Elation Network Device EWDMX User manual

EW DMX System
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free [phone]
TECHNICAL SPECIFICATIONS
• DMX Channels: 512 USITT DMX channels per system
• Control: 3 pin or 5 pin XLR data input & output
• Power Supply: 120V AC
• Voltage: 90-250v
• Dimensions: EWDMX R-Receiver & EWDMX T-Transmitter
( L x W x H
) 5” x 6.5” x 1.5” / 127 x 165 x 38 mm
• Weight: 1.6 lbs / 0.73 kg
• Rigging: Brackets & safety cable
FEATURES
• Transmitter & receiver package
• System includes 1 transmitter & 1 receiver
• Multiple receivers can be used per transmitter
• 1 button programming
• Up to 16 universes (transmitters)
• Up to 3,000 wireless feet
• FHSS Technology
• 3 & 5 pin XLR
System Components:
1 EWDMX T-Transmitter
• 1 Antenna
• 1 120v power supply
• 1 brackets + safety cable
• 1 user manual
1 EWDMX R-Receiver
• 1 Antenna
• 1 120v power supply
• 1 brackets + safety cable
• 1 user manual
The EW DMX System (EW DMX SYS) by Elation Professional is transmitter and receiver package which includes
one transmitter and one receiver featuring FHSS technology. W-DMX uses Adaptive Frequency Hopping
Technology (FHSS), which changes frequency 1000 times per second and jumps only to channels that are not
used by other W-LAN and/or any other products on the 2,45 GHz band. This together with TDMA (Time Division
Multiple Access) gives the user a guarantee for a much safer technology without interference. The technology
was invented by the US Army and is used in the GSM networks as well. With the EW DMX SYS multiple receivers
can be used per transmitter and control data input is via 3-pin or 5-pin XLR connections and rigging included
brackets and safety cable. This system also features 1 button programing, 512 USITT DMX channels per system,
up to 16 universes (transmitters) and up to 3,000 wireless feet.
EW DMX System Dimensions
