REPAIR
PARTS
LIST
790.40613801
For Parts or Service:
Call
1-800-4-MY-HOME®
(1-800-469-4663)
Or Visit
www.sears.com
24” DOUBLE ELECTRIC WALL OVEN
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
• Product Type • Part Number
• Model Number • Part Description
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
Publication number 5995556759

790.40613801
12/09 2
CONTROL PANEL
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.40613801
# Functional Parts 3 12/09
* Non-Illustrated Parts
CONTROL PANEL
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
18 5303311231 End Cap, black, RH
18A 5303311232 End Cap, black, LH
19 # 318030063 Panel, control, black, w/touch pad
20 # 316443816 Control, electronic, ES615W4, dual oven
20* 316524400 Screw, control mtg, 6-32 x .25, (5)
21 318028127 Trim, canopy, black
* 5303320422 Screw, 6-20 x 5/16, black, (6)
42 318027519 Trim, vent, black
65 318038810 Cover, control housing
68 318283906 Panel, control housing, rear
78 318036903 Cover, oven vent, black
* # 318402207 Wiring Harness, control, to power boards
* # 318370374 Wiring Harness, timer, to relay board
* 5995556759 Repair Parts List
* 318205140 Owners Manual
* 318047311 Service Data Sheet
* 318046121 Wiring Diagram
* 318201537 Instruction, installation
* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303211311 Screw, 8-18 x 0.500
* 5304436875 Screw, 8-18 X 1/2, black

790.40613801
12/09 4
UPPER OVEN
CAUTION: Use the Kenmore part number to order part, not the illustration number.
81
54
BU79040612801
6
67
66
68
83 127
14
15
16
17
58A
10
9
119
2
62
12
88
187
76
86
86
58B
123
3
89
59
59A
97
108
219
2A
129
128
37
98
77
100
100
77
77A

790.40613801
# Functional Parts 5 12/09
* Non-Illustrated Parts
UPPER OVEN
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
2 318195902 Wrapper, outer, top
2A 318258800 Shield, insulation
3 318565600 Bracket, reinforcement
6 318345305 Rack, oven, (2)
9 5303317977 Pan, broiler, OPTIONAL ACCESS0RY
10 5303317976 Insert, broiler pan, OPTIONAL ACCESS0RY
12 316445501 Switch, oven light, door frame
* # 318370377 Wiring Harness, door switch
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 318406100 Lens, oven light, glass
17 5304400195 Retainer, light cover
37 # 316217002 Probe, oven temp
54 318222400 Housing, oven light
* 5304415832 Screw, 8-18 x 0.406
58A 318386111 Insulation, oven wrapper
58B 318285036 Insulation, oven back
59 318072588 Tube, oven vent, upper
59A 318549803 Tube, oven vent, lower
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255601 Element, broil, 3400W
67 # 318255101 Element, bake, 2100W
68 5304403015 Support, hanger, (4), broil element
76 318056145 Front, oven
77 316247900 Spacer, power board
77A 316114100 Spacer
81 5303323710 Bracket, oven
83 318089521 Liner, oven
86 318561100 Receptacle, hinge, (2)
* 316517600 Spacer, oven door
86* 5304461333 Screw, 10-32 x 17/32
88 318118903 Rod, latch
89 # 318095955 Motor, latch assy, w/brkt & switch
97 318066606 Wrapper, back & sides
98 316443913 Board, relay, dual oven
100 5304401490 Screw, 6-18 x 1, (2)
108# 318073032 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
119# 5303302280 Thermostat, safety
123 318071444 Shield, insulation, top & sides
127 318317100 Adapter Assembly, vent tube, w/converter
128 318563000 Bushing, latch rod
129 5303311164 Spring
187 318013503 Tube, latch rod
* 5303311528 Screw, oval hd sq dr, 6-20AB x 0.625, black
219# 318003616 Thermostat, safety
* # 318078566 Box & wires assy
* 5303308449 Fastener, wire tie
* 3015722 Clip, wire retainer
* 3016303 Clip, insulator
* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303211311 Screw, 8-18 x 0.500
* 5303302745 Screw, 10-16X1-1/4, square drive
* 5303323136 Screw ground
* 5303323277 Screw, 8-18 X 13/32
* 5303325980 Screw, 10-32 x 0.437
* 5304436875 Screw, 8-18 X 1/2, black

790.40613801
12/09 6
LOWER OVEN
CAUTION: Use the Kenmore part number to order part, not the illustration number.
86
96
96A
96B
59
12
156
156
2A
227
103
101
102A
102
189
54
58B
121
BL79040613801
6
67
98
98A
56
56
66
68
83
127
99
99
14
15
16
17
80
80
71
76
97
58A
123
81
86
37

790.40613801
# Functional Parts 7 12/09
* Non-Illustrated Parts
LOWER OVEN
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
2A 5303305035 Shield, insulation
6 318345304 Rack, oven, (2)
12 316445501 Switch, oven light, door frame
* # 318370377 Wiring Harness, door switch
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 318406100 Lens, oven light, glass
17 5304400195 Retainer, light cover
37 # 316217002 Probe, oven temp
54 318222400 Housing, oven light
* 5304415832 Screw, 8-18 x 0.406
56 318176932 Trim, bodyside, black
* 5303320422 Screw, 6-20 x 5/16, black, (6)
58A 318386111 Insulation, oven wrapper
58B 318285036 Insulation, oven back
59 318072589 Tube, oven vent, upper
66 # 318255601 Element, broil, 3400W
67 # 318255101 Element, bake, 2100W
68 5304403015 Support, hanger, (4), broil element
71 318071141 Shield, rear wall
76 318056141 Front-oven
80 318192400 Spring, oven
* 5303211311 Screw, 8-18 x 0.500
81 5303323710 Bracket, oven
83 318089522 Liner, oven
86 318561100 Receptacle, hinge, (2)
96 318294600 Duct, oven vent
* 5303311220 Insulation, oven vent
96A 318549814 Duct-oven vent
96B 318549813 Duct-oven vent
97 318066602 Wrapper, back & sides
98 318029390 Trim, side, inner, RH
98A 318029391 Trim, side, inner, LH
99 318284201 Panel, adjustable, side, (2)
101 318039511 Bracket, trim, black
102 318070700 Cap, top panel, RH
102A 318070701 Cap, top panel, LH
103 318028710 Trim, base, black
121 318145005 Wrapper, base
123 318071444 Shield, insulation, top & sides
127 318317100 Adapter Assembly, vent tube, w/converter
156 5303317198 Bracket, oven vent
189 318042500 Plate, retainer
227 318370900 Clip, retainer
* # 318370300 Wiring Harness, main
* 5303308449 Fastener, wire tie
* 3015722 Clip, wire retainer
* 3016303 Clip, insulator
* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303302745 Screw, 10-16X1-1/4, square drive
* 5303323277 Screw, 8-18 X 13/32
* 5303325980 Screw, 10-32 x 0.437

790.40613801
12/09 8
DOORS
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.40613801
# Functional Parts 9 12/09
* Non-Illustrated Parts
DOORS
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
3 318051527 Glass, oven door, black, outer
4 318280013 Panel, exterior door, stainless
5 318212410 Glass, door, inner, (2)
6 318073610 Shield, air wash
7 318285086 Insulation, oven door
9 318156613 Liner, oven door
9A 318160503 Deflector, upper oven
10 5303311174 Screw, 10-24 x 3/8
* 5303304015 Washer, padded
11 318065102 Latch, door
12 5303316768 Seal, oven door, lower oven
12A 318178801 Seal, oven door, upper oven
15 318091102 Bracket, glass, (3)
16 318212400 Glass, door, inner
17 318162614 Support, glass, lower oven
17A 318139102 Spacer, glass, upper oven
18 318053206 Gasket, door glass seal, inner, lower oven
18A 318293400 Seal, window, upper oven
19 318139207 Collar, glass mtg
23 318567102 Hinge, door, lower oven, (2)
23A 318567104 Hinge, oven door
* 5304461333 Screw, 10-32 x 17/32
25 318048321 Liner, oven door
39 318264410 Handle, door, black, oven
54 5303300265 Screw, 8-18 X 1/2, (4)
59 3202113 Plug, button
60 5303316982 Foam seal, (2)
* 5304445498 Plug, button
* 316136900 Cleaner, stainless steel
* 5303323277 Screw, 8-18 X 13/32
* 5303325981 Screw, 10-16 x 1 1/2
* 5304415832 Screw, 8-18 x 0.406

790.40613801
12/09 10
WIRING DIAGRAM
