ElectrIQ EIQMW20LSS User manual

Microwave Oven
INSTRUCTION MANUAL
Model:EIQMW20LSS
Read these instructions carefully before using your
microwave oven, and keep them safe for future reference.

CONTENTS
IMPORTANT SAFETY INFORMATION
3
INSTALLATION INSTRUCTIONS
8
SETTING UP YOUR OVEN
9
OPERATION INSTRUCTIONS
10
CLEANING
15
USE OF SUITABLE UTENSILS
15
TROUBLESHOOTING
17
SPECIFICATIONS
18
ELECTRIQ UK SUPPORT
18
2

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
a Do not attempt to operate this oven with the door open since
this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
b Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on sealing
surfaces.
c WARNING: If the door or door seals are damaged, the oven
must not be operated until it has been repaired by a
competent person.
If the apparatus is not maintained in a good state of cleanliness, its
surface could be degraded and affect the lifespan of the apparatus
and lead to a dangerous situation.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, injury to persons or
exposure to excessive microwave oven energy when using your
appliance, follow basic precautions, including the following:
•Read and follow the specific: "PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY".
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Children less than 8 years of age shall be kept away unless
continuously supervised.
3

•Keep the appliance and its cord out of reach of children less
than 8 years.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
•WARNING: Ensure that the appliance is unplugged before
replacing the lamp to avoid the possibility of electric shock.
•WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair operation
that involves the removal of the cover which gives protection
against exposure to microwave energy.
•WARNING: Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
•When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
•Only use utensils that are suitable for use in microwave
ovens.
•If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
•Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when handling
the container.
•The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
•Eggs in their shell and whole hard-boiled eggs should not be
heated in microwave ovens since they may explode, even
after microwave heating has ended.
•The oven should be cleaned regularly and any food deposits
removed.
•Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
•Do not use a temperature probe with this oven.
•Metallic containers for food and beverages are not allowed
during microwave cooking.
•The appliance shall not be cleaned with a steam cleaner.
•Care should be taken not to displace the turntable when removing
containers from the appliance.
4

•This appliance is intended to be used in household and
similar applications such as:
ostaff kitchen areas in shops, offices and other working
environments;
oby clients in hotels, motels and other residential type
environments;
ofarm houses;
obed and breakfast type environments.
•The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of warming
pads, slippers, sponges, damp cloths and similar may lead to
risk of injury, ignition or fire.
•The appliance must not be installed behind a decorative door
in order to avoid overheating.
•The appliance is intended to be used freestanding.
•The rear surface of the appliance should be placed against a
wall.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
5

To Reduce the Risk of Injury to Persons Ensure the unit is
correctly earthed.
DANGER
Electric Shock Hazard - Touching some of the internal components
can cause serious personal injury or death. Do not disassemble
this appliance.
WARNING
Electric Shock Hazard - Incorrectly earthed units can result in
electric shock.
This appliance must be earthed. In the event of an electrical short
circuit, an earth connection reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance is
equipped with a cord containing an earth wire with an earth pin on
the plug. The plug must be plugged into an outlet that is properly
installed and earthed.
Consult a qualified electrician or serviceman if the earth
instructions are not completely understood or if doubt exists as to
whether the appliance is properly earthed. If it is necessary to use
an extension cord, use only a 3 core extension cord.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a longer
cord.
2. If a long cord set or extension cord is used:
a. The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
b. The extension cord must be a earthed 3 core cord.
c. The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.
6

Installation and connection
1. This appliance is only intended for domestic use.
2. This oven is intended for counter-top use only, it is not
designed for use inside a cupboard.
3. Please observe the special installation instructions.
4. The appliance is fitted with a plug and must only be
connected to a properly installed earthed socket.
5. The mains voltage must correspond to the voltage specified
on the rating plate.
6. The socket must be installed and connecting cable must only
be replaced by a qualified electrician. If the plug is no longer
to accessible following installation, an all-pole disconnecting
device must be present on the installation side with a contact
gap of at least 3mm.
7. Adapters, multi-way strips and extension leads must not be
used. Overloading can result in a risk of fire.
The accessible surface may be hot during
operation.
7

INSTALLATION INSTRUCTIONS
Please Note - Electrical Connection
The oven is fitted with a plug and must only be connected to a properly
installed earthed socket. The socket must only be installed and the
connecting cable must only be replaced by a qualified electrician, and in
accordance with the appropriate regulations. If the plug is no longer
accessible following installation, an all-pole isolating switch must be
present on the installation side with a contact gap of at least 3mm.
1. Select a level surface that provides enough open space for the
vents. Blocking the vents may cause damage to the oven.
2. The minimum installation height is 85cm
3. The rear surface of the oven should be placed against a wall.
Leave a minimum clearance of 30cm above the oven, and a
minimum of 20 cm to both sides.
4. Do not remove the legs from the underside of the oven.
5. Place the oven as far away as possible from radios and TV’s, as
operation of the oven may cause interference to their reception.
6. Plug your oven into a standard household outlet. Be sure the
voltage and frequency are the same as on the rating label.
WARNING: Do not install the oven over a cooking surface or heat
producing appliance. If installed near or over a heat source, the oven
could be damaged and the warranty would be void.
The accessible surface may be hot during operation
20CM
20CM
30CM
0CM
MIN
85CM
8

SETTING UP YOUR OVEN
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
A
A
Control Panel
E
Observation Window
B
Turntable Shaft
F
Door Assembly
C
Turntable Ring Assembly
G
Safety Interlock System
D
Glass Tray
Instruction Manual
Turntable Installation
C
B
E
D
F
G
Hub
(Underside)
Glass Tray
Turntable
Shaft
Turntable Ring
Assembly
•Never place the glass tray upside
down. The glass tray should never be
restricted.
•Both glass tray and turntable ring
assembly must always be used during
cooking.
•All food and containers of food are
always placed on the glass tray for
cooking.
•If glass tray or turntable ring assembly
cracks or breaks, contact the retailer
the microwave was purchased from.
9

OPERATION INSTRUCTIONS
This microwave oven uses modern electronic controls to adjust cooking
parameters in order to meet your needs for a better cooking experience.
1. Set the Clock
When the microwave oven is powered on, the display will show "0:00",
and the buzzer will bleep once.
1) Press " CLOCK/PRE-SET ", the hour figure flash;
2) Turn to adjust the hour figure (in the range 0—23)
3) Press "CLOCK/PRE-SET", the minute figures will flash.
4) Turn to adjust the minute figures. (in the range 0—59)
5) Press "CLOCK/PRE-SET" to finish clock setting. The ":" between the
numbers will start to flash.
Note: During the process of clock setting, if you press "STOP/CLEAR",
the oven will go back to the previous status automatically.
2. Microwave Cooking
1. Press the "MICROWAVE" key once, and "P100" will flash.
2. Press "MICROWAVE" repeatedly or turn to reduce the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10" will
display in order.
3. Press "START/+30SEC./CONFIRM" to confirm your selection.
4. Turn to adjust the cooking time. (The time setting should be 0:05-
95:00.)
5. Press " START/+30SEC./CONFIRM " to start cooking.
NOTE: the step quantities for the adjustment time of the coding switch
are as follow:
0 ---1 min
5 seconds
1 --- 5 min
10 seconds
5 --- 10 min
30 seconds
10 --- 30 min
1 minute
30 --- 95 min
5 minute
10

Microwave Power Chart
Microwave
Power
100
%
80%
50%
30%
10%
Display
P100
P80
P50
P30
P10
3. Defrost By Weight
1) Press the "W.T./TIME DEFROST" button once, the screen will display
"dEF1".
2) Turn to select the food weight. The range can be between 100-2000g.
3) Press the "START/+30SEC./CONFIRM" button to start defrosting.
4. Defrost By Time
1) Press the "W.T./TIME DEFROST" button twice, the screen will display
"dEF2".
2) Turn to select the cooking time. The maximum cooking time is 95
minutes.
3) Press the "START/+30SEC./CONFIRM" button to start defrosting. The
defrost power is P30 and cannot be changed.
5.Multi-Stage Cooking
Two stages can be set to run concurrently. If one of the stages is defrosting, it
will be automatically be put as the first stage. The buzzer will ring once after
each stage and the next stage will then begin. Note: Auto menu cannot be
set as one of the multi-stage options.
Example: if you want to defrost the food for 5 minutes, then to cook with
80% microwave power for 7 minutes. The steps are as following:
1) Press "W.T./TIME DEFROST" twice, the screen will display "dEF2";
2) Turn to adjust the defrost time of 5 minutes;
3) Press "MICROWAVE" once;
4) Turn to choose 80% microwave power until "P80" is displayed;
5) Press "START/+30SEC./CONFIRM" to confirm;
6) Turn to adjust the cooking time to 7 minutes
11

7) Press "START/+30SEC./CONFIRM" to start cooking.
6. Pre-set Function
1) Ensure the clock is set correctly
2) Input the cooking program. A maximum of 2 stages can be set. Defrosting
should not be set in the preset function .
Example: if you want to cook with 80% microwave power for 7
minutes.
a. Press "MICROWAVE " once;
b. Turn to choose 80% microwave power till "P80" display;
c. Press "START/+30SEC./CONFIRM" to confirm;
d. Turn to adjust the cooking time of 7 minutes;
After the above steps, please do not press "START/+30SEC./CONFIRM".
Then do as following:
3) Press "CLOCK/PRE-SET". The hour figure will flash;
4) Turn to adjust the hour figures, (in the range 0—23).
5) Press "CLOCK/PRE-SET ", the minute figures will flash .
6) Turn to adjust the minute figure, (in the range 0—59).
7) Press "START/+30SEC./CONFIRM" to finish setting. ":" will flash, the
buzzer will ring twice when the start time arrives, then cooking will start
automatically.
Note: The clock must be set first. Otherwise the pre-set function will not
work.
7. Auto Menu
1) With the unit in standby , turn right to choose the menu from "A-1" to
"A-8";
2) Press "START/+30SEC./CONFIRM " to confirm the menu you choose;
3) Turn to choose the weight of food;
4) Press "START/+30SEC./CONFIRM to start cooking;
5) After the cooking has finished, the buzzer will sound five times.
12

Menu
Weight
Display
Power
A-1 AUTO
REHEAT
200g
200
100%
400g
400
600g
600
A-2 VEGETABLE
200g
200
100%
300g
300
400g
400
A-3
FISH
250g
250
80%
350g
350
450g
450
A-4
MEAT
250g
250
100%
350g
350
450g
450
A-5
PASTA
50g (with water 450g)
50
80%
1 0g (with water 800g)0
100
A-6
POTATO
200g
200
100%
400g
400
600g
600
A-7
PIZZA
200g
200
100%
400g
400
A-8
SOUP
200ml
200
80%
400ml
400
8. Quick Start
1) In with the unit in standby, press "START/+30SEC./CONFIRM" key to
cook with 100% power level for 30 seconds. Each press of the same
key increases the time by 30 seconds. The maximum cooking time is 95
minutes.
2) During the microwave cooking and time defrost process, press
"START/+30SEC./CONFIRM" to increase the cooking time.
3) The button cannot be used to extend the cooking time in auto mode and
weight defrost.
4) In standby mode, turn left to choose the cooking time directly. After
choosing the cooking time, press "START/+30SEC./CONFIRM" to start
cooking. The microwave power is set to 100%.
13

9. Child Lock
Lock: In standby, hold "STOP/CLEAR" for 3 seconds, there will be a long
"beep" denoting entering the child-lock state and screen will display
Unlock: In locked state, hold "STOP/CLEAR" for 3 seconds, there will be
a long "beep" denoting that the lock is released.
10. Check current settings
1) While cooking, press "MICROWAVE" ,and the current power will be
displayed for 3 seconds.
2) In pre-set state, press "CLOCK/PRE-SET" to check the time for delay start
cooking. The pre-set time will flash for 3 seconds, then the oven will turn
back to the clock display.
3) During cooking state, press "CLOCK/PRE-SET" to check the current time. It
will be displayed for 3 seconds.
Further Operation Information
1) The buzzer will sound once when turning the knob at the beginning;
2) "START/+30SEC./CONFIRM" must be pressed to continue cooking if the
door is opened during cooking;
3) Once the cooking programme has been set, " START/+30SEC./CONFIRM"
is not pressed in 1 minute. The current time will be displayed. The setting
will be cancelled.
The buzzer will sound five times to remind you when cooking is finished.
14

CLEANING
Be sure to disconnect the appliance from the power supply before
commencing cleaning
1. Clean the cavity of the oven with a slightly damp cloth.
2. The accessories can be removed from the oven and cleaned in a bowl
of soapy water.
3. The door frame and seal and neighbouring parts must be cleaned
carefully with a damp cloth when they become dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of food residue on the cavity walls:
Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on
100% microwave power for 10 minutes. Wipe the oven clean using a
soft, dry cloth.
USE OF SUITABLE UTENSILS
See the table on "Materials you can use in microwave oven or to be avoided in
microwave oven." There may be certain non-metallic utensils that are not safe
to use for microwaving. If in doubt, you can test the utensil in question
following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with
the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for
microwave cooking.
4. Do not exceed 1 minute cooking time.
15

Materials you can use in microwave oven
Utensils
Remarks
Browning dish
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer's instructions. Do
not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glassware
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with a metal
tie. Make slits to allow steam to escape.
Paper plates and
cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for
steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labelled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as directed
on the packaging.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers
Microwave-safe only
Wax paper
Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils
Remarks
Aluminium tray
May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal
trimmed utensils
Metal shields the food from microwave energy. Metal trim may
cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven and may
split or crack.
16

TROUBLESHOOTING
Normal Behaviour
Microwave interfering
with TV reception when
running
Radio and TV reception may be interfered
when microwave is operating. It is similar
to interference from other small electric
appliances such as electric fans and is
normal.
Dim Oven light
In low power microwave cooking, the oven
light may become dim. This is normal
Steam accumulating on
door and hot air out of
vents
In cooking, water is released from the food
as steam, and most will exit via the vents,
but some will accumulate in cold places
such as the door. This is normal.
Oven started
accidentally with no
food in
The oven should not be operated without
any food inside, as it is very dangerous.
Problem
Possible cause
Remedy
Oven will not start
Power cord not fully
inserted
Unplug and plug back in
after 10 seconds
Fuse blowing, or circuit
breaker tripped
Replace fuse or reset circuit
breaker
Trouble with socket
Test Socket with other
electrical appliances
Oven does not
heat
Door not fully closed
Ensure door is fully closed
and sealed before operating
Glass turntable
makes a noise
when the oven
operates
Dirty roller rest or oven
bottom
Refer to "Cleaning" section
for advice on cleaning dirty
parts
17

SPECIFICATIONS
Model:
EIQMW20LSS
Rated Voltage:
240V~50Hz230-
Rated Input
Power(Microwave):
1270W1200-
Rated Output
Power(Microwave):
800 W750-
Oven Capacity:
20L
Turntable Diameter:
255mm
External Dimensions:
440X335X259mm
Net Weight:
11.35kg
According to Waste of Electrical and Electronic Equipment (WEEE)
directive, WEEE should be separately collected and treated. If at
any time in future you need to dispose of this product please do
NOT dispose of this product with household waste. Please send this
product to WEEE collecting points where available.
ElectrIQ UK Support
www.ElectrIQ.co.uk/support
. Office hours: 9AM - 5PM Monday to Friday
www.ElectrIQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA
18
PN:16170000A62215
