Electrolux EHS601210P User manual

user manual
Ceramic glass hob
EHS60210P
Get other manuals https://www.bkmanuals.com

We were thinking of you
when we made this product
Get other manuals https://www.bkmanuals.com

electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class
product from Electrolux, which hopefully
will provide you with lots of pleasure in
the future. The Electrolux ambition is to
offer a wide variety of quality products
that make your life more comfortable.
You will find some examples on the cov-
er in this manual. Please take a few min-
utes to study this manual so that you
can take advantage of the benefits of
your new machine. We promise that it
will provide a superior User Experience
delivering Ease-of-Mind. Good luck!
Get other manuals https://www.bkmanuals.com

4electrolux contents
Contents
Safety instructions 5
Description of the Appliance 7
Operating the appliance 11
Tips on Cooking and Frying 22
Cleaning and Care 25
What to do if … 27
Disposal 29
Installation Instructions 30
Assembly 31
Guarantee/Customer Service 35
Service 38
T
he following symbols are used in this user information:
1
Warning! This must be read! Important advice for the safety of persons and
information on avoiding damage to the appliance
3General information and advice
2Information on environmental protection
zDangerous voltage
Get other manuals https://www.bkmanuals.com

safety instructions electrolux 5
Safety instructions
Please comply with these instructions. If
you do not, any damage resulting is not
covered by the warranty.
Correct use
•This appliance is not intended for
use by children or other persons
whose physical, sensory or mental
capabilities or lack of experience and
knowledge prevents them from us-
ing the appliance safely without su-
pervision or instruction by a
responsible person to ensure that
they can use the appliance safely.
•Do not leave the appliance unattend-
ed during operation.
•This appliance should be used only
for normal domestic cooking and fry-
ing of food.
•The appliance must not be used as a
work surface or as a storage surface.
•Additions or modifications to the ap-
pliance are not permitted.
•Do not place or store flammable liq-
uids, highly inflammable materials or
fusible objects (e.g. plastic film, plas-
tic, aluminium) on or near the appli-
ance.
Children’s safety
•Small children must be kept away
from the appliance.
•Only let bigger children work on the
appliance under supervision.
•To avoid small children and pets un-
intentionally switching the appliance
on, we recommend activation of the
child safety device.
General safety
•The appliance may only be installed
and connected by trained, registered
service engineers.
•Built-in appliances may only be used
after they have built in to suitable
built-in units and work surfaces that
meet standards.
•In the event of faults with the appli-
ance or damage to the glass ceramic
(cracks, scratches or splits), the ap-
pliance must be switched off and
disconnected from the electrical
supply, to prevent the possibility of
an electric shock.
•Repairs to the appliance must only
be carried out by trained registered
service engineers.
Safety during use
•Overheated fats and oils can ignite
very quickly. Warning! Fire hazard!
•There is the risk of burns from the
appliance if used carelessly.
•Remove stickers and film from the
glass ceramic.
•Cables from electrical appliances
must not touch the hot surface of the
appliance or hot cookware.
•Switch the cooking zones off after
each use.
Safety when cleaning
•For cleaning, the appliance must be
switched off and cooled down.
•For safety reasons, the cleaning of
the appliance with steam jet or high-
pressure cleaning equipment is not
permitted.
Get other manuals https://www.bkmanuals.com

6electrolux safety instructions
How to avoid damage to the appli-
ance
•The glass ceramic can be damaged
by objects falling onto it.
•The edge of the glass ceramic can
be damaged by being knocked by
the cookware.
•Cookware made of cast iron, cast
aluminium or with damaged bottoms
can scratch the glass ceramic if
pushed across the surface.
•Objects that melt and things that boil
over can burn onto the glass ceramic
and should be removed straighta-
way.
•To avoid damaging cookware and
glass ceramics, do not allow sauce-
pans or frying pans to boil dry.
•Do not use the cooking zones with
empty cookware or without cook-
ware.
Get other manuals https://www.bkmanuals.com

description of the appliance electrolux 7
Description of the Appliance
Cooking surface layout
Control panel layout
Triple cooking zone
800/1600/2300W
Multi-purpose zone
1500/2400W
Single cooking zone
1200W
Control panel Single cooking zone
1200W
On/Off
with indicator
Timer display
Cooking zone indicators
Timer function
Child lock
with display
Timer
Cooking zone switch
with indicator
Triple cooking zone
switch with indicator
STOP+GO
with indicator
Heat setting selection
Automatic
warm-up Heat setting indicator
Residual heat indicator
Automatic
switch-off
indicator
Get other manuals https://www.bkmanuals.com

8electrolux description of the appliance
Touch Control sensor fields
The appliance is operated using Touch
Control sensor fields. Functions are
controlled by touching sensor fields and
confirmed by displays and acoustic sig-
nals.
Touch the sensor fields from above,
without covering other sensor fields.
Sensor field Function
On / Off To switch the appliance on and off
Child lock Locking control panel for children
Stop+Go To switch the Keep Warm setting on/off
Cooking zone Off To switch off the cooking zone
1-9/ Heat settings To set heat settings
Automatic warm-up Switch on the automatic warm-up
function
TIMER Timer Timer selection
Increase settings To increase Timer time
Reduce settings To reduce Timer time
Triple ring switch To switch outer rings on and off
Multi-purpose zone switch To switch the outside ring on and off
Get other manuals https://www.bkmanuals.com

description of the appliance electrolux 9
Displays
Residual heat indicator
Warning! Risk of burns from residu-
al heat. After being switched off, the
cooking zones need some time to
cool down. Look at the residual heat
indicator .
Residual heat can be used for melt-
ing and keeping food warm.
Display Description
Residual heat Cooking zone is still hot
Middle ring of triple-ring
function
The middle ring of the triple-ring function
is on
Outer ring of triple-ring func-
tion
The outer ring of the triple-ring function
is on
Outer ring of multi-purpose
function
The outer ring of the multi-purpose
function is on
+
number
Fault Malfunction has occurred
Automatic switch off Switch off is active.
Get other manuals https://www.bkmanuals.com

10 electrolux description of the appliance
Control bar
You can set the heat setting and auto-
matic warm-up function via the control
panel. The heat setting indicator com-
prises a row of lights.
If the control bar is touched for
longer than 6 seconds, a signal
sounds and the appliance switches
itself off.
Automatic warm-up
indicator
Operational readiness indica-
tor for cooking zone
Automatic warm-up
function
Heat setting indicator
Heat setting selection
Cooking zone Off
Get other manuals https://www.bkmanuals.com

operating the appliance electrolux 11
Operating the appliance
Switching the appliance on and off
After switching on, within approx.
10 seconds a heat setting or a func-
tion must be set, otherwise the ap-
pliance automatically switches
itself off.
Control panel Display
To sw itc h on Touch for 1 second lights up. The opera-
tional readiness
indicators of the indi-
vidual cooking zones
also light up.
To sw itc h off Touch for 1 second goes out. The opera-
tional readiness
indicators of the indi-
vidual cooking zones
also go out.
Get other manuals https://www.bkmanuals.com

12 electrolux operating the appliance
Setting the heat setting
The control bar is touched where the
desired heat setting is positioned. The
heat setting is shown in the display. Cor-
rect to the left or the right, if necessary.
Do not release before the desired heat
setting is reached.
Get other manuals https://www.bkmanuals.com

operating the appliance electrolux 13
Switching the outside ring on and
off
By switching the outside rings on or off,
the effective heating surface can be
matched to the size of the cookware.
Before an outside ring can be
switched on, the inside ring must be
switched on.
Triple cooking zone Sensor field Display
Switch on the middle ring Tou ch for 1-2 seconds lights up
Switch on the outer ring Tou ch for 1-2 seconds and light up
Switch off the outer ring Touch for 1-2 seconds goes out
Switch off the middle ring Tou ch for 1-2 seconds goes out
Cooking zone Sensor field Display
Switch on the outer ring Tou ch for 1-2 sec-
onds
lights up
Switch off the outer ring Touch for 1-2 sec-
onds
goes out
Get other manuals https://www.bkmanuals.com

14 electrolux operating the appliance
Locking/unlocking the control
panel
The control panel, with the exception of
the “On/Off” sensor field, can be locked
at any time in order to prevent the set-
tings being changed e.g. by wiping over
the panel with a cloth.
When you switch the appliance off,
the locking function is automatically
switched off.
Control panel Display
To sw i tc h o n Touch for 4 seconds lights up
To sw i tc h o ff Touch for 4 seconds goes out
Get other manuals https://www.bkmanuals.com

operating the appliance electrolux 15
Switching the STOP+GO func-
tion on and off
The STOP+GO function simultaneously
switches all cooking zones that are
switched on to the keep warm setting
and then back to the heat setting that
was previously set.
Timer functions are not stopped by
STOP+GO.
STOP+GO locks the whole control
panel except the sensor field .
Control panel Display
To sw i tc h o n Touch
To sw i tc h o ff Touch heat setting that was previously set
(not automatic warm up function)
Get other manuals https://www.bkmanuals.com

16 electrolux operating the appliance
Using the automatic warm-up
function
All cooking zones are equipped with an
automatic warm-up function. When set-
ting a heat setting using the automatic
warm-up function, the cooking zone
switches to full power for a certain
amount of time and then automatically
switches back to the heat setting set.
The length of time that the automatic
warm up function operates depends on
the heat setting selected.
Step Control panel Display
1. Select warm-up setting display flashes
2. Select the desired heat setting between
1 and 8
The desired heat setting is
displayed. display lights
up.
As long as the display is
lit, the appliance is working
at full power.
After the automatic warm-up
is completed, the display
goes out.
Heat setting Warm-up time
[min:sec]
1:00
1:40
4:50
6:30
10:10
2:30
3:30
4:30
---
Get other manuals https://www.bkmanuals.com

operating the appliance electrolux 17
Using the child safety device
The child safety device prevents unin-
tentional use of the appliance.
Switching on the child safety device
Overriding the child safety device
The child safety device can be switched
off in this way for a single cooking ses-
sion; it remains activated afterwards.
After overriding the child safety de-
vice, a heat setting or a function
must be set within
approx. 10 seconds, otherwise the
appliance automatically switches it-
self off.
Switching off the child safety device
Step Control panel Pilot light
1. Switch on appliance. (Do not set a
heat setting.)
lights up. The operational
readiness indicators of the
individual cooking zones
light up.
2. To u c h for 4 seconds over lights up
The child safety device is switched on
Step Control panel Pilot light
1. Switch appliance on over lights up
2. To u c h for 4 seconds over goes out.
Until the appliance is next switched off, it can used as normal.
Step Control panel Pilot light
1. Switch on appliance. (Do not set a
heat setting.)
above lights up
2. To u c h for 4 seconds above goes out
3. Switch appliance off.
The child safety device is switched off.
Get other manuals https://www.bkmanuals.com

18 electrolux operating the appliance
Using the timer
If a heat setting is set on this cook-
ing zone in addition to a countdown
timer, the cooking zone is switched
off after the time set has elapsed.
If a cooking zone is switched off, the
timer function set is also switched
off.
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches
off
Countdown timer cooking zones not in use acoustic signal
00 flashes
Get other manuals https://www.bkmanuals.com

operating the appliance electrolux 19
Selecting a cooking zone
If the pilot light is flashing more
slowly, the heat setting can be set or
modified.
If other timer functions are set, after
a few seconds the shortest remain-
ing time of all the timer functions is
displayed and the corresponding pi-
lot light flashes.
Step Control panel Display
1. Touch TIMER once Pilot light of the first cooking
zone flashes
2. Touch TIMER once Pilot light of the second
cooking zone flashes
3. Touch TIMER once Pilot light of the third cooking
zone flashes
4. Touch TIMER once Pilot light of the fourth cooking
zone flashes
Get other manuals https://www.bkmanuals.com

20 electrolux operating the appliance
Setting the time
Switching off the timer function
Changing the time
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel Indicator
1. Select TIMER cook-
ing zone
Pilot light for the cooking zone selected
flashes
2. To u c h o r 00 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel Indicator
1. Select TIMER cook-
ing zone
Pilot light of cooking zone selected flashes
faster
Time remaining is displayed
2. To u c h The time remaining counts backwards to 00.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Step Control panel Indicator
1. Select TIMER cook-
ing zone
Pilot light of the selected cooking zone
flashes faster
Time remaining is displayed
2. To u c h o r 01 to 99 minutes
After a few seconds, the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. TIMER Select cooking
zone
Pilot light of the cooking zone selected
flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. To u c h TIMER Acoustic signal to acknowledge.
Acoustic signal stops.
Get other manuals https://www.bkmanuals.com
