ETI Tracon GPT 230 User manual

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
PACKING LIST
QTY. PART NO. DESCRIPTION
1 25171 TRACON MODEL GPT 230 Dual-Point General Purpose Heat–Trace Control
225076 Temperature Sensor
1 25300 GPT230 Quick-Reference Installation Guide (this document)
- 25167 TRACON MODEL GPT-230 Installation & Operation Manual available online at:
networketi.com/product-manuals
PRIOR TO INSTALLATION
1. Read these installation instructions and manual prior
to beginning installation.
2. Install this device only if you are a qualied electrician
trained to perform such work.
3. Before beginning installation, lay out the system
components, the heat trace cable and the
temperature probe in their approximate locations to
visualize the system and evaluate exact component
and junction box placement, as well as required
cable and conduit lengths.
INSTALLATION
The GPT 230 Automatic Heat–Trace Control should be
installed by a qualied , licensed electrician . Installation
must conform to all applicable local and national
electrical codes and laws . The unit ’s NEMA 4X IP66
enclosure allows for indoor or outdoor applications.
The GPT 230 controller has an ambient operating
temperature range of −40 °F to 131 °F (−40 °C to 55 °C).
To avoid potential internal condensation mount the unit
out of direct sunlight.
Install the GPT on a xed, at, vertical surface using
the unit’s mounting anges. The mounting anges
accommodate 1/4” or 6.3 mm fasteners.
The GPT 230’s nonmetallic enclosure has one 1.046” hole
for conduit entry; this can hold both power and load wiring
.
Use only Listed Type 4X IP66 liquid–tight conduit hubs
or cable glands. Connect the hub to the conduit system
before connecting the hub to the enclosure.
The unit comes with two installed liquid–tight cable
glands. One of these ttings is for the temperature sensor
cable, and the other is for the alarm relay cable.
The cable glands can accommodate cable diameters
0.08” to 0.24” (2 mm to 6 mm). The temperature sensor
may be located up to 2,000’ (610m) from the GPT.
There is a removable electrical insulation divider that
must be in place when there is power applied to the unit.
All leads should be terminated; no unsecured leads
should be left inside the wiring compartment.
MODEL GPT-230TRACON
®
DUAL–POINT GENERAL PURPOSE HEAT–TRACE CONTROL
Copyright © 2019 ETI, ® All rights reserved.

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
2
FIGURE 1. The GPT 230 wiring layout.
FIGURE 2. Mounting dimensions.
JP1
JP2
FPT130
Thermistor
Fault FPT130
Set
Point
GPT
Heat On
Fire Prot Lock
Heat Off
1
01
1
0
0
1
0
0
1
50F
45F
30F
38F
JP1
JP2
FPT130
Thermistor
Fault FPT130
Set
Point
GPT
Heat On
Fire Prot Lock
Heat Off
1
01
1
0
0
1
0
0
1
50F
45F
30F
38F
JP1
JP2
FPT130
Thermistor
Fault FPT130
Set
Point
GPT
Heat On
Fire Prot Lock
Heat Off
1
01
1
0
0
1
0
0
1
50F
45F
30F
38F
INPUT POWER
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
HEATER CABLE
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
Perform the following steps with the circuit breaker to the unit OFF. The TRACON GPT 230- is permanently
connected equipment and does not have an internal disconnect device. When power is applied, the system
will start.
NOTE:
1. INSTALL THE CONTROL BOX
Use the box itself as a template to determine the mounting
hole footprint. Install the box to a solid, stable surface
capable of supporting four times the weight of the box,
or about 20 pounds. Use all four mounting holes. Install
the control box to the wall using heavy-duty 1/4” or 6.3
mm fasteners long enough to fasten the box securely. Do
not fully tighten mounting hardware at this time. Leave the
mounting hardware loose enough to work the conduit into
place. Hardware will be fully tightened following installation
of the conduit.
GPT 230
HEAT TRACE CONTROL
Copyright © 2019 ETI, ® All rights reserved.

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
3
2. CONNECT THE SUPPLY AND LOAD
Feed the Input Supply (Input Power) and the Load (Heater
Cable) through the Conduit Entry Hole in the enclosure as
shown, then connect the leads, as shown in the Figure 3.
Line is black; neutral is white; ground is green.
Note: Both the power and the load require a #10 AWG wire.
3. INSTALL THE TEMPERATURE SENSOR
The GPT 230 can use either a thermistor (provided), or
a 3–wire RTD sensor.
Thermistor (25076)
The GPT 230 comes with a thermistor temperature sensor
with a 20 ft. jacketed cable that has an operating range
of −40 °F to 230 °F (−40 ˚C to 110 ˚C). See the diagram
below for proper wiring and DIP switch conguration
when using a thermistor sensor. Refer to Figure 4.
RTD
The unit can use an RTD sensor for applications requiring
a wider temperature range. The GPT 230 can operate
with 3–wire RTD sensors. Refer to Figure 4.
Note: The sensor must be selected in the Sensor Type
parameter setting screen also.
4. INSTALL THE EXTERNAL ALARM
An alarm or power–off condition can be communicated
by either opening or closing a relay contact. It is important
to make the proper alarm relay connections to achieve
the desired result. The middle terminal labeled COM
(Common) is used in both wiring congurations. Connect
one alarm relay lead to the COM terminal. If the system
needs a contact to close to signal an alarm or power–off
condition, connect the other alarm relay lead to the NC
(Normally Closed) terminal.
If the system needs a contact to open to signal an alarm
or power–off condition, then connect the other alarm
relay lead to the NO (Normally Open) terminal.
If the unit has power, and there are no alarm conditions
then the NO and COM terminals will be connected. If
the unit loses power or an alarm condition occurs then
the NC and COM terminals will be connected. Refer to
Figure 5.
5. PANEL LOCKOUT
To prevent unauthorized changes of control settings, the
second DIP switch can be set to the on position to Lock
the settings. With Lock enabled, the control panel will
allow viewing but not changing any of the settings; only
the °C or °F option can be selected. Refer to Figure 6.
FIGURE 3. Contractor connections.
INPUT POWER
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
HEATER CABLE
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
INPUT POWER
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
HEATER CABLE
Line / Black - Line 1
Neutral / White - Line 2
Ground / Green
Note: The GPT reads the Lock DIP switch position
when the Settings screen is entered. If the switch is
changed, you need to re-enter the Settings screen.

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
4
6. INSTALL THE CONDUIT AND FULLY
TIGHTEN HARDWARE
Install the conduit runs to the control box. Use only Listed
Type 4X IP66 liquid–tight conduit hubs. With cabling
routed through conduit and conduit is secure, fully tighten
the control box mounting hardware and re-assemble
control box panels and cover in their original location.
Note: At this point the circuit breaker to the unit can be
turned on providing power
to the unit.
7. SETUP AND SETTINGS EDITING
Please refer to the GPT 230 Manual for comprehensive
instructions
for Setup and Settings Editing.
FIGURE 4. Temperature sensor wiring
FIGURE 5. External alarm connection
FIGURE 6. Panel lockout DIP switch conguration
Setting for
Panel Lockout ON
(default is OFF)
The
Thermistor
input is NOT
affected
by the DIP
switches.
Copyright © 2019 ETI, ® All rights reserved.

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
5
Pilot Duty
The GPT 230 Automatic Heat–Trace
Control with GFEP cannot be used for
Pilot Duty applications.
Resistive Load Usage Only
This product is not for use with Inductive loads.
Inductive loads may create nuisance tripping of
the Ground–Fault Equipment Protection circuit.
Abnormal Odor or Smoke
In the event of smoke or a burning or abnormal
odor , immediately interrupt power to the unit
by turning off the circuit breaker protecting the
unit.
Electrical Shock / Fire Hazard
Any installation involving electric heater wiring
must be grounded to earth to protect against
shock and re hazard . Suitable ground fault
detection and interrupting systems must be in
use at all times to reduce shock and re hazard
and to protect equipment.
Electric wiring to heating elements must be installed in
accordance with National Electrical Code (NEC)/
Canadian Electrical Code requirements, as well as all
other local and applicable electrical codes and any
thirdparty standards. This product is intended for
commercial and industrial applications. Follow the
installation instructions contained in this manual and
those provided by the heater manufacturer.
Size the circuit breaker appropriately for the expected
load and inrush current. The maximum rated current for
the GPT 230 is 30 amps with resistive load.
Heater loads and their controls should not share a circuit
branch with other types of equipment. A shared circuit
may result in electromagnetic interference that can affect
system operation.
Make certain that the heater shield is properly grounded
. Failure to do so may result in damage to the
equipment or re.
Following installation and prior to beginning system
operation, refer to and perform the Post-Installation Test
described in this manual.
Copyright © 2019 ETI,
®
All rights reserved.
Devoir du pilote
Le thermostat à usage général GPT 230
avec GFEP ne peut pas être utilisé pour
les applications Pilot Duty
Utilisation de charge résistive uniquement
Ce produit n’est pas destiné à être utilisé avec
des charges inductives. Les charges inductives
peuvent créer un déclenchement intempestif
du circuit de protection de l’ équipement
contre les défauts à la terre
Odeur ou fumée anormale
En cas de fumée ou de brûlure ou d’odeur
anormale, coupez immédiatement l’
alimentation de l’unité en fermant le disjoncteur
protégeant l’unité.
Risque de choc électrique / d’incendie
Toute installation impliquant un câblage de chauffage
électrique doit être mise à la terre pour se protéger
contre les chocs et les risques d ’incendie . Des systèmes
appropriés de détection et d’interruption des défauts à
la terre doivent toujours être utilisés pour réduire les
risques de choc et d’incendie et protéger l’équipement.
Le câblage électrique des éléments chauffants doit être
installé conformément aux exigences du Code national
de l’électricité (NEC) / du Code canadien de l ’électricité
ainsi qu ’à tous les autres codes électriques locaux et
applicables et à toute norme tierce . Ce produit est
destiné aux applications commerciales et industrielles .
Suivez les instructions d’installation contenues dans

South Bend, Indiana USA | networketi.com GPT-230 INSTALLATION GUIDE | PART NO. 25300 REV C
6
CONTACTING CUSTOMER SERVICE
For assistance, contact Customer Service. Ofce hours are
from 8:00 AM until 5:00 PM ET.
Email: [email protected]
Web: networketi.com
Mail: ETI
1850 North Sheridan Street
South Bend, IN 46628
LIMITED WARRANTY
ETI’s two year limited warranty covering defects in
workmanship and materials applies. Contact Customer
Service for complete warranty information.
DISCLAIMER
ETI makes no representations or warranties, either
expressed or implied, with respect to the contents
of this publication or the products that it describes,
and specically disclaims any implied warranties of
merchantability or tness for any particular purpose. ETI
reserves the right to revise this publication, and to make
changes and improvements to the products described
in this publication, without the obligation of ETI to notify
any person or organization of such revisions, changes or
improvements.
Copyright © 2019 ETI,
®
All rights reserved.
ce manuel et celles fournies par le
fabricant de l’appareil de chauffage .
Dimensionnez le disjoncteur en fonction
de la charge et du courant d’appel
attendus. Le courant nominal maximum
pour le GPT 230 est de 30 ampères avec
une charge résistive.
Les charges de chauffage et leurs
commandes ne doivent pas partager une
branche de circuit avec d’autres types d’
équipement. Un circuit partagé peut
entraîner des interférences
électromagnétiques qui peuvent affecter
opération Système. Assurez- vous que le
blindage du radiateur est correctement
mis à la terre . Ne pas le faire peut
endommager l’équipement ou
provoquer un incendie.
Après l’installation et avant de
commencer le fonctionnement du
système, reportez-vous et effectuez le
test de post -installation décrit dans ce
manuel.
