User Manual
PROTEUS
RAYZOR 1960

2
©2022 ELATION PROFESSIONAL all rights reserved. Information, speci󰤱cations, diagrams,
images, and instructions herein are subject to change without notice. ELATION PROFES-
SIONAL logo and identifying product names and numbers herein are trademarks of ELATION
PROFESSIONAL. Copyright protection claimed includes all forms and matters of copyrightable
materials and information now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or registered trademarks of their
respective companies and are hereby acknowledged. All non-ELATION brands and product
names are trademarks or registered trademarks of their respective companies.
ELATION PROFESSIONAL and all a󰤳liated companies hereby disclaim any and all liabilities
for property, equipment, building, and electrical damages, injuries to any persons, and direct
or indirect economic loss associated with the use or reliance of any information contained
within this document, and/or as a result of the improper, unsafe, insu󰤳cient and negligent
assembly, installation, rigging, and operation of this product.
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | [e-mail]
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
[phone] | [phone] fax | www.elationlighting.eu | [e-mail]
Elation Professional Mexico
AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000
[phone]
Date Document
Version
Software
Version DMX Channels Notes
09/08/2022 1.0 2.0.0 25 / 100 / 176 ch. Initial Release
09/21/2022 1.1 N/C No Change Updated Installation,
Specifications
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version
of this document may be available online.
Please check www.elationlighting.com for the latest revision/update of
this manual before beginning installation and/or programming.

3
TABLE OF CONTENTS
Introduction 4
Warranty Returns 6
Safety Precautions 7
Maintenance Guidelines 9
Overview 11
Installation 12
Torque Settings for Screws 20
Remote Device Management (RDM) 22
Control Panel 23
System Menu 24
Record Controller 27
Fan Control and Low Noise Operation 29
Lighting Console Patching Guidelines 30
DMX Traits 35
FX Generator Guidelines 46
RGBW Pixel FX Table 47
Spark LED FX Table 52
Waveforms 56
Dimmer Curves 57
Color Temperature Table 58
Primary-Secondary Set Up 60
Error Codes 61
Software Update 62
Dimensional Drawings 63
Specifications 65
FCC Statement 66

4
Please read and understand the instructions in this manual carefully and thoroughly before
attempting to operate this device. These instructions contain important safety and use infor-
mation. This device is intended for use by trained personnel only, and is not suitable for
private use.
UNPACKING
Every device has been thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the
carton is damaged, carefully inspect the device for damage, and be sure all accessories neces-
sary to install and operate the device have arrived intact. In the event that damage has been
found or parts are missing, please contact our customer support team for further instructions.
Please do not return this device to your dealer without 󰤱rst contacting customer support.
Please do not discard the shipping carton in the trash. Please recycle whenever possible.
IP65 RATED
An IP rated lighting 󰤱xture is commonly installed in outdoor environments and has been designed
with an enclosure that e󰤰ectively protects the ingress (entry) of external foreign objects such
as dust and water. The International Protection (IP) rating system is commonly expressed as
“IP” followed by two numbers (i.e. IP65) where the numbers de󰤱ne the degree of protection.
The 󰤱rst digit (Foreign Bodies Protection) indicates the extent of protection against particles
entering the 󰤱xture, while the second digit (Water Protection) indicates the extent of pro-
tection against water entering the 󰤱xture. An IP65 rated lighting 󰤱xture, such as this one,
has been designed and tested to protect against the ingress of dust (6) and low-pressure
water jets from any direction (5).
BOX CONTENTS
Power Cable (x1)
CUSTOMER SUPPORT
Contact ELATION Service for any product related service and support needs.
Also visit forums.elationlighting.com with questions, comments or suggestions.
ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
323-582-3322 | Fax [phone] | [e-mail]
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
[phone] | Fax [phone] | [e-mail]
REPLACEMENT PARTS - please visit parts.elationlighting.com
INTRODUCTION

5
INTRODUCTION
LENS POSITION FOR SHIPPING AND PACKAGING:
When re-packaging this 󰤱xture for shipping or transportation, the device must be placed
securely into the form-󰤱tting foam in-lay (FIL) that was included in the box when the 󰤱xture
was 󰤱rst purchased. Please refer to the Dimensional Drawings section of this manual for
detailed information about the foam in-lay.
Additionally, it is CRITICALLY IMPORTANT to orient the head of the 󰤱xture so that the lens
is pointing toward the base of the unit, as illustrated below. Failure to do so can result in
damage to the 󰤱xture’s zoom function while in transit. Reminder notices will be stamped
into the foam in-lay itself as a precautionary measure.
