Electrolux EI30EW45JS User manual

Luxury-Glide®Oven Rack
With a ball bearing system, oven rack is
so smooth it extends effortlessly.
Sure-2-Fit™Capacity
Coordinate an entire meal – our oven features
4.2 cubic feet of cooking space with three
adjustable baking racks.
Versatile Cooking Option
Self-clean oven with versatile cooking option
features 7 cooking modes and 6 cooking options.
Luxury-Design™Lighting
Our ramp-up designer halogen lighting is as
beautiful as it is functional and our Luxury-Hold™
oven door stays put at whatever angle you
place it.
Double Wall Oven
EI30EW45J S
30" ELECTRIC DOUBLE WALL OVEN
Configuration
Control Panel Features
IQ-Touch™Electronic Oven Controls
Keypad Entry of Time & Temperature
Electronic Clock & Timer
Temperature Display
Toggle Control
Automatic Oven (Delay, Cook & Off)
Lockout
Automatic Oven Shutoff – 12 Hour
Programmable for °F or °C
Luxury-Design™Halogen Oven Light Touch Pad
Oven Features
Oven Cavity (both ovens)
Hidden Bake Element
Electric Bake Element – 2200 Watts
Eight-Pass Broil Element – 4000 Watts
Convection Element – 2500 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3®with Variable 2-Speed Fans
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Convection Broil, Keep Warm, Slow Cook
Cooking Options –
Dehydrate, Bread Proof, My Favorites,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™Lighting with Dual 40W Halogen Bulbs
Luxury-Glide®Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Luxury-Hold™Oven Doors
Extra-Large Glass Windows
Sabbath Mode (Star-K®Certified)
Accessories
Porcelain Broiler Pan and Insert
3"-high Bottom Trim: S – PN# 903114-9110
Specifications
Color –
Stainless Steel
Oven Cavity Dimensions –
Height
Width
Depth
Product Dimensions –
Height (Including 1" Bottom Trim)
Width
Depth (to Front Door Corner)
(with 90° Door Open)
Power Supply Connection Location
Connected Load (kW Rating) @ 240/208 Volts
Amps@240/208 Volts
Minimum Circuit Required (Amps)
Armored Electrical Cable
Shipping Weight (Approx.)
NOTE: Always consult local and national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
Double
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
4.2 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
7
6
Yes
1
2
Yes
Yes
Yes
Yes
Yes
Included
Optional
S
16-1/2"
24-1/8"
18-1/32"
50-7/16"
30"
24-1/2"
44"
Left Bottom Rear
8.0/6.0
33.0/29.0
40
Included
395 Lbs.
electroluxappliances.com
Wall OvensRefrigerators Warmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsFreezers
Wine Tower/
Under Counter
Washers / Dryers Dishwashers /
Kitchen Cleanup

Double Wall Oven
EI30EW45J S
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EI30EW45J 01/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
30" Electric Double Wall Oven Specifications
•
Product Weight – 375 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit fused
on both sides of line.
•
Connected Load (kW Rating) @ 240/208 Volts = 8.0/6.0kW
•
Amps @ 240/208 Volts = 33.0/29.0 Amps
•
Recommended Circuit Breaker – 40 Amps
•
Always consult local and national electric codes.
•
Minimum 21" clearance for oven door depth when open.
•
Suggested distance from floor is 11-1/2". Minimum required distance
is 4-1/2".
•
Minimum 23-1/2" deep cutout dimension is critical for proper installation,
to ensure that oven’s faceplate will fit flush against cabinet front.
•
To adapt oven to fit cutout height between 49-1/8" and 49-3/4", add
one 2"-wide wood shim of appropriate height to each side of opening
under oven side rails. Lifting oven will hide larger cutout opening at
top and oven’s 1"-high bottom trim will hide shims at bottom.
(Standard 1"-High Bottom Trim included.)
•
To adapt oven to fit cutout height between 49-3/4" and 51-1/2", optional
3"-High Bottom Trim available.
•
Full oven base of solid plywood or similar material required, capable of
supporting 375 Lbs.
•
Base must be level and cabinet front must be square.
•
Double Wall Ovens are NOT approved to be used in stackable or
side-by-side installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
3"-High Bottom Trim: S – (PN# 903114-9110).
* Critical dimension – MUST be applied
** For cutout height between 49
1
/ 8 " and 49
3
/ 4 ", add one 2"-wide wood
shim of appropriate height to each side of opening under oven side rails.
Lifting oven will hide larger cutout opening at top and oven’s 1"-high
bottom trim will hide shims at bottom.
(Optional 3"-high bottom trim
available for cutout height between 49
3
/ 4 " and 51
1
/ 2 ".)
3" max.
Electrical
junction
box location
4" x 4"
opening
to route
armoured
cable
301/8"
min.
11/2"
min.
111/2"
suggested
distance
41/2"
min.
required
487/8"
min.
491/8"
max. Full base
required
to support
375 lbs.
2"-wide
wood spacers
(if needed)**
28 1/2"min.
29"max.
231/2"min.*
(critical
dimension)
2" min.
485/8"
281/4"
Spacers
24 1/2"
Power
supply
location
(left
bottom
rear)
507/16"
(includes
1"bottom
trim)
115/16"
30"
Allow at least
21" clearance
for door depth
when open
