Dear Customer
Thank you for choosing one of our high-quality products.
With this appliance you will experience the perfect combination of functional
design and cutting edge technology.
Convince yourself that our appliances are engineered to deliver the best per-
formance and control - indeed we are setting the highest standards of excel-
lence.
In addition to this you find environmental and energy saving aspects as an inte-
gral part of our products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfect-
ly and most efficiently.
To refer to this manual any time you need to, we recommend you to keep it in a
safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Th
e
f
o
ll
ow
i
ng sym
b
o
l
s are use
d
i
n t
hi
s user
i
n
f
ormat
i
on:
1
Warning! This must be read! Important advice for the safety of persons and
information on avoiding damage to the appliance
3General information and advice
2Information on environmental protection
zDangerous voltage

3Contents
Contents
Operating Instructions 4
Safety instructions 4
Description of the Appliance 6
Cooking surface layout 6
Control panel layout 6
Touch Control sensor fields 7
Displays 8
Residual heat indicator 8
Operating the appliance 9
Switching the appliance on and off 9
Setting the heat setting 9
Switching the outside ring on and off 10
Locking/unlocking the control panel 11
Switching the STOP+GO function on and off 11
Using the automatic warm-up function 12
Using the child safety device 13
Using the timer 14
Automatic switch off 17
Tips on Cooking and Frying 18
Cookware 18
Energy saving 18
Examples of cooking applications 19
Cleaning and Care 20
What to do if … 21
Disposal 22
Installation Instructions 23
Safety instructions 23
Assembly 25
Rating Plate 28
Guarantee/Customer Service 29
Service 31

Operating Instructions4
Operating Instructions
1Safety instructions
Please comply with these instructions. If you do not, any damage resulting is not
covered by the warranty.
Correct use
•This appliance is not intended for use by children or other persons whose
physical, sensory or mental capabilities or lack of experience and knowledge
prevents them from using the appliance safely without supervision or instruc-
tion by a responsible person to ensure that they can use the appliance safely.
•Do not leave the appliance unattended during operation.
•This appliance should be used only for normal domestic cooking and frying of
food.
•The appliance must not be used as a work surface or as a storage surface.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials or fusi-
ble objects (e.g. plastic film, plastic, aluminium) on or near the appliance.
Children’s safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
•To avoid small children and pets unintentionally switching the appliance on,
we recommend activation of the child safety device.
General safety
•The appliance may only be installed and connected by trained, registered
service engineers.
•Built-in appliances may only be used after they have built in to suitable built-
in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ceramic
(cracks, scratches or splits), the appliance must be switched off and discon-
nected from the electrical supply, to prevent the possibility of an electric
shock.
•Repairs to the appliance must only be carried out by trained registered service
engineers.

5Safety instructions
Safety during use
•Overheated fats and oils can ignite very quickly. Warning! Fire hazard!
•There is the risk of burns from the appliance if used carelessly.
•Remove stickers and film from the glass ceramic.
•Cables from electrical appliances must not touch the hot surface of the appli-
ance or hot cookware.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or high-pres-
sure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by the cook-
ware.
•Cookware made of cast iron, cast aluminium or with damaged bottoms can
scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass ceramic
and should be removed straightaway.
•To avoid damaging cookware and glass ceramics, do not allow saucepans or
frying pans to boil dry.
•Do not use the cooking zones with empty cookware or without cookware.

Description of the Appliance6
Description of the Appliance
Cooking surface layout
Control panel layout
Triple cooking zone 800/1600/2300 W
Multi-purpose zone 1500/2600 W
Single cooking zone 1200 W
Control panel Single cooking zone 1200 W
On/Off
with power indicator
Timer display
Cooking zone indicators
Timer function
Child lock with
pilot light
Timer
Multi-purpose zone
switch with pilot light
Triple ring cooking zone
switch with pilot lights
STOP+GO
with pilot light
Heat setting selection
Automatic warm-up
function Heat setting indicator

7Description of the Appliance
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are con-
trolled by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
Control bar
The control bar is a special Touch Control field.
The control bar is touched where the de-
sired heat setting is positioned. The heat
setting is shown in the display. Correct to
the left or the right, if necessary.
Do not release before the desired heat set-
ting is reached.
3If the control bar is touched for longer
than 6 seconds, a signal sounds and the
appliance switches itself off.
Sensor field Function
On / Off To switch the appliance on and off
Child lock Locking control panel for children
Stop+Go To switch the Keep Warm setting on/
off
Triple ring switch To switch outer rings
on and off
TIMER Timer Timer selection
Increase settings To increase Timer time
Reduce settings To reduce Timer time
Multi-purpose zone switch To switch the outside ring on and off
Automatic warm-up func-
tion
To switch automatic warm-up function
on/off

Description of the Appliance8
Displays
Residual heat indicator
1Warning! Risk of burns from residual heat. After being switched off, the cook-
ing zones need some time to cool down. Look at the residual heat indicator .
3Residual heat can be used for melting and keeping food warm.
Display Description
Cooking zone is switched off
/ Keep Warm setting STOP+GO function / Keep Warm
setting is set
- Heat settings Heat setting is set
Automatic warm up
function
Automatic warm-up function is
activated
Fault Malfunction has occurred
Residual heat Cooking zone is still hot
Child safety device Child safety device is engaged
Automatic switch off Switch off is active.

9Operating the appliance
Operating the appliance
Switching the appliance on and off
3After switching on, within approx. 10 seconds a heat setting or a function must
be set, otherwise the appliance automatically switches itself off.
Setting the heat setting
Control panel Display Pilot light
Switch on Touch for 1 second / lights up
Switch off Touch for 1 second / none goes out
Control bar Display
To set the heat
setting
Touch the desired heat setting, if
necessary, correct to the left or the
right
to /
To switch off Touch 0

Operating the appliance10
Switching the outside ring on and off
By switching the outside rings on or off, the effective heating surface can be
matched to the size of the cookware.
3Before an outside ring can be switched on, the inside ring must be switched on.
Triple ring cooking
zone
Sensor field Pilot light
To switch on the central
ring
Touch 1-2 seconds Second pilot light lights
up
To switch on the outer
ring
Touch for 1-2 seconds Third pilot light lights up
To switch off the outer
ring
Touch for 1-2 seconds Third pilot light goes out
To switch off the central
ring
Touch for 1-2 seconds Second pilot light goes
out
Multi-purpose zone Sensor field Pilot light
To switch on the outer
ring
Touch 1-2 seconds Second pilot light lights
up
To switch off the outer
ring
Touch for 1-2 seconds Second pilot light goes
out

11Operating the appliance
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can be locked
at any time in order to prevent the settings being changed e.g. by wiping over
the panel with a cloth.
3When you switch the appliance off, the locking function is automatically
switched off.
Switching the STOP+GO function on and off
The STOP+GO function simultaneously switches all cooking zones that are
switched on to the keep warm setting and then back to the heat setting that
was previously set.
3Timer functions are not stopped by STOP+GO.
3STOP+GO locks the whole control panel except the sensor field .
Control panel Display
Switch on Touch (for 4 seconds)
Switch off Touch previously set heat setting
Control panel Display
To switch on Touch
To switch off Touch heat setting that was previously
set (not automatic warm up func-
tion)

Operating the appliance12
Using the automatic warm-up function
All cooking zones are equipped with an automatic warm-up function. When set-
ting a heat setting using the automatic warm-up function, the cooking zone
switches to full power for a certain amount of time and then automatically
switches back to the heat setting set.
The length of time that the automatic warm up function operates depends on
the heat setting selected.
Step Control panel Display
1. Touch
2. Move your finger down from to se-
lect the desired heat setting between
and
/ ,
after 5 seconds .
As long as is displayed,
the appliance works at full
power.
After the automatic warm
up is completed, the heat
setting / is dis-
played again.
Heat setting Length of the automatic warm up
[min:sec]
11:00
21:40
32:40
44:50
55:30
66:30
78:10
810:10
912:20
10 2:30
11 2:30
12 3:30
13 4:30
14 ---

13Operating the appliance
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Switching on the child safety device
Switching off the child safety device
3The child safety device can only be switched on and off, if no heat setting is set.
Overriding the child safety device
The child safety device can be switched off in this way for a single cooking ses-
sion; it remains activated afterwards.
3After overriding the child safety device, a heat setting or a function must be set
within approx. 10 seconds, otherwise the appliance automatically switches itself
off.
Step Control panel Display/Signal
1. Switch on appliance. (Do not set
a heat setting.)
2. Touch for 4 seconds
The child safety device is switched on.
Step Control panel Display/Signal
1. Switch on appliance. (Do not set
a heat setting.)
2. Touch for 4 seconds lights up
3. Switch appliance off.
The child safety device is switched off.
Step Control panel Display/Signal
1. Switch appliance on
2. Touch for 4 seconds lights up
Until the appliance is next switched off, it can used as normal. After switching
off the appliance, the child safety device is active again.

Operating the appliance14
Using the timer
3If just one countdown value is set you can change it only when the appliance is
switched on.
3If a heat setting is set on this cooking zone in addition to a countdown timer,
the cooking zone is switched off after the time set has elapsed.
3If a cooking zone is switched off, the timer function set is also switched off.
Selecting a cooking zone
3If other timer functions are set, after a few seconds the shortest remaining time
of all the timer functions is displayed and the corresponding pilot light flashes.
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches
off
Countdown timer cooking zones not in use acoustic signal
00 flashes
Step Control panel Display
1. Touch TIMER once Pilot light of the first
cooking zone flashes
2. Touch TIMER once Pilot light of the second
cooking zone flashes
3. Touch TIMER once Pilot light of the third
cooking zone flashes
4. Touch TIMER once Pilot light of the fourth
cooking zone flashes

15Operating the appliance
Setting the time
Switching off the timer function
Changing the time
Step Control panel Indicator
1. Select TIMER
cooking zone
Pilot light for the cooking zone selected
flashes
2. Touch or 00 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel Indicator
1. Select TIMER cook-
ing zone
Pilot light of cooking zone selected flashes
faster
Time remaining is displayed
2. Touch The time remaining counts backwards to
00.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Step Control panel Indicator
1. Select TIMER
cooking zone
Pilot light of the selected cooking zone
flashes faster
Time remaining is displayed
2. Touch or 01 to 99 minutes
After a few seconds, the pilot light flashes more slowly.
The time is set.
The time counts down.

Operating the appliance16
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel field Display
1. TIMER Select
cooking zone
Pilot light of the cooking zone selected
flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch TIMER Acoustic signal to acknowledge.
Acoustic signal stops.

17Operating the appliance
Automatic switch off
Cooking surface
•If after switching on the cooking surface, a heat setting is not set for a cook-
ing zone within approx. 10 seconds, the cooking surface automatically switch-
es itself off.
•If one or more sensor fields are covered by objects (a pan, cloths, etc.) for
longer than approx. 10 seconds, a signal sounds and the cooking surface
switches off automatically.
•If all cooking zones are switched off, the cooking surface automatically
switches itself off after approx. 10 seconds.
Control panel
•When the appliance is switched off, if one or more of the sensor fields on the
control panel are covered for more that 10 seconds, an acoustic signal sounds.
The acoustic signal switches itself off automatically when the sensor fields are
no longer covered.
Cooking zones
•If one of the cooking zones is not switched off after a certain time, or if the
heat setting is not modified, the relevant cooking zone switches off automati-
cally. is displayed. Before being used again, the cooking zone must be set to
.
Heat setting Switches off after
1- 36 hours
4- 75 hours
8-94 hours
10 -14 1.5 hours

Tips on Cooking and Frying18
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, espe-
cially in products containing starch, can constitute a health risk due to acryla-
mides. Therefore we recommend cooking at the lowest possible temperatures
and not browning foods too much.
Cookware
•You can recognise good cookware from the bottoms of the pans. The bottom
should be as thick and flat as possible.
•Cookware made of enamelled steel or with aluminium or copper bottoms can
leave discolorations on the glass ceramic surface which are difficult or impos-
sible to remove.
Energy saving
2Always place cookware on the cooking
zone before it is switched on.
2If possible, always place lids on the pans.
2Switch cooking zones off before the end of
the cooking time, to take advantage of re-
sidual heat.
2Bottom of pans and cooking zones should
be the same size.

19Tips on Cooking and Frying
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
setting
Cooking-
process suitable for Cooking time Tips/Hints
0Residual heat, Off position
1 Keeping
food warm Keeping cooked foods warm as required Cover
1-3 Melting
Hollandaise sauce,
melting butter, chocolate,
gelatine
5-25 mins. Stir occasionally
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
3-5
Simmer-
ing on low
heat
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
25-50 mins.
Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
5-7 Steaming
Braising
Steaming vegetables, fish
braising meat 20-45 mins.
With vegetables add only
a little liquid (a few table-
spoons)
7-9 Boiling
Steaming potatoes 20-60 mins.
Use only a little liquid, e.
g.: max. ¼l water for
750 g potatoes
Cooking larger quantities of
food, stews and soups 60-150 mins. Up to 3 l liquid plus in- gredients
9-12 Gentle
Frying
Frying escalopes, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts
Steady frying Turn halfway through
cooking
12-13 Heavy
Frying
Hash browns, loin steaks,
steaks, Flädle (pancakes for
garnishing soup)
5-15 mins.
per pan
Turn halfway through
cooking
14
Boiling
Searing
Deep
frying
Boiling large quantities of water, cooking pasta, searing meat (goulash,
pot roast), deep frying chips

Cleaning and Care20
Cleaning and Care
1Take care! Risk of burns from residual heat.
1Warning! Sharp objects and abrasive cleaning materials will damage the appli-
ance. Clean with water and washing up liquid.
1Warning! Residues from cleaning agents will damage the appliance. Remove
residues with water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place a scraper on the glass ceramic surface at an angle.
2. Remove residues by sliding the blade over the surface.
3. Wipe the appliance with a damp cloth and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialized shops
3Remove stubborn residues with a cleaner for glass ceramic or stainless steel.
3Scratches or dark stains on the glass ceramic that cannot be removed do not
however affect the functioning of the appliance.
Remove
Type of dirt immedi-
ately
when the appliance has
cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes
cleaner for glass ceram-
ic or stainless steel*
fat splashes --- yes
shiny metallic discolouration --- yes
