El.mo. spa Fx/20 User manual

Analogue Addressable Fire Panel

FX/20

USER MANUAL

COMPLIANCE WITH

EN 54 - 2 1997

UNI EN 54 - 2 - 1999

CONTROL UNITS

EN 54 - 4 - 1997

UNI EN 54 - 4 - 1999

POWER SUPPLY UNITS

FX/20 - USER MANUAL

FOREWORD

FOR THE INSTALLER:

Please follow carefully the specifications on electric and security systems realization further to the manufacturer’s pre-

scriptions indicated in the manual provided.

Provide the user the necessary indication for use and system’s limitations, specifying that there exist precise specifi-

cations and different safety performances levels that should be proportioned to the user needs. Have the user view

the directions indicated in this document.

FOR THE USER:

Periodically check carefully the system functionality making sure all enabling and disabling operations were made cor-

rectly.

Have skilled personnel make the periodic system’s maintenance. Contact the installer to verify correct system opera-

tion in case its conditions have changed (e.g.: variations in the areas to protect due to extension, change of the access

modes, etc…)

......................................................

This device has been projected, assembled and tested with the maximum care, adopting control procedures in accor-

dance with the laws in force. The full correspondence to the functional characteristics is given exclusively when it is

used for the purpose it was projected for, which is as follows:

Analogue Addressable Fire Panel

Any use other than the one mentioned above has not been forecasted and therefore it is not possible to guarantee its

correct operativeness.

The manufacturing process is carefully controlled in order to prevent defaults and bad functioning. Nevertheless, an

extremely low percentage of the components used is subjected to faults just as any other electronic or mechanic pro-

duct. As this item is meant to protect both property and people, we invite the user to proportion the level of protection

that the system offers to the actual risk (also taking into account the possibility that the system was operated in a de-

graded manner because of faults and the like), as well reminding that there are precise laws for the design and as-

semblage of the systems destinated to these kind of applications.

The system’s operator is hereby advised to see regularly to the periodic maintenance of the system, at least

in accordance with the provisions of current legislation, as well as to carry out checks on the correct running

of said system on as regular a basis as the risk involved requires, with particular reference to the control unit,

sensors, sounders, dialler(s) and any other device connected. The user must let the installer know how well

the system seems to be operating, based on the results of periodic checks, without delay.

Design, installation and servicing of systems which include this product, should be made by skilled staff with the ne-

cessary knowledge to operate in safe conditions in order to prevent accidents. These systems’ installation must be

made in accordance with the laws in force. Some equipment’s inner parts are connected to electric main and therefore

electrocution may occur if servicing was made before switching off the main and emergency power. Some products

incorporate rechargeable or non rechargeable batteries as emergency power supply. Their wrong connection may da-

mage the product, properties and the operator’s safety (burst and fire).

YOUR DEALER:

USER MANUAL - FX/20

1. GENERAL

FX/20 analogue-addressable fire panel is a sophisticated microprocessor-based control unit. Its operating

principle is based on an analogue addressable communication protocol that allows prompt identification of sys-

tems alarms and faults.

FX/20 panel has been designed for fire detection systems management and is particularly suitable for large-

size installations, such as those in hotels, company buildings, shopping centres and office blocks, all areas re-

quiring high technological performance, quick installation, and easy management.

Block diagram of a fire detection system based on FX/20 control panel:

FX/20 - USER MANUAL

2. USER INTERFACE

FX/20 control panel is equipped with a large metal housing. On the front panel there is a label indicating all

LEDs functions and control keys.

Front label view:

3. LED DISPLAY INDICATIONS AND MENU

3.1 Normal operating status

The display will show the following information:

NORMAL OPERATING MODE

SUPERVISION MODE

LEVEL 1

ID CODE OF

GLOBAL

MANAGEMENT

SOFTWARE

USER MANUAL - FX/20

3.2 Fire alarm event condition

3.3 Reset procedure

RESET PROCEDURE OF AN

ALARM CYCLE, A FAULT CYCLE,

OR A MALFUNCTION CYCLE.

ACCESS LEVEL UNCHANGED.

USER PASSWORD

TO GO BACK TO NORMAL

OPERATING STATUS:

PRESS "ESC",

SELECT "EXIT TO LEVEL 1",

PRESS "ENT",

OR WAIT FOR THE TIMEOUT

FX/20 - USER MANUAL

3.4 Access with user’s password

There are four access levels:

To access different levels, digit the relevant password set.

Default passwords are:

1234 (User 0): from level 1 to level 2 - 10 USER passwords available.

2468 (Maintenance 0) from level 2 to level 3 - 10 MAINTENANCE passwords available.

Note: USER and MAINTENANCE codes are indicated on the display by asterisks.

Level 4, MANUFACTURER level, is used for firmware update procedures to be carried out by manufacturer

only.

3.5 User menu

1 = BASIC level (public level) 3 = MAINTENANCE level

2 = USER level 4 = MANUFACTURER level

USER PASSWORD

ACCESS TO THE KEYPAD

AND THE MENU.

LEVEL 2.

EXIT TO NORMAL OPERATING

MODE (LEVEL 1) WHEN THE

TIMEOUT EXPIRES.

DEFAULT USER PASSWORD = 1234

USER PASSWORD

TO ENTER

THE MENU

INDICATED

BY “>”

TO EXIT

THE MENU

CURRENT LEVEL

NOTE: THE “PROGRAM” MENU IS NOT AVAILABLE FOR USERS, ONLY FOR INSTALLERS.

USER MANUAL - FX/20

3.6 Test menu

FX/20 - USER MANUAL

3.7 Enablement menu

First diagram:

USER PASSWORD

TO SWITCH

DIS = DISABLED ENABL = ENABLED

(EXCLUDED) (INCLUDED)

EXAMPLE:

DISPLAY OF A DISABLED ZONE

(EXCLUDED). A DISABLED ZONE

GENERATES ONLY FAULT EVENTS.

NOTE: HERE ZONES ARE INDICATED ONLY

IN GENERAL TERMS.

THE NAME ASSIGNED WILL BE DISPLAYED

ONLY IN CASE OF ALARM EVENT.

DIGIT LOOP NUMBER

IF THE LOOP NUMBER EXISTS, THE LIST OF CONTROLLED

DEVICES WILL BE DISPLAYED (DETECTOS, BUTTONS, ETC.)

IF THE LOOP NUMBER DOES NOT EXIST OR HAS NOT BEEN

SAVED, THE MESSAGE “LOOP NOT SAVED” WILL BE

DISPLAYED.

TO SWITCH

DIS = DISABLED

(EXCLUDED)

ENABL = ENABLED

(INCLUDED)

DISPLAY OF A DISABLED

(EXCLUDED) DEVICE.

IN CASE OF A BELL ALARM,

THIS LED WILL LIGHT ON.

NOTE:

HERE DEVICES ARE

INDICATED ONLY IN

GENERAL TERMS.

THE NAME ASSIGNED

WILL BE DISPLAYED

ONLY IN CASE OF

ALARM EVENT.

AN EXCLUDED DEVICE

WILL CONTINUE TO

SEND DATA BUT WILL

NOT GENERATE ALARM

OR FAULT EVENTS.

TO ENTER

A MENU

OR CHANGE

THE ITEM

SELECTED

KEYS FUNCTION

USER MANUAL - FX/20

Second diagram:

DELAYED

MODE

FIRST TIME DELAY START

(ACKNOWLEDGMENT TIME)

SECOND TIME

DELAY START

(INVESTIGATION

TIMER): TOTAL

CHECK OF THE

SYSTEM TO FIND

THE REAL CAUSE

OF THE ALARM

EVENT.

OPERATIONS

CAUSE

REAL

CAUSE

LET THE REMAINING

TIME EXPIRE, OR PRESS

DELAYED MODE OPERATING DIAGRAM

INTERNAL

BUZZER

TO SWITCH

DIS = DISABLED

(EXCLUDED)

ENABL = ENABLED

(INCLUDED)

DISPLAY OF RELAY 2

DISABLED (EXCLUDED)

IN CASE OF A BELL ALARM,

THIS LED WILL LIGHT ON.

NOTE: IF YOU DISABLE A

BELL, THE

CONTROL LINE

WILL BE SUSPENDED.

SUPERVISION

OF THE

NOTE: ONLY GLASS BREAK DETECTORS

ARE EXCLUDED FROM DELAYED MODE

NOTE: “PROGRAM” MENU IS NOT AVAILABLE FOR USERS, ONLY FOR INSTALLERS.

FX/20 - USER MANUAL

3.8 Display menu

First diagram:

USER PASSWORD

MESSAGES

TO DISPLAY

NO DATA TRANSMITTED FROM

DETECTOR WITH ADDRESS 002

ASSIGNED TO LOOP 1, ZONE 1

THE BATTERY OF THE

PANEL POWER UNIT

(ADDRESS 00) IS NOT

WIRED TO FASTON CABLES

NOTE: THE MENU “DISPLAY EVENTS” LISTS DATE AND TIME OF ALL EVENTS.

IN CASE OF FIRE EVENT,

MESSAGES WITH LOWER PRIORITY

WILL BE SUSPENDED. THEY WILL

BE LOGGED IN THIS MENU UPON

ALARM RESET.

KEYS FUNCTION

TO SWITCH

YES / NO

IN THE

SELECTED

ROW

TO ENTER A MENU

OR CHANGE THE

ITEM SELECTED

KEYS FUNCTION

TO ENTER

“EDIT” MENU

OR EXIT

THE MENU

AND SAVE

THE CHANGES

KEYS FUNCTION

USER MANUAL - FX/20

Second diagram:

EVENTS LIST .

THE FIRST EVENT DISPLAYED

(4000 total) WILL BE THE OLDEST

“SYSTEM RESET” EVENT.

SET THE EVENTS FILTER

(SEE ABOVE) IF YOU WANT

TO DISPLAY ONLY PART

OF THE EVENTS LOGGED.

DISPLAY

EVENT

NUMBER OF THE EVENT

KEYS FUNCTION

DETAILS ASSOCIATED

MAX 16 CHARACTERS

KEYS FUNCTION

LOOP

ADDRESS

CURRENT

ANALOGUE VALUE

ZONE

DISPLAY OF

ACTIVE OUTPUTS

KEYS FUNCTION

FX/20 - USER MANUAL

3.9 Print menu

3.10 Outputs activation menu

USER PASSWORD

OFF LINE

EVENTS LOG

EVENTS

DEVICES

MAINTENANCE

= PRINTER OFF LINE (DEFAULT)

= PRINT ALL SYSTEM EVENTS

= APPLY FILTERS TO SYSTEM EVENTS AND PRINT RESULTS

APPLY FILTERS TO DEVICES LIST AND PRINT RESULTS

PRINT ALL DEVICES REQUIRING MAINTENANCE

SAVE CHANGES

AND EXIT

THE MENU

KEYS FUNCTION

TO EDIT

SETTINGS

ENTER A MENU

OR CHANGE

A SELECTION

KEYS FUNCTION

LOOP

USER PASSWORD

NOTE: THE ACTIVATION OF PANEL OUTPUTS MAY

DISTURB THE PEACE.

USER MANUAL - FX/20

4. GENERAL SETUP TABLES

It is strongly recommended to copy the following tables (showing operator’s general setup) to a different

location, write all settings down and keep them in a safe place.

• Password:

A- Set Level 2 access passwords:

4.1 Test Menu

•LED:

A - LED indicators test

•LCD:

B - LCD display test

LEV1 -> LEV2 Default 1234

P10

Panel power ON First LED indicators row ON

Test OK 

Test failed 

Test OK 

Test failed 

Test LCD Test OK 

Test failed 

FX/20 - USER MANUAL

• Panel Outputs:

C - LCD display test

D - Panel output test:

E -Loop output test : digit ’L’ and ’A’ addresses:

BELL A BELL B RELAY 2

Test OK 

Test failed 

Test OK 

Test failed 

Test OK 

Test failed 

Address Test result

Tes t O K Test failed 

USER MANUAL - FX/20

4.2 Enablement menu

Set:

zone,

device,

panel output,

delayed mode.

4.3 Display Menu

1. Messages cleared: displays cleared messaged.

2. Events filter

A= Set Date:

B= Set Class:

C= Set Origin:

3. Events: displays events list.

4. Device: displays devices list by indicating Land Adata.

Enabled zones (YES)

Bypassed zones (NO)

Enabled loop outputs (ON)

Disabled loop outputs (OFF)

Enabled panel outputs (ON)

Disabled panel outputs (OFF)

Delayed mode ON OFF 

Date from to

Class Settings

ALARM Display (YES) Hide (NO) 

FAULT Display (YES) Hide (NO) 

SYSTEM Display (YES) Hide (NO) 

Origin Event

DEVICE Display (YES) Hide (NO) 

CONTROL PANEL Display (YES) Hide (NO) 

LOOPS Display (YES) Hide (NO) 

PERIPHERALS Display (YES) Hide (NO) 

FX/20 - USER MANUAL

5. PROPERTIES TABLES

Table 1

DEVICE/PROPERTIES Type

Text

Zoea

Generated

System

Event

Activat.

System

Event

Generated

Logic

Event

Activat.

Logic

Event

Pattern

Standard

Thresholds

Scheduled

Thresholds

Input

Monitoring

AS Heat Detector Heat YES YES FIRE NO YES NO NO YES YES NO

EV Heat Detector Heat YES YES FIRE NO YES NO NO NO NO NO

AS Optical Smoke Detector Optic YES YES FIRE NO YES NO NO YES YES NO

EV Optical Smoke Detector Optic YES YES FIRE NO NO NO NO NO NO NO

Push Button YES YES YES YES NO YES NO NO NO NO NO

AS Input Module YES YES YES YES NO YES NO NO NO NO NO

EV Input Module YES YES YES NO NO NO NO NO NO NO NO

Output Module YES YES YES NO YES NO YES YES NO NO YES

Bell Module YES YES YES NO YES NO YES YES NO NO NO

Conventional Detectors

Module YES YES YES NO YES YES YES YES NO NO NO

Detector YES YES YES YES NO YES NO NO NO NO NO

AS = AS series device

EV = Evolution series device

YES =

Setting available

NO =

Setting unavailable (other) = set by default, cannot be modified

Table 2

Origin Event message Class Origin Generated* Activation*

N/O UNUSED N/O N/O YES YES

Device DEVICE FAULT FAULT DEVICE YES FAULT

Device FIRE ALARM DEVICE YES FIRE

Device BOMB ALARM DEVICE YES YES

Device SAFETY ALARM DEVICE YES YES

Device MESSAGE ALARM DEVICE YES NO

Device MAINS FAULT FAULT DEVICE YES MAINS FAULT

Device NO BATTERY FAULT DEVICE YES NO BATTERY

Device BATTERY OVERVOLT. FAULT DEVICE YES BATTERY OVERVOLT

Device BATTERY FAULT FAULT DEVICE YES BATTERY FAULT

Device EXTINGUISH FAULT FAULT DEVICE YES EXTINGUISH FAULT

Device PANIC ALARM DEVICE YES YES

Device TECHNOLOGIC ALARM DEVICE YES YES

Device GAS LEAKAGE ALARM DEVICE YES YES

Device WATER LEAKAGE ALARM DEVICE YES YES

Device ID CONFLICT FAULT DEVICE NO FAULT

Device NO DATA FAULT DEVICE NO FAULT

Device FAULT FAULT DEVICE NO FAULT

Device NON REGISTERED FAULT DEVICE NO FAULT

Device DEVICE DISABLE SYSTEM PANEL NO NO

Device DEVICE ENABLE SYSTEM PANEL NO NO

Device ON OUTPUT SYSTEM PANEL NO NO

Device PULSE OUTPUT SYSTEM PANEL NO NO

Loop SHORT-CIRCUITED LOOP FAULT LOOP NO FAULT

Loop OPEN LOOP FAULT LOOP NO FAULT

Loop NO DATA FAULT LOOP NO FAULT

Zone ZONE DISABLED SYSTEM PANEL NO NO

Zone ZONE ENABLED SYSTEM PANEL NO NO

Bell/RELAY RELAY DISABLED SYSTEM PANEL NO NO

USER MANUAL - FX/20

Origin Event message Class Origin Generated* Activation*

Bell/RELAY RELAY ENABLED SYSTEM PANEL NO NO

Bell OPEN CIRCUIT FAULT PANEL NO FAULT

Bell SHORT CIRCUIT FAULT PANEL NO FAULT

Bell PASSWORD ACCESS SYSTEM PANEL NO NO

Bell DELAYED MODE ENABLED SYSTEM PANEL NO NO

Bell DELAYED MODE DISABLED SYSTEM PANEL NO NO

Bell SOUNDERS ALARM ALARM PANEL NO FIRE

Bell TEMPORARY SILENCE SYSTEM PANEL NO YES

Bell BUZZER SILENCE SYSTEM PANEL NO NO

Bell PANEL RESET SYSTEM PANEL NO YES

PC PC CONNECT SYSTEM PANEL NO NO

PC PC DISCONNECT SYSTEM PANEL NO NO

PC START PC SETUP SYSTEM PANEL NO NO

PC END PC SETUP SYSTEM PANEL NO NO

Panel PHASE 1 DELAYED SYSTEM PANEL NO YES

Panel PHASE 2 DELAYED SYSTEM PANEL NO YES

Panel EXIT TO L1 SYSTEM PANEL NO NO

Panel EXIT TO L2 SYSTEM PANEL NO NO

Panel TIME OUT L2 SYSTEM PANEL NO NO

Panel TIME OUT L3 SYSTEM PANEL NO NO

Device SERVICE SYSTEM PANEL NO YES

Panel MULTIPLE ALARMS SYSTEM PANEL NO YES

Extinguish. Module EXTINGUISH. FAULT FAULT PERIPHERAL NO EXTINGUISH. FAULT

Extinguish. Module EXTINGUISH. ALARM ALARM PERIPHERAL NO FIRE

Extinguish. Module EXTINGUISH. PRE-ALARM ALARM PERIPHERAL NO PRE-ALARM

Extinguish. Module DISABLE EXTINGUISH. SYSTEM PANEL NO NO

Extinguish. Module ENABLE EXTINGUISH. SYSTEM PANEL NO NO

Panel PANEL START UP SYSTEM PANEL NO NO

Panel SYSTEM RESET SYSTEM PANEL NO NO

Panel STANDARD TIME CHANGE SYSTEM PANEL NO NO

Panel DST TIME CHANGE SYSTEM PANEL NO NO

Panel INTERNAL FLASH ERROR FAULT PANEL NO FAULT

Panel EXTERNAL FLASH ERROR FAULT PANEL NO FAULT

Panel RAM ERROR FAULT PANEL NO FAULT

Panel MODEM ERROR FAULT PANEL NO FAULT

Panel NO LOOP REGISTER. FAULT PANEL NO FAULT

Power supply LOAD FUSE FAULT FAULT PERIPHERAL NO FAULT

Power supply CPU FAULT FAULT PERIPHERAL NO FAULT

Power supply EARTH-GND SHORT-CIRC. FAULT PERIPHERAL NO FAULT

Power supply EARTH-VDC SHORT-CIRC. FAULT PERIPHERAL NO FAULT

Power supply NO BATTERY FAULT PERIPHERAL NO NO BATTERY

Power supply LOW BATTERY FAULT PERIPHERAL NO BATTERY FAULT

Power supply BATTERY OVERVOLTAGE FAULT PERIPHERAL NO BATTERY OVERVOLTAGE

Power supply MAINS FAILURE FAULT PERIPHERAL NO MAINS FAILURE

Power supply NO DATA FAULT PERIPHERAL NO FAULT

Keypad OUTPUT ON / M SYSTEM PANEL NO NO

Device OUTPUT OFF / M SYSTEM PANEL NO NO

Device ENABLED INPUT SYSTEM DEVICE NO NO

Device DISABLED INPUT SYSTEM DEVICE NO NO

Device OFF OUTPUT SYSTEM PANEL NO NO

Origin = Indicates hardware related to the event.

Event message = String displayed on display or on event log upon event occurrence.

Class = Indicates event type (alarm, fault, system). Used as a filter for event log file.

Origin = Indicates the cause of the event. Used as a filter for event log file.

Generated = indicates whether it can be associated to 'Gener. Syst. Event' and, if so, to which devices.

Activation = YES: indicates it can be used as activation event. In case it is grouped under one or

several global events, these events will be displayed.

FX/20 - USER MANUAL

6. NOTE

USER MANUAL - FX/20

7. GLOSSARY

- Self Learning: function allowing the control unit to automatically acknowledge devices connected to a

loop by reading their analogue values and comparing them to preset tables.

- Serial Bus: (bit) data transfer system used by the various parts of an electronic system for communica-

tions (sequencially).

- Events: the memory area (fixed size) containing system events.

- Cursor: display symbol indicating the insertion point of digited characters.

- System events: events generated by devices and peripherals to signal system status. The occurrence of

some of these events can be used to enable outputs (enabling events).

- Logic events: defined by a number that varies from 0 to 999, where zero (0) stands for no “association”

or “not in use”.

- Address assignation function: function allowing the control unit to identify devices connected.

- Interface: input/output device allowing panel communications.

- LCD: display emplying liquid crystals that react to polarized light and to electrical signals.

- Loop: loop modules allow realizing serial lines via loop connections and can manage up to 254 freely-

programmable devices; panels supports 2 loop modules max. to be selected according to system type:

AS loop or Evolution loop.

- Pattern: path to enable some electronic outputs in case of alarm events from preset zones.

- Analogue signal: signal not subject to numeric processing (vs. digital signals).

- Concentrators: concentrators (transmitters/receivers) are interface boards which, according to type, are

used to: connect single conventional devices, control and supervision of conventional ST-P smoke detec-

tors, control alarms, and the remote supervision of bells.

- Default value: a value set at manufacturer’s factory.

- Glassbreak / Push Button: fire alarm call point with film for protection against injuries.

- Optical smoke detector: smoke detector adopting Tyndall-effect operation mode. It is based on an inter-

nal light proof chamber equipped with a transmitter and a receiver: during normal working mode IR beam

does not reach the receiver. As the smoke enters the sensor, the amount of scattered light increases and

will reach the receiver and generate an alarm event. Regular maintenance required (esp. internal clean-

ing) to prevent false alarms.

- Temperature detector: it will trigger an alarm when the temperature of the sensitive element reaches the

threshold temperature set due to an environment temperature rise. The slower the rising, the closer the

alarm temperature will be to set threshold.

- Output module: output module to control fire detection devices featuring a free-from-potential input con-

tact, C/NC/NO (2A @ DC30V) relay output and OC output.

- Input module: input module that allow connecting conventional detectors featuring a NO contact output

to the detection loop.

- Bells output module: module to control sounders with 1 supervised output for sounders (1A max. load),

input for power unit supervision and local silencing button. External DC24V power supply required.

- Conventional detectors module: control module to monitor up to 20 ST-P conventional detectors or 5

NFD/68P flame detectors. It features 1 OC output and 1 relay output. External DC24V power supply

required.

Analogue Addressable Fire Panel FX/20 - USER MANUAL

February 2009 Edition Made in Italy 090091480

Product specifications as described above do not bind the manufacturer and may be altered without prior notice.

EL.MO. SpA Global Security Solutions Via Pontarola, 70 - 35010 Reschigliano di Campodarsego (PD) - Italy

Tel. +39 0499203333 (R.A.) - Fax +39 0499200306 - Technical Ass. +39 0499200426 - www.elmo.it - [email protected]

8. CONTENTS

1. GENERAL - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

2. USER INTERFACE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

3. LED DISPLAY INDICATIONS AND MENU - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

3.1. Normal operating status - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

3.2. Fire alarm event condition - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

3.3. Reset procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

3.4. Access with user’s password - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

3.5. User menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

3.6. Test menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7

3.7. Enablement menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8

3.8. Display menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

3.9. Print menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

3.10. Outputs activation menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

4. GENERAL SETUP TABLES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13

4.1. Test Menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13

4.2. Enablement menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

4.3. Display Menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

5. PROPERTIES TABLES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

6. NOTE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18

7. GLOSSARY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19

8. CONTENTS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20

Table of contents
