ekwb EK-RES X3 Lite Series Manual

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Revision 1.0. Released on November 11th 2015
Installation and mounting manual for EK-RES X3 Lite series
reservoir
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
1. Please carefully read the manual before through before beginning with the installation process!
2. The EK-ACF and EK-HDC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber o-ring gaskets.
3. The use of corrosion inhibiting coolants is always recommended for any liquid cooling system.
4. DO NOT USE any kind of alcohol or alcohol derivate with this reservoir or the acrylic tube may crack and fail! Do not clean it using alcohol either!
STEP 1: GENERAL INFORMATION. Factory provided EK-RES X3 Lite series reservoir
Congratulations on your purchase of EK-RES X3 Lite series reservoir! By default the EK-RES X3 Lite series reservoir comes with the following:
STEP 2: INSTALLING THE RESERVOIR HOLDERS
EK-RES X3 Lite series reservoirs comes with a pair of special EK-Reservoir holders. These holders are meant to be installed directly on the computer chassis.
User may need to drill 2 (two) Φ4mm holes through chassis metal using electric power drill if there are no appropriate mounting holes available.
STEP 2.1
STEP 2.2
STEP 2.3
Use enclosed M4 screw, washer and nut to
mount the reservoir holder through the pre-
drilled hole to the computer chassis.
Install reservoir onto reservoir holders. Using a
gentle force the reservoir will easily 'click' into
position. The clamps should always hold onto acrylic
tube and not the acetal top or bottom.
Once the reservoir is positioned please use enclosed
2.5mm Allen key to tighten the hex head screw in
order to clamp the reservoir. Do not use high force.
Partially unscrew the aforementioned screw when
removing the reservoir.
STEP 3 USING POLYETHER ANTI-VORTEX FOAM:
EK-RES X3 series reservoir comes preinstalled with Acrylic tube by default. In case your system suffers from excessive vortex issues, air bleeding problems or if
the pump is sucking in air you may add the enclosed polyether foam.
Default configuration
PE foam –use whole
PE foam –trim to fit recess (for Vertikal
upside down possition only!!)
This is the default configuration of EK-RES X3
series reservoir.
Use the foam as a whole in Bottom. (Could be use
in vertical position)
Trim the foam to size to fit into the desired recess
on the Reservoir Top. (For vertical upside down
position only)
EK-RES X3 –Sealing gasket
(O-Ring 12x2mm)
EK-RES X3 –AcryTube HD
EK-RES X3 –Sealing gasket
(O-Ring 52x2.5mm)
EK-RES X3 –TUBE
(104-, 204mm)
depending on the variant
EK-RES X3 –Sealing gasket
(O-Ring 52x2.5mm)
EK-RES X3 Lite –Reservoir
Bottom
EK-RES X3 Lite –Reservoir
3-port Top
EK-RES X3 Lite –M-M Extender
Revo Dual D5 Add on
TUBE
-EK-RES X3 series reservoir with preinstalled Acrylic tube
-EK-Multioption RES X3 Holder 60mm (2 pcs)
-Polyether anti-vortex foam (H=15mm)
-Mounting mechanism:
o2x G1/4 Plug
o2x EK-G1/4 Extender
oAllen Key 6mm
o1x EK-AF Extender Revo Dual D5 Add on

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Revision 1.0. Released on November 11th 2015
STEP 4: RECOMMENDED RESERVOIR CONFIGURATION
EK-RES X3 Lite series reservoir features 1 (one) G1/4 threaded inlet/outlet openings on the Reservoir Bottom plus additional 3 (three) on the Reservoir Top. In
order for reservoir to function properly one port must be used as an inlet and one as an outlet. Unused ports must be closed with plugs using enclosed 6mm
Allen key!
GENERAL OVERVIEW OF ALL G1/4 THREADED PORTS:
OTHER RECOMMENDED RESERVOIR CONFIGURATION
REQUIRED TOOLS AND ACCESSORIES:
philips screwdriver power drill with 4mm drill bit (optional)
1- Vertical Port
2- Vertical Port
3- Vertical Port
4- Vertikal Port (bottom)
RES X3 Lite in Horizontal position
RES X3 Lite in
Vertical position (PE-
foam recommended)
RES X3 Lite in
Vertical upside
down position
Inlet
Inlet
Outlet
Outlet
Inlet
Outlet
EK-Plug G1/4
Allen Key 6mm
RECOMMENDED RESERVOIR CONFIGURATION:
EK-ACF fitting
Tubing
IMPORTANT NOTES:
1. When using ports #2, #3 or #4 it is mandatory to use the enclosed EK-Extender G1/4
(EAN: 3831109845165) due the ports being recessed into the plastic Reservoir Bottom and
Top.
2. When using EK-Extender G1/4 make sure not to use fittings or barbs with G1/4 thread
longer than 5mm! All EK-ACF and EK-HDC fittings are compatible!
3. When using ports #1, #2 and #3 make sure not to use fittings or barbs with diameter
larger than 25mm! All EK-ACF and EK-HDC fittings are compatible!
4. EK recommends the use of EK-ACF fittings. When using fittings other than EK-ACF series
please use hose clamps or appropriate substitute to secure the tubing to the barb. The use
of biocide containing and corrosion inhibiting coolant is always recommended for any liquid
cooling system.
TIPS AND ADVICES:
-Using a horizontal pass-through configuration (using ports #1 as outlet #4 as inlet) will
yield in most optimal hydraulic conditions but may result in difficult initial bleeding of air in
low restriction- or high pumping power water cooling systems.
-When using a top feeding vertical configuration (using ports #1 and #4 as inlet/outlet) you
may experience severe vortex issues. Using a PE foam as will remedy this issue. Please see
STEP 3!
To connect RES X3 Lite with XTOP Revo Dual
D5 you need to use enclosed Male-Male Extender.
Extender have threat longer than 5mm!!!
NOT compatible with EK-XTOP DDC!!!
