ELCOM RE 705 Series User manual

1
6LE002622A Ind. A
System overview
The RE..705.. display call module features an
LCD via which calls can be made to residents
quickly and cost-effectively.
3 buttons are provided for scrolling through the
list of alphabetically sorted names from A to
Z or Z to A. Press and hold down a button to
automatically increase the search speed.
A RE..704.. keyboard module for display call
built-in can be connected to the RE..705.. as an
option. in order to make calls to residents directly
by entering their call number. This option also
provides a code lock function.
Direct dial push-buttons can also be connected
to the RE..705.. by adding an REH311X/BTE-116
push-button expander.
The Display Call Module software supplied with
the product is used to update resident data and
congure the RE..705... The connection between
the PC and RE..705.. is normally established
via the RS232 interface. An REE001X/DCI-256
LAN interface built-in for display call module,
via which a TCP/IP network connection can be
established, can also be connected as an option.
If the RE..704.. display lock module is connected,
resident data can be updated and conguration
settings can be made locally via the keyboard.
The RE..705.. is connected to the 2-wire bus or
the i2 Audio bus.
TCP/IP
Network
RE..705..
RS232
Bus
REE001X/
DCI-256
RE..704..
REH311X/ BTE-116
Direct call
push-button
(or)
Description RE..705..
10
a
1 2 34b
T1 T1 T2 T2
(1)
(2)
(1) LC display
(2) Scroll and call buttons
(scroll down list / make call / scroll up list)
DE0
Xa Xb1 2 3 4
T1 T1 T2 T2
(6)(5)
(9) (10) (11)
(3) (4)
(7) (8)
(3) Connecting terminals:
Terminal 1/2: Power supply
12-28 V = / 12-18 V~ / max.
150 mA
Terminal 3/4: (no function with 2-wire)
Terminal Xa/
Xb:
2-wire or i2 Audio bus con-
nection
(4) Bus LED:
lights up when bus voltage is connected
(5) Connection for RE..704.. keyboard module
for display call built-in or REH311X/BTE-116
push-button expander
(6) Code lock connecting terminals
Terminals T1/T1:
Code lock switching contact 1 (max. 24V / 1A)
Terminals T2/T2:
Code lock switching contact 2 (max. 24V / 1A)
(7) RS232 interface
(2400/8/1/N RTS/CTS handshake)
(8) Connecting LAN interface REE001X/DCI-256
The RS232 interface must not be used when
using the LAN interface!
(9) EEproms for data storage
(10) Display contrast controller
(11) Cover
Description RE..704..
(optional module)
(12)
(13) (14)
(12) Plug connection to RE..705..
(13) Data output to RE..705..
(14) Data input for cascading REH311X/BTE-116
push-button expanders
Description REE001X/DCI-256
(optional module)
(15) (17)
(18)
(16)
(15) Plug connection to RE..705..
(16) RJ45 network connection
(17) Status LED left
OFF = no network,
Yellow = 10 Mbps,
Green = 100 Mbps
(18) Status LED right
OFF = no activity,
Yellow = half duplex,
Green = full duplex
Conguration with PC via serial
interface
The operating instructions for the REE001X/
DCI-256 LAN interface describe how to
congure a TCP/IP connection.
Software installation
System requirement:
Minimum CPU 1GHz, RAM 256MB, RS232
Interface, Windows XP SP2, NET-Framework 2.0
To start the installation process, launch the
Display Call Module Setup programme.
Follow the instructions in the installation
programme and then launch the Display Call
Module programme.
z
RE..705..
Display call module built-in
RE..704..
Keyboardmodule
6LE002622A Ind. A

2
Programme settings
To start the process, select the interface once.
Select -> -> .
In the dialog window, select
and a free interface 1-8 on your PC.
Use the data cable supplied to connect the
RE..705.. to the RS232 interface on your PC.
The RE..705.. must be in standby (graphics
animation visible).
Conguring the RE..705..
Select the set interface under
and press the button to conrm.
The current settings are then read out from the
RE..705.. and displayed in the dialog window.
Select the intercom system you are using under
.
For the bus system, the
Audio or Video door station settings and the
assigned door address must also be made.
: Door address setting on the red
rotary switch or parameter, depending on
type of door station. See also the installation
example.
 Dene the access code (consisting of 1 to 6
digits) and the relay pulse time for
and .
The master code (consisting of 1 to 6 digits)
is the security code for conguration of the
RE..705.. using the 12 keys on the RE..704..
keyboad.
Add/Change/Delete resident data
To add resident data, press the button.
The following entries can be made in the dialog
that opens next:
Display name in the list of names sorted
alphabetically.
If you want an entry to always appear rst in
the list of names, start the name with a blank
space!
Additional information that is displayed
when the resident is selected.
Number: Call number (consisting
of 1 to 6 digits) for direct selection using the 12
keys on the RE..704.. keyboard.
As call numbers are always checked for
compatibility immediately on entry, they must be
the same length for all users.
(Wrong: Resident A = 10, Resident B = 100)
(Correct: Resident A = 010, Resident B = 100)
G-Adr.: group address (0-9, A-F), corresponds
to the black rotary switch on the indoor station.
T-Adr.: intercom device address (0-9, A-F),
corresponds to the blue rotary switch on the
indoor station.
To edit or delete resident data, select the name
in the table and press the Edit or Delete button.
Transmitting resident data
To transmit data to the RE..705.., select the
interface you have set up from
and then press the button.
Press the to read out the data
from the RE..705...
Saving/loading resident data
Resident data can be saved/loaded on the
PC with the -> and ->
functions.
Conguration with RE..704.. keyboard
module for display call built-in
Initiate conguration
In standby, press and hold down the button.
Press button on the keyboard.
Enter master code
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C(Factory setting 1234).
Conrm entry with .
The conguration menu appears.
1 (Add resident)
2 (Change resident)
3 (Delete resident)
4 (Code lock 1)
5 (Code lock 2)
6 (Set operating mode)
7 (Change master code)
C (Exit)
Exit conguration
Press button to exit conguration menu.
Operating mode Set intercom system
Press the button to select “Set operating
mode” .
Press the button to select “ ” operating
mode or the button to select “ ”.
Conrm entry with button .
Select door station type
(1= video doors, 2= audio doors).
Conrm entry with button .
Use the arrow keys / to set
the door address (address 0–9, A–F).
The door address must be identical to the
setting on the door station; in the case of the
REU311X/REU511X it must be identical to the
red rotary switch.
Conrm entry with button .

3
Add resident
Press the button to select “Add resident”
.
Enter name (a max. of 16 characters)
using the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C.
Use the keyboard to enter additional
information (max. 16 characters) which appears
when someone rings the bell.
Conrm entry with button .
Enter call number (a max. of 6
digits) using the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C.
Use the arrow keys / to set the
group address (address 0–9, A–F).
Conrm entry with button .
Use the arrow keys / to set the
intercom device address (address 0–9, A–F).
Conrm entry with button .
Modify resident
Press the button to select „Edit resident“
.
Use the arrow keys / to select a resident.
Conrm the selection with the button.
Name is displayed and can be changed.
Conrm entry with button .
Once you have changed the name, proceed
as you would after entering a name in the “Add
resident” process.
Delete resident
Press the button to select “Delete resident”
.
Use the arrow keys / to select a resident.
Conrm the selection with the button.
Resident data are displayed.
Name
Info
Call number
0=Delete C=Cancel
Press the button to delete the resident or the
button to cancel.
Code lock 1
Select “Code lock1” by pressing
button .
Use the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
Cto enter the code (max. 6
digits).
Conrm entry with button .
Enter the switching duration (1–9 sec. or
0 = on/off function) via the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C
.
Conrm entry with button .
Code lock 2
Select “Code lock2” by pressing
button .
Use the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
Cto enter the code (max. 6
digits).
Conrm entry with button .
Enter the “switching duration”
(1–9 sec. or 0= on/off function) via the
keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C.
Conrm entry with button .
Change master code
Press the button to select “Change master
code” .
Use the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C
to enter the code (max. 6
digits).
Conrm entry with button .
Keyboard assignment for entering names
But-
ton
Possible characters
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
- .
0
DEF
3
MNO
6
WXYZ
9
C
1 <EMPTY> 1
2 a äâà b c A ÄÂ B C 2
3 d e é è f D E ÉF 3
4 g h iíî G H I 4
5 j k l J K L 5
6 m n o ö óôM N O Ö 6
7p q r s ß P Q R S 7
8t u ü ûúv T U Ü V 8
9w x y z W X Y Z 9
0<EMPTY> - . 0
Factory settings
The RE..705.. is delivered with the following
settings:
- Operating mode:
i2 bus, Video door station, door address 0
- Codes lock 1:
Code = 1; Switching duration = 1 sec.
- Codes lock 2:
Code = 2;Switching duration = 1 sec.
- Master code: 1234
Data import/export
The Display Call Module software saves the
resident data as a CSV le. In this format, the
data can be imported into and exported from
other programs (e.g. spreadsheet programs).
Field lengths and permissible characters:
Name
(a max. of 16 characters)
{a-z, A-Z, 0-9,
äöüèéêáàâßAÈÀÖÜ.!}
Info
(a max. of 16 characters)
{a-z, A-Z, 0-9,
äöüèéêáàâßAÈÀÖÜ.!}
Call number
(a max. of 6 characters)
{0-9}
Group addr.
(1 character)
{0-9, A-F}
Subscriber addr.
(1 character)
{0-9, A-F}
Replacing data storage
When you open the cover you will see two
EEproms (9).
DE0
Xa Xb1 2 3 4
T1 T1 T2 T2
(9)
Resident data is stored in the left-hand
EEprom 0. When a device is replaced, the
resident data can be transferred by changing
over the EEprom.
Country-specic texts are saved in the right-
hand EEprom DE .
Operation
Making a selection from the list of names
The names of all residents appear in the list of
names sorted alphabetically. Use the arrow keys
/ to scroll through the list of names from A
to Z or Z to A. Press and hold down a button to
automatically increase the search speed.
Use the arrow keys / to select a resident.
Landmann Peter
Maier Hans
Nietschke Erwin
Ottmann Fritz
Once you have made your selection, press the
button.
The resident is called and the additional
information and call number are
displayed.
To call the resident again press button .
Making a selection by entering a call number
(RE..704.. only)
If you know the resident‘s call number, you can
enter it using the 12 keys on the keyboard.
Use the 12 keys on the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C
to enter
the call number.
Input eld is displayed.
Once the call number has been entered in full,
the call is made to the resident.
To call the resident again press button .
Intercom connected indicator
When the user picks up the door call, a
loudspeaker symbol appears on the display.
Code lock function
Press button .
Use the keyboard
1
GHI
4
PQRS
7
ABC
2
JKL
5
TUV
8
-.
0
DEF
3
MNO
6
WXYZ
9
C
to enter the code .
To conrm, press button again.
If the code is entered correctly, also
appears in the display and the relevant code
lock contact is closed for the set amount of
time.
or
If the code is entered incorrectly, also
appears in the display and an error signal
sounds.
Installation and electrical connection
DANGER!
Touching live parts in the installation
environment can result in an electric
shock!
An electric shock can be lethal!
Before working on the device or load,
disconnect all associated circuit brea-
kers. Cover all live parts in the area!
ç
Installing the device
Installation of the device depends upon the
respective product it is going to be installed in
(see relevant mounting instructions)

4
Connect device
The connection cables and indoor stations are
connected to the line power supply while taking
the maximum cable lengths and attenuations into
account (see operating instructions of the line power
supply).
Bring pre-assembled station (door station,
frame, etc.) in installation position - if necessary
with safety rope and tools.
Shorten connection cable of the station as
required and strip the required wires.
Connect the wire pair of the 2-wire bus cable,
together with the additional wire pair, to the Xa
Xb terminals of the display call module.
Connect 12 V~ to terminals 1 and 2.
Optional: Plug the connection cable for the
keyboard module into the plug connector of
the display call module. Optional: Connect a
button expander to the plug connector for the
keyboard module.
Pull off connection terminal block from the audio
or video module.
Connect the additional wire pair of the 2-wire
bus cable to the XX terminals and 12 V~ to the
~~ terminals of the connection terminal block of
the video or audio module.
The video/audio module must be connected to
the 2-wire bus cable as the nal device in the
line.
Connect the door release cable to the terminals
TT of the connection terminal block if required.
The door release can be installed in a tamper-
proof manner without using the code lock
function (see system manual).
For call push-button backlighting and camera
heating connect 12 V~ lead from the power
transformer to the terminals ~~ of the
connection terminal block.
Attach connector of the module connection
cable to the next call push-button module on
the device.
Attach connection terminal block to the device.
Engage and screw in the module e.g. in the
rear latching receptacle of a door station (see
corresponding mounting instructions).
Close station
Circuit symbols and elements of the circuit
diagrams
Indoor station (audio)
Indoor station video
Video module
Set door address 00
ABC
Display call module built-in
Set door address 0
Line power supply RMD
Mains transformer 12 V~ RMD
Push-button, NO contact
Storey push-button
Terminator/terminating resistor
Door release
Wrapped wire pair for 2-wire devices
(recommendation: white/yellow wire pair)
Wire pair
Technical data
Power supply: 12-18 V~ or
12-28 V= (max. 150 mA)
Intercom systems: 2-wire
i2 Audio
Replacement 1+n
Memory slot: 256 resident data records with:
name eld: 16 characters
info eld: 6 characters
call number: 1–6 digits
Code lock:
(only with RE..704..) 2 independent potential-free
Switching contacts (max 24V/1A).
Code 1-6 digits.
Switch-on time 1–9 sec. or
On/off mode (toggle mode)
Interfaces: RS232;
REE001X/DCI-256 LAN interface
Display: 128 x 64 pixels (63 x 44mm),
illuminated
Temperature range: -25 °C .. +55 °C
Dimensions (W x H x D): 120 x 120 x 39 mm
00
2
0
1
2
.
.
.
.
4(52))
2
2
2
2
2
ABC
0
7
2
Mon
12 V~
Cam 230 V~PE
230 V~
Push-button-
expander
connection
6LE002622A Ind. A12.2017
