Electro-Voice RE90P-12 User manual

Description
The RE90P-12 and RE90P-18 podium mi-
crophones are phantom-powered “back-
electret”miniaturecondensergooseneckmi-
crophones. The back-electret feature pro-
vides greater sensitivity, wider frequency re-
sponse, and superior immunity from han-
dling noise than a diaphragm-electret mi-
crophone. The RE90P-12 and RE90P-18 are
mechanically designed for quick, easy
mounting to a lectern, pulpit or podium
equipped with a bulkhead female XLR-type
3-pin receptacle. For permanent installation,
optional fixed (FMK flange-mount kit) and
shock-mounted (CPSM shock-mount kit)
accessories are also available. The RE90P-
12 and RE90P-18 are designed for sound
reinforcement applications. The frequency
response is tailored for full-range sound re-
production with natural sound pick-up op-
timized for close-up use. The small-diam-
eter gooseneck has two supple joints and a
rigid center tube. The rigid tube prevents
unsightly twisting of the gooseneck but per-
mits the user to exactly position the micro-
phone.The electronics housing has a 3/4-inch
diameter base terminated with an XLR-type
3-pin connector which allows the micro-
phone to be plugged directly into an ex-
isting panel-mount XLR-type recep-
tacle. The housing is machined steel for
ruggedness and superior EMI/RFI attenua-
tion. The electronics’ output circuit utilizes
atransformerlessbalancedconstructionwith
a low-output impedance, which is typically
200 ohms. This permits very long cable runs
without degrading the microphone perfor-
mance. The RE90P-12 and RE90P-18 are
designed to be phantom powered with a
wide voltage range, 9-52 V dc (DIN Stan-
dard 45 596).
Applications
The RE90P-12 and RE90P-18 gooseneck
microphones are designed for sound rein-
forcement applications requiring high qual-
ity, wide response and a uniform polar pat-
tern in a slender, adjustable gooseneck mi-
crophone. The RE90P-12 and RE90P-18
can be employed on lecterns, podiums, and
on mixing consoles as a talk-back micro-
phone or other applications which require a
quick plug-in gooseneck microphone.
Applications of close or normal miking of
speech at podiums, lecterns or pulpits nor-
mally require a windscreen to control breath
noise and P-popping or, in some cases, wind
noise from circulating air. A small foam
windscreen is included with the RE90P-12
and RE90P-18 mics. This windscreen is
made of two stages of foam (a dense exte-
rior surrounding a sparser core) which is
easily slipped over the transducer. This two-
stage filtering provides greater isolation
from P-pop noise in a smaller package.
In some locations, there is a desire to per-
manently attach the foam windscreen to the
microphone to prevent loss. Included with
the microphone are two strips of double-
sided tape (the second strip is a spare). To
permanently attach the foam windscreen,
first crack and peel off the protective back
layer of one strip of tape. Apply the tape to
the transducer by wrapping it around the
gooseneck adapter. The eight screened ports
on the transducer should be well above the
tape so as to not disturb the sound recep-
tion. Next remove the protective front layer
of the attached tape. Now, pull the wind-
screen down over the tape, stopping when
the end of the foam is even with the flexible
gooseneck. Caution:the windscreenfoam
is delicate and therefore easily ripped by
applying too much force.
RE90P-12 and
RE90P-18
Condenser Cardioid
Gooseneck Microphones
• Small size – unobtrusive for podium
applications
• Frequency and cardioid polar response
uniform across the range, for natural
sound and high resistance to feedback
• All-metal construction substantially
reduces noise from stray magnetic
fields and RFI
• Low, 200-ohm output allows long
cable runs
• Optional CPSM podium shock mount
provides more than 15 dB of mechnical
shock isolation at 200 Hz

RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
2
Mounting Accessories
CPSM SHOCK-MOUNT KIT
The Electro-Voice CPSM shock mount ef-
fectively isolates the mounted RE90P-12
and RE90P-18 podium microphones from
shock-induced vibrations that would be ex-
perienced on podiums, pulpits, table and
desk tops, plus it provides theft-resistant se-
curity. Compared to hard mounting, the
CPSM shock mount provides 15 dB (over 5
times) of shock isolation at 200 Hz.
FMK FLANGE-MOUNT KIT
For installations which do not require a
shock mount, the FMK flange mount is de-
signed for quick installation on podiums,
pulpits, table and desk tops and provides
theft-resistant security.
Architects’ and Engineers’
Specifications
RE90P-12
The microphone shall be a single-D cardioid
back-electret condenser type with frequency
response of 100 to 15,000 Hz.
Themicrophoneshallhavea200-ohmnomi-
nal balanced output, with an output level of
–43.0 dB (0 dB = 1 mW/pascal). The mi-
crophone shall have a back-electret gener-
ating element whose output shall not be ap-
preciably affected by temperature extremes
from –17.8° C (0° F) to 54.4° C (130° F)
and/or by humidity extremes.
Dimensions shall be 20 mm (0.79 in.) di-
ameter and 392 mm (15.43 in.) long. The
microphone shall include a 280.7-mm
(11.05-in.) gooseneck with professional
XLR-type 3-pin style terminating connec-
tor and an external windscreen. The mi-
crophone shall be of metal construction.
The Electro-Voice RE90P-12 is specified.
RE90P-18
The microphone shall be a single-D cardioid
back-electret condenser type with frequency
response of 100 to 15,000 Hz.
Themicrophoneshallhavea200-ohmnomi-
nal balanced output, with an output level of
–43.0 dB (0 dB = 1 mW/pascal). The mi-
crophone shall have a back-electret gener-
ating element whose output shall not be ap-
preciably affected by temperature extremes
from –17.8° C (0° F) to 54.4° C (130° F)
and/or by humidity extremes.
Dimensions shall be 20 mm (0.79 in.) di-
ameter and 557.5 mm (21.95 in.) long. The
microphone shall include a 443.2-mm
(17.45-in.) gooseneck with professional
XLR-type 3-pin style terminating connec-
tor and an external windscreen. The mi-
crophone shall be of metal construction.
The Electro-Voice RE90P-18 is specified.
Warranty (Limited)
Electro-Voice products are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a specified period,
as noted in the individual product-line
statement(s) below, or in the individual
product data sheet or owner’s manual, be-
ginning with the date of original purchase.
If such malfunction occurs during the speci-
fied period, the product will be repaired or
replaced (at our option) without charge. The
product will be returned to the customer pre-
paid. Exclusions and Limitations: The
Limited Warranty does not apply to: (a) ex-
terior finish or appearance; (b) certain spe-
cific items described in the individual prod-
uct-line statement(s) below, or in the indi-
vidualproductdatasheetorowner’s manual;
(c) malfunction resulting from use or op-
eration of the product other than as speci-
fied in the product data sheet or owner’s
manual; (d) malfunction resulting from mis-
use or abuse of the product; or (e) malfunc-
tion occurring at any time after repairs have
been made to the product by anyone other
than Electro-Voice Service or any of its au-
thorized service representatives. Obtaining
Warranty Service: To obtain warranty ser-
vice, a customer must deliver the product,
prepaid, to Electro-Voice Service or any of
its authorized service representatives to-
gether with proof of purchase of the prod-
uct in the form of a bill of sale or receipted
invoice. A list of authorized service repre-
sentatives is available from Electro-Voice
Service at 600 Cecil Street, Buchanan, MI
49107(800/234-6831orFAX 616/695-4743).
Incidental and Consequential Damages
Excluded: Product repair or replacement
and return to the customer are the only rem-
edies provided to the customer. Electro-
Voice shall not be liable for any incidental
or consequential damages including, with-
out limitation, injury to persons or property
or loss of use. Some states do not allow the
exclusion or limitation of incidental or con-
sequential damages so the above limitation
or exclusion may not apply to you. Other
Rights: This warranty gives you specific
legal rights, and you may also have other
rights which vary from state to state.
Electro-Voice Wired Microphones are
guaranteed against malfunction from any
cause for two (2) years from the date of
original purchase. In addition, the Limited
Warranty for the acoustic system contained
in these microphones shall apply for the life
of the product, defined as a period of ten
(10) years from the date that the manufac-
ture of the specific microphone has been dis-
continued. Any and all active electronics in-
corporated in these microphones are guar-
anteed against malfunction due to defects
in materials or workmanship for a period of
three (3) years from the date of original pur-
chase. The Limited Warranty does not ex-
tendto cables, cable connectors, or switches.
Additional details are included in the Uni-
form Limited Warranty statement.
For warranty repair, service information,
oralisting of the repair facilities nearest you,
contact the service repair department at:
616/695-6831 or 800/685-2606.
For technical assistance, contact Techni-
cal Support at 800/234-6831 or
616/695-6831, M-F, 8:00 a.m. to 5:00 p.m.
Eastern Standard time.
Specifications subject to change without
notice.

RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
3
Figure 1—Frequency Response
Figure 2—Polar Response 5 dB per division
90
60
30
120
150
180
210
240
270
300
330 0
1,000 Hz
2,500 Hz
5,000 Hz
Figure 3—Dimensions
3"
0° (On Axis)
5 dB
RESPONSE IN dB
20 50 10030 200 500 1000 2000 5000 10000 20000
FREQUENCY IN HERTZ
19 mm
(0.75 in.)
20 mm
(0.79 in.)
12.7 mm
(0.50 in.)
RE90P-12
RE90P-18 - 392 mm (15.43 in.) - 557.5 mm (21.95 in.)
RE90P-12 - 208.7 mm (11.05 in.)
RE90P-18 - 443.2 mm (17.45 in.)

RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
RE90P-12 and RE90P-18 Condenser Cardioid Gooseneck Microphones
4
MICROPHONES-Condensers Part Number 534326 — 9818
600 Cecil Street, Buchanan, MI 49107
616/695-6831, 616/695-1304 Fax
©Telex Communications, Inc. 1998 • Litho in U.S.A.
Specifications
Generating Element:
Condenser, back electret
Frequency Response (see Figure 1):
100-15,000 Hz (5 in. or greater)
70-15,000 Hz (3 in. distance)
Polar Pattern:
Cardioid (see figure 2)
Sensitivity,
Open Circuit Voltage:
4.5 mV/pascal @ 1,000 Hz
Power Level:
-43dB at 1,000 Hz
(0 dB = 1 mW/pascal)
Dynamic Range:
102 dB
Equivalent Output Noise:
<28 dB SPL “A” weighted
(0 dB=20 micropascals)
Impedance:
measured at 1,000 Hz
(works with all low-Z mic inputs)
Power Requirements:
9-52 V dc phantom supply
Current Consumption:
2.5 mA
Polarity:
A positive pressure on the diaphram
produces a positive voltage on
output pin 2(+)
Color:
Nonreflecting black
Environmental Conditions,
Relative Humidity 0-50%:
–29° to 74° C (–20° to 165° F)
Relative Humidity 0-95%:
–29° to 57° C (–20° to 135° F)
Net Weight,
RE90P-12: 182 grams (6.4 oz)
RE90P-18: 244 grams (8.6 oz)
Shipping Weight,
RE90P-12: 400 grams (14.1 oz)
RE90P-18: 528 grams (18.6 oz)
Mounting:
Male XLR-type 3-pin connector
Dimensions (see Figure 3),
Gooseneck and Head Length:
RE90P-12: 280.7 mm (11.05 in.)
RE90P-18: 443.2 mm (17.45 in.)
Maximum Head Diameter:
12.7 mm (0.50 in.)
Gooseneck Diameter:
6.4 mm (0.25 in.)
Electronics Module Diameter:
20 mm (0.79 in.)
Connector Diameter:
19 mm (0.75 in.)
Accessories Furnished:
Windscreen
Double-sided tape
Optional Accessories:
FMK flange-mount kit
CPSM shock-mount kit
