janitza Procont-LMC Instruction manual

Doc. no. 2.100.141.1.a 08/2023
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau | Germany
Support tel. [phone]
[email protected] | www.janitza.de
User manual and technical data
Load Management Controller
Procont®-LMC
Procont®-LMC-LITE
www.janitza.de

www.janitza.de
2
Procont®-LMC | Procont®-LMC-LITE
Procont®-LMC
Procont®-LMC-LITE
Load Management Controller
Doc. no.: 2.100.141.1.a
08/2023
The German version is the original edition of the documentation.

www.janitza.de
3
Procont®-LMC | Procont®-LMC-LITE
Subject to technical alterations.
The contents of our documentation have been compiled with great care and reflect the current state of
the information available to us. Nonetheless, we wish to point out that updates of this document are not
always possible at the same time as technical refinements are implemented in our products. Information
and specifications are subject to change at any time.
Please check for the latest version at www.janitza.de.

www.janitza.de
4
Procont®-LMC | Procont®-LMC-LITE
TABLE OF CONTENTS
1. Information on the device and the user manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Copyright notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 Technical changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 About this user manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Defective device/disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Display of warning notices and safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Hazard levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Product safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.4 Dangers when handling the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5 Electrically qualified personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.6 Warranty in the event of damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Device description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Incoming goods inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4 EU conformity declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.5 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.6 Variant overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Structure of the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1 Front panel - Display and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Rating plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Assembly and installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6. Connection and PC connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7. Screen on Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8. Alarm settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.1 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.2 Instantaneous value alarm (limit values) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9. Eco controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10. Inputs/outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.2 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10.3 Pulse valency for external meters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10.4 Function modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

www.janitza.de
5
Procont®-LMC | Procont®-LMC-LITE
11. Ethernet adapter/ network settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11.1 TCP/IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11.2 TCP/IP addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11.3 TCP/IP ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11.4 DNS address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11.5 Internet clock: active. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
12. External meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
12.1 External meters - configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
13. Load groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
13.1 Controller type: Normal
(digital -> on/off e.g. with relay) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
13.2 Controller type: Controller
(analog 0-100%). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
13.3 Early warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
14. Lastkontrolle (Load control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
14.1 Sollwerte (Setpoints) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
14.2 Max. values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
14.3 Main meter (HZ): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4 Div. parameters 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4.1 Hysteresis: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4.2 Switching interval: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4.3 !LG reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4.4 12 setpoints:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.4.5 Div. parameters 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14.5 Gas ALS: Gas load control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
14.6 Maximum power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
14.7 Progressive maximum: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
14.8 Emergency stop curve: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
14.9 Main meter alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
14.10 ABS (reactive power management) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
15. Master and sub-controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
15.1 Control types & links for Procont®-LMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
16. Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
17. Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
17.1 SS1 Interface 1 RS-232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
17.2 SS2 interface 2 RS-232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
17.3 SS3 interface 3 RS-485 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

www.janitza.de
6
Procont®-LMC | Procont®-LMC-LITE
18. Special days . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
19. System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
19.1 Uhrzeit/Datum (Time/Date) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
19.2 Allgemein (General) 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
19.3 Allgemein (General) 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
20. Tarife/Synchronisation Tariffs/Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
20.1 Synchronisation (Synchronization) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
20.2 Tariff switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
20.3 Niedertarif (Low tariff) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
20.4 Sommertarif (Summer tariff) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
20.5 Spezialtarif (Special tariff) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
21. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
21.1 Overview of displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
21.2 Kontrollen und Momentanwerte (Controls and instantaneous values) . . . . . . . . . . . . . . . . . 49
21.2.1 Alarme (Alarms). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
21.2.2 Momentanwerte (Instantaneous values). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
21.2.3 Load group state . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
21.2.4 Period view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
21.2.5 I/O: Eingäng/Ausgänge (Inputs/outputs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
21.2.6 Lastgruppen (Load groups) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
21.2.7 Control types: Procont®-LMC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
21.2.8 Analog inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
21.2.9 Schaltuhr (Timer). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
21.2.10 E-Ladesteuerung (E-charge control). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
21.2.11 TCP/IP module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
21.3 Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
21.3.1 Zustand (State) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
21.3.2 Tagesverbrauch (Daily consumption)TVb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
21.3.3 Monthly consumption (MVb): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
21.3.4 Annual consumption (JVb):. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
22. Procedure in the event of a malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
23. FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

www.janitza.de
7
Procont®-LMC | Procont®-LMC-LITE
24. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
24.1 Dimensional drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
24.2 Connection diagram, example of
Procont®-LMC, Procont®-LMC-LITE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
25. Maintenance and service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
25.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
25.2 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

www.janitza.de
8
Procont®-LMC | Procont®-LMC-LITE
1. Information on the device and the user manual
1.1 Disclaimer
Compliance with the usage information for the
devices is a prerequisite for safe operation and
attaining the stated performance characteristics
and product features.
Janitza electronics GmbH assumes no liability for
bodily injury, material damage or financial losses
which result from disregard of the usage informa-
tion.
Make sure that your usage information is readily
available and legible.
1.2 Copyright notice
© 2022 - Janitza electronics GmbH - Lahnau.
All rights reserved.
Any reproduction, processing, distribution or other
use, in whole or in part, is prohibited.
All trademarks and the rights arising from them
are the property of the respective owners of these
rights.
1.3 Technical changes
· Make sure that your device matches the user
manual.
· This user manual is valid for the Procont®-LMC
and Procont®-LMC-LITE. Separate validities and
distinctions are marked.
· First make sure you have read and understood
the usage information accompanying the prod-
uct.
· Keep the usage information associated with the
product available for the entire service life and
pass it on to any possible subsequent users.
· Find out about device revisions and the associat-
ed modifications of the usage information associ-
ated with your product at www.janitza.de.
1.4 About this user manual
If you have questions, suggestions or ideas for im-
provement of the user manual, please let us know
via email at: [email protected].
INFORMATION
This manual is valid for devices of the type:
• Procont®-LMC-LITE
• Procont®-LMC
The settings can be made directly on the device or
also via the Procont®-VIS configuration software.
You can find this software and the corresponding
user manual in the download area on our website
www.janitza.de.
Please note that after 30 days a paid license key is
required for the software.
In addition to this user manual, please refer to ad-
ditional usage information for your device, such as:
• Installation manual.
• Data sheet
• “Safety Information” supplement.
If applicable, also refer to the usage information
about expansion modules, such as
User manuals
Data sheets
Installation manual.
INFORMATION
Our usage information uses the grammatical mas-
culine form in a gender-neutral sense! This form
always refers equally to women, men and diverse.
In order to make the texts more readable, distinc-
tions are not made. We ask for your understand-
ing for these simplifications.

www.janitza.de
9
Procont®-LMC | Procont®-LMC-LITE
1.5 Defective device/disposal
Before sending defective devices, modules or
components back to the manufacturer for testing:
· Contact the manufacturer's Support department.
· Send devices, modules or components complete
with all accessories.
· When doing so, please bear the terms for trans-
portation in mind.
INFORMATION
Please return defective or damaged devices to
Janitza electronics GmbH in accordance with the
shipping instructions for air or road freight (complete
with accessories).
Observe special regulations for devices with built-in
batteries or rechargeable batteries!
Do not attempt to open or repair the device (the
component) on your own because otherwise all
warranty claims become invalid!
For the Disposal of the device please observe
national regulations! Dispose of individual parts, as
applicable, depending on their composition and
existing country-specific regulations, e.g. as
· Electronic waste,
· Batteries and rechargeable batteries,
· Plastics,
· Metals.
Engage a certified disposal company to handle
scrapping as needed.
Information on service and maintenance of your
device can be found in chapter „25. Maintenance
and service“ on page 63.

www.janitza.de
10
Procont®-LMC | Procont®-LMC-LITE
The chapter on Safety contains information which
must be observed to ensure your personal safety
and avoid material damage.
2.1 Display of warning notices and safety
information
The warning notices shown below
· are found throughout all of the documentation,
· can be found on the devices themselves.
· indicate potential risks and hazards,
· underscore aspects of the information provided
that clarifies or simplifies procedures.
The additional symbol onthedevice itself indi-
cates anelectrical danger that can result in serious
injuries or death.
This general warning symbol draws attention to a
possible risk of injury. Be certain to observe all of
the information listed under this symbol in order to
avoid possible injury or even death.
2. Safety
2.2 Hazard levels
Warning and safety information is marked by a
warning symbol, and the hazard levels are shown
as follows, depending on the degree of hazard:
DANGER
Warns of an imminent danger which, if not avoid-
ed, results in serious or fatal injury.
WARNING
Warns of a potentially hazardous situation which, if
not avoided, could result in serious injury or death.
CAUTION
Warns of an immediately hazardous situation
which, if not avoided, can result in minor or mod-
erate injury.
ATTENTION
Warns of an immediately hazardous situation
which, if not avoided, can result in material or envi-
ronmental damage.
INFORMATION
Indicates procedures in which there is no hazard
of personal injury or material damage.

www.janitza.de
11
Procont®-LMC | Procont®-LMC-LITE
WARNING
Risk of injury due to electrical voltage!
Severe bodily injury or death can result! Therefore
please abide by the following:
· Switch off your installation before commenc-
ing work! Secure it against being switched on!
Check to be sure it is de-energized! Ground and
short circuit! Cover or block off adjacent live
parts!
· During operation and troubleshooting (espe-
cially for DIN rail devices), check your system
for dangerous voltages and switch these off if
necessary!
· Wear protective clothing and protective equip-
ment in accordance with applicable guidelines
when working on electrical systems!
· Before making connections to the device/the
component, ground the device by means of the
ground wire connection, if present.
· Do not touching bare or stripped leads that are
energized! Equip stranded conductors with wire
ferrules!
· Hazardous voltages can be present in all circuit-
ry parts that are connected to the power supply.
· Protect wires, cables and devices with a suitable
line circuit breaker/fuse!
· Never switch off, remove or tamper with safety
devices!
· There can still be hazardous voltages present
in the device or in the component even after it
has been disconnected from the supply voltage
(capacitor storage).
· Do not operate equipment with current trans-
former circuits when open.
· Only connect screw terminals with the same
number of poles and design!
· Do not exceed the limit values specified in the
user manual and on the rating plate! This must
also be observed during testing and commis-
sioning.
· Take note of the safety and warning notices in
the documents that belong to the device!
2.3 Product safety
The device reflects current engineering practice
and accepted safety standards, but hazards can
nonetheless arise.
Observe the safety regulations and warning no-
tices. If notices are disregarded, this can lead to
personal injury and/or damage to the product.
Every type of tampering with or use of this device,
· which goes beyond the mechanical, electrical or
other operating limits can lead to personal injury
and/or damage to the product;
· constitutes “misuse” and/or “negligence” under
the product’s warranty and thus voids the war-
ranty for any possible resulting damage.
Read and understand the user manual before
installing, operating, maintaining and using the
device.
Only operate the device when in perfect condition
and in compliance with this user manual and the
usage information that is included. Send defective
devices back to the manufacturer in compliance
with proper transport conditions.
Retain the user manual throughout the service life
of the device and keep it at hand for consultation.
When using the device, also observe the legal and
safety regulations for your system that are applica-
ble for the respective use case.
2.4 Dangers when handling the device
When operating electric devices, it is unavoid-
able for certain parts of these devices to conduct
hazardous voltage. Consequently, severe bodily
injury or material damage can occur if they are not
handled properly.
Therefore, when handling our devices, always
observe the following:
· do not exceed the limit values specified in the
user manual and on the rating plate! This must
also be observed during testing and commission-
ing!
· Take note of the safety and warning notices in all
usage information that belongs to the device!

www.janitza.de
12
Procont®-LMC | Procont®-LMC-LITE
WARNING
Warning against unauthorized manipulation or
improper use of the device or its components!
Opening, dismantling or unauthorized manipula-
tion of the device and its components which goes
beyond the mechanical, electrical or other operat-
ing limits indicated can lead to material damage or
injury, up to and including death.
· Only electrically qualified personnel are permit-
ted to work on the devices and their compo-
nents, assemblies, systems and current circuits.
· Always use your device or component only in
the manner described in the associated docu-
mentation.
· If there is discernible damage, send the device
or the component back to the manufacturer!
2.5 Electrically qualified personnel
To avoid bodily injury and material damage, only
electrically qualified personnel are permitted to
work on the devices and their components, mod-
ules, assemblies, systems and current circuits who
have knowledge of:
· The national and international accident preven-
tion regulations.
· Safety technology standards.
· Installation, commissioning, operation, discon-
nection, grounding and marking of electrical
equipment.
· The requirements concerning personal protective
equipment.
Electrically qualified persons within the scope
of the technical safety information of all usage
information associated with the device and its
components are persons who can furnish proof of
qualification as an electrically skilled person.
2.6 Warranty in the event of damage
Any unauthorized tampering with or use of the
device constitutes "misuse" and/or "negligence"
under the product’s warranty and thus voids the
warranty for any possible resulting damage. In
this regard, note chapter „3.3 Intended use“ on
page14.

www.janitza.de
13
Procont®-LMC | Procont®-LMC-LITE

www.janitza.de
14
Procont®-LMC | Procont®-LMC-LITE
3. Product description
3.1 Device description
The device is the central system for a load control
and energy management system that can spe-
cifically influence consumption and thus avoid
expensive load peaks.
A 9-key keypad is used for operation.
3.2 Incoming goods inspection
Safe and trouble-free operation of this device and
its components presupposes proper transport,
proper storage, set-up and assembly as well as
operation and maintenance in addition to com-
pliance with the safety information and warning
notices.
Exercise due caution when unpacking and packing
the device, do not use force and only use suitable
tools.
Before installing the device, please check the
following:
· Its flawless mechanical condition by visual in-
spection.
· The scope of delivery for completeness.
If it can be assumed that safe operation of the
device is no longer possible:
· Disconnect the device from operation immediate-
ly!
· Secure the device against being switched on
again!
It can be assumed that safe operation is no longer
possible if the device, for example:
· Has visible damage.
· No longer functions despite an intact power
supply.
· Was subjected to extended periods of unfavor-
able conditions (e.g. storage outside of the per-
missible climate thresholds without adjustment to
the room climate, condensation, etc.) or transport
stress (e.g. falling from an elevated position, even
without visible external damage, etc.).
3.3 Intended use
The device is:
· Only for use in the industrial sector.
· Intended for installation in switchboard cabinets
and small distribution boards.
· Intended for mounting on a DIN rail.
· Not intended for installation in vehicles! Use of
the device in non-stationary equipment consti-
tutes an exceptional environmental condition and
is only permissible by special agreement.
· Not intended for installation in environments with
harmful oils, acids, gases, vapors, dusts, radia-
tion, etc.
· Designed as an interior meter.
Safe and trouble-free operation of the device
requires proper transport, storage, assembly,
installation, operation and maintenance.
3.4 EU conformity declaration
Please see the EU declaration of conformity post-
ed at www.janitza.de for the laws, standards and
directives applied by Janitza electronics GmbH for
the devices. The CE conformity marking require-
ments for the device arise from the EU conformity
declaration and the laws, standards and directives
mentioned therein.
3.5 Scope of delivery
Quantity Part. no. Designation
160 00 300
60 00 301
Procont®-LMC
Procont®-LMC-LITE
1 33 03 389 Installation manual

www.janitza.de
15
Procont®-LMC | Procont®-LMC-LITE
3.6 Variant overview
Features Procont®-LMC Procont®-LMC-LITE
Total number of charging stations and storage facilties, max. 32 16
Inverter and Modbus devices in total, max. 20 8
Functions Procont®-LMC Procont®-LMC-LITE
Watchdog: Autom. restart after a mains power failure • •
Emergency stop curve • •
"Multi-out" (linked outputs) • •
"multi-switch" (outputs) • •
"multi-timer" (timer) • •
Alarm processing (e-mail) • •
Eco-controller function • •
Tariff management (12 setpoints) •
Self-optimization (progressive maximum) •
KNX/EIB Dupline •
"multi-control" (control types) •
Parameter switching •
Curve 2 (2nd setpoint curve) •
Multi-link (logical links load groups) •
Gas load control •
8 main meters control performance •
Control performance •
Special tariff for emergency power •
Procont®-LMC Procont®-LMC-LITE

www.janitza.de
16
Procont®-LMC | Procont®-LMC-LITE
4. Structure of the device
4.1 Front panel - Display and controls
Item Function/Designation
1Display (4 lines, background illumination)
2Inputs (utility pulses, synchronous, sub-meter)
3Outputs (load groups)
4Analog inputs (measurement, sensor and envi-
ronmental data)
5Serial interfaces (RS-232, RS-232/485)
6Status LED (inputs/outputs) LED on = I/O ac-
tive, LED off = I/O inactive
7EthernetTCP/IP (100BaseT)
8USB service interface
9Operation (9-key keypad)
10 Mains supply 230 VAC, 50 Hz
1
2 3 54
7
8
10
6
9
Button Function
Programming
Retrieve data
Apply input
Navigate down
Navigate up
Navigate right
Navigate left
Increase value
Decrease value
DATA
PROG
+
-

www.janitza.de
17
Procont®-LMC | Procont®-LMC-LITE
Smart Energy &
Power Quality Solutions
Janitza electronics GmbH / Germany • www.janitza.com
Blatt / Page : 1 / 1
Ausgabe : 04.04.2022
Vorschlag: Typenschild PROCONT-Serie
Hinweis: Janitza Typenschilder gibt es in zwei Größen-Varianten.
Diese Vorschlags-Variante ist 50,8 mm breit und 25,4 mm hoch.
Typenschild PROCONT-Serie Datum Dok.-Nr.:
Erstellt: Th. Braun 18.10.2021 2.100.087.0.a
Korrigiert: Th. Braun 27.10.2021 2.100.087.0.b
Korrigiert: Th. Braun 02.12.2021 2.100.087.0.c
Korrigiert: Th. Braun 04.04.2022 2.100.087.0.d
Korrigiert: Th. Braun 04.01.2023 2.100.087.0.e
Category supply voltage
Item number
Type
2D code (DataMatrix)
with device name
and item number.
CE
Date of manufacture or delivery month / year
Hardware or firmware index
Country of manufacture
Address (quasi-manufacturer)
Imprint (manufacturer-specific),
serial number
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC • 6000300 10/2021 • 16.0f
Aux: 230V, 50Hz .9VA
PROCONT-LMC-008-IO • 6000303 10/2021 •002
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC-LITE • 6000301 10/2021 • 16.0f
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-EMC • 6000302
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
10/2021 • 16.0f
Typenschild PROCONT-LMC-LITE Typenschild PROCONT-EMC
Typenschild PROCONT-LMC-008-IOTypenschild PROCONT-LMC
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
UK importer
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC-LITE • 1402025 10/2021 • 16.0f
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
Category supply voltage
Item number
Type
2D code (DataMatrix)
with device name
and item number.
CE
Date of manufacture or delivery month / year
Hardware or firmware index
Country of manufacture
Address (quasi-manufacturer)
Imprint (manufacturer-specific),
serial number
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC • 6000300 10/2021 • 16.0f
Aux: 230V, 50Hz .9VA
PROCONT-LMC-008-IO • 6000303 10/2021 •002
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC-LITE • 6000301 10/2021 • 16.0f
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-EMC • 6000302
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
10/2021 • 16.0f
Typenschild PROCONT-LMC-LITE Typenschild PROCONT-EMC
Typenschild PROCONT-LMC-008-IOTypenschild PROCONT-LMC
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau / Germany
Made in Austria
UK importer
Aux: 100..240V, 50/60Hz .9-15VA
PROCONT-LMC-LITE • 1402025 10/2021 • 16.0f
UK: Represented by
Authorised Rep Compliance Ltd.
ARCHouse
Thurnham
Lancaster
LA2 0DT
UK
4.2 Rating plate
Procont®-LMC and Procont®-LMC-LITE
3
1
2
4
56 7
9
10
Item Designation Description
1UK representative Country of origin and address of the UK representative
2Operational data Supply voltage, AC in V Nominal frequency in Hz
Power consumption in VA
3Device type Device designation
4Part number Manufacturer’s part number
5Data matrix code Coded manufacturer data
6Designation of origin Country of origin and address of the manufacturer
7CE conformity marking See section „3.4 EU conformity declaration“ on page 14.
8Manufacturer-
specific data Manufacturer data
9Hardware version Hardware version of the device
10 Type/serial number Number for identification of the device
8

www.janitza.de
18
Procont®-LMC | Procont®-LMC-LITE
5. Assembly and installation
The installation of the load management controller
Procont®-LMC-LITE, Procont®-LMC is carried out
as follows:
1. Install an isolation device (switch or circuit
breaker) and an overcurrent protective device
(2-10 A).
INFORMATION
As an alternative to the isolation device or
fuse, you can use a line circuit breaker.
2. Mount the measurement device in switchboard
cabinets or small distribution boards according
to DIN 43880 (any mounting orientation) on a
35mm (1.38in) DIN rail.
3. Press the bottom bolt into the device. Check
the device for a firm fit. The mounting orienta-
tion is arbitrary.
Press
4. Connect the device to your local network
using a standard RJ45 patch cable.
DANGER
Risk of injury due to electrical voltage!
Severe bodily injury or death can result from:
·Touching bare or stripped leads that are ener-
gized.
·Device inputs that pose a hazard when
touched.
Switch off your installation before commencing
work! Check to be sure it is de-energized!
5. Connect the supply voltage.
Refer to the rating plate for the proper supply
voltage for your device. After connecting the
supply voltage, the display becomes active. If
no display appears, check whether the supply
voltage is within the nominal voltage range.
PE L L N N
L1
L2
L3
N
PE
Fig. Power supply connection
ATTENTION
Material damage due to disregard of the instal-
lation instructions!
Disregard of the installation instructions can
damage or destroy your device.
·Observe the information on the mounting orien-
tation in the sections “Mounting” and “Technical
Data”.
·Provide adequate air circulation in your installa-
tion environment and, as needed, cooling when
the temperatures are high!

www.janitza.de
19
Procont®-LMC | Procont®-LMC-LITE
6. Connection and PC connections
Establish the connection to the PC
Possible connections for communication between
the PC and the device: Example circuit diagrams/
connections:
The PC and device need a static IP address.
Patch cable Patch cable
DHCP
Server PC
Switch/Router
The DHCP server automatically assigns IP addresses to device
and PC.
Procont®
ATTENTION
Material damage due to security vulnerabili-
ties in programs, IT networks and protocols.
Security vulnerabilities can lead to data misuse
and faults and even the standstill of your IT infra-
structure.
To protect your IT system, network, data com-
munications and measurement devices:
·Inform your network administrator and/or IT
representative.
·Always keep the meter firmware up to date and
protect the communication to the meter with
an external firewall. Close unused ports.
·Take protective measures against viruses and
cyber attacks from the Internet, e.g. through
firewall solutions, security updates and virus
protection programs.
·Eliminate security vulnerabilities and update or
renew existing protection for your IT infrastruc-
ture.
Patch cable
PC Procont®
ATTENTION
Material damage due to incorrect network
settings.
Incorrect network settings can cause faults
intheIT network!
·Ask your network administrator
about the correct network settings for your
device.
Patch cable
Fig. Ethernet interface.

www.janitza.de
20
Procont®-LMC | Procont®-LMC-LITE
7. Screen on Display
The following screen appears on the display after
an initialization routine has been completed:
Time hh:mm:ss (hours:minutes:seconds)
Day of the week
Date dd.mm.yyyy
Main meter (HZ): kW
10.0 m (elapsed time in measurement interval)
Tariff (HT or NT) /Winter /Summer
Switched-off load groups (AbgLG): 0
10:00:00 MI 10.05.2022
HZ: 0.00 kW 10.0m
HT/Wint. Abg.LG: 0
10:00:00 MI 10.05.2022
HZ: 0.00 kW 10.0m
HT/Wint. Abg.LG: 0
Pressing the PROG button takes you to the se-
lection menu for the settings. Use the keypad to
select the desired settings and confirm with OK.
The following settings can be selected:
·Alarmeinstellungen (Alarm settings)
·Eco-Regler (Eco controller)
·Ein/Ausgänge (Inputs/outputs)
·Ethernet-Adapter (Ethernet adapter)
·E-Ladesteuerung (E-charge control)
·Ext. Zähler (Ext. meter)
·Lastgruppen (Load groups)
·Lastkontrolle (Load control)
· Master-Strg.+ Ust (Master controller + sub-con-
troller)
·Regeln + Verknüpfung (Control types + links)
·Schaltuhr (Timer)
·Interfaces
·Sondertage (Special days)
·System settings
·Tarife/Synchronisier. (Tariffs/Sync.)
