is not malfunction.
Percentage of effective pixels : 99.9994% or higher.
The backlight of the LCD panel has a xed life span. When the screen becomes dark or begins to icker, please contact
your dealer.
Do not press on the panel or edge of the frame strongly, as this may result in the display malfunction, such as the
interference patterns, etc. If pressure is continually applied to the LCD panel, it may deteriorate or damage your LCD
panel. (If the pressure marks remain on the LCD panel, leave the monitor with a white or black screen. The symptom
may disappear.)
Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in damage to the
panel. Do not attempt to brush with tissues as this may scratch the LCD panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation
may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation
disappears, otherwise it may cause some damages to the monitor.

4
Cleaning
Attention
• Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage
the cabinet or LCD panel.
NOTE
• Optional ScreenCleaner is recommended for cleaning the panel surface.
[LCD Panel]
• Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper.
• Remove persistent stains gently with a cloth dampened with a little water, and then clean the LCD panel again with a
dry cloth for better nishing.
[Cabinet]
Clean the cabinet with a soft cloth dampened with a little mild detergent.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the
environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
CONTENTS
Cover .............................................................1
Notice for this monitor.............................................. 3
CONTENTS.............................................................5
Chapter 1 Features and Overview .....................7
1-1 Features............................................................ 7
1-2 Controls and Functions .................................. 9
1-3 Compatible Resolutions/Frequencies ......... 10
1-4 Functions and Basic Operation.....................11
Chapter 2 Settings and Adjustments ..............15
2-1 Utility Disk ...................................................... 15
●Disk contents and software overview............... 15
●To use “ScreenManager Pro for LCD (DDC/CI)/
EIZO ScreenSlicer” .......................................... 15
2-2 Screen Adjustment........................................ 16
Digital Input.......................................................... 16
Analog Input ........................................................ 16
2-3 Color Adjustment........................................... 19
●To select the display mode
(FineContrast mode) ........................................ 19
●To perform advanced adjustments................... 20
●Adjustment items in each mode....................... 20
●To adjust the brightness [Brightness] ............... 20
●To adjust the contrast [Contrast]....................... 21
●To adjust the color temperature
[Temperature]................................................... 21
●To adjust the gamma value [Gamma]............... 21
●To adjust the color saturation [Saturation]........ 22
●To adjust the hue [Hue] .................................... 22
●To adjust the gain value [Gain]......................... 22
●To set the Overdrive intensity [Overdrive] ........ 22
2-4 Adjusting Volume [Volume] .......................... 23
2-5 Switching sound source during DisplayPort
signal input [Source]..................................... 23
2-6 Turning off the audio output at Power Saving
mode [Power Save]........................................ 23
2-7 Setting On/Off for Power Saving mode
[Power Save] .................................................. 23
2-8 Turning off the monitor automatically
[Off Timer] ...................................................... 24
2-9 Setting On/Off for the automatic brightness
adjustment function [Auto EcoView]........... 24
2-10 Shifting to the power saving mode when a
person leaves the monitor
[EcoView Sense]............................................ 25
●To set EcoView Sense On/Off.......................... 25
●To change the detection level........................... 25
2-11 Setting On/Off for the power saving level
indicator [EcoView Index]............................. 26
2-12 Screen Size Selection.................................... 26
●To change screen size [Screen Size]............... 26
●To adjust brightness of non-display area
[Border Intensity].............................................. 27
2-13 Setting Adjustment Menu Display................ 27
●To update menu settings
[Menu Size/Menu Position/Menu Off Timer/
Translucent]...................................................... 27
2-14 Setting Orientation ........................................ 28
●To set the orientation of the Adjustment menu
[Orientation]...................................................... 28
2-15 Locking Buttons ............................................ 28
2-16 Displaying Monitor Information
[Information]................................................... 29
2-17 Enabling/Disabling DDC/CI
communication.............................................. 29
2-18 Setting Power Indicator ON/OFF
[Power Indicator] .......................................... 29
2-19 Setting Language [Language]...................... 29
2-20 Setting EIZO logo display ON/OFF............... 30
2-21 Resuming the Default Setting [Reset] ......... 30
●To reset color adjustment values...................... 30
●To reset all adjustments to the factory default
settings............................................................. 30
Chapter 3 Connecting Cables..........................31
3-1 Connecting More than Two PCs to the
Monitor............................................................ 31
●To switch the input signal ................................. 32
●To set input signal selection [Input Signal] ....... 32

6CONTENTS
Chapter 4 Troubleshooting...............................33
Chapter 5 Reference .........................................36
5-1 How to Attach the Optional Arm................... 36
5-2 Attaching the FlexStand................................ 38
5-3 Attaching the TriStand .................................. 39
5-4 Folding the TriStand...................................... 40
5-5 Specications ................................................ 42
5-6 Glossary ......................................................... 48
5-7 Preset Timing................................................. 50
FCC Declaration of Conformity..........................51
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor.........................52
Hinweis zur Ergonomie.......................................52
CONTENTS

7
Chapter 1 Features and Overview
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• 23” wide format LCD
• Applicable to the resolution of 1920 × 1080
• Power saving function
Suppressing the power consumption*1 reduces the carbon dioxide emissions.
This product is equipped with various power saving functions.
– Power Consumption when main power switch is Off: 0W
Equipped with main power switch.
Turning off the main power switch completely shuts off power supply to the monitor while the monitor is not used.
– Standby power: 0.1W or less
Standby power when Power button is Off: 0.1W or less.
– LED backlight LCD panel (EV2313W only)
The LED backlight provides better power efciency and reduced power consumption*1 compared to existing uorescent
backlight LCD panels.
No mercury, a hazardous substance, is used.
– Auto EcoView function
The sensor on the front side of the monitor detects the environmental brightness to adjust the screen brightness automatically
and comfortably.
Excessively high brightness may lead a damage to the natural environment as well as to your eyes. Suppressing the excessively
high brightness will be helpful to reduce the power consumption and the damage to your eyes.
2-9 “Setting On/Off for the automatic brightness adjustment function [Auto EcoView]” (page 24)
– EcoView Sense function
The sensor on the front side of the monitor detects the movement of a person. When a person moves away from the monitor, it
shifts to the power saving mode automatically and does not display the images on the screen. Therefore, the function reduces
the power consumption.
2-10 “Shifting to the power saving mode when a person leaves the monitor [EcoView Sense]” (page 25)
– EcoView Index function
The green indicator shows the power consumption ratio responding to the brightness of the monitor. You can realize the power
consumption reduction by taking consideration in the ratio of power saving.
2-11 “Setting On/Off for the power saving level indicator [EcoView Index]” (page 26)
• Brightness stabilization through dimming control
Supports brightness adjustments over a wide range (EV2313W: 2-100%, EV2333W: 20-100%).
Even when lowering brightness to its minimum value, a stable and accurate image will be maintained. Even during use in an
extremely dark place, the brightness can be adjusted to a level which is gentle and comfortable to the eye.
• FineContrast function
2-3 “To select the display mode (FineContrast mode)” (page 19)
• Applicable to DisplayPort (applicable to 8 bit)*2
The image signal and audio signal can both be transmitted via a single DisplayPort cable (option).
• Portrait/Landscape display available
• The software “ScreenManager Pro for LCD (DDC/CI)” to adjust the screen using the mouse and keyboard is included
2-1 “Utility Disk” (page 15)
• HDCP (High-bandwidth Digital Content Interface)
• Built-in speakers and headphone jack
1-2 “Controls and Functions” (page 9)
• Overdrive function
2-3 “To set the Overdrive intensity [Overdrive]” (page 22)

8Chapter 1 Features and Overview
*1Reference values:
– EV2313W
Maximum power consumption: 32W (Luminance Max., at default settings)
Standard power consumption: 16W (100VAC, Luminance 120cd/m2, at default settings)
Standard power consumption: 16W (200VAC, Luminance 120cd/m2, at default settings)
– EV2333W
Maximum power consumption: 42W (Luminance Max., at default settings)
Standard power consumption: 25W (100VAC, Luminance 120cd/m2, at default settings)
Standard power consumption: 24W (200VAC, Luminance 120cd/m2, at default settings)
*2 When transmitting an audio signal using the DisplayPort cable, the graphics board must be compatible with audio
output. (“5-5 Specications” on page 42)
NOTE
• This monitor supports the Portrait/Landscape display. This function allows you to change the orientation of the Adjustment menu
when using the monitor screen in vertical display position. (Refer to “To set the orientation of the Adjustment menu [Orientation]”
on page 28.)
• For using the monitor with “Portrait” position, the graphics board supporting portrait display is required. When placing the monitor
in a "Portrait" position, settings of your graphics board need to be changed. Refer to the manual of the graphics board for details.
• An optional arm (or an optional stand) can be attached by removing the stand section. (Refer to “5-1 How to Attach the Optional
Arm” on page 36.)

9
Chapter 1 Features and Overview
1-2 Controls and Functions
Ex. FlexStand
1 2 3 4 5 6 7 8 9
17
10 11 12
16 13
14
15
Adjustment menu
(*ScreenManager ®)
1 EcoView Sense sensor Detects the movement of a person in front of the monitor. EcoView Sense
function (page 25).
2 Auto EcoView sensor Detects ambient brightness. Auto EcoView function (page 24).
3 EcoView button Displays the setting menu of the power saving function (Auto EcoView,
EcoView Sense and EcoView Index) (page 24, 25, 26).
4 Input Signal Selection button Switches input signals for display when more than two PCs are connected to
the monitor (page 32).
5 Enter button Displays the Adjustment menu, determines an item on the menu screen, and
saves values adjusted (page 14).
6 Control buttons (Left, Down,
Up, Right) • Chooses an adjustment item or increases/decreases adjusted values for
advanced adjustments using the Adjustment menu (page 14).
• or button: Switches the display mode (page 19).
• or button: Displays the adjustment menu of the brightness and
volume (page 11).
7 Power button Turns the power on or off.
8 Power indicator Indicates monitor’s operation status.
Blue: Operating Orange: Power saving Off: Power off
9 Main Power Switch Turns the main power on or off.
10 Power connector Connects the power cord.
11 Input signal connectors Left : DisplayPort Connector / Center : DVI-D Connector / Right : D-Sub mini
15-pin connector
12 Stereo mini jack Connects the stereo mini jack cable.
13 Security lock slot Complies with Kensington’s MicroSaver security system.
14 Stand Used to adjust the height and angle of the monitor screen.
15 Cable holder Covers the monitor cables.
16 Speaker Outputs audio source.
17 Headphone jack Connects the headphones.
* ScreenManager ® is an EIZO’s nickname of the Adjustment menu. See page 11 for how to use.

10 Chapter 1 Features and Overview
1-3 Compatible Resolutions/Frequencies
The monitor supports the following resolutions.
Analog Input (D-Sub)
Resolution Frequency
Dot Clock
640 × 480 (VGA, VESA) ~75 Hz
148.5 MHz (Max.)
720 × 400 (VGATEXT) 70 Hz
800 × 600 (VESA) ~75 Hz
1024 × 768 (VESA) ~75 Hz
1152 × 864 (VESA) 75 Hz
1280 × 960 (VESA) 60 Hz
1280 × 1024 (VESA) ~75 Hz
1280 × 720 (CEA-861) 60 Hz
1680 × 1050 (VESA CVT, VESACVT RB) 60 Hz
*1920 × 1080 (CEA-861) 60 Hz
Digital Input (DVI-D)
Resolution Frequency
Dot Clock
640 × 480 (VGA) 60 Hz
148.5 MHz (Max.)
720 × 400 (VGATEXT) 70 Hz
800 × 600 (VESA) 60 Hz
1024 × 768 (VESA) 60 Hz
1280 × 960 (VESA) 60 Hz
1280 × 1024 (VESA) 60 Hz
1280 × 720 (CEA-861) 60 Hz
1680 × 1050 (VESA CVT, VESACVT RB) 60 Hz
*1920 × 1080 (CEA-861) 60 Hz
Digital Input (DisplayPort)
Resolution Frequency
Dot Clock
640 × 480 (VGA, CEA) 60 Hz
148.5 MHz (Max.)
720 × 400 (VGATEXT) 70 Hz
720 × 480 (4:3) (CEA) 60 Hz
720 × 480 (16:9) (CEA) 60 Hz
800 × 600 (VESA) 60 Hz
1024 × 768 (VESA) 60 Hz
1280 × 960 (VESA) 60 Hz
1280 × 1024 (VESA) 60 Hz
1280 × 720 (CEA-861, CEA) 60 Hz
1680 × 1050 (VESA CVT, VESACVT RB) 60 Hz
*1920 × 1080 (CEA-861) 60 Hz
A graphics board in conformance with VESA standard and CEA-861 standard is required.
* Recommended resolution (Set this resolution)
