Electrolux EHS6610K User manual

Glaskeramisk-kogezone
Ceramic glass hob
Monterings- og brugsanvisning
Installation and Operating
Instructions
EHS6610K
822 924 561-A-250405-03 g
k

2
Dear Customer,
Please read these user instructions carefully and
keep them to refer to later.
Please pass the user instructions on to any future
owner of the appliance.
The following symbols are used in the
text:
1Safety instructions
Warning! Information that affects your per-
sonal safety.
Important! Information that prevents damage
to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Control panel layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Touch Control sensor fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switching the appliance on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Selecting the cooking zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting the heat setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Activating the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Deactivating the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overriding the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Tips on Cooking and Frying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4
Operating Instructions
1Safety instructions
3Please comply with these instructions. If you
do not, any damage resulting is not covered
by the warranty.
5This appliance conforms with the following EU
Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Direc-
tive
–89/336/EEC dated 03.05.1989 EMC Directive in-
clusive of Amending Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal do-
mestic cooking and frying of food.
•The appliance must not be used as a work surface
or as a storage surface.
•Additions or modifications to the appliance are not
permitted.
•Do not place or store flammable liquids, highly in-
flammable materials or fusible objects (e.g. plastic
film, plastic, aluminium) on or near the appliance.
Children’s safety
•Small children must be kept away from the appli-
ance.
•Only let bigger children work on the appliance un-
der supervision.
General safety
•The appliance may only be installed and connect-
ed by trained, registered service engineers.
•Built-in appliances may only be used after they
have built in to suitable built-in units and work sur-
faces that meet standards.
•In the event of faults with the appliance or damage
to the glass ceramic (cracks, scratches or splits),
the appliance must be switched off and discon-
nected from the electrical supply, to prevent the
possibility of an electric shock.
•Repairs to the appliance must only be carried out
by trained registered service engineers.
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used
carelessly.
•Cables from electrical appliances must not touch
the hot surface of the appliance or hot cookware.
•Overheated fats and oils can ignite quickly. When
cooking with fat or oil (e.g. chips) do not leave the
appliance unattended.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off
and cooled down.
•For safety reasons, the cleaning of the appliance
with steam jet or high-pressure cleaning equip-
ment is not permitted.
How to avoid damage to the appli-
ance
•The glass ceramic can be damaged by objects fall-
ing onto it.
•The edge of the glass ceramic can be damaged by
being knocked by the cookware.
•Cookware made of cast iron, cast aluminium or
with damaged bottoms can scratch the glass ce-
ramic if pushed across the surface.
•Objects that melt and things that boil over can
burn onto the glass ceramic and should be re-
moved straightaway.
•Do not use the cooking zones with empty cook-
ware or without cookware.

5
Description of the Appliance
Cooking surface layout
Control panel layout
Single cooking zone
2300W
Single cooking zone
1800W
Singlecooking zone
1200W
Control panel Singlecooking zone
1200W
Display
Cooking zone and heat setting selection
On/Off

6
Touch Control sensor fields
The appliance is operated using the Touch Control
sensor fields. Functions are controlled by touching
sensor fields and confirmed by displays.
Touch the sensor fields from above, without covering
other sensor fields.
Displays
Residual heat indicator
1Warning! Risk of burns from residual heat. Af-
ter being switched off, the cooking zones need
some time to cool down. Look at the residual
heat indicator h.
3Residual heat can be used for melting and
keeping food warm.
Sensor field Function
On / Off To switch the appliance on and off
Increase settings To select the cooking zone
To increase heat settings
Reduce settings To reduce heat settings
Display Description
¾Cooking zone is switched off
¿- ÇHeat settings Heat setting is set
ER Fault Malfunction has occurred
hResidual heat Cooking zone is still hot
lChild safety device Lock/child safety device is engaged

7
Operating the appliance
Switching the appliance on and off
Selecting the cooking zone
3The decimal point is displayed by the selected
cooking zone. Then a heat setting must be set
for this cooking zone within 6 seconds, other-
wise it must be re-selected.
Setting the heat setting
3After selecting the cooking zone, briefly re-
lease the sensor field .
3After 6 seconds with no input the selection is
cancelled and the decimal point goes out. To
set a new setting, select the required cooking
zone again.
Control panel Display
Switch on Touch for 2 seconds ¾/ decimal point flashes
Switch off Touch for 1 second h/ none
Control panel Display
Select Touch ¾Decimal point lights up
Control field Display
Increase Touch ¾to Ç
Decrease Touch Çto ¾
Switch off Touch and at the same time ¾

8
Using the child safety device
The child safety device prevents unintentional use of
the appliance.
3To override the child safety device or switch it
off sucessfully, the steps must be performed
immediately one after the other.
No other sensor fields must be touched be-
tween the steps described. If the steps are
performed in the wrong order, the display au-
tomatically switches itself off.
Activating the child safety device
Deactivating the child safety device
Overriding the child safety device
The child safety device can be released in this way
for a single cooking session; it remains activated af-
terwards.
Step Control panel Display
1. Switch on the appliance (Do not set a heat
setting)
¾/ h(if hot)
2. Touch of the front right cooking zone and
at the same time
4 x ¾or h
Decimal points flash
3. Touch of the front right cooking zone l
Appliance switches off.
Step Control panel Display
1. Switch on the appliance l/ h(if hot)
2. Touch of the front right cooking zone and
at the same time
4 x ¾or h
Decimal points flash
3. Touch
Appliance switches off.
Step Control panel Display
1. Switch on the appliance l/ h(if hot)
2. Touch of the front right cooking zone and
at the same time
4 x ¾Decimal points flash
Until the appliance is next switched off, it can used as normal.

9
Safety cut-out
Cooking surface
•If after switching on the appliance a heat setting is
not set for a cooking zone within approx. 10 sec-
onds, the appliance automatically switches itself
off.
•If one or more sensor fields are touched for longer
than approx. 10 seconds, the cooking surface is
automatically switched off. ER03 flashes on the
display or changes to hif there is still residual
heat.
•If all cooking zones are switched off, the cooking
surface automatically switches itself off after ap-
prox. 10 seconds.
Control panel
3Moisture (e.g. a wet cloth) or liquid boiling over
onto the control panel switches all cooking
zones off.
Cooking zones
•If one of the cooking zones is not switched off after
a certain time, or if the heat setting is not modified,
the relevant cooking zone switches off automati-
cally. his displayed.
Heat setting Switches off after
1 - 2 6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hours

10
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowledge,
intensive browning of food, especially in prod-
ucts containing starch, can constitute a health
risk due to acrylamides. Therefore we recom-
mend cooking at the lowest possible tempera-
tures and not browning foods too much.
Cookware
•You can recognise good cookware from the bot-
toms of the pans. The bottom should be as thick
and flat as possible.
•Cookware made of enamelled steel or with alumin-
ium or copper bottoms can leave discolorations on
the glass ceramic surface which are difficult or im-
possible to remove.
Energy saving
2Always place cookware on the cooking zone
before it is switched on.
2If possible, always place lids on the pans.
2Switch cooking zones off before the end of the
cooking time, to take advantage of residual
heat.
2Bottom of pans and cooking zones should be
the same size.

11
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
setting
Cooking-
process suitable for Cooking time Tips/Hints
0 Residual heat, Off position
1Keeping
food warm Keeping cooked foods warm as required Cover
1-2 Melting Hollandaise sauce,
melting butter, chocolate, gelatine 5-25 mins. Stir occasionally
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3 Simmering
on low heat
Simmering rice and milk-based
dishes
Heating up ready-cooked meals
25-50 mins.
Add at least twice as much
liquid as rice, stir milk dishes
part way through cooking
3-4 Steaming
Braising
Steaming vegetables, fish
braising meat 20-45 mins. With vegetables add only a lit-
tle liquid (a few tablespoons)
4-5 Boiling
Steaming potatoes 20-60 mins.
Use only a little liquid, e. g.:
max. ¼l water for
750 g potatoes
Cooking larger quantities of food,
stews and soups 60-150 mins. Up to 3 l liquid plus ingredi-
ents
6-7 Gentle
Frying
Frying escalopes, veal cordon
bleu, cutlets, rissoles, sausages,
liver, roux, eggs, pancakes,
doughnuts
Steady frying Turn halfway through cooking
7-8 Heavy
Frying
Hash browns, loin steaks, steaks,
Flädle (pancakes for garnishing
soup)
5-15 mins.
per pan Turn halfway through cooking
9
Boiling
Searing
Deep frying
Boiling large quantities of water, cooking pasta, searing meat (goulash, pot roast),
deep frying chips

12
Cleaning and Care
1Take care! Risk of burns from residual heat.
1Warning! Sharp objects and abrasive cleaning
materials will damage the appliance. Clean
with water and washing up liquid.
1Warning! Residues from cleaning agents will
damage the appliance. Remove residues with
water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little
washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place a scraper on the glass ceramic surface at an
angle.
2. Remove residues by sliding the blade over the sur-
face.
3. Wipe the appliance with a damp cloth and a little
washing up liquid.
4. Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel
can be purchased in specialist shops
3Remove stubborn residues with a cleaner for
glass ceramic or stainless steel.
3Scratches or dark stains on the glass ceramic
that cannot be removed do not however affect
the functioning of the appliance.
Remove
Type of dirt immedi-
ately
when the appliance has
cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes
cleaner for glass ceramic
or stainless steel*
fat splashes --- yes
shiny metallic discolorations --- yes

13
What to do if …
3In the event of any other fault codes that arise,
disconnect the appliance from the electrical
supply for a few seconds. (Take out the fuse
from the house’s wiring system.) If the fault is
displayed again, please call the Customer
Care Department and inform them of the fault
code.
If you are unable to remedy the problem by fol-
lowing the above suggestions, please contact
your dealer or the Customer Care Department.
1Warning! Repairs to the appliance are only to
be carried out by qualified service engineers.
Considerable danger to the user may result
from improper repairs.
3If the appliance has been wrongly operated,
the visit from the customer service technician
or dealer may not take place free of charge,
even during the warranty period.
Problem Possible cause Remedy
The cooking zones are not func-
tioning.
No cooking zone selected Select cooking zone within 10 sec-
onds of switching on (Decimal point
lights up)
The cooking zones cannot be se-
lected / Appliance does not react to
the control panel input
More than 10 seconds have passed
since the appliance was switched
on
Switch on the appliance again.
Select cooking zone within 10 sec-
onds of switching on
The child safety device is activated
l
Deactivate the child safety device
(See section “Child safety device”)
The sensor fields are partly covered
by a damp cloth or with liquid
Remove the cloth or the liquid
Safety cut-out has been triggered Switch on the appliance again
The residual heat indicator is not
displaying anything
The cooking zone was only on for a
short time and is therefore not hot
If the cooking zone is supposed to
be hot, call the Customer Service
Department.
Er03 is displayed Several sensor fields were touched
at the same time Only touch one sensor field
Er21 is displayed Safety cut-out due to overheating Let the appliance cool down.
Remove cookware.
Er25 is displayed
(only for 10 seconds) Appliance is incorrectly connected
Disconnect the appliance from the
electrical supply and have it con-
nected properly
Er40 is displayed The overvoltage protector has been
activated (for an incorrect connec-
tion see above Er25 or for over-
heating of the electronic
components see Er21)
Separate the appliance from the
mains for a few minutes (remove
the mains fuse).
Let the appliance cool down.

14
Disposal
2Packaging material
The packaging materials are environmentally
friendly and can be recycled. The plastic com-
ponents are identified by markings, e.g. >PE<,
>PS<, etc. Please dispose of the packaging
materials in the appropriate container at the
community waste disposal facilities.
2Old appliance
The symbol Won the product or on its pack-
aging indicates that this product may not be
treated as household waste. Instead it shall be
handed over to the applicable collection point
for the recycling of electrical and electronic
equipment. By ensuring this product is dis-
posed of correctly, you will help prevent po-
tential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed in-
formation about recycling of this product,
please contact your local city office, your
household waste disposal service or the shop
where you purchased the product.

15
Installation Instructions
Safety instructions
The laws, ordinances, directives and standards in
force in the country of use are to be followed (safety
regulations, proper recycling in accordance with the
regulations, etc.)
Installation may only be carried out by a qualified
electrician.
The minimum distances to other appliances and
units are to be observed.
A protective floor must be installed under the ap-
pliance.
The cut surfaces of the worktop are to be protected
against moisture using a suitable sealant.
The sealant seals the appliance to the work top with
no gap.
Do not use silicon sealant between the appliance
and the work top.
Avoid installing the appliance next to doors and un-
der windows. Otherwise hot cookware may be
knocked off the rings when doors and windows are
opened.
1WARNING!
Risk of injury from electrical current.
•The electrical mains terminal is live.
•Make electrical mains terminal free of voltage.
•Observe connection schematic.
•Observe electrical safety rules.
•Ensure anti-shock protection through correct in-
stallation by a qualified electrician.
•The appliance must be connected to the electrical
supply by a qualified electrician.
1IMPORTANT!
Risk of injury from electrical current.
Loose and inappropriate plug and socket connec-
tions can make the terminal overheat.
•Have the clamping joints correctedly installed by a
qualified electrician.
•Use strain relief clamp on cable.
•In the event of single-phase or two-phase connec-
tion, the appropriate mains cable of type H05BB-F
Tmax 90° (or higher) must be used.
•If this appliance’s mains cable is damaged, it must
be replaced by a special cable (type H05BB-F
Tmax 90°; or higher). The latter is available from
the Customer Care Department.
A device must be provided in the electrical installa-
tion which allows the appliance to be disconnected
from the mains at all poles with a contact opening
width of at least 3 mm.
Suitable isolation devices include line protecting cut-
outs, fuses (screw type fuses are to be removed from
the holder), earth leakage trips and contactors.

16

17
Service
In the event of technical faults, please first check
whether you can remedy the problem yourself with
the help of the operating instructions (section “What
to do if…”).
If you were not able to remedy the problem yourself,
please contact the Customer Care Department or
one of our service partners.
In order to be able to assist you quickly, we require
the following information:
–Model description
–Product number (PNC)
–Serial number (S No.)
(for numbers see rating plate)
–Type o f fau lt
–Any error messages displayed by the appliance
–three digit letter-number combination for glass ce-
ramic
So that you have the necessary reference numbers
from your appliance at hand, we recommend that
you write them in here:
Model description: .....................................
PNC: .....................................
S No: .....................................

The Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products
(such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more
than 150 countries around the world.
822 924 561-A-250405-03 Ret til ændringer uden varsel forbeholdes
Subject to change without notice
