Electro-Harmonix S8 User manual

S8 Multi-Output Power Supply
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Power Supply
Connect the AC power adapter to an AC outlet of the correct voltage. Please be sure to use only
an AC adapter which supplies 12VDC (+/- 10%) center negative. The maximum working voltage is
15V. Any voltage higher than 15V will create a dangerous situation. Always unplug the AC power
adapter when not in use.
Connections
Always turn off the power of this and all other equipment before connecting or disconnecting.
This will help prevent malfunction and/or damage to your devices.
Handling
Do not apply excessive force to the inputs and outputs. Do not drop the unit and do not subject it
to shocks or excessive pressure.
Cleaning
Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth. Do not use abrasive
cleanser, cleaning alcohol, paint thinners, wax, solvents, cleaning fluids or chemical-impregnated
wiping cloths.
Interference with Other Electrical Devices
Radios and televisions placed nearby may experience reception interference. Operate this unit at
a suitable distance from radios and televisions.
Location
To avoid deformation, discoloration, or other serious damage, do not expose this unit to the
following conditions: direct sunlight, magnetic fields, excessive dust or dirt, strong vibrations or
shocks, heat sources, extreme temperatures, or high moisture.
FEATURES
•Provides stable 9V DC and 18V DC high-performance power. Each 9V output provides a
maximum current of 250mA, meeting the power requirements of most pedals.
•Powers up to eight effect pedals with individually regulated outputs
•Short circuit protection design for individual outputs
OVERVIEW
1. 12V DC INPUT POWER LIGHT: When connected to the power supply, the LED lights.
2. OUTPUT POWER LIGHTS: When connected to the power cords, the corresponding LED lights.
3. INPUT POWER JACK: Connect the output plug from the supplied AC power supply here.
4. OUTPUT POWER JACKS: Connect the supplied DC power cables for your pedals to these jacks.
WELCOME
Congratulations on your purchase of the S8 Multi-Output Power Supply, a convenient solution to
unwanted cable mess and noise. The S8 will supply power to up to eight effects pedals and is
housed in a compact, rugged metal chassis.

CONNECTION INSTRUCTIONS
If the input polarity of the pedal is center negative, connect the DC power cable directly to the
pedal.
NOTE
Before use, please confirm the input polarity of your pedals. If a polarity reversal cable is
required and not used, damage to your devices may occur.
SPECIFICATIONS
Power Supply: 12V DC power adapter
Outputs: Seven 9V power supply outputs and one 18V power supply output
Current Draw: 9V DC output maximum current of 250mA
Current Draw: 18V DC output maximum current of 150mA
INCLUDED
One 12VDC/2A Power Adapter
Four 460mm DC Power Cables
Four 610mm DC Power Cables
Pedalboard Mounting Strap
Owner’s Manual
www.ehx.com
AC Power Adaptor
If the input polarity of the electrical device is center positive, connect the DC power cable to a
polarity reversal cable (not included) and then connect the polarity reversal cable to the pedal.
AC Power Adaptor
WARRANTY & NOTICES
Warranty Information
Please register online at http://www.ehx.com/product registration.
Electro-Harmonix will repair or replace, at its discretion, a product
that fails to operate due to defects in materials or workmanship for
a period of one year from date of purchase. This applies only to
original purchasers who have bought their product from an
authorized Electro-Harmonix retailer. Repaired or replaced units will
then be warranted for the unexpired portion of the original
warranty term. If you should need to return your unit for service
within the warranty period, please contact the appropriate office
listed below. Customers outside the regions listed below, please
contact EHX Customer Service for information on warranty repairs
at [email protected] or [phone]. USA and Canadian
customers: please obtain a Return Authorization Number (RA#)
from EHX Customer Service before returning your product. Include,
with your returned unit, a written description of the problem as well
as your name, address, telephone number, e-mail address, RA# and
a copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX c/o NEW SENSOR CORP.
55-01 2ND STREET LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ UNITED KINGDOM
Tel: [phone]
Email: [email protected]
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for
help.
Disposal: This symbol indicates that this product shall not
be treated as household waste. Instead it shall be disposed in
accordance with local environmental laws and guidelines and,
where as appropriate, handed over to the applicable collection
point for the recycling of electrical and electronic equipment.
This product was produced after Jan 1 2006.
