Electrolux Professional Compass Pro WH6-8 User manual

Installation manual
Washer extractor
WH6–7, WH6–8, WH6–11, WH6–14,
WH6–20, WH6–27, WH6–33
Compass Pro
Type W3....
Original instructions
438917550/GB, IE
2022.11.14

Contents
Contents
1 Safety Precautions ..............................................................................................................................5
1.1 General safety information..........................................................................................................6
1.2 Commercial use only..................................................................................................................6
1.3 Symbols....................................................................................................................................6
2 Warranty terms and exclusions.............................................................................................................7
3 Technical data.....................................................................................................................................8
3.1 Drawing ....................................................................................................................................8
3.1.1 WH6–7, WH6–8, WH6–11 ................................................................................................8
3.1.2 WH6–14 .........................................................................................................................9
3.1.3 WH6–20, WH6–27, WH6–33 ..........................................................................................10
3.2 Technical data ......................................................................................................................... 11
3.3 Connections ............................................................................................................................12
4 Setup ...............................................................................................................................................13
4.1 Unpacking...............................................................................................................................13
4.1.1 WH6–7, WH6–8, WH6–11 ..............................................................................................13
4.1.2 WH6–14, WH6–20, WH6–27, WH6–33 ...........................................................................15
4.2 Recycling instruction for packaging ...........................................................................................17
4.3 Siting ......................................................................................................................................18
4.4 Mechanical installation .............................................................................................................19
5 Marine installation .............................................................................................................................20
6 Water connection ..............................................................................................................................21
7 Connection of external dosing systems ...............................................................................................23
7.1 Connection of the hoses...........................................................................................................23
7.2 Electrical connection of external dosing system..........................................................................24
7.2.1 Machine with connectors.................................................................................................24
7.2.2 Machine without connectors ............................................................................................25
7.2.3 Outputs .........................................................................................................................26
7.2.4 Inputs ............................................................................................................................27
8 Drain connection ...............................................................................................................................28
9 Electrical connection..........................................................................................................................29
9.1 Electrical installation ................................................................................................................29
9.2 Electrical connections ..............................................................................................................30
9.3 Machine connection .................................................................................................................32
9.4 Machine connection with ferrite.................................................................................................33
9.4.1 WH6–14, WH6–20, WH6–27, WH6–33 ...........................................................................33
9.5 Functions for I/O-cards.............................................................................................................34
9.5.1 External coin meter/Central payment (2A) ........................................................................34
9.5.2 Central payment (2B)......................................................................................................35
9.5.3 Central payment (2C) .....................................................................................................36
9.5.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price re-
duction (2D) ...................................................................................................................37
9.5.5 Central booking/payment (2F) .........................................................................................38
9.5.6 Machines with I/O module type 3 .....................................................................................39
9.6 Converting heating elements ....................................................................................................40
9.6.1 WH6–7, WH6–8 and WH6–11 can be converted from 400-415V 3AC to 230-240V 1AC
with reduced power ........................................................................................................40
9.6.2 WH6–14 can be converted from 380-415V 3N AC to 220-240V 1N AC with reduced
power ............................................................................................................................41
10 Steam connection .............................................................................................................................42
11 At first power up ................................................................................................................................43
11.1 Select language.......................................................................................................................43
11.2 Set time and date.....................................................................................................................43
12 Function check..................................................................................................................................44
13 Disposal information..........................................................................................................................45
13.1 Disposal of appliance at end of life ............................................................................................45
13.2 Disposal of packing..................................................................................................................45
The manufacturer reserves the right to make changes to design and component specifications.

Installation manual 5
1 Safety Precautions
• Servicing shall be carried out only by authorized personnel.
• Only authorized spare parts, accessories and consumables shall be used.
• Only use detergent intended for water-wash of textiles. Never use dry cleaning agents.
• The machine shall be connected with new water hoses. Re-used water hoses must not
be used.
• The machine's door lock must under no circumstances be bypassed.
• If the machine develops a fault, this must be reported to the person in charge as soon
as possible. This is important both for your safety and that of others.
• DO NOT MODIFY THIS APPLIANCE.
• When performing service or replacing parts, the power must be disconnected.
• When the power is disconnected, the operator must see that the machine is discon-
nected (that the plug is removed and remains removed) from any point to which he has
access. If this is not possible, due to the construction or installation of the machine, a
disconnection with a locking system in the isolated position shall be provided.
• In accordance with the wiring rules: mount a multi-pole switch prior to the machine to
facilitate installation and service operations.
• If different rated voltages or different rated frequencies (separated by a /) are stated at
the machine data plate, instructions for adjusting the appliance for operation at the re-
quired rated voltage or rated frequency are stated in the installation manual.
• Stationary appliances not fitted with means for disconnection from the supply mains
having a contact separation in all poles that provide full disconnection under overvolt-
age category III, the instructions state that means for disconnection must be incorpo-
rated in the fixed wiring in accordance with the wiring rules.
• The openings in the base, shall not be obstructed by a carpet.
• Maximum mass of dry cloth: WH6–7: 7.5 kg, WH6–8: 8.5 kg, WH6–11: 11.5 kg, WH6–
14: 14.5 kg, WH6–20: 21 kg, WH6–27: 27.5 kg, WH6–33: 36.5 kg.
• A-weighted emission sound pressure level at working stations:
– Wash: WH6–7: <70 dB(A), WH6–8: <70 dB(A), WH6–11: <70 dB(A), WH6–14: <70
dB(A), WH6–20: <70 dB(A), WH6–27: <70 dB(A), WH6–33: <70 dB(A).
– Extraction: WH6–7: <70 dB(A), WH6–8: <70 dB(A), WH6–11: <70 dB(A), WH6–14:
<70 dB(A), WH6–20: <70 dB(A), WH6–27: <70 dB(A), WH6–33: <70 dB(A).
• Maximum inlet water pressure: 1000 kPa
• Minimum inlet water pressure: 50 kPa
• Additional requirements for the following countries; AT, BE, BG, HR, CY, CZ, DK, EE,
FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH,
TR, UK:
– The appliance can be used in an area open to the public if equipped with any of the
following programs from factory: 6A01, 6A08, 6L01, 6L02, 6G05, 6G06, 6R01, 6C01,
6L31, 6L33 and 6L12.
– This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowl-
edge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the

6Installation manual
appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Additional requirements for other countries:
– This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
– This appliance is intended to be used in household and similar applications such as:
(IEC 60335-2-7) staff kitchen areas in shops, offices and other working environments,
farm houses, by clients in hotels, motels and other residential type environments, bed
and breakfast type environments, areas for communal use in blocks of flats or in
launderettes.
1.1 General safety information
The machine is only intended for water-wash use.
Do not hose down the machine with water.
In order to prevent damage to the electronics (and other parts) that may occur as the result of condensation, the ma-
chine should be placed in room temperature for 24 hours before being used for the first time.
1.2 Commercial use only
The machine/machines covered by this manual is/are made for commercial and industrial use only.
1.3 Symbols
Caution
Caution, high voltage
Read the instructions before using the machine

Installation manual 7
2 Warranty terms and exclusions
If the purchase of this product includes warranty coverage, warranty is provided in line with local regulations and sub-
ject to the product being installed and used for the purposes as designed, and as described within the appropriate
equipment documentation.
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance
in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec-
tronic format.
Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling
agents to obtain optimal results and maintain product efficiency over time.
The Electrolux Professional warranty does not cover:
• service trips cost to deliver and pick up the product;
• installation;
• training on how to use/operate;
• replacement (and/or supply) of wear and tear parts unless resulting from defects in materials or workmanship re-
ported within one (1) week from the failure;
• correction of external wiring;
• correction of unauthorized repairs as well as any damages, failures and inefficiencies caused by and/or resulting
from;
– insufficient and/or abnormal capacity of the electrical systems (current/voltage/frequency, including spikes and/
or outages);
– inadequate or interrupted water supply, steam, air, gas (including impurities and/or other that does not comply
with the technical requirements for each appliance);
– plumbing parts, components or consumable cleaning products that are not approved by the manufacturer;
– customer’s negligence, misuse, abuse and/or non-compliance with the use and care instructions detailed within
the appropriate equipment documentation;
– improper or poor: installation, repair, maintenance (including tampering, modifications and repairs carried out
by third parties not authorized third parties) and modification of safety systems;
– Use of non-original components (e.g.: consumables, wear and tear, or spare parts);
– environment conditions provoking thermal (e.g. overheating/freezing) or chemical (e.g. corrosion/oxidation)
stress;
– foreign objects placed in- or connected to- the product;
– accidents or force majeure;
– transportation and handling, including scratches, dents, chips, and/or other damage to the finish of the product,
unless such damage results from defects in materials or workmanship and is reported within one (1) week of deliv-
ery unless otherwise agreed;
• product with original serial numbers that have been removed, altered or cannot be readily determined;
• replacement of light bulbs, filters or any consumable parts;
• any accessories and software not approved or specified by Electrolux Professional.
Warranty does not include scheduled maintenance activities (including the parts required for it) or the supply of
cleaning agents unless specifically covered within any local agreement, subject to local terms and conditions.
Check on Electrolux Professional website the list of authorized customer care.

8Installation manual
3 Technical data
3.1 Drawing
3.1.1 WH6–7, WH6–8, WH6–11
A
C
31
2
B
E
D2
D1
I
H
L
K
J
10
G 5
8
11
F
MO
N
4
9
7
6
fig.X01718
1 Operating panel
2 Door opening, WH6–7, WH6–8: ⌀310 mm, WH6–11: ⌀365 mm
3 Detergent container
4 Cold water
5 Hot water
6 Cold/Hot water or Re-used water with network pressure (option)
7Re-used water from tank/pump or Liquid detergent supply
8 Drain
9 Liquid detergent supply
10 Electrical connection
11 Steam connection
mm A B C D1 D2 E F G
WH6–7 720 720 1135 360 425 1135 835 80
WH6–8 720 720 1135 360 425 1135 835 80
WH6–11 830 770 1215 365 435 1240 920 80
mm H I J K L M N O
WH6–7 1035 215 125 1015 915 280 100 240
WH6–8 1035 215 125 1015 915 280 100 240
WH6–11 1120 215 125 1100 1000 280 105 295

Installation manual 9
3.1.2 WH6–14
A
C
31
2
B
E
D2
D1
I
J
G
8
4
N
H
L
K
11
12
F
9
MO
10
6Q
7
P
5
fig.X01751
1 Operating panel
2 Door opening, WH6–14: ⌀395 mm
3 Detergent container
4 Cold/Hot water (Detergent container)
5Cold water
6 Hot water
7Cold/Hot water or Re-used water with network pressure (option)
8 Re-used water from tank/pump or Liquid detergent supply
9 Drain
10 Liquid detergent supply
11 Electrical connection
12 Steam connection
mm A B C D1 D2 E F G
WH6–14 910 820 1345 440 515 1310 1050 80
mm H I J K L M N O
WH6–14 1245 375 295 1225 1125 360 105 305
mm P Q
WH6–14 295 210

10 Installation manual
3.1.3 WH6–20, WH6–27, WH6–33
3
A
C
1
2
D2
B
E
D1
I
J
G
8
4
N
H
L
K
11
12
F
9
MO
10
6Q 7
P
5
fig.X01752
1 Operating panel
2 Door opening, WH6–20, WH6–27, WH6–33: ⌀435 mm
3 Detergent container
4 Cold/Hot water (Detergent container)
5Cold water
6 Hot water
7Cold/Hot water or Re-used water with network pressure (option)
8 Re-used water from tank/pump or Liquid detergent supply
9 Drain
10 Liquid detergent supply
11 Electrical connection
12 Steam connection
mm A B C D1 D2 E F G
WH6–20 970 945 1430 470 555 1480 1135 150
WH6–27 1020 990 1465 500 580 1525 1170 135
WH6–33 1020 1135 1465 500 580 1665 1170 135
mm H I J K L M N O
WH6–20 1330 400 300 1290 1210 350 105 335
WH6–27 1365 400 300 1325 1245 335 105 360
WH6–33 1365 400 300 1325 1245 335 105 360
mm P Q
WH6–20 330 215
WH6–27 340 215
WH6–33 340 215

Installation manual 11
3.2 Technical data
WH6–7 WH6–8 WH6–11 WH6–14 WH6–20 WH6–27 WH6–33
Weight, net kg 145 158 202 263 354 425 560
Drum volume litres 65 75 105 130 180 240 300
Drum diameter mm 520 520 595 650 725 795 795
Drum speed during wash rpm 49 49 46 44 42 40 40
Drum speed during extraction rpm 1245 1245 1165 1113 1054 1007 1007
G-factor, max. 450 450 450 450 450 450 450
Heating: Electricity kW 3.0 3.0 5.2 13 18 23 23
kW 5.2 5.2 7.5
kW 5.4 5.4 10
kW 7.5 7.5
Heating: Steam x x x x x x x
Heating: Hot water x x x x x x x
Frequency of the dynamic
force
Hz 20.8 20.8 19.4 18.6 17.6 16.8 15.8
Floor load at max extraction kN 1.8 ± 0.5 1.9 ± 0.5 2.5 ± 0.5 3.1± 0.5 4.2 ± 1.0 5.2 ± 1.0 6.2 ± 1.3
Sound power/pressure level at
extraction*
dB(A) 73/58 73/59 76/62 78/62 84/68 83/68 82/66
Sound power/pressure level at
wash*
dB(A) 57/43 61/47 61/46 63/48 66/50 64/48 66/50
Heat emission of installed
power, max
%5 5 5 5 5 5 5
* Sound power levels measured according to ISO 60704.

12 Installation manual
3.3 Connections
WH6–7 WH6–8 WH6–11 WH6–14 WH6–20 WH6–27 WH6–33
Water valves DN
BSP
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
Recommended water
pressure
kPa 200–600 200–600 200–600 200–600 200–600 200–600 200–600
Continuous operating
pressure
kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800
Capacity at 300 kPa l/min 20 20 20 20 30 60 60
Drain valve
⌀outer
mm 50/75 50/75 50/75 75 75 75 75
Draining capacity l/min 170 170 170 170 170 170 170
Steam valve connection DN
BSP
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
Recommended steam
pressure
kPa 300–600 300–600 300–600 300–600 300–600 300–600 300–600
Functioning limits for steam
valve
kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800

Installation manual 13
4 Setup
4.1 Unpacking
4.1.1 WH6–7, WH6–8, WH6–11
Remove the front and rear panel.
Remove the four transport supports. Save the transport supports if the machine needs to be moved in the future.
Note!
Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus-
pension components.
fig.W00841D
Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another
diagonally opposed to it, at the back of the machine.
fig.W00841E

14 Installation manual
Remove the machine from the pallet.
Note!
When moving the machine, handle it with care. Make sure that the machine does not come down on the floor
with either of the rear corners first. The side panel of the machine can be damaged.
Place the machine on its final position.
Mount the supporting feet.
fig.W00859
Remount the panels.

Installation manual 15
4.1.2 WH6–14, WH6–20, WH6–27, WH6–33
Note!
Two persons are recommended for the unpacking.
Remove the side panels.
Remove the front and rear panel.
Remove the transport securities. Save the transport securities if the machine needs to be moved in the future.
Note!
Once the transport securities have been removed, handle the machine carefully to avoid damage to the sus-
pension components.
fig.W00843D
Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another
diagonally opposed to it, at the back of the machine.
fig.W00843E

16 Installation manual
Remove the machine from the pallet.
Note!
When moving the machine, handle it with care.
Place the machine on its final position.
Mount the supporting feet.
WH6–14, WH6–20, WH6–27
WH6–33
Remount the panels.

Installation manual 17
4.2 Recycling instruction for packaging
45
6
7
3
1
2
fig.X02395
Fig. Description Code Type
1 Wrapping film LDPE 4 Plastics
2 Corner protection PS 6 Plastics
3 Cardboard packaging PAP 20 Paper
4 Pallet FOR 50 Wood
5Screw FE 40 Steel
6 Nut FE 40 Steel
7 Plastic bag PET 1 Plastics

18 Installation manual
4.3 Siting
Install the machine close to a floor drain or open drain.
The machine should be positioned so that there is plenty of room for working, both for the user and service personnel.
The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will
prevent easy access for maintenance and service operations.
A A
B
fig.X00959
A 50 mm
B 500 mm

Installation manual 19
4.4 Mechanical installation
If the machine is not to be mounted on a base the machine must be fastened to the floor with the enclosed expansion
bolts.
The table shows the correct position of feet and drilling points.
WH6–7-WH6–11: Mark and drill two holes (⌀8 mm) about 40 mm deep in position (1).
WH6–14-WH6–33: Mark and drill two holes (⌀10 mm) about 50 mm deep in position (1).
C A
D
G
FE
B
H
FRONT = drilling points
= position of feet
1
1
X
X
X-X
fig.5989C
mm A B C D E F G H
WH6–7 495 460 110 125 375 170 40 100
WH6–8 495 460 110 125 375 170 40 100
WH6–11 575 465 130 140 455 185 35 95
WH6–14 635 490 135 175 515 195 65 125
WH6–20 715 545 125 205 595 185 65 125
WH6–27 790 615 115 180 670 175 65 125
WH6–33 900 835 60 140 670 175 60 80
Place the machine over the two drilled holes. The holes are at the front of the machine.
Level the machine with the feet of the machine. Screw in the feet as much as possible before starting to level the ma-
chine. This will make the machine stand steadier.
The maximum height adjustment of the feet is 30 mm for WH6–7-WH6–11 and 50 mm for WH6–14-WH6–33.
Insert the expansion bolts (1) into the holes drilled in the floor. Fit the washers and nuts and tighten with tightening
torque 5 Nm.
It is of the upmost importance that the machine is placed in level, from side to side as well as front to rear.
Remount the panels when ready.

20 Installation manual
5 Marine installation
The maximum inclination allowed in any direction is 4°.
To ensure steadiness of the machine; the machine must be fastened to the floor.
