REPAIR
PARTS
LIST
790.48832901
790.48834901
790.48839901
For Parts or Service:
Call
1-800-4-MY-HOME®
(1-800-469-4663)
Or Visit
www.sears.com
30” SINGLE ELECTRIC WALL OVEN
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
• Product Type • Part Number
• Model Number • Part Description
Sears Brands Management Corporation, Hoffman Estates, IL 60179
Publication number 5995577821

790.4883
10/10 2
CONTROL PANEL
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.4883
# Functional Parts 3 10/10
* Non-Illustrated Parts
CONTROL PANEL
CAUTION: Use the Kenmore part number to order part, not the illustration number.
Model Index: A790.4883 (790.48832901)
B790.4883 (790.48834901)
C790.4883 (790.48839901)
POS. NO PART NO. DESCRIPTION
2A 318257305 A B C Shield, oven top
2B 318260104 A B C Cover, box
3 318577800 A B C Box, fan service
19 # 318275014 A - - Control Panel Assy., glass, white, w/membrane
19 # 318275015 - B - Control Panel Assy., glass, bisque, w/membrane
19 # 318275016 - - C Control Panel Assy., glass, black, w/membrane
20 # 316418583 A B C Clock/Timer, electronic, ES355W2
20* 5303311306 A B C Screw, 8-18 x 0.375, (4)
* 5995577821 A B C Repair Parts List
* 318205310 A B C Owner's Manual
* 318047453 A B C Service Data Sheet
* 318416203 A B C Wiring Diagram
* 318201530 A B C Instruction, installation
* 5304436875 A B C Screw, 8-18 X 1/2, black, (3)
* 5304454881 A B C Screw, #8-18 x 3/8, (10)

790.4883
10/10 4
BODY
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.4883
# Functional Parts 5 10/10
* Non-Illustrated Parts
BODY
CAUTION: Use the Kenmore part number to order part, not the illustration number.
Model Index: A790.4883 (790.48832901)
B790.4883 (790.48834901)
C790.4883 (790.48839901)
POS. NO PART NO. DESCRIPTION
1 318259220 A B C Back, main
2 318570500 A B C Panel, insualtion, top
3 318577700 A B C Panel, mounting
6 318262500 A B C Rack, oven
8 318262001 A B C Cover, element
8A 318318600 A B C Bracket, element, hidden bake
9 5303317977 A B C Pan, broiler OPTIONAL ACCESS0RY
10 5303317976 A B C Insert, broiler pan OPTIONAL ACCESS0RY
12 316445501 A B C Switch, oven light, door frame
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, light
16 318406100 A B C Lens, oven light, glass
17 5304400195 A B C Retainer, light cover
29 316517600 A B C Spacer, oven door
37 # 318562500 A B C Sensor, oven temp probe
54 318222400 A B C Housing, oven light
54* 318368501 A B C Seal, housing, flat washer
* 5304415832 A B C Screw, 8-18 x 0.406
56 318903702 A - - Trim, side, white, RH
56 318903708 - B - Trim, side, bisque, RH
56 318903704 - - C Trim, side, black, RH
56A 318903703 A - - Trim, side, white, LH
56A 318903709 - B - Trim, side, bisque, LH
56A 318903705 - - C Trim, side, black, LH
57 318402800 A B C Plate, cover
58A 318133791 A B C Insulation, oven back, back/bottom
58B 318386113 A B C Insulation, oven wrapper
59 318570602 A B C Duct, cooling fan
59* 318579001 A B C Bracket, wire
62 316056000 A B C Terminal Block
62* 5303323144 A B C Nut, 10-32
66 # 318255600 A B C Element, broil, 2750W
67 # 318254906 A B C Element, bake, 3400W, 8 pass
68 5304403015 A B C Support, hanger, broil element
70 318259105 A B C Shield, insulation, sides, (2)
71 318260007 A B C Panel, rear box
76 318056292 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
81 318192400 A B C Spring, oven
* 5303323129 A B C Screw, 8 X 0.750
82 318258765 A B C Shield, insulation, lower
83 318261454 A B C Liner, oven assy
86 318561100 A B C Receptacle, hinge, (2)
86* 5304461333 A B C Screw, 10-32 x 17/32
87 318260622 A B C Bracket, cable mtg.
89 # 318261222 A B C Motor, latch assy
* # 318572719 A B C Harness, wiring, latch

790.4883
10/10 6
BODY
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.4883
# Functional Parts 7 10/10
* Non-Illustrated Parts
BODY
CAUTION: Use the Kenmore part number to order part, not the illustration number.
Model Index: A790.4883 (790.48832901)
B790.4883 (790.48834901)
C790.4883 (790.48839901)
POS. NO PART NO. DESCRIPTION
* 5303324184 A B C Screw, 8-18 x 5/16, black
90 318259700 A - - Trim, oven front, white, bottom
90 318259702 - B - Trim, oven front, bisque, bottom
90 318259701 - - C Trim, oven front, black, bottom
99 318256201 A B C Bracket, side, bottom, (2)
108# 318575603 A B C Motor, cooling fan
112# 318112703 A B C Relay
119# 318578506 A B C Thermostat, cooling fan, 105 deg.
127 318317105 A B C Adapter Assembly, vent tube, w/converter
131 318574805 A B C Bottom, cooling duct
142 318123910 A B C Deflector
143 318172904 A B C Support, wire
163 318531703 A B C Spacer
185 318531800 A B C Spacer, oven shield, (2)
219# 318003624 A B C Thermostat, safety, 105/120
264 318257706 A B C Trim, oven, black, front
* # 318394441 A B C Box & wires assy
* # 318572730 A B C Harness, wiring, main
* 318165800 A B C Spacer
* 3051050 A B C Screw, shoulder
* 5303211311 A B C Screw, 8-18 x 0.500
* 5303308450 A B C Screw, 8 x 0.375, (10)
* 5303323136 A B C Screw ground
* 5303323139 A B C Screw, 10-24 x 0.906
* 5303323277 A B C Screw, 8-18 X 13/32
* 5303325981 A B C Screw, 10-16 x 1 1/2

790.4883
10/10 8
DOOR
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.4883
# Functional Parts 9 10/10
* Non-Illustrated Parts
DOOR
CAUTION: Use the Kenmore part number to order part, not the illustration number.
Model Index: A790.4883 (790.48832901)
B790.4883 (790.48834901)
C790.4883 (790.48839901)
POS. NO PART NO. DESCRIPTION
3 318260201 A B C Trim, oven door, black, upper
3A 318260401 A B C Trim, oven door, side, (2)
4 318403502 A - - Glass Assy., oven door, white, outer, w/trim & badge
4 318304145 - B - Glass Assy., oven door, bisque, outer, w/trim & badge
4 318304124 - - C Glass Assy., oven door, black, upper, w/trim & badge
6 318260522 A B C Baffle, door
7 318372000 A B C Insulation, 13.25 X 2.375, 1" thick, (2)
7A 318372002 A B C Insulation, 24 x 2.375, 1" thick, (2)
8 316117500 A B C Glass, oven door, heat barrier
9 318411650 A B C Liner, oven door
10 5304416408 A B C Screw, 10-24 x 1.750
12 318053132 A B C Gasket, oven door seal
16 318212210 A B C Glass, oven door, heat barrier, lower door
17 318264710 A B C Spacer, glass, lower, (2)
23 318567101 A B C Hinge, oven door, (2)
* 5304461333 A B C Screw, 10-32 x 17/32
29 318014405 A B C Spacer, door
39 318372416 A - - Handle, door, white, w/spacer
39 318372418 - B - Handle, door, bisque, w/spacer
39 318372417 - - C Handle, door, black, w/spacer
42 318382301 A B C Bracket, glass retainer, (4)
56 5304436875 A B C Screw, 8-18 X 1/2, black, (3)
64 318165800 A B C Spacer

790.4883
10/10 10
WIRING DIAGRAM

790.4883
# Functional Parts 11 10/10
* Non-Illustrated Parts
WIRING DIAGRAM
